WAP739I05AIROC Matter Module

A I R O C T M B l u e t o o t h ® & B l u e t o o t h ® L E m o d u l e G e n e r a l d e s c r i p t i o n The CYW30739B2-P5TAI051 module is a multi-protocol solution wireless module solution with an integrated 2.4 GHz transceiver that is Matter 1.2, Thread 1.3, and Bluetooth® 5.3-compliant. The CYW30739B2-P5TAI051 includes onboard crystal oscillators, 2 MB flash, passive components, and the CYW30739 silicon device. The CYW30739B2-P5TAI051 supports a number of peripheral functions (ADC, PWM), as well as multiple serial communication protocols (UART, SPI, I2C, I2S/PCM). The device is intended for use in smart home applications such as thermostats, sensors, smart lighting and smart door locks. The CYW30739B2-P5TAI051 is the optimal solution for applications in smart home, industrial and Internet of Things (IoT) devices, with the flexibility to address the increasing size of protocol stacks and applications. The CYW30739B2-P5TAI051 includes a royalty- free stack compatible with Bluetooth® core specification v5.1 with Bluetooth® LE 2 Mbps and IEEE 802.15.4-2015 in a small module form-factor. The CYW30739B2-P5TAI051 has 2MB external flash memory and qualified by Bluetooth® SIG and Matter v1.3, and includes regulatory certification approval for FCC, ISED, and CE. M o d u l e d e s c r i p t i o n • Module size: 13.47 mm × 15.83 mm × 1.95 mm • Complies with Bluetooth® Core specification version 5.3 supporting BR, EDR 2/3 Mbps, eSCO, Bluetooth® LE, and LE 2 Mbps. - QDID: D068835 - Declaration ID: 243084 • Certified for FCC ISED and CE • Up to 13 GPIOs • External 2048-KB flash memory. And Internal 1024-KB flash memory, 512-KB SRAM memory • Industrial temperature range: –30 °C to +85 °C • Integrated Arm® Cortex®-M4 microprocessor core with floating point unit (FPU) R F c h a r a c t e r i s t i c s • Maximum TX output power: +5.0 dBm • Bluetooth® LE RX receive sensitivity: –92.0 dBm • Received signal strength indicator (RSSI) with 1-dB resolution P o w e r c o n s u m p t i o n • TX current consumption - Bluetooth® LE silicon: 5.6 mA (MCU + radio only, 0 dBm) • RX current consumption - Bluetooth® silicon: 5.9 mA (MCU + radio only) • CYW30739 silicon low power mode support - PDS: 6.1 μA with 512 KB SRAM retention - SDS: 1.6 μA - HIDOFF (external interrupt): 400 nA Preliminary Datasheet Please read the Important Notice and Warnings at the end of this document 002-40069 Rev. ** www.infineon.com page 1 2024-06-21 r e s t r i c t e d CYW30739B2-P5TAI051 restricted AIROCTM Bluetooth ® & Bluetooth ® LE module Functional capabilities F u n c t i o n a l c a p a b i l i t i e s • 1x ADC with (12-bit ENoB for DC measurement and 13-bit ENoB for Audio measurement) with 10 channels • 1x HCI UART for programming and HCI • 1x peripheral UART (PUART) • 1x SPI (master or slave) blocks (SPI, Quad SPI, MIPI DBI-C) • 1x I2C master/slave and 1x I2C master only • I2S/PCM audio interfaces • Up to 6 16-bit PWMs • Watchdog timer (WDT) • Bluetooth® Basic Rate (BR) and Enhanced Data Rate (EDR) Support • Bluetooth® LE protocol stack supporting generic access profile (GAP) central, peripheral, or broadcaster roles • Features are subject to support in the Bluetooth® SDK. • Matter-ready SDK and Bluetooth® LE SDK: Check the latest version of the Bluetooth® SDK technical brief for supported features • Hardware security engine Preliminary Datasheet 2 002-40069 Rev. ** 2024-06-21 restricted AIROCTM Bluetooth ® & Bluetooth ® LE module T a b l e o f c o n t e n t s General description ....................................................................................................................................1 Module description .....................................................................................................................................1 RF characteristics .......................................................................................................................................1 Power consumption ....................................................................................................................................1 Functional capabilities ................................................................................................................................2 Table of contents ........................................................................................................................................3 1 Benefits ...................................................................................................................................................5 2 More information .....................................................................................................................................6 2.1 References ....................................................................................................................................................................... 6 2.2 Technical support ........................................................................................................................................................... 6 3 Overview .................................................................................................................................................7 Functional block diagram ............................................................................................................................7 3.1 Module description ......................................................................................................................................................... 7 3.1.1 Module dimensions and drawing ................................................................................................................................ 7 4 Pad connection interface ..........................................................................................................................9 5 Recommended host PCB layout ...........................................................................…
