FCC Test Report Report No. : FR382756 SPORTON INTERNATIONAL INC. Page No. : 1 of 34 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Equipment : Thermal Label Printer Brand Name : Godex Model Name : EZPi-1200 SMP, EZPi-1300 SMP FCC ID : WD6SMP Standard : 47 CFR FCC Part 15.225 Operating Band : 13.553 – 13.567 MHz (channel freq. 13.56 MHz) Equipment Class : DXX Applicant Manufacturer : GODEX INTERNATIONAL CO., LTD. 13F., No.168, Jian-Kang Rd., Zhonghe Dist., New Taipei City 235, Taiwan R.O.C The product sample received on Sep. 30, 2013 and completely tested on Nov. 22, 2013. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager FCC Test Report Report No. : FR382756 SPORTON INTERNATIONAL INC. Page No. : 2 of 34 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Accessories ............................................................................................................................................ 6 1.3 Support Equipment ................................................................................................................................. 6 1.4 Testing Applied Standards ..................................................................................................................... 6 1.5 Testing Location Information .................................................................................................................. 6 1.6 Measurement Uncertainty ...................................................................................................................... 7 2 TEST CONFIGURATION OF EUT ........................................................................................................ 8 2.1 The Worst Case Modulation Configuration ............................................................................................ 8 2.2 Test Channel Frequencies Configuration ............................................................................................... 8 2.3 The Worst Case Measurement Configuration ........................................................................................ 8 2.4 Test Setup Diagram ............................................................................................................................... 9 3 TRANSMITTER TEST RESULT .......................................................................................................... 11 3.1 AC Power-line Conducted Emissions .................................................................................................. 11 3.2 Emission Bandwidth ............................................................................................................................. 17 3.3 Field Strength of Fundamental Emissions and Spectrum Mask .......................................................... 19 3.4 Transmitter Radiated Unwanted Emissions ......................................................................................... 21 3.5 Frequency Stability ............................................................................................................................... 31 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 33 APPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR382756 SPORTON INTERNATIONAL INC. Page No. : 3 of 34 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna RequirementAntenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]: 0.1532130MHz 31.58 (Margin 24.24dB) - AV 49.33 (Margin 16.49dB) - QP FCC 15.207 Complied 3.2 15.215(c) Emission Bandwidth 20dB Bandwidth 4.66 [kHz] FL: 13.55803 MHz FH: 13.56269 MHz Fall in band F L ≥ 13.553 MHz F H ≤ 13.567 MHz Complied 3.3 15.225(a)~(d) Field Strength of Fundamental Emissions and Spectrum Mask Fundamental Emissions quasi peak:38.39 dBuV/m at 10m Device complies with spectrum mask – refer to test data 103.08 dBuV/m at 10 Complied 3.4 15.225(d) Transmitter Radiated Unwanted Emissions [dBuV/m at 3m]: 622.670MHz 44.82 (Margin 1.18dB) - QP FCC 15.209 Complied 3.5 15.225(e) Frequency Stability 33.19 ppm ± 0.01% (100ppm) Complied FCC Test Report Report No. : FR382756 SPORTON INTERNATIONAL INC. Page No. : 4 of 34 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR382756 Rev. 01 Initial issue of report Dec. 30, 2013 FCC Test Report Report No. : FR382756 SPORTON INTERNATIONAL INC. Page No. : 5 of 34 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range Modulation Ch. Frequency (MHz) Channel Number Field Strength (dBuV/m) 13.553 – 13.567 MHz ISO 14443-2 (ASK)13.56 1 38.39 Note 1: Field strength performed quasi peak level at 10m. 1.1.2 Antenna Information Antenna Category Equipment placed on the market without antennas Integral antenna (antenna permanently attached) External antenna (dedicated antennas) 1.1.3 Type of EUT Identify EUT EUT Serial Number N/A…
