NCEE Labs Test Setup Photos External Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 1 - External Photo Figure 2 - External Photo NCEE Labs Test Setup Photos External Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 3 - External Photo Figure 4 - External Photo

13 A B 24 C DRAWING PRODUCT FAMILY THIRD ANGLE PROJECTION ( ) BRAND STANLEY SECURITY SOLUTIONS 6161 E. 75TH STREET INDIANAPOLIS, IN 46250 SIZE PROJECT SHEET SCALE HARDNESS: FINISH: MATERIAL: TITLE 1.500
#.015 .800
#.015 4X R.100
#.025 ----- ----- NOTED 10030 BEST This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: WEF-UVC4041 IC:7713A-UVC4041 Model: UVC4041 SEE NOTE #2 SEE NOTE #4 NOTES: 1. MATERIAL: 2MIL GLOSS WHITE POLYESTER, COLOR: WHITE, ADHESIVE: 3M 7871, TEXT COLOR: BLACK 2. FONT TYPE: ARIAL, SIZE: .06", STYLE: NARROW 3. FONT TYPE: ARIAL, SIZE: .06", STYLE: BOLD 4. SEE STANLEY LOGO GUIDE 5. TEXT AND LOGO POSITIONED APPROXIMATELY AS SHOW. SEE NOTE #3 A A85090 "Copyright © 2011 Stanley Security Solutions, Inc. All Rights Reserved." FOR UVC4041 "Export of this document to countries outside the United States is subject to U.S. export administration regulations." 2.000 FCC LABEL "CONFIDENTIAL - This document and all information contained herein is the sole property of Stanley Security Solutions, Inc. and may not be disclosed to unauthorized persons or reproduced by any means or used for any purpose other than that submitted without the express written permission from Stanley Security Solutions, Inc." 1 OF 1 SPECIFICATIONS ARE TO BE INTERPRETED ACCORDING TO ASME Y14.5M-1994. CTQ'S TO BE INTREPRETED ACCORDING TO SP02.3.BAS DUAL DIMENSIONS INCH TO BE SHOWN AS: [Millimeter] .XXX = BASIC DIMENSION ALL DIMENSIONS ARE IN INCHES UNLESS OTHERWISE SPECIFIED REVISIONS = CHANGED IN THIS REVISION REV.ECN/EAFBYDATEAPR. BY A101579BDH12/13/11BJB

NCEE Labs Test Setup Photos Internal Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 1 - Transmitter Board and Antenna Figure 2 - Transmitter Board NCEE Labs Test Setup Photos Internal Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 3 - Back of Transmitter Board Figure 4 - Main Circuit Board NCEE Labs Test Setup Photos Internal Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 5 - Back of Main Circuit Board

Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Phone: 402.323.6233 Fax: 402.323.6238 The Nebraska Center for Excellence in Electronics (NCEE) authorizes the above named company to reproduce this report provided it is reproduced in its entirety for use by the company’s employees only. Any use that a third party makes of this report, or any reliance on or decisions made based on it, are the responsibility of such third parties. NCEE accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Amended Test Report Includes Report R101810-01-02B and Amendment Client: Stanley Security Solutions, Inc. 6161 E 75 th Street Indianapolis, IN 46250 EUT: Model UVC4041 125kHz RF ID Lockset FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Test Report No.: R101810-01-02C Approved By: __________________ Nic S. Johnson, NCE EMC Test Engineering Manager/Technical Manager iNARTE Certified EMC Engineer #EMC-003337-NE Date: 22 June 2012 Total Pages: 12 NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 2 of 12 Revision Page Rev. No. Date Description Original 16 January 2012 Original - NJohnson A 11 June 2012 Repeated measurement of occupied bandwidth and included new plot for test report -NJohnson B 18 June 2012 Section 3.2 was modified to state that the EUT was tested at 125kHz. -NJohnnson C 22 June 2012 Section 3.` was modified to state the the EUT was tested at 3m from 100kHz to 30MHz and at 10m from 30MHz to 1GHz. The limits and margins in Table 2 have been modified to reflect the applicable limits from FCC Part 15.209. -NJohnson NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 3 of 12 Table of Contents 1 Summary of Test Results .............................................................................................. 4 1.1 Emissions Test Results .......................................................................................... 4 2 EUT Description ............................................................................................................ 5 2.1 Equipment under Test (EUT) ................................................................................. 5 2.2 Testing Location ..................................................................................................... 5 2.3 EUT Setup ............................................................................................................. 5 2.4 EUT Antenna ......................................................................................................... 5 3 Test Results .................................................................................................................. 6 3.1 Radiated Emissions ............................................................................................... 7 3.2 Occupied Bandwidth .............................................................................................10 Tables Table 1 – Equipment under Test (EUT) ................................................................................ 5 Table 2 – Radiated Emissions Quasi-peak Measurements, 100kHz – 1GHz ........................ 9 Figures Figure 1 - Radiated Emissions Plot, 100kHz to 30MHz ........................................................ 8 Figure 2 - Radiated Emissions Plot, 30MHz - 1GHz ............................................................. 9 Figure 3 - Occupied Bandwidth, 771.54Hz ..........................................................................11 NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 4 of 12 1 Summary of Test Results 1.1 Emissions Test Results The EUT was tested for compliance to FCC Part 15.209 and RSS-210 issue 8 using ANSI C63.4:2003. Below is a summary of the test results. Complete results of testing can be found in Section 3. NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 5 of 12 2 EUT Description The Equipment Under Test (EUT) was an RF ID activated lockset that runs at 125 kHz. 2.1 Equipment under Test (EUT) Table 1 – Equipment under Test (EUT) Identification UVC4041 Manufacturer Stanley Security Solutions, Inc. Serial Number NCEE Test 2 RF ID Module HID EProx Lock Module (eProxL) EUT Received Date 2 December 2011 EUT Tested Date 10 January 2012 11 June 2012 (occupied bandwidth) 2.2 Testing Location All testing was performed at the NCEE Lincoln facility, which is an A2LA accredited EMC test laboratory accredited per scope 1953.01. 2.3 EUT Setup The EUT was tested while powered by 4 AA batteries with an RF ID card attached to the reader to create continuous activity. It was tested upright while affixed to a wooden test fixture at an 80cm height. 2.4 EUT Antenna The EUT features an antenna which is integral to the device. The device is not meant to be, and is difficult to disassemble. NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 6 of 12 3 Test Results NCEE Labs R101810-01-02C FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Page 7 of 12 3.1 Radiated Emissions Test: CFR Title 47 FCC Part 15.209 Test Method: ANSI C63.4:2003 Test Result: Complies Date: 1/16/2012 3.1.1 Test Description Radiated emissions measurements were made from 100kHz to 30MHz at a distance of 3m and 30MHz to 1GHz at a distance of 10m inside a semi-anechoic chamber. The EUT was rotated 360 o , the antenna height varied from 1 – 4 meters and both the vertical and horizontal antenna polarizations examined. The results were compared against the limits. Measurements were made by first using a spectrum analyzer to acquire the signal spectrum; individual frequencies were then measured using a CISPR 16.1 compliant receiver with the following bandwidth setting: 100kHz – 30MHz: 10kHz IF Bandwidth, 5kHz steps* 30MHz – 1GHz: 120kHz IF bandwidth, 60kHz steps *For measurements from 100kHz to 30MHz, the antenna used was a passive loop antenna with a 1m height. 3.1.2 Test Resul…

Text truncated - open the document above for the full version.

NCEE Labs Test Setup Photos Test Setup Photos FCC ID: WEF-UVC4041 IC: 7713A-UVC4041 Figure 1 - Radiated Emissions Test Setup Figure 2 - Radiated Emissions Test Setup
