WF5-ODS-156POS System

SHENZHEN JASSWAY INFOTECH CO., >> USER MANUAL << U URANUS KDS LTD Disclaimer ✓ Please read the instructions carefully before equipment installation and using the device. ✓ Do not put the product in high temperature, humid or dusty environment. ✓ Do not drop, crash or break down this product. ✓ Do not power off the device when it’s formatting or upgrading, otherwise it will cause operation system error. ✓ Use only approved add-on enhancements. Content ............................................................................................................................0 Product Description............................................................................................................1 Hardware Instruction .......................................................................................................2 Precautions and example images................................................................................. 3 Interface Description...........................................................................................................4 Wall-mounted installation and maintenance instructions ........................................5 Warranty Notice.................................................................................................................6 Power AdapterPower Cord Wall-mounted host Dear user, Before using this product, please do read these operation manual carefully, and use it properly on the basis of full understanding of the content. Please do keep this Manual properly for later reference packing list . 0 1 Product Description URANUS KDS is a multifunctional touch all-in-one system, 16:9 widescreen display, equipped with touch LCD panel, easy to integrate the core peripheral equipment and display system, suitable for a diversified self-service terminal and various interactive multimedia terminal, can meet the needs of different applicationfields. The panel design can be embedded, so that the product is also suitable for industrial control systems. The URANUS KDS series of touch control all-in-one computer is the best choice to improve user satisfaction, enhance brand value and help optimize business profits. Overview –Specifications SYSTEM Processor Rockchip RK3576 Cortex-A72 + Quad-Core Cortex-A53 up to 2.2GHz Memory Storage 32GB Standard, 64/128GB Option OS Andriod 14/ Linux Operation System DISPLAY Type 15.6 Inch TFT LED Backlight Resolution 1920*1080 Aspect Ratio 16:9 Brightness 250 nits Touchscreen Projective Capacitive Touch Screen with 2.5D Glass INTERFACE USB 2*USB3.0, 2*USB2.0/1*USB3.0, 1*USB2.0 Serial ( 1*DB9/M(RS232)RJ11, COM2 LAN 1*RJ45 10/1000M Ethernet Audio 1*3.5mm Line-Out+MIC Audio Jack Power DC-IN Input AC 100~240V/50~60hz, Output DC 12V/5A PHYSICAL&ENVIRONMENTAL Operating Temperature Operating 0~40° at 5% to 90% Humidity Storage Temperature Storage -20°~60° at 10% to 90% Humidity CoolingFanless Dimensions(W×H×D) (W×H×D) 377.98x227.98x43.90 MM) Packing Dimensions(W×H×D) W×H×D) 465.00x350.00x150.00 MM Net Weight2.5KG Packing Weight3.0KG ColorBlack OPTIONS & PERIPHERALS WIFI IEEE 802.11 a/b/g/n/ac, 2.4 GHz(5GHz Option) Speaker 2*8R/2W Speaker Bluetooth Bluetooth 4.2(Option) VESA VESA 75*75 Bracket(Option) 4GB DDR4 Standard, 8GB Option TF/SIM TF /SIM Card slot 2 Hardware Instruction 1. 15.6 inch Display 2. Wi-Fi Antenna 3. Power Button 4. DC12V In 5. RJ11 6. COM Dimension Unit: 7. SIM/TF 8. USB*2*/3.0 9. L AN Por t 10. USB*2*/2.0 11. Line-Out + MIC 2in1 3.5mm Jack 12. RS232 mm Note Attention should be paid to the following considerations when the cash register is installed. Otherwise, it may cause fire, electric shock or personal injury. * When you remove protective film from the display screen, ensure slow operation. If the action is too quick, statics may be produced, which may damage the display screen. * Avoid placing the equipment into following adverse environments: direct sunlight high temperature and high humidity frequent temperature change excessive vibration dirt and smoke * Away from any equipment that gives out magnetic field or electromagnetic wave. * Away from open fire. * Ensure that the cash register is placed at a horizontal and stable surface. 1Ensure that at least 10cm space is left at front, back, left and right of thecash register for heat dissipation to prevent damage to cash registercaused by blocked ventilation or airflow obstruction. Hidden Line Indicator Map 3 1.Insertthepowercord (Insertwiththepluginterface surfaceinwardsandensuethatthe powercordisinsertedtightly withoutlooseness). 1,Start-up procedure 2. Hold down the power key 1 2To power off, press and hold the button or click the power off icon in the status bar on the home screen. 4 The machine does not start when powering on and the power light of the machine is not on. 1Check whether the socket is energized. Other electric devices may be used for test. 2Check that the cash register's power cord is securely plugged in. The power cord may become loose if the cash register is moved or its wall-mounted location is changed. Maintenance Fix to the wall Mounted to host screen Maintenance of the cash register 1The position of cash register should avoid place with direct sunlight, large temperature change and be far away from water source and dirt. 2Keep the cash register far away from strong electromagnetic field 3In region or stores where the power quality is poor, voltage-stabilized source should be equipped to provide power to cash register separately. Dont plug and pull the energized component and peripheral of the cash register at the energized state. Dont carry the machine or internal component at will. Pay attention to cleaning work of the cash register and prevent water, dirt and oil. When cleaning the cash register, dont use damp cloth or chemicals to wipe machine body such as gasoline and thinner, etc. When the cash register malfunctions, the power supply should be cut at once and stop use. Dont dismantle or repair without authorization. …

Text truncated - open the document above for the full version.

Local Representative Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name WF5-ODS-156 ODS-156 We hereby acknowledge as follows: i.both signees confirm that the point of contact accepts responsibility to act as a US- American Representative on behalf of the applicant ii.the point of contact provides the physical U.S. address and email as listed below iii.both parties maintain the requirements of this agreement for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. iv.An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. US-American Point of Contact Applicant/Approval Holder Signature Date: 2026-01-22 Signature Date: 2026-01-22 Company Name: 4 Dimensions Distribution Corp. Aroot Co., Ltd. FRN: 0033036922 0027509835 Contact Name: Lukas Zheng Min Seok Song Address: 5 CHARLOTTE AVE, HICKSVILLE, New York United states 11801 28-6, Gajangsaneopdong-ro Osan-si, Gyeongi-do, South Korea 18103 Phone: +1-6466274015+82-31-8077-5000 Email: [email protected] [email protected]

FCC ID:WF5-ODS-156 TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 7 Appearance of EUT Photo 8 Appearance of EUT FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 9 Appearance of EUT Photo 10 Appearance of Adapter

FCC ID:WF5-ODS-156 TB-RF-073-3.1 Appendix I Label Appendix II Label Location

FCC ID:WF5-ODS-156 TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 11 Internal of EUT Photo 12 Internal of EUT FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 13 Internal of EUT Photo 14 Appearance of PCB FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 15 Appearance of PCB Photo 16 Appearance of PCB Ant. FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 17 Appearance of PCB Photo 18 Appearance of PCB FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 19 Appearance of PCB Photo 20 Appearance of PCB FCC ID:WF5-ODS-156 TB-RF-073-3.1 Photo 21 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0041-4 Page: 1 of 13 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: WF5-ODS-156 Original Grant Report No. : TBR-C-202512-0041-4 Applicant : Aroot Co., Ltd. Equipment Under Test (EUT) EUT Name : POS System Model No. : ODS-156 Series Model No. : ---- Brand Name : SEWOO Sample ID : HC-C-202512-0041-01-01# & HC-C-202512-0041-01-02# Receipt Date : 2025-12-19 Test Date : 2025-12-19 to 2026-03-13 Issue Date : 2026-03-13 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gold Zhang Reviewed By : Camille Li Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0041-4 Page: 2 of 13 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Antenna Gain ........................................................................................................................ 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. METHOD OF MEASUREMENT .............................................................................................. 7 5. TEST RESULT............................................................................................................................ 8 Report No.: TBR-C-202512-0041-4 Page: 3 of 13 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202512-0041-4 Rev.01 Initial issue of report 2026-03-13 Report No.: TBR-C-202512-0041-4 Page: 4 of 13 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Aroot Co., Ltd. Address : 28-6, Gajangsaneopdong-ro Osan-si, Gyeongi-do, South Korea 18103 Manufacturer : Aroot Co., Ltd. Address : 28-6, Gajangsaneopdong-ro Osan-si, Gyeongi-do, South Korea 18103 1.2 General Description of EUT (Equipment Under Test) EUT Name : POS System Models No. : ODS-156 Model Different : ---- Product Description : Operation Frequency: Bluetooth: 2402MHz~2480MHz 802.11b/g/n(HT20):2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz U-NII-1: 5180MHz~5240MHz U-NII-2A: 5260MHz~5320MHz U-NII-2C: 5500MHz~5700MHz U-NII-3: 5745MHz~5825MHz Power Rating : For Adapter (Model: HYT-1205000) Input: 100-240V~ 50/60Hz 1.5A Max Output: 12.0V5.0A Software Version : S1138D01-14-A--20251014 Hardware Version : V1.0 Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. 1.3 Antenna Gain Band Antenna Type Antenna Gain(dBi) Bluetooth Dipole 2.56 2.4G Wi-Fi Dipole 2.56 5G Wi-Fi U-NII-1 Dipole 4.57 5G Wi-Fi U-NII-2A Dipole 4.57 5G Wi-Fi U-NII-2C Dipole 4.57 5G Wi-Fi U-NII-3 Dipole 4.57 Report No.: TBR-C-202512-0041-4 Page: 5 of 13 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202512-0041-4 Page: 6 of 13 www.cotecna-toby.com TB-RF-073-3.1 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredited Test Site Number: 854351. Designation Number: CN1223. IC Registration No.: (11950A) The Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. The site registration: Site# 11950A. CAB identifier: CN0056. Report No.: TBR-C-202512-0041-4 Page: 7 of 13 www.cotecna-toby.com TB-RF-073-3.1 …

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0041-2 Page: 1 of 36 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID:WF5-ODS-156 Original Grant Report No. : TBR-C-202512-0041-2 Applicant : Aroot Co.,Ltd. Equipment Under Test (EUT) EUT Name : POS System Model No. : ODS-156 Series Model No. : ---- Brand Name : SEWOO Sample ID : HC-C-202512-0041-01-01# & HC-C-202512-0041-01-02# Receipt Date : 2025-12-19 Test Date : 2025-12-19 to 2026-03-13 Issue Date : 2026-03-13 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gold Zhang Reviewed By : Camille Li Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0041-2 Page: 2 of 36 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 7 1.4 Description of Support Units .............................................................................................. 8 1.5 Description of Test Mode ................................................................................................... 8 1.6 Description of Test Software Setting ................................................................................ 9 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION ...................................................................................................... 14 5.1 Test Standard and Limit ................................................................................................... 14 5.2 Test Setup........................................................................................................................... 14 5.3 Test Procedure .................................................................................................................. 14 5.4 Deviation From Test Standard......................................................................................... 15 5.5 EUT Operating Mode ........................................................................................................ 15 5.6 Test Data............................................................................................................................. 15 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 16 6.1 Test Standard and Limit ................................................................................................... 16 6.2 Test Setup........................................................................................................................... 17 6.3 Test Procedure .................................................................................................................. 18 6.4 Deviation From Test Standard......................................................................................... 19 6.5 EUT Operating Mode ........................................................................................................ 19 6.6 Test Data............................................................................................................................. 19 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 20 7.1 Test Standard and Limit ................................................................................................... 20 7.2 Test Setup........................................................................................................................... 20 7.3 Test Procedure .................................................................................................................. 21 7.4 Deviation From Test Standard......................................................................................... 21 7.5 EUT Operating Mode ........................................................................................................ 21 7.6 Test Data............................................................................................................................. 21 8. BANDWIDTH TEST................................................................................................................. 22 8.1 Test Standard and Limit ............................................................................…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0041-22 Page: 1 of 41 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: WF5-ODS-156 Original Grant Report No. : TBR-C-202512-0041-22 Applicant : Aroot Co.,Ltd. Equipment Under Test (EUT) EUT Name : POS System Model No. : ODS-156 Series Model No. : ---- Brand Name : SEWOO Sample ID : HC-C-202512-0041-01-01# & HC-C-202512-0041-01-02# Receipt Date : 2025-12-19 Test Date : 2025-12-19 to 2026-03-13 Issue Date : 2026-03-13 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 KDB 558074 D01 15.247 Meas Guidance v05r02 KDB 662911 D01 Multiple Transmitter Output v02r01 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Tested By : Gold Zhang Reviewed By : Camille Li Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0041-22 Page: 2 of 41 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 7 1.4 Description of Support Units .............................................................................................. 8 1.6 Description of Test Software Setting .............................................................................. 10 1.7 Measurement Uncertainty ................................................................................................ 11 1.8 Test Facility ......................................................................................................................... 12 2. TEST SUMMARY ..................................................................................................................... 13 3. TEST SOFTWARE ................................................................................................................... 13 4. TEST EQUIPMENT AND TEST SITE ................................................................................... 14 5. CONDUCTED EMISSION TEST ........................................................................................... 16 5.1 Test Standard and Limit .................................................................................................... 16 5.2 Test Setup ........................................................................................................................... 16 5.3 Test Procedure ................................................................................................................... 16 5.4 Deviation From Test Standard ......................................................................................... 17 5.5 EUT Operating Mode ........................................................................................................ 17 5.6 Test Data ............................................................................................................................. 17 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 18 6.1 Test Standard and Limit .................................................................................................... 18 6.2 Test Setup ........................................................................................................................... 19 6.3 Test Procedure ................................................................................................................... 20 6.4 Deviation From Test Standard ......................................................................................... 22 6.5 EUT Operating Mode ........................................................................................................ 22 6.6 Test Data ............................................................................................................................. 22 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 23 7.1 Test Standard and Limit .................................................................................................... 23 7.2 Test Setup ........................................................................................................................... 23 7.3 Test Procedure ................................................................................................................... 24 7.4 Deviation From Test Standard ......................................................................................... 26 7.5 EUT Operating Mode ........................................................................................................ 26 7.6 Test Data ............................................................................................................................. 26 Report No.: TBR-C-202512-0041-22 Page: 3 of 41 www.cotecna-toby.com TB-RF-073-3.1 8. BANDWIDTH TEST ................................................................................................................. 27 8.1 Test Standard and Limit ..................................…

Text truncated - open the document above for the full version.

2025-3-12 Customer Customer Name Project Name Project No. Frequency Range PCB Customer confirmation RF Engineer Designed By Remark Review Date WIFI antenna date Notes Client's Approval 2.4MHz~2.5MHz 5100MHz~5900MHz Checked By design Antenna report Yunge (Shenzhen) Communication Co., Ltd. The Main Antenna Sample Confirmation Structural Engineer Document Number: SNW-QR-D-007/A.0 Manufacturer: Uniform (Shenzhen) Communication Co., Ltd. Address: Room 712-717, Block A, Jinfulai Building, No. 49-1, Dabao Road, Xin'an 28th District, Bao'an District, Shenzhen Engineering Manager Page 1 of 10 3.1. Antenna Frequency Band......................................................... 3 3 Cover.........................................................................................................................................1 2. Appearance.................................................................. 3 4. PCB Shelf Life Instructions...................................................... 9 4 Table of Contents.........................................................................................................................................2 Table of contents 1. Specification Overview............................................................ 3 3.3. Antenna VSWR Plot Log mag+smith .......................................... 3.4. Antenna Efficiency.........................................................4 3.2. Matching Circuit.........................................................3 3. Electrical properties................................................................ Yunge (Shenzhen) Communication Co., Ltd. Page 2 of 10 Yunge (Shenzhen) Communication Co., Page 3 of 10 Ltd. 1. Specification Overview 2. Antenna Appearance E1 2.4MHz~2.5MHz WIFI 2.1. Antenna Frequency Band 5100MHz~5900MHz 2.2. Matching Circuit E3 0ÿ Value 0ÿ Antenna operating frequency Element E2 E4 0ÿ NC Yunge (Shenzhen) Communication Co., Ltd. Antenna drawings Page 4 of 10 Yunge (Shenzhen) Communication Co., Page 5 of 10 Ltd. Antenna VSWR diagram Log mag+smith WiFi 2.4 Antenna Efficiency/Gain Yunge (Shenzhen) Communication Co., Ltd. Page 6 of 10 Yunge (Shenzhen) Communication Co., Page 7 of 10 Ltd. WiFi 5.8 Antenna Efficiency/Gain Test pattern Page 8 of 10 5500MHz 5500MHz 5500MHz 5500MHz 2400MHz 2400MHz 2400MHz 2400MHz The Environment of Antenna Radiation Pattern Page 9 of 10 PCB Shelf Life Page 10 of 10 Instructions Yunge (Shenzhen) Communication Co., Ltd. B: Avoid using FPC at sharp corners, as this can easily cause breakage. 2. HOT BAR Assignment 4. Hand soldering: The soldering iron temperature should not exceed 350ÿ, and the soldering iron should not remain on the board for more than 3 seconds. To allow for a few minutes to prevent the board from cracking due to rapid oxidation caused by moisture absorption during operation. A: When using FPC for hot pressing, CVI should be laid across the glass to avoid being suspended in mid-air, which could cause the copper to break when bent. 3: SMT operation: The tin-plated parts need to be masked to prevent fogging during soldering. I. Storage conditions: Temperature 21ÿ±4ÿ; Humidity 60%H±10% II. Factory Warranty 1. Appearance Guarantee: No oxidation will occur within 12 months under the original packaging storage conditions. 2. Functional Guarantee A: Ensure good weld adhesion for one year. B: Ensure good conductivity within two years. 3. Temperature resistance of t…
