WIWAR402RFID Reader

AR402 Administration 1 AR402 FINGERPRINT KEY Manual Version 1.6 e-DATA GmbH AR402 Administration 2 e-DATA GmbH Mollenbachstrasse 19 D-71229 Leonberg Phone (0 71 52) 93979-0 Fax (0 71 52) 93979-50 [email protected] AR402 Manual Version 1.5 Firmware 1.717 or higher Copyright 2011 e-DATA GmbH This Manual is protected by copyright. The user manual may only be copied within the framework of the intended usage. Any reproduction or translations of the manual beyond this or its transmission onto electronic media, even in extract form, is only allowed with the express permission of e-DATA GmbH. e-DATA GmbH reserves the right to make changes to the user manual and to the devices without special notice. e-DATA GmbH does not accept any liability whatsoever for direct or indirect damage, especially loss of data, that results from the usage of the AR402 terminal, or from the information in this Manual AR402 Administration 3 Content 1 General Comments 5 1.1 Symbols ..................................................................................... 5 1.2 Device name .............................................................................. 6 1.3 Intended Usage.......................................................................... 6 1.4 Protection Class ......................................................................... 6 1.5 Safety Measures ........................................................................ 6 1.6 Before Commissioning ............................................................... 6 1.7 Operation ................................................................................... 8 1.8 Installation and Service .............................................................. 8 1.9 CE Conformance ....................................................................... 8 1.10 FCC Conformance ..................................................................... 9 2 Technical Data 10 2.1 Mechanical Structure ............................................................... 10 2.2 Hardware Features .................................................................. 10 2.3 Biometric Sensor...................................................................... 10 2.4 Visual and Audible Indicators................................................... 10 2.5 Connection............................................................................... 10 2.6 Interface ................................................................................... 10 2.7 Power Supply ........................................................................... 11 2.8 Environment Conditions ........................................................... 11 2.9 Dimensions and Weight ........................................................... 11 2.10 Cable Specifications ................................................................ 11 3 Installation 12 3.1 Installation Requirements ........................................................ 12 3.2 Condition.................................................................................. 12 3.3 Wiring....................................................................................... 12 4 Operation 13 4.1 View of the Control Elements................................................... 13 4.2 Basics ...................................................................................... 14 4.3 Basic Operating Principles ....................................................... 14 4.4 User Operation......................................................................... 15 AR402 Administration 4 4.4.1 Authentication, AR402: ............................................................ 15 4.4.2 Authentication, AR402-smart card type: .................................. 15 4.4.3 Authentication, 'Template on Card' (AR402-smart card type only) ......................................................................................... 15 5 Wiegand Configuration - Administrator Functions 16 5.1 Change the Admin Code.......................................................... 16 5.2 Enrollment ................................................................................ 17 5.2.1 Enroll user................................................................................ 17 5.2.2 Write Template onto smart Card (AR402-smart card reader type only) ......................................................................................... 18 5.3 Define the Number of Digits for the User ID (optional) ............ 19 5.4 Enable Validation of the User ID (optional) .............................. 19 5.5 Delete Specific User(s) ............................................................ 20 5.6 Delete Entire Database ............................................................ 20 5.7 Select iCLASS Mode (AR402-iCLASS only)............................ 21 5.8 Define Facility Code ................................................................. 22 5.9 Choose 37-bit or 26-bit Format ................................................ 22 5.10 Reset - Manually switch to Wiegand mode .............................. 23 5.11 Reset - Manually switch to RS485 mode ................................. 23 6 RS485 Configuration with NEXTOR Series Access Controller 24 6.1 Status Indication ...................................................................... 24 6.2 Allocation of IDs on the NEXTOR Series Access Controller.... 24 7 Maintenance 25 7.1 Customer Service .................................................................... 25 7.2 Repairs..................................................................................... 25 7.3 Warranty, Limitation on Liability to Third Parties...................... 25 Caution: 25 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. 25 8 Datasheet 26 Appendix 27 8.1 Quick Guide to Admin Functions ............................................. 27 AR402 Administration 5 8.2 …

Text truncated - open the document above for the full version.

Ersteller: U. Rodemeier Revision: 04 Erstelldatum: 03.08.01 Datum: 11.05.07 Seite 1 von 2 Request for Confidentiality PHOENIX TESTLAB GmbH Date: 2011-11-28 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: WIWAR402 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Confidential information provided by HID Global Corp. directly to Phoenix Testlab GmbH • Exhibit – 6 - OEM75 Technical Report – confidential.doc • Exhibit – 9 - Schematic – Confidential.pdf • Exhibit – 7 - OEM75 Upper Level block Diagram – Confidential.pdf Confidential information provided by EMCE GmbH directly to Phoenix Testlab GmbH • Schematic_AR402.pdf • Operational description #1.pdf • Operational description #2.pdf • Block_Diagram_AR402 The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company address :on behalf: EMCE GmbH, Untere Wiesen 1, 88483 Burgrieden / Germany Signature : Job Title and Dept. :CEO Ersteller: U. Rodemeier Revision: 04 Erstelldatum: 03.08.01 Datum: 11.05.07 Seite 2 von 2 Approved by: Mr. Ulrich Titze / e-Data GmbH / Mollenbachst. 19 / 71229 Leonberg / Germany Signature : Job Title and Dept. : Grantee Contact Person HID Global Corporation / 10385 Westmore Drive, Suite 300 / Westminster, CO 80021 / USA / Mr.Cresswell, Compliance Engineering Signature : Job Title and Dept. : Compliance Manager

External Photos (FCCC ID WIWAR4 402)

Internal Photos (FCC ID: WIWAR402)

DGA-PL-153/98-02 Test report TLH26c01 Product / EUT: RFID device Type designation: AR402-75 Tested type: AR402-75 EUT authorization: Certification Declaration of Conformity Verification Production level: 06/2011 S/N: n/a Manufacturer: e-data GmbH Mollenbachstraße 19 71229 Leonberg / Germany Test remit: FCC Rules 47 CFR Part 15 – Subpart C – Intentional radiators in accordance with the procedures given in §15.207; §15.209; §15.215, §15.225 ANSI C63.4-2003 The standards were: kept* not kept* *Remark: Validation covered by the accredited scope Validation not covered by the accredited scope according:__________ Applicant: e-data GmbH Mollenbachstraße 19 71229 Leonberg / Germany EUT- Date of arrival: 2011-05-02 Test ID: PRH18_10 Date(s) of test: 2011-05-13; 2011-06-09 Burgrieden, 2012-01-18 Released by: _______________________________________________ Principal engineer - Christian Vogelmann Remark: The test results effects only to the relate items tested at the time of the test. The test report shall not be reproduced except in full without the written approval of the testing laboratory. Recognised by Test report TLH26c01 2011-06-27 Page 2 of 41 DGA-PL-153/98-02 Test laboratory: EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Untere Wiesen 1 / 88483 Burgrieden / Germany DAR-Registration No.: DGA-PL-153/98-02 – New CAB-Registration No.: BnetzA-CAB-02/21-01/1 FCC-Registration No.: 90568 – old FCC-Registration No.: 219415 – new Additional test site: University of Applied Sciences Eberhard-Finckh-Str. 11 / 89075 Ulm / Germany The susceptibility test according EN 61000-4-3 performed in the EMC-testing laboratory of the University of Applied Sciences Responsible inspector: P. Hauser EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Contact person: Mr. Titze EUT- Description: RFID device operating at 13.56MHz. The device use an integrated antenna and is supplied via the door unit - a separate device connected to the mains supply with a wall plug power supply Voltage supply: 120V/60Hz Frequency list: 13.56MHz Temperature range: n/a Approximate Size: (LxWxH) / mm - 115x65x55 Test report TLH26c01 2011-06-27 Page 3 of 41 DGA-PL-153/98-02 Supplied / used equipment: Designation Type Manufacturer S/N Power supply SYS1308-2412-W2E Sunny G090702018890 Door unit AD102 e-data GmbH n/a Configuration: As-delivered condition* Modified* *_________ Cable designation Type Length Remarks Supply and I/O cable unshielded >3m n/a Antenna: Antenna requirement according 47CFR Part 15 - Section 15.203 Internal antenna Permanently attached antenna Antenna with unique coupling to the intentional radiator Remarks: n/a Test report TLH26c01 2011-06-27 Page 4 of 41 DGA-PL-153/98-02 State of revision: Source document New Document Date / Reviser Modifications TLH26_01 TLH26a01 2011-07-12 Chr. Vogelmann Document layout changed TLH26a01 TLH26b01 2011-07-12 Chr. Vogelmann Supplement of transmitter frequency drift vs. temperature and voltage TLH26b01 TLH2cb01 2012-01-16 Chr. Vogelmann FCC-Registration number updated Amendment of §15.215 (c); §15.225 spectrum envelope Test report TLH26c01 2011-06-27 Page 5 of 41 DGA-PL-153/98-02 Test equipment list of EMCE GmbH: Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 001 Test receiver ESS 5Hz - 1000 MHz Rohde & Schwarz 833776/008 1 Year(s)/ 2011-10-15 002 Probe ESH2-Z3 Rohde & Schwarz 1 Year(s)/ 2011-08-31 003 LISN 1 ESH3-Z5 Rohde & Schwarz 835268/007 1 Year(s)/ 2012-02-16 004 LISN 2 ESH3-Z5 Rohde & Schwarz 835268/003 1 Year(s)/ 2011-12-27 006 LISN NNBM 8125 Schwarzbeck 8125371 1 Year(s)/ 2011-12-21 007 Absorbing clamp MDS 21 Schwarzbeck 942436 1 Year(s)/ 2012-04-08 008 Loop antenna 9kHz- 30MHz HFH2-Z2 Rohde & Schwarz 835776/0002 3 Year(s)/ 2013-11-03 009 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 435 2 Year(s)/ 2011-08-31 010 Antenna 250-1200MHz UHALP 9108A Schwarzbeck 108 3 Year(s)/ 2012-06-19 011 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 0408/94 3 Year(s)/ 2012-06-19 012 Antenna 250-1200MHz UHALP 9108A Schwarzbeck 166 2 Year(s)/ 2011-08-31 013 Antenna 9kHz-30MHz Ø 1.5m EMCE GmbH 1 Year(s)/ 2011-08-31 014 OATS 3m EMCE GmbH 1 Year(s)/ 2012-06-30 015 OATS 10m EMCE GmbH 1 Year(s)/ 2011-08-30 020 Coupling clamp IP4A Haefely 082672-13 1 Year(s)/ 2011-08-31 022 ESD-Gun NSG 435 Schaffner 577 1 Year(s)/ 2012-06-10 024 RF-Generator SMY01 Rohde & Schwarz 844146/046 1 Year(s)/ 2011-08-31 025 Current clamp BCI F-120-2 FCC 47 1 Year(s)/ 2011-08-31 026 Coupling device network CDN 801-M3-25 FCC 92 1 Year(s)/ 2011-08-31 030 Coupling device network CDN 801- S1/9pol.DSUB EMCE GmbH 1 Year(s)/ 2011-08-31 Test report TLH26c01 2011-06-27 Page 6 of 41 DGA-PL-153/98-02 Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 031 Coupling device network CDN 801- S1/9pol.DSUB EMCE GmbH 1 Year(s)/ 2011-08-31 032 RF Power Amplifier 75A250 Amplifier Research 22789 1 Year(s)/ 2011-08-31 033 Coupling device network CDN-AF2 EMCE GmbH 1 Year(s)/ 2011-08-31 034 Coupling device network CDN-AF2 EMCE GmbH 1 Year(s)/ 2011-08-31 035 3-phase coupling device network 086 EMC-Partner CDN-1000-45 3 Year(s)/ 2012-07-21 036 Coupling device network CDN 801-M5-25 EMCE GmbH 1 Year(s)/ 2011-08-31 037 Coupling device network CDN 801-S1 EMCE GmbH 1 Year(s)/ 2011-08-31 038 Helmholtz coil 1 m x 1 m EMCE GmbH 1 Year(s)/ 2011-08-31 039 Helmholtz coil 1 m x 1 m EMCE GmbH 1 Year(s)/ 2011-08-31 040 Current transformer EMCE GmbH 1 Year(s)/ 2011-08-31 041 Loop antenna, shielded HZ-10 0816.2511.02 Rohde & Schwarz 849788/0020 3 Year(s)/ 2013-11-02 042 AC-Source / Analyser / Norm impedance EMV D 5000/PAS Spitzenberger + Spies A2747 00/0 0501 A2747 07/00501 (ARS16/3) 2 Year(s)/ 2011-08-31 043 Receiver 3DH/E Fieldmeter ESM-100 Maschek 971521 3 Year(s)/ 2014-01-28 044 CDN CN-U EMC-Partner 86 1 Year(s)/ 2011-08-31 045 CDN DN-HF EMC-Partner 86 1 Year(s)/ 2011-08-31 046 CDN DN-LF2 EMC-Partner 86 1 Year(s)/ 2011-08-31 047 CDN DN-LF1 EMC-Partner 86 1 Year(s)/ …

Text truncated - open the document above for the full version.

Test Setup Photos (FCC ID: WIWAR402)
