WIY-VEGA5000MEFTPOS

VEGA 5000 User ’s Manual V0.4 Version: 0.4 Date: March, 20 11 Castles Technology Co., LTD. Tel: 886 (2) 8913 -1771 Fax: 886 (2) 8913 -1772 E-Mail: fae @castech.com.tw Web: www.castech .com.tw © Castles Technology Co., LTD. All rights reserved VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 2/20 WARNING This equipment has been tested and found to comply with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in OET 65 Supplement C. No part of this publication may be reproduced, transmitted, stored in a retrieval Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. system, nor translated into any human or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise, without the prior written permission of Castles Technology Co., LTD. All trademarks mentioned are proprietary of their respective owners. Information in this document is subject to change without prior notice. VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 3/20 Table Of Contents WARNING........................................................................................................ 2 1. Introduction.................................................................................................4 1.1 Front View..................................................................................4 1.2 Side View....................................................................................5 1.3 Back View (Base)....................................................................... 5 1.4 Back View...................................................................................5 1.5 Magnetic Stripe Card Reader & Smart Card Introduction...........7 1.6 Handset and the Base Connection.............................................8 1.7 Rechargeable Battery Cover Installation.................................... 9 1.8 Rechargeable Battery Installation.............................................11 1.9 SAM Card Installation...............................................................12 1.10 Paper Roll Installation...............................................................13 1.11 Power.......................................................................................15 2. Program Manager.....................................................................................16 VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 4/20 1. Introduction 1.1 Front View 1. Power Key：Power On- Press Power Key 3 Second To Start. Press Off - Press Power Key To Turn Off 2. F1 Key：Press F1 To The Download Main M enu To Enter The Download Mode Under The Program Manager Screen . Press Cancel Key Will Go Back To The Program Manger Screen. 3. F2 Key : Set default application 4. F3 Key：Delete application from Program Manager. 5. F4 Key : Programmable by application F1 Key F2 Key F3 Key Cancel Key Clear Key Enter Key Paper Roll Box LED (Green) LED (Orange) LED (Red) Power Key F4 Key VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 5/20 1.2 Side View 1.3 Back View (Base) 1. USB:USB Interface 2. LAN:RJ45 Port ,Provide TCP/IP Interface 3. COM1:RJ11 Port,Provide RS232 Interface 4. COM2:RJ11 Port,Provide RS232 Interface 5..COM3:RJ11 Port,Provide RS232 Interface 6. Tel Switch 7. Line Switch 8. Power Cord 1.4 Back View Smart Card Insert Location Handset Base Power Cord LAN USB COM1 LINE TEL COM2 COM3 VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 6/20 Open The Rechargeable Battery Cover, Inserting The SAM Card Rechargeable Batter y Cover Rechargeable Battery Cover 4 SAM Slots Rechargeable Battery Micro SD Card Slots VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 7/20 1.5 Magnetic Stripe Card Reader & Smart Card Introduction 1. Magnetic Stripe Card Should Be Placed On Card Reading Slot With Magnetic Stripe Facing Left , Sw ipe The Card From Top To The Bottom. 2. Insert User IC Card With Chip Facing Up. 1. 2. VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 8/20 1.6 Handset and the Base Connection VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 9/20 1.7 Rechargeable Battery Cover Installation Step1 : Align the battery cover to the middle location of machine then cover down . Step2: Push the battery cover to the end VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 10 /20 Step3: Switch the latch to the left. VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 11 /20 1.8 Rechargeable Battery Installation VEGA5000 use rechargeable Li Polymer battery, 7.4V, 1050mAh. 1. Please use attached rechargeable lithium battery pack . A nd make sure to fully charge the battery up to at least 2 hours. 2. Please turn on both the power of the handset and the base to charge the battery automatically. CAUTION：Use specified Castles charger only. Do not expose to fire or high temperature. Do not short-circuit or disassemble. VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 12 /20 1.9 SAM Card Installation 1. Open The Battery Cover To Find 4 SAM Card Slots SA M1 SAM4 SAM2 SAM3 VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 13 /20 2. Insert The SAM Card To The SAM Slot As The Below Picture 1.10 Paper Roll Installation Insert The Paper Roll To The Box And Pull The Paper Down As The Picture. SAM1 SAM4 SAM2 SAM3 VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All rights reserved. 14 /20 Close The Paper Roll Box To Start Paper Loading. The dimension of paper roll as below. Width : 57mm Outside diameter : 40mm VEGA 50 00 User's Manual V0.4 Castles Technology Co., Ltd. All…

Text truncated - open the document above for the full version.

AGENCY AUTHORIZATION LETTER To whom it may concern: We, the undersigned CASTLES TECHNOLOGY CO., LTD. , hereby authorize Max Light Technology Co. Ltd. (MLT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15 approval and any communication needed with the national authority. Any and all acts carried out by MLT on our behalf shall have the same effects as acts of our own. For questions regarding the authorization, please contact us. Thank you! Sincerely yours, _____________________________________ (Signature) Original written signature of authorized signer: Eddie Lin / Vice Prisdent Printed name of authorized signer / Title Date: Feb 02, 2012

Date: Feb.02, 2012 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: WIY-VEGA5000M To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operational Descriptions Typically Parts List(BOM) Tune-up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Eddie Lin / Vice President _____________________________ (Signature)

GPRS Antenna GPRS Antenna

Report Number: MLT1109P22001 Label Format: Label Position: Equipment Label 3cmX2.5cm This device complies with Part 22/24 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including Interference that may cause undesired operation. Model No. : VEGA5000 FCC ID: WIY-VEGA5000M

GPRS Antenna Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001 Report Number: MLT1109P22001

Page: 1 of 33 TEST REPORT of SAR New Application; Class I PC; Class II PC Product: EFTPOS Brand: CASTLES TECHNOLOGY Model Difference: N/A Model: VEGA5000M FCC ID: WIY-VEGA5000M Standard: FCC 47 CFR Part2(2.1093) IIEEE C95.1-1999; IEEE 1528 FCC OET 65 Supplement C(Edition 01-10) Applicant: CASTLES TECHNOLOGY CO., LTD Address: 2F, No.205, Sec.3, Beixin Rd., Xindian District, New Taipei City 23143, Taiwan (R.O.C.) Test Performed by: International Standards Laboratory <Lung-Tan LAB> *Site Registration No.: TAF: 0997 *Address: No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan *Tel : 886-3-407-1718; Fax: 886-3-407-1738 Report No.: ISL-11LR091SAR Issue Date : 2012/02/29 Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. This report MUST not be used to claim product endorsement by TAF or any agency of the Government. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory. -2 of 33- FCC ID: WIY-VEGA5000M International Standards Laboratory Report Number: ISL-11LR091FSAR VERIFICATION OF COMPLIANCE Applicant: CASTLES TECHNOLOGY CO., LTD Product Description: EFTPOS Brand Name: CASTLES TECHNOLOGY Model No.: VEGA5000M Model Difference: N/A FCC ID: WIY-VEGA5000M Date of Receipt: Nov. 28, 2011 Date of Test: Dec. 2, 2011 – Dec. 05, 2011 Standard: FCC 47 CFR Part2(2.1093) IIEEE C95.1-1999; IEEE 1528 FCC OET 65 Supplement C(Edition 01-10) We hereby certify that: All the tests in this report have been performed and recorded in accordance with the standards described above and performed by an independent electromagnetic compatibility consultant, International Standards Laboratory. The test results contained in this report accurately represent the measurements of the characteristics and the energy generated by sample equipment under test at the time of the test. The sample equipment tested as described in this report is in compliance with the limits of above standards. Test By: Date: 2012/02/29 Arno Hsieh / Supervisor Prepared By: Date: 2012/02/29 Arno Hsieh / Supervisor Approved By: Date: 2012/02/29 Vincent Su / Manager -3 of 33- FCC ID: WIY-VEGA5000M International Standards Laboratory Report Number: ISL-11LR091FSAR Version Version No. Date Description 00 2011/12/06 Initial creation of document 01 2012/02/29 Update Raw data of Z-axis -4 of 33- FCC ID: WIY-VEGA5000M International Standards Laboratory Report Number: ISL-11LR091FSAR Table of Contents 1 STATEMENT OF COMPLIANCE ........................................................................... 5 2 GENERAL INFORMATION ..................................................................................... 6 2.1 DESCRIPTION OF DEVICE UNDER TEST (DUT) .......................................................................... 6 2.2 DUT PHOTOS ............................................................................................................................. 7 2.3 APPLIED STANDARDS ................................................................................................................. 7 2.4 DEVICE CATEGORY AND SAR LIMITS ....................................................................................... 7 2.5 TEST ENVIRONMENT .................................................................................................................. 7 2.6 TEST CONFIGURATION ............................................................................................................... 8 3 SPECIFIC ABSORPTION RATE (SAR) .................................................................. 8 3.1 INTRODUCTION ........................................................................................................................... 8 3.2 SAR DEFINITION ........................................................................................................................ 8 4 SAR MEASUREMENT SYSTEM ............................................................................. 9 4.1 ALSAS-10U SYSTEM DESCRIPTION .......................................................................................... 9 4.2 E-FIELD PROBE ALS-E-020S ................................................................................................... 10 4.3 DAQ-PAQ (ANALOG TO DIGITAL ELECTRONICS) ALS-DAQ-PAQ-3 BOUNDARY DETECTION UNIT ALS-PMDPS-3 ............................................................................................................................ 12 4.4 AXIS ARTICULATED ROBOT ALS-F3 ....................................................................................... 14 4.5 ALSAS UNIVERSAL WORKSTATION ALS-UWS ..................................................................... 14 4.6 SAM PHANTOMS ALS-P-SAM-L / ALS-P-SAM-R ................................................................ 15 4.7 UNIVERSAL DEVICE POSITIONER ............................................................................................. 17 4.8 TEST EQUIPMENT LIST ............................................................................................................. 18 5 TISSUE SIMULATING LIQUIDS .......................................................................... 19 6 SAR MEASUREMENT EVALUATION ................................................................. 20 7 DUT TESTING POSITION ...................................................................................... 23 8 SAR MEASUREMENT PROCEDURES ................................................................ 26 9 SAR TEST RESULTS ............................................................................................... 28 9.1 CONDUCTED POWER TABLE: .................................................................................................... 28 9.2 TEST RECORDS FOR BODY SAR TEST ........................................................…

Text truncated - open the document above for the full version.

Page: 1 / 51 Report Number: MLT1109P22001 (FCC Part : 22/24) Product : EFTPOS Trade Name : CASTLES TECHNOLOGY Model No. : VEGA5000M Applicant : CASTLES TECHNOLOGY CO., LTD Applicant Address : 2F, No.205, Sec.3, Beixin Rd., Xindian District, New Taipei City 23143, Taiwan (R.O.C.) Page: 2 / 51 Report Number: MLT1109P22001 Report Number MLT1109P22001 Applicant CASTLES TECHNOLOGY CO., LTD Product EFTPOS Sample Received Date 2011/9/21 Report Prepared By Jesse Tien Signature Date Prepared 2011/9/21 ～ 2012/1/18 Report Authorized By Roger Chen Signature Date Authorized 2012/1/19 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of our laboratory. Page: 3 / 51 Report Number: MLT1109P22001 Table of Contents : History of Test Report .............................................................................................................. 4 1. General ................................................................................................................................ 5 2. Summary of Tests................................................................................................................ 7 3. Conducted RF Output Power and Radiated RF Output Power - FCC 22.913(a), 24.232(b) 8 4. Conducted Band Edge and Radiated Band Edge Compliance - FCC 22.917(a), 24.238(a) ............................................................................................................................................... 15 5. Occupied Bandwidth - FCC 2.1049................................................................................... 24 6. Radiated Spurious Emission at antenna terminals - FCC 22.917 , 2.1051 ........................ 29 7. Radiated Spurious Emission - FCC 22.917 , 2.1053 ......................................................... 35 8. Frequency Stability Temperature Variation - FCC 2.1055 and 22.355 and Voltage Variation - FCC 2.1055(d)..................................................................................................................... 41 9. Conducted Emissions Requirements - EMI Test ............................................................... 45 10 Radiated Emissions Requirements - EMI Test ................................................................. 48 Appendix I - Brand / Trade Name & Model No. Multiple Listee.............................................. 51 Page: 4 / 51 Report Number: MLT1109P22001 History of Test Report Original Report Issue Date: Jan. 19, 2012 ■ No additional attachment □ additional attachments were issued as in the following record: Attachment No. Issue Date Description MLT1109P22001 Jan. 19, 2012 Original report Page: 5 / 51 Report Number: MLT1109P22001 1. General 1.1 Customer Details Applicant Name CASTLES TECHNOLOGY CO., LTD Applicant Address 2F, No.205, Sec.3, Beixin Rd., Xindian District, New Taipei City 23143, Taiwan (R.O.C.) Manufacturer Name CASTLES TECHNOLOGY CO., LTD Manufacturer Address 2F, No.205, Sec.3, Beixin Rd., Xindian District, New Taipei City 23143, Taiwan (R.O.C.) 1.2 Technical data of EUT Equipment EFTPOS Model No VEGA5000 FCC ID WIY-VEGA5000M Type of Modulation GMSK Transmission Power GSM/GPRS 850: 32.9 dBm GSM/GPRS 1900: 31.0dBm GPRS connectivity Class 10 (2D2U, ↓↓↑↑) Type of Antenna Dipole Antenna (Antenna P/N : APP8P-700260) Antenna Gain (dBi) GSM/GPRS 850: -8.1dBi GSM/GPRS 1900: -2.0dBi Frequency Range GSM/GPRS 850: 824.2MHz ～ 848.8MHz GSM/GPRS 1900: 1850.2MHz ～1909.8MHz Power Supply AC adapter : Powertron Electronics Corp. Model No.: PA1050-090T1A500 Input : AC 100-240V / 1.8A Output : DC 9V, 5.0A Battery : Li Polymer Battery 7.4V, 1050mAh Note: “D”; “↓” downstream, “U” , ” ↑”: upstream Page: 6 / 51 Report Number: MLT1109P22001 1.3 GSM/GPRS Specification Equipment GSM/GPRS quad-band module Module No GC864-QUAD V2 DC Power Supply 3.3 Volt DC Current Max. 370 mA 1.4 Standard Test Conditions 1.5 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Temperature +15°C ~ +35 Degrees Celsius Relative Humidity 20% ~ 75% Supply Voltage 120VAC Power Supply EUT Page: 7 / 51 Report Number: MLT1109P22001 2. Summary of Tests 2.1 Follow the regulations Standard Description Result 2.1046, 22.913 Conducted Power of Transmitter PASS 22.913, 24.232 Radiated Power of Transmitter PASS 2.1047 Modulation Characteristics PASS 2.1051, 22.917, 24.238 Band Edges Compliance PASS 2.1049 Occupied Bandwidth PASS 2.1051, 22.917, 24.238 Spurious Emissions at Antenna Terminals PASS 2.1053, 22.917, 24.238 Radiated Spurious Emissions PASS 2.1055, 22.355 Frequency Stability PASS 2.2 Measurement uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Parameter Uncertainty Radio Frequency ±2.18E-08% Total RF power (conducted) ±1.32 dB Spurious emissions (conducted) ±2.36 dB All emissions (radiated) ±4.24 dB Temperature ±1°C Humidity ±3.66 % DC and low frequency voltages ±0.335 % Remark : The test results only relate to the submitted test sample specified above. Page: 8 / 51 Report Number: MLT1109P22001 3. Conducted RF Output Power and Radiated RF Output Power - FCC 22.913(a), 24.232(b) 3.1 Test Condition The conducted RF output power measurements were made at the RF output terminals of the EUT using an attenuator, power splitter and spectrum analyzer. The EUT was controlled via the Universal Radio Communication tester R&S CMU200 selecting maximum transmission power of the EUT and GMSK modulated signal. For radiated measurements the EUT was placed on a 1 m high no…

Text truncated - open the document above for the full version.

Report Number: MLT1109P22001 Photograph of Radiated Measurement Front View of The Test Configuration Rear View of The Test Configuration
