FAST OPERATION MANUL M50 M50 FAST OPERATION MANUAL 1. Power On-Off Power on：Press any key to turn on. Power off：Power off automatically based on the system off time, if there is no press and voting; or power off remotely by software. Indicator Led：After power-on and channel locked, the green light flash every half second; if lost channel, the red light flash slowly; if low battery, green light flash every two seconds; starting voting, the green light quick flash 4 times within every second;after effective key pressing, 2 times with every second;after voting submitted successfully,led stay green. 2. Function Polling types Operation l Sign-in Press “OK” or “1” to sign in l Vote “1.2.3” stand for “Yes, No, Abstain” separately. The answer will be submitted automatically based on the system settings. l Single choice Support max. 10 options. Make the single choice by pressing 1~9 (0 stands for 10) The answer will be submitted automatically based on the system settings or pressing OK to submit If changing the choice, please press the new choice directly. l Multiple choice Support max. 10 options. Make the multiple choices by pressing 1~9 (0 stands for 10), after the choices number reaching the set value, adding choices will not be accepted. If changing the choice, please press C key to clear, and then input the new choices and press “OK” to submit. After submit successfully, if changing is allowed, re-input directly. If under forced choice mode, submit can be successful only after Indicator Led OK Numerical key Cancel FAST OPERATION MANUL M50 selecting enough options. l Sequence As Above But, if repeated choices are allowed, an option can be input repeatedly. l Score Input max. continuously 3 numbers Press “C” key to cancel the previous number. l Fastest answer Press “OK” or “1” to be the first answerer. 3. Match up Before using together with the base station, new keypads should be matched up with the base stations. Firstly make the base station entering into match-up mode by operating the software, secondly press “OK” and “C” till the indicator lamp red and green flash alternating , finally if the green light indicates channel locked, it stands match up successfully. Meanwhile the software will also indicate it. If directly powered off, it stands match-up failure. 4. Parameter configure Press “OK” together with base station and software to read or write keypads ID. FCC Caution. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. RF warning: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 2011-9-1 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Changsha SunSky Electronic Design & Development Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Wireless Voting Keypad model name: ARS_M50，ARS-50R FCC ID: WSVSUNVOTEKEY50 We affirm that between SIEMIC and Changsha SunSky Electronic Design & Development Co., Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature： Client’s name / title：Jack Pei/ CTO Contact information / address：Room1024, Building A, Biaozhi Business Center, No. 198 Xiang Fu Road, Tianxin District, Changsha，China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 2011-9-1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: WSVSUNVOTEKEY50 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic - Tune up - BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature： Client’s name / title：Jack Pei/ CTO Contact information / address：Room1024, Building A, Biaozhi Business Center, No. 198 Xiang Fu Road, Tianxin District, Changsha，China

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. In Put: 3V==0~35mA P<0.105W FCC ID: WSVSUNVOTEKEY50 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn Label Location PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

FCCID:WSVSUNVOTEKEY50 Portable device According to § 15.247(e)(i) and § 1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According toKDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz)High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2404 2466 243424.65 Maximum measured transmitter power ConductedPower (mw)Max Antenna Gain (dBi)EIRP (mw) 0.165-3.40.076 Threshold at which no SAR required is 24.65mw. Maximum Tx power is0.076mw EIRP. Conclusion:No SAR is required. SIMULTANEOUS TRANSMISSIONEVALUATION N/A
