WUI-4KMINI4K Dash Cam & Body cam

Important, retain for future reference: Read carefully WP ITM. BT534745 Care & Use Instructions 4K DASH CAM AND BODY CAM 2 For more detailed instructions, please scan the QR code above or visit www.typesauto.com to access the complete user manual. 3 TABLE OF CONTENTS 1. Introduction ...............................................................................................................................................................................4 2. Package Contents ...................................................................................................................................................................5 3. Product Specifications ..........................................................................................................................................................6 4. Dimensions ................................................................................................................................................................................6 5. Product Overview ....................................................................................................................................................................7 6. Controlling The Camera ........................................................................................................................................................8 7. Installing The Camera ..........................................................................................................................................................10 8. Recording Time .......................................................................................................................................................................12 9. Technical Specifications .....................................................................................................................................................12 10. Downloading The App .....................................................................................................................................................13 11. Setting Up The App ............................................................................................................................................................13 12. FAQs ..........................................................................................................................................................................................17 13. Safety Information ..............................................................................................................................................................18 14. Maintenance & Warranty ................................................................................................................................................20 15. General Information .........................................................................................................................................................22 4 Please carefully review all installation instructions before installing the product. Improper installation may void the manufacturer's warranty. These instructions are not applicable to all vehicle types and are provided as guidelines to aid in product installation. If you require assistance with camera installation, please feel free to either consult an experienced technician or reach out to TYPE S customer support at 1.866.294.9244. BEFORE using the camera, please read the safety information in this manual, and always follow the guidelines outlined in it while using the product. Please make sure you've read and understood local laws and regulations regarding cameras in vehicles, as these laws can vary by state. 1. INTRODUCTION 5 2. PACKAGE CONTENTS 1.2.3.4. 5.6.7. 32GB 1. 1 x 4K Dash Cam & Body Cam 2. 1 x Back Clip Bracket 3. 1 x 3M VHB™ Windshield Mount with 12/24V Power Adapter 4. 1 x Adhesive Film 5. 1 x Spare 3M VHB™ Double-Sided Tape 6. 1 x 32GB MicroSD Card (Factory-installed, Replaceable) 7. 1 x Warranty Card www.typesauto.com/register Register this product within 30 days of purchase to receive 1 FREE YEAR of additional warranty coverage (beyond the standard one year warranty), along with special product offers and announcements. Registre este producto dentro de los 30 días siguientes a la compra para recibir 1 AÑO GRATUITO de cobertura de garantía adicional (más allá de la garantía estándar de un año), junto con ofertas de productos y anuncios especiales. Enregistrez ce produit dans les 30 jours suivant l'achat pour recevoir une couverture supplémentaire GRATUITE DE 1 AN (au-delà de la garantie standard d'un an), ainsi que des offres et des annonces spéciales. STOP ARRÊT DETÉNGASE Mon-Fri, 8am-5pm PST / Lundi au vendredi, 8h à 17h HNP / Lun-vie, 8 a. m. a 5 p. m. Hora del Pacífico [email protected] / (866) 294-9244 Please contact our customer service before returning this product to the store. Our friendly representatives are happy to help with any questions or concerns you have. Póngase en contacto con nuestro servicio a clientes antes de regresar este producto a la tienda. A nuestros amables representantes les dará mucho gusto ayudarle con cualquier pregunta o inquietud que tenga. Veuillez communiquer avec notre service à la clientèle avant de retourner le produit au magasin. Nos représentants se feront un plaisir de vous assister pour toute question ou préoccupation. Product code / Code de produit / Código del producto : BT534799 @TypeSAuto ML-534799DNR_V1 BT534799F M L- 5 3 479 9 FDNR _V1 DASHCAM INSTALLATION STEPS Apply this adhesive film onto a cleaned windshield, and peel off the protective film. 1 Peel off the 3M VHB TM tape backer from the Dashcam Mount and attach the dashcam onto the center of this sticker. 2 SK-534745A_V 1 6 3. PRODUCT SPECIFICATIONS Display: Lens (View Angle): Video Resolution: Frequency: Slow Motion Recording: Image Stabilization: Operating Temperature: Operating Voltage: Ba…

Text truncated - open the document above for the full version.

网址: www.fn-link.com 承 认 书 FN-LINK TECHNOLOGY LIMITED CUSTOMER APPROVED BY 批准 Approved by审核 Checked by制表 Prepared by SUPPLIER APPROVED BY 批准 Approved by审核 Checked by制表 Prepared by Customer Project Name Customer NO. specification WiFi-5.8G specification Supplier NO. Write by 韦源 基 REV. Ver.1 Date 202 5-04 - 22 Note 天线测试报告 antenna testing FN-LINK TECHNOLOGY LIMITED FN-LINK TECHNOLOGY LIMITED 序号 内容 页码 - 承认书封面 1 - 版本变更记录 2 1 承认书项目表 3 2 试验设备和条件 4 3 样机结构说明件5 4 天线成品图 6 5 S11 7 6 增益/效率/3D 图 8 7 包装 9 1.承认书项目表 (Index) FN-LINK TECHNOLOGY LIMITED 1.试验设备和条件(Test Equipment & Conditions) 1.1 Network Analyzers : KEYSIGHT P5002A 1.2 Communications Test Set: R& S CMW 500 1.3 3D Chamber Test System: 24探头测试系统 1. 微波暗室的测试原理图 2.说明。 这份报告总结了该项目天线的电气性能结果，包括天线的S11 参数,Gain和Efficiency. FN-LINK TECHNOLOGY LIMITED FN-LINK TECHNOLOGY LIMITED 1.整机说明 2.调试数据报告 3.测试数据 目录 FN-LINK TECHNOLOGY LIMITED Freq/GHz500055005850 VSWR1.51.11.2 WIFI1天线S11(Black antenna S11) FN-LINK TECHNOLOGY LIMITED WIFI-FPC天线测试数据: FN-LINK TECHNOLOGY LIMITED Frequency/Mhz Efficiency / %MaxGain/dBi 5000 52.760.58 5100 42.11.08 5200 44.871.43 5300 44.721.3 5400 45.862.08 5500 46.111.63 5600 42.211.22 5700 42.131.09 5800 48.752.11 5900 51.091.58 5100MHz 5800MHz

SAR Test Setup Report No.: EFTA25070040-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030S Page 1 of 4 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. SAR Test Setup Picture 1: Back Side, the distance from EUT to the bottom of the Phantom is 0mm Picture 2: Back Side 2, the distance from EUT to the bottom of the Phantom is 0mm SAR Test Setup Report No.: EFTA25070040-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030S Page 2 of 4 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Picture 3: Front Side, the distance from EUT to the bottom of the Phantom is 0mm Picture 4: Left Edge, the distance from EUT to the bottom of the Phantom is 0mm SAR Test Setup Report No.: EFTA25070040-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030S Page 3 of 4 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Picture 5: Right Edge, the distance from EUT to the bottom of the Phantom is 0mm Picture 6: Top Edge, the distance from EUT to the bottom of the Phantom is 0mm SAR Test Setup Report No.: EFTA25070040-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030S Page 4 of 4 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Picture 7: Bottom Edge, the distance from EUT to the bottom of the Phantom is 0mm

11N20SISO_Ant1_5825_30~5650 11N20SISO_Ant1_5825_5925~40000 Appendix H: Frequency Stability Test Result Voltage TestMode Antenna Frequen cy[MHz] Voltage [Vdc] Temper ature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict 11A Ant1 5180 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5200 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT -20000.00 -3.846154 20 PASS 5240 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5745 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5785 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5825 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 11N20SI SO Ant1 5180 NV NT 0.00 0.000000 20 PASS LV NT 20000.00 3.861004 20 PASS HV NT 20000.00 3.861004 20 PASS 5200 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5240 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5745 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT -20000.00 -3.481288 20 PASS 5785 NV NT 20000.00 3.457217 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 20000.00 3.457217 20 PASS 5825 NV NT 20000.00 3.433476 20 PASS LV NT 20000.00 3.433476 20 PASS HV NT 20000.00 3.433476 20 PASS Note: LV: 4.5V HV:5.5V Temperature TestMode Antenna Frequen cy[MHz] Voltage [Vdc] Temper ature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict 11A Ant1 5180 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 20000.00 3.861004 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5200 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 -20000.00 -3.846154 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5240 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 20000.00 3.816794 20 PASS 5745 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 20000.00 3.481288 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5785 NV -30 20000.00 3.457217 20 PASS NV -20 -20000.00 -3.457217 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 -20000.00 -3.457217 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 -20000.00 -3.457217 20 PASS 5825 NV -30 20000.00 3.433476 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 20000.00 3.433476 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 11N20SI SO Ant1 5180 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 20000.00 3.861004 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 20000.00 3.861004 20 PASS NV 40 20000.00 3.861004 20 PASS NV 50 0.00 0.000000 20 PASS 5200 NV -30 0.00 0.000000 20 PASS NV -20 20000.00 3.846154 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5240 NV -30 0.00 0.000000 20 PASS NV -20 20000.00 3.816794 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 20000.00 3.816794 20 PASS NV 10 40000.00 7.633588 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 -20000.00 -3.816794 20 PASS NV 50 -20000.00 -3.816794 20 PASS 5745 NV -30 0.00 0.000000 20 PASS NV -20 20000.00 3.481288 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 -20000.00 -3.481288 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5785 NV -30 0.00 0.000000 20 PASS NV -20 20000.00 3.457217 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 -20000.00 -3.457217 20 PASS NV 10 20000.00 3.457217 20 PASS NV 20 20000.00 3.457217 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 20000.00 3.457217 20 PASS 5825 NV -30 20000.00 3.433476 20 PASS NV -20 20000.00 3.433476 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 -20000.00 -3.433476 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 20000.00 3.433476 20 PASS NV 30 20000.00 3.433476 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 20000.00 3.433476 20 PASS Appendix F: Unwant Emissions Test Result Note 1: The low frequency, which starts from 9 kHz to 30 MHz, is pre-scanned and the result which is 20 dB lower than the limit line is not reported. Note 2: During the test, the Radiates Emission from 30MHz to 1GHz was performed in all modes with all channels. The test data of the worst-case condition was recorded in this report. Note 3: The measurement results above 18GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz are reported. NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 33.2738 31.67 -16.49 40.00 8.33 100 10 Horizontal PASS 2 83.9562 24.59 -20.46 40.00 15.41 100 349 Horizontal PASS 3 137.54825.40 -16.94 43.50 18.10 100 161 Horizontal PASS 4 186.41227.60 -18.52 43.50 15.90 100 10 Horizontal PASS 5 318.81724.00 -15.46 46.00 22.00 100 92 Horizontal PASS 6 593.57024.61 -9.17 46.00 21.39 100 285 Horizontal PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 36.4263 36.55 -16.35 40.00 3.45 100 181 Vertical PASS 2 72.9225 29.42 -19.26 40.00 10.58 100 82 Vertical PASS…

Text truncated - open the document above for the full version.

Test Graphs B4 11A_Ant1_Low_5745 11A_Ant1_High_5825 11N20SISO_Ant1_Low_5745 11N20SISO_Ant1_High_5825 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] Max. Fre [MHz] Max. Level [dBm] Limit [dBm] Verdict 11A Ant1 5180 30~5140 3677.35 -42.14 ≤-27 PASS 5360~40000 38763.35 -36.04 ≤-27 PASS 5200 30~5140 3817.02 -41.39 ≤-27 PASS 5360~40000 38650.19 -36.18 ≤-27 PASS 5240 30~5140 5135.57 -41.58 ≤-27 PASS 5360~40000 38734.49 -34.34 ≤-27 PASS 5745 30~5650 3208.86 -31.55 ≤-27 PASS 5925~40000 38677.89 -45.5 ≤-27 PASS 5785 30~5650 3824.81 -31.94 ≤-27 PASS 5925~40000 38729 -45.67 ≤-27 PASS 5825 30~5650 3196.31 -31.3 ≤-27 PASS 5925~40000 38707.42 -44.68 ≤-27 PASS 11N20SISO Ant1 5180 30~5140 5063.86 -41.16 ≤-27 PASS 5360~40000 38001.27 -35.59 ≤-27 PASS 5200 30~5140 3784.15 -42.28 ≤-27 PASS 5360~40000 35753.14 -28.75 ≤-27 PASS 5240 30~5140 5007.48 -42.08 ≤-27 PASS 5360~40000 38667.51 -35.47 ≤-27 PASS 5745 30~5650 3773.67 -31.12 ≤-27 PASS 5925~40000 38768.76 -44.22 ≤-27 PASS 5785 30~5650 3783.79 -31.19 ≤-27 PASS 5925~40000 38209.93 -45.33 ≤-27 PASS 5825 30~5650 3784.35 -31.36 ≤-27 PASS 5925~40000 38886.88 -45.64 ≤-27 PASS Test Graphs 11A_Ant1_5180_30~5140 11A_Ant1_5180_5360~40000 11A_Ant1_5200_30~5140 11A_Ant1_5200_5360~40000 11A_Ant1_5240_30~5140 11A_Ant1_5240_5360~40000 11A_Ant1_5745_30~5650 11A_Ant1_5745_5925~40000 11A_Ant1_5785_30~5650 11A_Ant1_5785_5925~40000 11A_Ant1_5825_30~5650 11A_Ant1_5825_5925~40000 11N20SISO_Ant1_5180_30~5140 11N20SISO_Ant1_5180_5360~40000 11N20SISO_Ant1_5200_30~5140 11N20SISO_Ant1_5200_5360~40000 11N20SISO_Ant1_5240_30~5140 11N20SISO_Ant1_5240_5360~40000 11N20SISO_Ant1_5745_30~5650 11N20SISO_Ant1_5745_5925~40000 11N20SISO_Ant1_5785_30~5650 11N20SISO_Ant1_5785_5925~40000

Appendix D: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11A Ant1 5180 1.39 1.43 97.20 5200 1.39 1.43 97.20 5240 1.39 1.43 97.20 5745 1.39 1.43 97.20 5785 1.40 1.43 97.90 5825 1.40 1.43 97.90 11N20SISO Ant1 5180 1.30 1.34 97.01 5200 1.30 1.33 97.74 5240 1.30 1.33 97.74 5745 1.30 1.34 97.01 5785 1.30 1.34 97.01 5825 1.30 1.34 97.01 Test Graphs 11A_Ant1_5180 11A_Ant1_5200 11A_Ant1_5240 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 Appendix B: Maximum conducted output power Test Result Test Mode Antenna Frequenc y[MHz] Channel Powert [dBm] Duty Cycle [%] DC Factor [dBm] Result [dBm] Limit [dBm] Verdict 11A Ant1 5180 10.66 96.45 0.16 10.82 ≤23.98 PASS 5200 10.53 96.45 0.16 10.69 ≤23.98 PASS 5240 10.21 96.45 0.16 10.37 ≤23.98 PASS 5745 12.66 96.45 0.16 12.82 ≤30.00 PASS 5785 12.94 95.77 0.19 13.13 ≤30.00 PASS 5825 12.56 95.74 0.19 12.75 ≤30.00 PASS 11N20SIS O Ant1 5180 10.40 96.21 0.17 10.57 ≤23.98 PASS 5200 10.46 95.49 0.20 10.66 ≤23.98 PASS 5240 10.21 96.21 0.17 10.38 ≤23.98 PASS 5745 12.82 96.21 0.17 12.99 ≤30.00 PASS 5785 12.90 95.49 0.20 13.10 ≤30.00 PASS 5825 12.44 96.24 0.17 12.61 ≤30.00 PASS Appendix C: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result [dBm/MHz] Limit[dBm/MHz] Verdict 11A Ant1 5180 2.57 ≤11.00 PASS 5200 -3.32 ≤11.00 PASS 5240 2.01 ≤11.00 PASS 5745 -0.39 ≤30.00 PASS 5785 0.61 ≤30.00 PASS 5825 0.21 ≤30.00 PASS 11N20SISO Ant1 5180 -0.85 ≤11.00 PASS 5200 1.66 ≤11.00 PASS 5240 3.36 ≤11.00 PASS 5745 0.71 ≤30.00 PASS 5785 0.49 ≤30.00 PASS 5825 -0.43 ≤30.00 PASS Note：1.The Result and Limit Unit is dBm/500 kHz in the band 5.7255.85 GHz. 2.The Duty Cycle Factor and RBW Factor is compensated in the graph. Test Graphs 11A_Ant1_5180 11A_Ant1_5200 11A_Ant1_5240 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 Appendix E: Band edge measurements Test Result B1/2/3 TestMode Antenna ChName Frequency[MHz] Result[dBm] Limit[dBm] Verdict 11A Ant1 Low 5180 -41.29 ≤-27 PASS High 5240 -43.34 ≤-27 PASS 11N20SISO Ant1 Low 5180 -41.3 ≤-27 PASS High 5240 -43.14 ≤-27 PASS Test Result B4 TestMode Antenna ChName Frequency[ MHz] FreqRange [MHz] Result [dBm] Limit [dBm] Verdict 11A Ant1 Low 5745 5650~5700 -44.07 ≤-26.96 PASS 5700~5720 -44.71 ≤10.12 PASS 5720~5725 -42.02 ≤16.60 PASS 5760~5650 -43.2 ≤-27 PASS High 5825 5850~5855 -35.04 ≤16.96 PASS 5855~5875 -35.51 ≤15.58 PASS 5875~5925 -44.85 ≤-26.91 PASS 5925~5935 -42.43 ≤-27 PASS 11N20SI SO Ant1 Low 5745 5650~5700 -44.54 ≤-26.70 PASS 5700~5720 -39.72 ≤13.05 PASS 5720~5725 -36.6 ≤17.13 PASS 5760~5650 -43.59 ≤-27 PASS High 5825 5850~5855 -39.04 ≤15.73 PASS 5855~5875 -36.46 ≤14.82 PASS 5875~5925 -43.64 ≤-26.71 PASS 5925~5935 -43.14 ≤-27 PASS Test Graphs B1/2/3 11A_Ant1_Low_5180 11A_Ant1_High_5240 11N20SISO_Ant1_Low_5180 11N20SISO_Ant1_High_5240

Appendix A1: Emission Bandwidth Test Result TestMode Antenna Frequency[MHz] 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 33.520 5164.000 5197.520 --- --- 5200 19.880 5190.120 5210.000 --- --- 5240 22.800 5228.280 5251.080 --- --- 5745 20.040 5734.880 5754.920 --- --- 5785 27.320 5771.480 5798.800 --- --- 5825 32.580 5810.000 5842.580 --- --- 11N20SISO Ant1 5180 25.280 5167.080 5192.360 --- --- 5200 28.400 5185.600 5214.000 --- --- 5240 28.280 5226.600 5254.880 --- --- 5745 29.440 5729.560 5759.000 --- --- 5785 25.760 5772.200 5797.960 --- --- 5825 34.720 5808.360 5843.080 --- --- Test Graphs 11A_Ant1_5180 11A_Ant1_5200 11A_Ant1_5240 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 Appendix A2: Occupied channel bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 20.758 5169.8495 5190.6075 --- --- 5200 17.033 5191.4439 5208.4769 --- --- 5240 17.293 5231.3195 5248.6125 --- --- 5745 17.219 5736.3028 5753.5218 --- --- 5785 18.076 5776.1064 5794.1824 --- --- 5825 22.909 5814.4003 5837.3093 --- --- 11N20SISO Ant1 5180 18.209 5170.9453 5189.1543 --- --- 5200 22.343 5188.8179 5211.1609 --- --- 5240 18.454 5230.8453 5249.2993 --- --- 5745 18.462 5735.8113 5754.2733 --- --- 5785 18.511 5775.8512 5794.3622 --- --- 5825 21.769 5815.0194 5836.7884 --- --- Test Graphs 11A_Ant1_5180 11A_Ant1_5200 11A_Ant1_5240 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 Appendix A3: Min emission bandwidth Test Result B4 TestMode Antenna Frequency[MHz] 6db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 16.280 5736.880 5753.160 0.5 PASS 5785 16.280 5776.880 5793.160 0.5 PASS 5825 16.320 5816.880 5833.200 0.5 PASS 11N20SISO Ant1 5745 12.560 5738.720 5751.280 0.5 PASS 5785 12.520 5780.000 5792.520 0.5 PASS 5825 13.160 5819.360 5832.520 0.5 PASS Test Graphs B4 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825

EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: 4K Dash Cam & Body cam Model name: BT534745 FCC ID: WUI-4KMINI Test Report Number: EFGX25050474-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Phone: +86-0755-829118671 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, Fax: +86-0755-82910749 No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China Page 1 of 30 Content 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Measurement uncertainty 7 2.4 Test mode 8 2.5 Test equipment utilized 9 2.6 Auxiliary equipment used during test 10 2.7 Test software information 10 2.8 Test setup 11 2.9 Test results 13 3 Technical Requirement 14 3.1 Conducted emission AC power port 14 3.2 Duty cycle 15 3.3 6dB bandwidth 16 3.4 99% Occupied Bandwidth 17 3.5 26 dB Bandwidth 18 3.6 Maximum Conducted Output Power 19 3.7 Power spectral density 24 3.8 Transmitter radiated spurious emissionsr 26 4 Test Setup Photos 30 5 External Photo 30 6 Internal Photos 30 7 Appendix 30 Test Report No.: EFGX25050474-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 30 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2025-09-07 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2025-09-07 Albert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX25050474-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 30 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Winplus Co., Ltd. Address : Suites 6-11, 7th Floor, Corporation Park, 11 On La, Shatin, Hong kong Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : Winplus Co., Ltd. Address : Suites 6-11, 7th Floor, Corporation Park, 11 On La, Shatin, Hong kong Telephone : ./. Fax : ./. Test Report No.: EFGX25050474-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 30 1.5 Application details Date of receipt of application : 2025-05-23 Date of receipt of test item : 2025-05-23 Date of test : 2025-09-02 to 2025-09-07 Date of issue : 2025-09-07 1.6 Test item Product type : 4K Dash Cam & Body cam Model name : BT534745 Brand : Type S Sample ID : 250523-31-001 Serial number : ./. Ratings : Input: DC 5.0V 2.0A 3.7V battery Test voltage : 3.7V Hardware Version : DVR16A-V1.0 Software / Firmware Version : 2025_0701_V1.0 ASR Additional information : ./. RadioTechnical data Radio Tech. : WLAN (IEEE 802.11 a,n) / UN-III-1, U-NII-3 Frequency Range : 5 180 ㎒ ~ 5 240 ㎒ (U-NII-1 Band) 5 745 ㎒ ~ 5 825 ㎒ (U-NII-3 Band) Modulation : 802.11a: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Antenna type : FPC antenna Channel Spacing : 802.11a/n(HT20)/ac(VHT20): 20MHz Antenna gain : 1.43 dBi for 5.2G 2.11 dBi for 5.8G The above sample(s) and sample information was/were submitted and identified on behalf of the applicant. Eurofins assures objectivity and impartiality of the test, and fulfills the obligation of confidentiality for applicant’s commercial infor- mation and technical documents. Test Report No.: EFGX25050474-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 30 1.7 Test standards Test Standards FCC Part 15 Subpart E Subpart E—Unlicensed National Information Infrastructure Devices Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless D…

Text truncated - open the document above for the full version.

2025-08-06 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: WUI-4KMINI [Winplus Co., Ltd.] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Signature: Name: Benson Leung 2025-08-06 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: WUI-4KMINI Winplus Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name: Benson Leung

Prepared by: Wei Fangying Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 SAR TEST REPORT Applicant Winplus Co., Ltd. FCC ID WUI-4KMINI Product 4K Dash Cam & Body cam Brand Type S Model BT534745 Report No. EFTA25070040-IE-01-S1V1 Issue Date September 17, 2025 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in IEEE 1528-2013, ANSI C95.1: 1992, IEEE C95.1: 1991. The test results show that the equipment tested can demonstrae compliance with the requirements as documented in this report. SAR Test Report Report No.: EFTA25070040-IE-01-S1V1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-06-003S Page 2 of 69 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Version Revision Description Issue Date Rev.0 Initial issue of report. September 2, 2025 Rev.1 Updated information. September 17, 2025 Note: This revised report (Report No.: EFTA25070040-IE-01-S1V1) supersedes and repl…

Text truncated - open the document above for the full version.
