WYK-ES2440Quad radio access point/bridge

High-capacity wireless mesh point for rapid outdoor deployment The Fortress ES2440 High Capacity Infrastructure Mesh Point utilizes MIMO technology to bring high performance secure wireless communica- tions to outdoor locations and across long distances through a self-forming, self-healing mesh network. The ES2440 offers FIPS 140-2 validated security and is upgradeable to NSA Suite B algorithms*. Delivered in a form factor that is rugged, weatherized and easy to set-up and operate, the Fortress ES2440 functions as both a wireless access point and bridge, with four powerful radios for maximum range and performance. Fortress Mesh Points ensure high performance networking under highly mobile conditions, allowing nodes to move within the network and to seamlessly leave and join the network. Rapidly deployable in theater network extension solution Enabled for COTS-for-SECRET deployments* Ruggedized for use in harsh environments High capacity through 4 MIMO radios Long range links with high throughput and reliability Comprehensive Security The central component of DoD and other sensitive network solutions is the ability to ensure data security at all times and at all levels. Fortress products support the most advanced security implementations in the industry. Using standards based, interoperable and compliant security protocols certified to FIPS-140-2 and upgradable to NSA Suite B cryptography, Fortress is a leader in secure wireless networking. Fortress products are unique in that they support in-built RADIUS, advanced Wi-Fi WPA2 security with EAP-TLS, use a hardware crypto implementation and have a hardware based True Random Number Generator (TRNG) ensuring the richest security with the highest performance. FastPath Mesh ™ Fortress FastPath Mesh technology provides a self-forming, path optimizing, self-healing network architecture designed from the ground up to support truly mobile and often transported networks, elegantly addressing the needs of dynamic tactical networks. FastPath Mesh is link protocol agnostic and utilizes all interfaces and radio links to reach a destination using the lowest cost path. The resulting network is a unique mix of proactive and reactive protocols designed to work together to improve network performance and address moving nodes. Overlaid on the mesh is end-to-end encryption and capabilities to eliminate multicast/broadcast flooding for improved overall network performance. Fortress’s implementation includes a fully distributed DNS capability and is IPv4 and IPv6 multicast-aware. Rugged for Outdoor Robust packaging and enhanced RF specifications are crucial to adapting standard Wi-Fi to the harsh and long range conditions typical in tactical wireless deployments and transportable networks. Size, Weight and Power (SWaP) and highest levels of en- vironmental certification are the cornerstone of providing a solution that can withstand the toughest conditions, can survive constant portability, and can be easily embedded in larger systems. Better quality and high power RF enables reliable, high throughput long distance operation required for typical in-theater operational conditions. Fortress solutions are delivered in ruggedized form factors with superior RF hardware and antennas while remaining more cost effective than custom designed technology once typical in secure networks. COTS+ Fortress Solutions leverage industry proven and cost effective technologies adapted for tactical environments. High quality cryptographic implementation Specially rugged packaging State of the art design optimized for size, weight and power consumption High-power, low-noise radio designs Fortress’ COTS+ approach provides the most suited solution to address secure wireless networking in military, government and other sensitive arenas. Suite B Capable The NSA Suite B initiative is a common set of cryptographic algorithms to create products that meet the widest range of US Government needs. Suite B Cryptography is built on COTS information-assurance products using Advanced Encryption Standard (AES) and is under evaluation by the NSA to protect information up to the SECRET level. Fortress products are NSA Suite B capable and can be upgraded where approval is achieved. Hardware Based Encryption Fortress products deliver much higher performance by using a hardware crypto FPGA that enables fast, deter- ministic performance to protect against timing attacks. Fast security throughput is critical in supporting real-time applications such as encrypted voice and video. Fortress’ cryptographic implementa- tion has passed rigorous examination and been approved by NIST. Licensed 4.4 GHz C Band Fortress products can operate in the 4.4 GHz C Band a licensed band allocated to US and NATO military use. Operating at 4.4 GHz in the C Band offers several advantages. 4.4 GHz is a licensed band restricted to military use, so it offers an additional level of security, and less crowded use of the spectrum. Superior Performance Fortress Mesh Points use hardware crypto and hardware TRNG to provide fast, deterministic performance that is unmatched in the industry. They are equipped with pow- erful radios that can operate in 802.11 a/b/g modes, providing superior range and performance. GPS Enabled GPS capability provides real-time position data that is displayed in Fortress’s Topology Viewer and Mesh Viewer as well as Google Earth, and Cursor on Target / FalconView for Blue Force Tracking. Features of the ES2440 High-Capacity Infrastructure Mesh Point Made in the USA Fortress products are designed and manufactured in the USA to maintain the highest levels of quality with oversight to provide manufacturing design assurance. All software or program- mable hardware devices are built from source code that is controlled in house. Optimal SWaP+C (Size, Weight, Power & Cost) Fortress provides the lightest and smallest Mesh Points in the industry, purpose built for frequent transportation and integration into land, sea and…

Text truncated - open the document above for the full version.

ES2440 High-Capacity Infrastructure Mesh Point Hardware Guide www.fortresstech.com © 2011 Fortress Technologies QA review draft1 ES2440 Hardware Guide i 009-00045-00r1 Fortress ES2440 High-Capacity Infrastructure Mesh Point [rev.1] Copyright © 2011 Fortress Technologies, Inc. All rights reserved. This document contains proprietary information protected by copyright. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, without written permission of Fortress Technologies, 2 Technology Park Drive, Westford, MA 01886-3140, except as specified in the Product Warranty and License Terms. FORTRESS TECHNOLOGIES, INC., MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. FORTRESS TECHNOLOGIES, INC. SHALL NOT BE LIABLE FOR ERRORS CONTAINED HEREIN OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE FURNISHING, PERFORMANCE OR USE OF THIS MATERIAL. THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. The Fortress Technologies and AirFortress logos and AirFortress and are registered trademarks; Multi-Factor Authentication, Unified Security Model, Wireless Link Layer Security and Three Factor Authentication (TFA) are trademarks of Fortress Technologies, Inc. The technology behind Wireless Link Layer Security™ enjoys U.S. and international patent protection under patent number 5,757,924. All trademarks mentioned in this document are the property of their respective owners. IMPORTANT SAFETY INFORMATION The ES2440 is an outdoor device. It should be powered by PoE (Power over Ethernet) using a weatherized Ethernet cable. A mid-span PoE injector is provided with the ES2440. This mid-span PoE injector, as well as the power supply/adapter used to power that injector, should remain indoors, protected from the weather. From the mid-span PoE injector, a weatherized Ethernet cable should be run to the outdoor ES2440. In this way, power can be safely provided to the outdoor ES2440 while the power supply and injector remain protected indoors, as shown: The power port on the ES2440 should not be used; it is reserved for future expansion. Weatherized Ethernet Cable PoE Midspan Injector ES2440 Wall Outlet Ethernet QA review draft1 ES2440 Hardware Guide ii IMPORTANT FCC INFORMATION The Federal Communications Commission has released Office of Engineering and Technology Laboratory Division Knowledge Database (KDB) 44399, which refines the definition of Dynamic Frequency Selection (DFS) support. Since this device has the ability to use frequencies covered by DFS, KDB 443999 must be followed. It is published in full on the FCC web site: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41732 In order to support FCC KDB 443999, Fortress has limited the use of certain frequencies within the 5400–5725 MHz range. Specifically, the frequencies defined by the FCC as being of primary interest are those in the 5600–5650 MHz range, which correspond to 802.11a channels 120, 124, and 128. In order to comply with the KDB 443999, these channels have been removed from use, or notched. Notched channels are unavailable for use on this device. KDB 44399 provides additional restrictions on the use of channels within 30 MHz of notched channels when the device is within 35 km of a Terminal Doppler Weather Radar (TDWR) installation. Affected channels 116, 132, and 136 serve as a guard of 30 MHz around the critical notched frequencies. Guard frequencies are unavailable for use on this device by default. The FCC allows these channels to be used, however, as long as the device is not within 35 km of a TDWR installation, as described in this excerpt of KDB 443999: Any installation of either a master or a client device within 35 km of a TDWR location shall be separated by at least 30 MHz (center-to-center) from the TDWR operating frequency. In some instances it is possible that a device may be within 35 km of multiple TDWRs. In this case the device must ensure that it avoids operation within 30 MHz for each of the TDWRs. This requirement applies even if the master is outside the 35 km radius but communicates with outdoor clients which may be within the 35 km radius of the TDWRs. The requirement for ensuring 30 MHz frequency separation is based on the best information available to date. If interference is not eliminated, a distance limitation based on line-of-sight from TDWR will need to be used. Please refer to the original KDB 443999 as posted on the FCC web site for the complete text. In order to enable channels 116, 132, and/or 136, please contact Fortress to obtain a special license. This license will be issued after it is confirmed that the installation is not within 30 MHz and 35 km of registered TDWR sites. The following table (provided by the FCC in KDB 443999 published on 10/14/2010) describes the locations of TDWR sites, as well as the frequencies at which these sites operate: TDWR Location InformationTERRAIN ELEVATION (MSL) [ft] ANTENNA HEIGHT ABOVE TERRAIN [ft] STATE CITY LONGITUDE LATITUDE FREQUENCY AZ PHOENIX W 112 09 46 N 33 25 14 5610 MHz 1024 64 CO DENVER W 104 31 35 N 39 43 39 5615 MHz 5643 64 FL FT LAUDERDALE W 080 20 39 N 26 08 36 5645 MHz 7 113 FL MIAMI W 080 29 28 N 25 45 27 5605 MHz 10 113 FL ORLANDO W 081 19 33 N 28 20 37 5640 MHz 72 97 FL TAMPA W 082 31 04 N 27 51 35 5620 MHz 14 80 FL WEST PALM BEACH W 080 16 23 N 26 41 17 5615 MHz 20 113 GA ATLANTA W 084 15 44 N 33 38 48 5615 MHz 962 113 IL MCCOOK W 087 51 31 N 41 47 50 5615 MHz 646 97 IL CRESTWOOD W 087 43 47 N 41 39 05 5645 MHz 663 113 IN INDIANAPOLIS W 086 26 08 N 39 38 14 5605 MHz 751 97 KS WICHITA W 097 26 13 N 37 30 26 5603 MHz 1270 80 KY COVINGTON CINCINNATI W 084 34 48 N 38 53 53 5610 MHz 942 97 KY LOUISVILLE W 085 36 38 N 38 02 45 5646 MHz 617 113 LA NEW ORLEANS W 090 24 11 N 30 01 18 5645 MHz 2 97 QA review draft1 ES2440 Hardware Guide ii…

Text truncated - open the document above for the full version.

Fortress Technologies · 4023 Tampa Road, Suite 2000 · Oldsmar, FL · 1.888.4PRIVACY · www.fortresstech.com Long Term Confidentiality Request Letter August 5, 2011 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR ES2440, FCC ID: WYK-ES2440 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the follow list of items: Exhibit Type File Name Block Diagram Schematics Schematics Operational Description ES2440BlkDia.pdf ES2440Schem1.pdf ES2440Schem2.pdf ES2440OpDes.pdf Photos which are required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, John Pacheco Engineering Director Fortress Technologies · 4023 Tampa Road, Suite 2000 · Oldsmar, FL · 1.888.4PRIVACY · www.fortresstech.com

A DWG. NO. SIZE 1410-00089 -01 REV. MATERIAL Compliance DRAWING IS THE SOLE PROPERTY OF DATE JCB FINISH DO NOT SCALE DRAWING CHANGE DESC. PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS FORTRESS TECHNOLOGIES IS PROHIBITED. COMMENTS: SHEE T 1 OF 1 Q.A. MFG A PPR. ENG A PPR. CHECKED DRAWN WITHOUT THE WRITT EN PERMISS ION OF REPRODUCTIO N IN PART OR AS A WHOLE FORTRESS TECHNOLOGI ES. ANY 05AUG11 ES2 440-3555 NAME .00 5 Label REV REVISION HISTORY DI MENSIO NS ARE IN INCHES TOLERANCES: FR ACTIONAL ANGULAR: MACH BEND TWO PLACE DECIMAL .01 THREE PLACE DECIMAL SCALE:1:1 Notes: 1) L abel material t o b e 3 M 7 872 P latinum P olyest er ( UL a pproved). 2) 1 mil clear matte polyester overlaminate required. 3) A ll p rint color t o be black. 4) L abel to b e R oHS c ompliant p er E U d irective 2002/95/EC. Statement o f c ompliance t o b e a vailable u pon r equest . 3.20 max 0.125 4 places R 1.50 ES2440-3555 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Input Voltage: 9 to 30VDC, 56VDC (POE+), 45W Max. FCC ID: WYK-ES2440 IC: 8190A-ES2440 1Initial release. RoHS Model: Compliance label goes here

Next-Gen 2x2 Dual Polarity MIMO Omni Antenna Models: AMO-2G10, AMO-2G13, AMO-5G10, AMO-5G13 Hi-Performance, Long Range Seamlessly Integrates with Rocket M 360 Degree Coverage Omni Datasheet | Omni AirMax Omni is a Carrier Class 2x2 Dual Polarity MIMO omnidirectional antenna that was designed to seamlessly integrate with Rocket M radios (Rocket M sold separately). Rocket M combines the “brains” in one robust unit; just pair Rocket M with AirMax Omni to create powerful 360 ̊ omnidirec- tional basestation. This seamless integra- tion gives network architects unparalleled flexibility and convenience. On the right is one example of how AirMax Omni can be deployed: Internet Backbone ISP Network RocketDish with Rocket M (PtP backhaul) RocketDish with Rocket M (PtP backhaul) AirMax Omni with Rocket M (PtMP) Corporate campus with NanoBridge M clients Mobile computer with AirGrid M client Omnidirectional Coverage 02 Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com Overview Unlike standard WiFi protocol, Ubiquiti's Time Division Multiple Access (TDMA) AirMax protocol allows each client to send & receive data using pre-designated time slots scheduled by an intelligent AP controller. This "time slot" method eliminates hidden node collisions & maximizes air time efficiency. It provides many magnitudes of performance improvements in latency, throughput, & scalability compared to all other outdoor systems in its class. Intelligent QoS Priority is given to voice/video for seamless access. Scalability High capacity and scalability. Long Distance Capable of high speed Carrier Class links Latency Multiple features dramatically reduce noise. Utilize AirMax Technology Time Channel Time Slot 1 Time Slot 2 Time Slot 3 Time Slot 4 Frame Time Slot 4 Packet Prioritization VOIPVOIPVOIPVOIP DATA AirMax Clients (up to 100 clients can be connected per AirMax Omni, 4 clients are shown to show general concept) AirMax Omni Usage Example AirMax Omni Antennas provide wide 360° coverage and utilize AirMax technlogy to produce Carrier Class performance and power. 12 3 4 5 OMNI PTMP LINKS (Point to Multi-Point) 1 2 3 4 5 6 6 7 7 *When Omni is paired with Rocket M * Datasheet | Omni 03 Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com Models [left to right] AMO-5G10 (5GHz, 10dBi), AMO-5G13 (5GHz, 13dBi), AMO-2G10 (2.4GHz, 10dBi), AMO-2G13 (2.4GHz, 13dBi) Datasheet | Omni AirOS is an intuitive, versatile, highly developed Ubiquiti firmware technology. It is exceptionally intuitive and was designed to require no training to operate. Behind the user interface is a powerful firmware architecture which enables hi-performance outdoor multipoint networking. Protocol Support Ubiquiti Channelization Spectral Width Adjust ACK Auto-Timing AAP Technology Multi-Language Support 04 Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com Software View OS Integrated on all Ubiquiti M products, AirView provides Advanced Spectrum Analyzer Functionality: Waterfall, waveform, and real-time spectral views allow operators to identify noise signatures and plan their networks to minimize noise interference. Waterfall Aggregate energy over time for each frequency. Waveform Aggregate energy collected. Real-time Energy is shown real-time as a function of frequency. Recording Automize AirView to record and report results. Contro l AirControl is a powerful and intuitive web based server network management application which allows operators to centrally manage entire networks of Ubiqutii devices. Network Map Monitor Device Status Mass Firmware Upgrade Web UI Access Manage Groups of Devices Task Scheduling www.ubnt.com/aircontrol www.ubnt.com/airview www.ubnt.com/airos * When AirMax Omni is paired with Rocket M * Datasheet | Omni Antenna Characteristics AMO-2G10AMO-2G13AMO-5G10AMO-5G13 Frequency Range2.35 - 2.55 GHz5.45 - 5.85 GHz* Gain10 dBi13 dBi10 dBi13 dBi Elevation Beamwidth12 deg7 deg12 deg7 deg Downtilt4 deg2 deg4 deg2 deg Dimensions** (l x w x h)217 x 123 x 1011 mm217 x 123 x 1386 mm158 x 98 x 579 mm158 x 98 x 834 mm Weight**2.1 kg2.4 kg0.68 kg0.82 kg Wind Loading28 lb @ 100 mph38 lb @ 100 mph8 lb @ 100 mph10 lb @ 100 mph Wind Survivability125 mph100 mph125 mph Max VSWR1.7:11.6:11.5:1 PolarizationDual Linear Cross-pol Isolation25 dB min ETSI SpecificationEN 302 326 DN2 MountingUniversal pole mount, Rocket M bracket, and weatherproof RF jumpers included 05 Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com Specifications * Only 5745 - 5825 MHz is supported in the USA ** Dimensions and weight include pole mount; do not include Rocket M (Rocket M sold separately) Datasheet | Omni 06 Specifications (cont.) AMO-2G10 - Antenna Information 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -30 2.42.45 V-pol dB GHz 2.5 -20 -10 H-pol Vertical AzimuthReturn LossVertical Elevation Horizontal Elevation 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB -9 -3 dB Horizontal Azimuth Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB AMO-2G13 - Antenna Information 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -24 2.42.45 V-pol dB GHz 2.5 -18 -12 -6 H-pol Vertical AzimuthReturn LossVertical Elevation Horizontal Elevation 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB -9 -3 dB Horizontal Azimuth 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB Datasheet | Omni 07 Specifications (cont.) AMO-5G10 - Antenna Information 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -24 5.555.65 V-pol dB GHz 5.75 -18 -12 -6 H-pol Vertical AzimuthReturn LossVertical Elevation Horizontal Elevation 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB -9 -3 dB Horizontal Azimuth Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reservedwww.ubnt.com 90 -90 120 -120 150 -150 180 60 -60 30 -30 0 -9 -3 dB 90 -90 120…

Text truncated - open the document above for the full version.

4.9-5.9GHz 65° & 90° Sector Panels This WiMAX antenna is designed to cover frequencies from 4.9 to 5.9 GHz. It offers excellent port to port isolation of 30 dB typical, with a VSWR of less than 1.5 in a rugged, off-white UV resistant radome. Features • Outstanding port to port isolation of 30 dB typical • VSWR of less than 1.5 • Great upper side lobe suppression • Adjustable scissors-style pipe mount bracket with 0-10° downtilt Model Frequency Range Nominal Gain Azimuth Beamwidth Elevation Beamwidth RF/Electrical Specifi cations Mechanical Specifi cations SP4959-17XP654.9-5.4 GHz 5.4-5.9 GHz 17.5 dBi 16.5 dBi 65° +/- 10% 65° +/- 10% 5° 5° SP4959-16XP904.9-5.4 GHz 5.4-5.9 GHz 16.5 dBi 15.5 dBi 90° +/- 10% 90° +/- 10% 5° 5° SP4959-17XP65 -40°C to 65°C storage / -40°C to 65°C operating 28” x 6.7” x 3.5” (711 x 171 x 90 mm) 7 lbs (3.1 kg) 125 mph (200 km/h) SP4959-16XP90 -40°C to 65°C storage / -40°C to 65°C operating 28” x 6.7” x 3.5” (711 x 171 x 90 mm) 7 lbs (3.1 kg) 125 mph (200 km/h) Model Temperature Range Dimensions (L X W X D) Weight (Mass) Wind Survivability Technical Data Polarization: Linear dual slant +/- 45° Nominal Impedance: 50 ohms VSWR: < 1.5 Front to Back Ratio: > 25 dB Port to Port Isolation: 30 dB typical Upper Side Lobe Suppression: 30 degrees above horizon: > -15 dB Radome Material: Gray UV resistant plastic Connector: Type N female Mounting Method: Adjustable pipe mount bracket (included) Mount Material: Nickel Zinc Trivalent Plated Steel (RoHS Compliant) INFRASTRUCTURE ANTENNAS Sector Panels PCTEL, Inc. WEB: www.antenna.com 125

RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 5725-5825 MHz; highest conducted power = 15.574 dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Gain of Antenna @ 5GHz = 10 dBi Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density (mW/cm 2 ) P = Power Input to antenna (36.088 mW) G = Antenna Gain (10) R = Radius (20 cm) S = (36.088 * 10)/(4*3.14*20 2 ) = 0.072 mW/cm 2 Gain of Sector Antenna @ 5GHz = 15.5 dBi Highest Conducted Power with Sector Antenna = 15.5 dBm S = Power Density (mW/cm 2 ) P = Power Input to Antenna (35.48 dBm) G = Numeric Antenna Gain (35.48) R = Radius (20 cm) S = (35.48 * 35.48)/(4 * 3.14 * 20 2 ) = 0.241 mW/cm 2

§ 15.407(f) RF Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 5150-5350, 5470-5825 MHz; highest conducted power = 19.782dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Gain of Omni Antenna @ 5GHz = 10 dBi Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density (mW/cm 2 ) P = Power Input to antenna (95.109mW) G = Numeric Antenna Gain (10) R = Radius (cm) S = (95.109 * 10)/(4*3.14*20 2 ) = 0.189 mW/cm 2 Gain of Sector Antenna @ 5GHz = 15.5 dBi Highest Conducted Power with Sector Antenna = 14.46 dBm S = Power Density (mW/cm 2 ) P = Power Input to antenna (27.93 mW) G = Numeric Antenna Gain(35.48) R = Radius (20 cm) S = (27.93 * 35.48)/(4*3.14*20 2 ) = 0.197 mW/cm 2

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory March 2, 2012 Fortress Technologies 2 Technology Park Drive Westford, MA 01886 Dear John Pacheco, Enclosed is the EMC Wireless test report for compliance testing of the Fortress Technologies, ES2440 as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-06 ed.), Title 47 of the CFR, Part 15, Subpart B, Industry Canada ICES-003 Issue 4 February 2004 for Unintentional Radiators and Part 15.407, Industry Canada RSS-210, Issue 8, December 2010 for Intentional Radiators. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Jennifer Warnell Documentation Department Reference: (\Fortress Technologies\EMC32466A-FCC407 Rev. 1 (UNII3)) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 MET Report: EMC32466A-FCC407 Rev. 1 (UNII3) © 2012, MET Laboratories, Inc. Page i of xvii Electromagnetic Compatibility Criteria Test Report for the Fortress Technologies Model ES2440 Tested under the Certification Rules contained in Title 47 of the CFR, Part 15, Subpart B and ICES-003 Issue 4 February 2004 for Unintentional Radiators and Title 47 of the CFR, Part 15.407 and Industry Canada RSS-210, Issue 8, December 2010 for Intentional Radiators MET Report: EMC32466A-FCC407 Rev. 1 (UNII3) March 2, 2012 Prepared For: Fortress Technologies 2 Technology Park Drive Westford, MA 01886 Prepared By: MET Laboratories, Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 Electromagnetic Compatibility Fortress Technologies Cover Page ES2440 CFR Title 47, Part 15, Subpart E MET Report: EMC32466A-FCC407 Rev. 1 (UNII3) © 2012, MET Laboratories, Inc. Page i of xvii Electromagnetic Compatibility Criteria Test Report for the Fortress Technologies Model ES2440 the Certification Rules contained in Title 47 of the CFR, Part 15, Subpart B and ICES-003 Issue 4 February 2004 for Unintentional Radiators and Title 47 of the CFR, Part 15.407 and Industry Canada RSS-210, Issue 8, December 2010 for Intentional Radiators Jeffrey Pratt, Project Engineer Jennifer Warnell Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Parts 15B, 15.407, of the FCC Rules and ICES-003 and RSS-210 of the Industry Canada rules under normal use and maintenance. Shawn McMillen, Wireless Manager Electromagnetic Compatibility Lab Electromagnetic Compatibility Fortress Technologies Report Status ES2440 CFR Title 47, Part 15, Subpart E MET Report: EMC32466A-FCC407 Rev. 1 (UNII3) © 2012, MET Laboratories, Inc. Page i of xvii Report Status Sheet Revision Report Date Reason for Revision  January 5, 2012 Initial Issue. 1 March 2, 2012 Revised to reflect engineer corrections. Electromagnetic Compatibility Fortress Technologies Table of Contents ES2440 CFR Title 47, Part 15, Subpart E MET Report: EMC32466A-FCC407 Rev. 1 (UNII3) © 2012, MET Laboratories, Inc. Page i of xvii Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview ...........................................................................................................................................................…
