X2U-SHAMU-M2MShamu M2M Data Card

Engineering Test Software (ETS) Operation This document provides final product specifications. VIA Telecom reserves the right to make changes to this product at any time without notice. This document contains proprietary information of VIA Telecom, Inc. The information contained herein is not to be used by or disclosed to third parties without the express written permission of an officer of VIA Telecom, Inc. This document describes VIA Telecom’s Engineering Test Software and will remain the official reference source for all revisions/releases of this product until rescinded by an update. VIA Telecom, Inc. reserves the right to make changes to any product herein at any time without notice. VIA Telecom does not assume any responsibility or liability arising out of the application or use of any product described herein, except as expressly agreed to in writing by VIA Telecom; nor does the purchase or use of a product from VIA Telecom convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of VIA Telecom or third parties. The VIA Telecom logo design and VIA TELECOM are trademarks owned by the company. Microsoft, Windows, Windows NT, Visual Basic, and Visual C++ are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. LabVIEW is a trademark of National Instruments Corporation. CommLib is a trademark of sysFire LLC. All other brand and product names may be trademarks of their respective companies. VIA Telecom products are not intended for use in life-support appliances, devices, or systems. Use of any VIA Telecom product in such applications without written consent of the appropriate VIA Telecom officer is prohibited. VIA Telecom is certified to the ISO 9001:2000 quality management system international standard. VIA Telecom, Inc. 3390 Carmel Mountain Road San Diego, CA 92121, U.S.A. Tel: 858.350.5560 Internet: www.via-telecom.com Copyright © VIA Telecom, Inc. 2006 All Rights Reserved. Printed in U.S.A. January 2006 Engineering Test Software Operation Rev 28_A Sept 2005 VIA Telecom, Inc. Proprietary Internal Revision History Page Engineering Test Software Operation Revision: 32 Status: Draft Author: Multiple Function: VIA Telecom, Inc. Path and Filename: C:\CM\CBPTOOLS\Docs\ctm_ets_overview.doc File Type: Microsoft Word 2000 Version 32 Release Date: May 10, 2007 Engineering Test Software Operation Rev 28_A Sept 2005 ii VIA Telecom, Inc. Proprietary Revision History Rev Status* Date Author Reason for change/description 32 Draft 5/10/2007 C. Lewis Corrected the description of non-bitpacked bit fields. 31 Draft 1/24/2007 C. Lewis Added string and numeric field password description. 30 Draft 2/21/2006 C.Lewis Added the Download.dll documentation. 29 Draft 1/19/2006 C. Lewis M. Liu D. Orloff Added ViaHub description, updated the EtsMain command line options, added the ViaBinary interface to the ViaIf.dll and the EtsIf.ocx interface. Added BINLOG and GETDEF sections. Added conditionally and invisible definition support descriptions. 28 Approved 9/19/2005 Roy Davis, Bryan Yang Rev 26_D approved for release as Rev 28_A 27 Draft 09/02/2005 C. Lewis M. Liu Added ViaIf.dll description and added explanations to the Get Command, Error and Response interface functions. Added USB support 26 Approved 5/24/2005 Roy Davis, Bryan Yang Rev 25_P approved for release as Rev 26_A 25 Pending 05/02/2005 M. Liu Added the description of ViaCrypt utility and binary EtsMsg.bin file 24 Approved 1/13/2005 R. Smith J. Miller Rev 23_P approved for release as Rev 24_A. 23 Pending 01/06/2005 Chuck Lewis D. Orloff Made generic to all CBP products Added section on DBM Templates and AutoRspQ interface Removed ETS Visual Basic Interface Updated sections for adding Commands, Traces, Spies, and Faults Miscellaneous minor updates 22 Draft 10/06/2004 H. Nguyen Added Register OCX and updated External EXEs 21 Draft 08/17/2004 H. Nguyen Added Auto Config Loading when phone is detected. 20 Draft 06/18/2004 H. Nguyen Added External EXEs to ETS GUI 19 Draft 2/5/2004 C. Lewis Added the Lock Config File command line option 18 Draft 10/13/2003 D. Schaeffer Convert to customer template 17 Approved 7/15/2003 P. LaBarbera R. Smith S. O’Leary Version 16_D approved for release as version 17_A 16 Draft 6/12/03 C. Lewis Added the description of “Default ETS Options” section. 15 Draft 5/28/03 C. Lewis Added descriptions of the following new options. Disabled commands, hidden fields, read only fields and startup command options. Updated with changes as recommended in review. Added Fault Log section description. Moved section 5 to the end. 14 Draft 4/14/03 C. Lewis Updated the command line options and added the COUNT_OF option to expression definitions. 12 Draft 3/10/03 C. Lewis Added bitpacked arrays. Updated documentation for Lite message definitions. Added description of the “Save Engineering Test Software Operation Rev 28_A Sept 2005 VIA Telecom, Inc. Proprietary Internal Revision History Page Rev Status* Date Author Reason for change/description 32 Draft 5/10/2007 C. Lewis Corrected the description of non-bitpacked bit fields. 31 Draft 1/24/2007 C. Lewis Added string and numeric field password description. 30 Draft 2/21/2006 C.Lewis Added the Download.dll documentation. 29 Draft 1/19/2006 C. Lewis M. Liu D. Orloff Added ViaHub description, updated the EtsMain command line options, added the ViaBinary interface to the ViaIf.dll and the EtsIf.ocx interface. Added BINLOG and GETDEF sections. Added conditionally and invisible definition support descriptions. 28 Approved 9/19/2005 Roy Davis, Bryan Yang Rev 26_D approved for release as Rev 28_A 27 Draft 09/02/2005 C. Lewis M. Liu Added ViaIf.dll description and added explanations to the Get Command, Error and Response interface functions. Added USB support 26 Approved 5/24/2005 Roy Davis, Bryan Yang Rev 25_P approved for release as Rev 26_A 25 Pending 05/02/2005 M. Liu Added the desc…

Text truncated - open the document above for the full version.

SHAMU M2M User Manual z USB Driver Installation 1. To install the VIA USB Windows device driver, you must first start the Setup application, VIA USB Drivers 2.1.5 (32-Bit).exe, by double-clicking the associated icon. 2. Choose the directory for the application to be installed. 3. Click Install, then this setup program will copy all the files into the directories on the local system drive of your PC. The following dialog box will appear upon execution. 4. Click Finish when this action has been completed. 5. Plug in the USB dongle to PC. Then Windows will install all the related drivers automatically. You can find “VIA Telecom USB Modem”, “VIA Telecom AT Port”, “VIA Telecom LBS Port”, “VIA Telecom Voice Port” and “VIA Telecom USB ETS” in Device Manager. z Dial up Application Setup 1. Select “New Connection Wizard” 2. Select Connect to the Internet 3. Select “Set up my connection manually” 4. Select” Connect using a dial- up modem” 5. Enter your ISP name 6. Enter your Number to Dial 7. Select Anyone’s use 8. Enter user name and password 9. After finishing the configuration, you can set up a connection If Driver is properly installed, you can see “VIA Telecom USB Modem” in the properties menu. z IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter As long as these conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: X2U-SHAMU-M2M”. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help.

FCC ID：X2U‐SHAMU‐M2M Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely. Daniel Lee VIA Telecom, Inc. Tel/Fax: +001 858 523 5319 / +001 858 350 0171

external photo

internal photo

RF Exposure / MPE Calculation Dear Reviewer, As specified in Table 1B of 47 CFR 1.1310 – Limits for Maximum Permissible Exposure(MPE), Limits for General Population/Uncontrolled Exposure: The RF Exposure level is calculated using the general equation: S = P/ 4 πR2 The maximum measured radiated power output is CDMA 800MHz: 23.95 dBm (~ 0.24831 W) CDMA1900MHz: 24.04 dBm (~ 0.25293 W) With an antenna gain of 800MHz ： 0.8 dBi 1900MHz ：3.0 dBi R = 20 cm π = 3.1416 Solving for S, the power density at 20 cm is CDMA800: 0.0494 mW/cm 2 CDMA1900: 0.0504 mW/cm2 The power density limit is: For 800MHz: f/1500 = 824.7/1500 = 0.5498 mW/cm 2 For 1900MHz: 1.0 mW/cm2 So, the power density limit is well kept with this antenna gain. Please contact us if you have any additional questions. Best Regards Morlab ZhangWenjie

Report No.: SH10050030R01 Page 2 of 51 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .......................................................................................... 4 2. GENERAL INFORMATION .................................................................................................... 5 2.1 Equipment under Test (EUT) Description ............................................................................... 5 2.2 Test Standards and Results ........................................................................................................ 6 2.3 Facilities and Accreditations ...................................................................................................... 7 2.3.1 Facilities .................................................................................................................................... 7 2.3.2 Test Environment Conditions .................................................................................................... 7 2.4 47 CFR Part 2, Part 22H ,Part 24E Requirements .................................................................. 8 2.4.1 Conducted Related Tests ........................................................................................................... 8 2.4.2 Radiated Power and Spurious Emission Tests .......................................................................... 9 2.4.3 Frequency Stability Test .......................................................................................................... 10 2.4.4 Test Mode ................................................................................................................................ 10 2.5 Frequencies ................................................................................................................................ 11 2.5.1 Requirement ............................................................................................................................ 11 2.5.2 Procedure................................................................................................................................. 11 2.5.3 Test Results ............................................................................................................................. 12 2.5.4 Test Plots ................................................................................................................................. 13 2.6 Conducted RF Output Power .................................................................................................. 19 2.6.1 Requirement ............................................................................................................................ 19 2.6.2 Test Procedure ......................................................................................................................... 19 2.6.3 Test Results ............................................................................................................................. 20 2.6.4 Test Plots ................................................................................................................................. 22 2.7 Occupied Bandwidth ................................................................................................................ 25 2.7.1 Occupied Bandwidth Definition ............................................................................................. 25 2.7.2 Test Procedure ......................................................................................................................... 25 2.7.3 Test Result ............................................................................................................................... 26 2.7.4 Test plots ................................................................................................................................. 27 2.8 Band-edge .................................................................................................................................. 30 2.8.1 Requirement ............................................................................................................................ 30 2.8.2 Test Description ...................................................................................................................... 30 Report No.: SH10050030R01 Page 3 of 51 2.8.3 Test Result ............................................................................................................................... 30 2.8.4 Test plots ................................................................................................................................. 31 2.9 Conducted Spurious Emission ................................................................................................. 33 2.9.1 Requirement ............................................................................................................................ 33 2.9.2 Test Procedure ......................................................................................................................... 33 2.9.3 Test Results ............................................................................................................................. 34 2.9.4 Test Plots ................................................................................................................................. 35 2.10 Transmitter Radiated Power (EIRP/ERP) .......................................................................... 38 2.10.1 Requirement ............................................................................................................................ 38 2.10.2 Test Procedure ......................................................................................................................... 38 2.10.3 Test Result ............................................................................................................................... 39 2.10.4 Test plots ...................................................................…

Text truncated - open the document above for the full version.

Test Setup Photo Conducted Te s t Setup Radiation Te s t Setup
