Report No.: EM09042278a Page: 2 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 JOB DESCRIPTION Equipment: ADRS Radio Modem transmitterr operating in the frequency band 902 to 928MHz Equipment Model No.: RM013 Equipment Serial No.: 900011 Phase: Compliance Customer: Smiths Detection (Watford) Test Plan Reference: - Test Standards: CFR47 Part15:247 FCC Ident X4M - 16852 Test Location: Intertek Semko - Leatherhead Test Work Started: 3 rd November 2009 Test Work Completed: 5 th May 2010 Report No.: EM09042278a Page: 3 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 1. TEST SUMMARY 1.1. ADRS Radio Modem – RM013 1.1.1. CFR 47 Part 15:247 Test Standards Test COMMENT CFR47 15:247.a(1) RSS 210 A8.1 channel seperation Pass CFR47t15:247.a(1) RSS 210 A8.1 20 dB Bandwidth Pass CFR47 15:247.a(1)(1) RSS 210 A8.1 Dwell Time Pass CFR47 15:247.a(1)(111) RSS 210 A8.1 Number of hopping channels Pass CFR47 15:247.b(1) RSS 210 A8.4 RF Conducted Power Pass CFR47 15:247.d RSS 210 A8.5 Radiated emissions Pass CFR47 15:247.e RSS 210 A8.2 Power Density Note Note: Not applicable to frequency hopping systems 1.1.2. CFR 47 Part 15 Product Specific Standard: CFR47 Part 15C TEST STANDARD TEST Comment CFR47 15: 209 RSS 210. 2.7 Table 1 Radiated Emissions (Note 1) Pass CFR47 15: 205 RSS 210: 2.7 Table 2 Restricted Bands of Operation Pass Note 1: This test was carried out in a FCC registered chamber, which plies with FCC limits for Radiated Emissions over the frequency range 30MHz to 1000MHz.. There is an emission at 640MHz which has an amplitude within the uncertainty budget. All the above tests have been carried out to meet the requirements of ANSI C63.4:2003 Test procedures. Report No.: EM09042278a Page: 4 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 2. EQUIPMENT UNDER TEST (EUT) 2.1. Description of the EUT The Smiths Detection (Watford) Automatic Detection Reporting System (ADRS) Radio Modem enables a collection of Fixed Site Chemical Detectors (FSD) to be combined into a wireless network reporting to a single location to provide centralized recording of FSD data and control and monitoring of the FSDs. Each FSD is connected to a Radio Modem (outstation) which communicates with another Radio Modem (Base Station) connected to a controller Laptop. The Radio Modems also have built in Global Positioning System (GPS) receivers that are activated at startup to obtain position co-ordinates. The ADRS unit operates in the frequency sub-band of 902MHz to 928MHz and can be powered by internal batteries (6vdc) or powered externally (12vdc – 30vdc). The frequencies tested were 902MHz, 915MHz and 927MHz. The EUT was as received with no external visible signs of damage and was of production quality. 2.2. EUT’s Modes of Operation All tests are performed with Frequency modulation producing a maximum of 1.6W radiated power unless stated otherwise. Standard test mode waveform profile is 16KF1D. 2.3. EUT Configuration Diagram See test set up photographs. 2.4. EUT Support Equipment Software control computer 2.5. Cables Associated With the EUT EUT PORT TYPE LENGTH (m) TERMINATION/LOAD EUT multicore 1.5m Laptop controller 3. TESTS Report No.: EM09042278a Page: 5 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 3.1. RF Conducted Power The testing was performed in accordance with FCC CFR47 Part 15:247b (3). 3.2. SAR Evaluation Refer Annex A for Radiated Exposure Levels report. The RF power output was set to maximum power output (CW) and was measured at the antenna port connected directly to a Spectrum Analyser, at the lower, middle and upper frequencies . 3.3. RF Conducted Power Test Results The RF power output was set to maximum power output (CW) and was measured at the antenna port connected directly to a Spectrum Analyser, at the lower, middle and upper frequencies. The results are given in Table 1 and pages 8 – 9. These tests were carried out on the 26 th November 2009. Table 1 Freq MHz Peak Power dBm Peak Power mWatts 902 25.85 384.6 915 25.84 383.7 927 25.24 334.2 The duty cycle is defined in Operational Description in Annex 2. 3.4. Test Plots – Conducted Power Report No.: EM09042278a Page: 6 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 902MHz Peak Power (367.28mW) 915MHz(366mW) Report No.: EM09042278a Page: 7 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 Peak Power 927.3MHz (334.2mW) These tests carried out on the 26 th November 2009 3.5. Modifications Performed During Testing None. 3.6. RF Conducted Power Tests The EUT complied with CFR47:Part 15:247b(3) 3.7. Radiated Peak Powers Report No.: EM09042278a Page: 8 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 EIRP = Analyser dBμV(dBm)+AFdB+cab1+cab2+cab3+cab4 = dBm Field Strength(dBμV/m) = Analyser(dBμV + AF(dBm) + cabs(dB) EIRP = Field Strength(dBμV/m) – 95.2(conversion from dBμv/m to dBm) EIRP = 94.31 + 21.2 + 7.7 -95.2 = 28.01dBm EIRP = 632mW EIRP = 93.99+ 21.2+7.7-95.2= 27.69dBm= 587mW Report No.: EM09042278a Page: 9 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 EIRP = 94.22 +21.2+7.7-95.2 = 27.92dBm = 619mW These tests carried out on the 5 th November 2009 4. HOPPING CHANNEL SEPARATION Channel Separation (186.00kHz) Report No.: EM09042278a Page: 10 of 86 Product: ADRS Radio Modem Issue Date: May 13 th 2010 Model No.: RM013 Issue No.: 5 Ref 137 dBμVAtt 60 dB A PS 3DB * RBW 30 kHz VBW 100 kHz SWT 5 ms Center 927.5 MHzSpan 3 MHz300 kHz/ 1 PK MAXH 40 50 60 70 80 90 100 110 120 130 1 Marker 1 [T1 ] 132.99 dBμV 926.936000000 MHz 2 Delta 2 [T1 ] -0.03 dB 186.000000000 kHz 100 kHz RBW Date: 5.MAY.2010 13:53:37 4.1. Pseudorandom Hopping and Receiver Hopping The client attests that the receiver bandwidth hops In synchrony with the transmit bandwidth. This is n…

Text truncated - open the document above for the full version.
