X5HS102BonSayON S102 Bone Conduction Bluetooth Sunglasses

BonSayOn Product Manual Preface Introduction Caution Description Specification Wear the Glasses Adjusting the Nose Pad Chang the Lenses Illustration of Button Function Pairing How to use Dual Pairing Table of Operation Instruction of Battery Charge Q&A Product Service Electromagnetic safety 1 1 1 2 3 5 7 7 8 9 10 11 12 14 14 4 6 B Preface Introduction Caution BonSayOn products are proudly produced with high tech and fashion merged together. Please read the manual in details for using correctly and comfortably. Completely different from the conventional microphone which picks up the sound or voice through air BonSayOn products adopt the newly developed nasal bone conduction microphone by picking up the sound through bone or solid material instead of air Through high-quality Bluetooth communication, the speaker s voice sensed by the nasal bone conduction chip is quite clear like face-to-face talking with whom you are familiar. The most outstanding feature is that no or little background noise is added into the human voice. The clear conversation through BonSayOn products always never stops in any noisy environment Please enjoy the noiseless communication with BonSayOn fashion products. 1. This product is humidity proof but not water proof or ust proof. Do not use it in water or dust environment to avoid the damage as well as shortening the lifetime of the product 2. Temperature range 3. In order to guarantee communication quality, do not cover the product with metal 4. For the sake of product surface and accessories intact please avoid rubbing the product with hard objects. , ,. ' . ,- - . -10°C~°C . , - ： d 50 BonSayOn BonSayOn 1 5.Please adopt the qualified accessories which have authenticated by NeoVictory Company so as to ensure smooth and normal operation. 6.All accessories have been officially certified In order to guarantee the product functioning normally please do not use the accessories not officially certified Anti UV Fit safety standards CNS VEDR Standby abouthours Talking about hours, Music: about 5 hours. Bluetooth connection to mobile phone and computer for music MSN Skype Support A DP for superior quality music play Communication rangemeter Barrier free Touch nose small and smooth Special adjustable nose pad design for wearing comfort . , . 7.When using the earphone, your can not access outside sound very well. Do not use the earphone where it can endanger your safety. Description Sunglasses Bluetooth Nasal bone conduction microphone -400 (15067) 2.1+,：50, ：6 ,, . 2. ：10(-) ,. . BonSayOn BonSayOn 2 Specification Microphone type Bluetooth standard Bluetooth operation mode Transmission range Earphone Battery .0 - NeoV Nasal bone conduction microphone Version 2 Hand free Profile XOutputmW Bluetooth VEDR with A DP function High quality sound output 2.1+ 2 (190/3.7 )，: 2 - (2 :)A DP Advanced Audio Distribution Profile 2.402~2.480, :10(-) 2,:10 GHzGHz MaxBarrier free meter 32Ω Li-polymer Battery mAVcharge time about hours. Adjustable Nose Pad Button Charge Jack Indicator(Blue) /Charge(Red) Earphone Screw of Adjusting Nose Pad Battery BonSayOn BonSayOn 3 Music play time Talk time Idle Size Weight Operation condition Battery charger standard Standard accessories 5 0 170 68 -10°C~50°C，0~90% About hours hours mmX155mmX45mm g humidity About hours About 6 5 1. 2. Input ACVHz Output DC V MAXA Cleaning potch, Ear plug(three specs), Indoor and night drive lens, screwdriver Put on the sunglasses and adjust them to your comfort Adjust the nose pads to fit the nose for high quality communication and a low amount of background noise while using this product :110/220 50/60 :50.6 . . ,,Manual Battery charger Warranty, Wear the Sunglasses ( ) Refer to the Adjust the Nose Pads section BonSayOn BonSayOn 4 3. 4. Pull out the earphone to get a suitable wire length (four steps within the wire). Pull out the earphone to the end and release it quickly, it will return to the socket automatically. Push down the earphone to fix it into the socket. How to Get a Suitable Wire Length How to Return the Earphone 123 1 2 3 Get a suitable wire length Rotate and Pull it out Hold the earphone Ka! 123 1 2 3 Pull again softly and release quickly It will return to the socket automatically Pull out it to the end Adjust the Nose Pads 1. 2. Loosen the screw counterclockwise with the attached screwdriver for 2-3 cycles. Adjust the angle of nose pads to fit your nose. Hold the stand to fix the angle and then tighten the screw clockwise. BonSayOn BonSayOn 5 Insert the lens 1. 2. 3. 4. Insert the protruding left side of the lens. Grasp the right side and then bend up lightly to insert the lens into the frame. Adjust the lens to make sure it is completely stationary. For the other side follow the exact above instructions in reverse. Change the Lenses Pull out the lens 1. 2. 3. 4. Take off the glasses and put the front side toward to yourself. Grasp the right side and then bend up lightly to make the lens go out from the frame. Pull out the lens from left side to right side. For the other side follow the exact above instructions in reverse. BonSayOn BonSayOn 6 Pairing Turn on the Bluetooth communication of the device mobile phone or computer connected to the product Long press button U until the blue and red LED flashes quickly to turn on the product Search the product by using the Bluetooth of the device mobile phone or computer The identification code or password is Turn off the product first after communication ends then turn off the device connected to the products () . . , . (). “0000”. Illustration of Button Function Short press : Long press : Press button less than 1 second Press button about 2 seconds Button F (Push Forward) Button U (Push Up) Button B (Push Backward) BonSayOn BonSayOn 7 How to Use Talk mode: Music mode: / . . . . . . . . / Answer End a call: Short press button U once. Increase volume: Short press button B once Long press button B increases volume until upper limit Decrease volume: Short press button …

Text truncated - open the document above for the full version.

ACX Advanced Ceramic X Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™2.4GHz WLAN, Home RF, Bluetooth Modules, etc. Specifications Part Number Frequency Range (MHz) Peak Gain (dBi typ.) Average Gain (dBi typ.) VSWR Impedance AT7020 -E3R0HBA_ 2400~2500 1.3dBi (XZ-V) -0.5dBi (XZ-V)2 max. 50 Ω Q’ty/Reel (pcs) : 1,000 pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : +5 ~ +35 o C, Humidity 45~75%RH Storage Period : 12 months max. Power Capacity : 2W max. Part Number c Type AT : Antenna d Dimensions ( L × W ) 7.0× 2.0 mm e Material Code E f Frequency Range 3R0=3000MHz g Specification Code HBA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point e NC d NC f NC AT7020 Series Multilayer Chip Antenna c d e f A CX AT 7020 - E 3R0 HBA ‡ ‡ c d efhg i ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Mark L W L1 W1 T a Dimensions 7.00.2 2.00.2 2.60.2 0.50.2 2.0+ 0.1/-0.2 0.50.3 ™With Matching Circuits (Unit in mm) *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. Unit : mm a T L1 W1 L W ACX Top view Bottom view Side view (Matching circuit and component values will be different, depending on PCB layout) 0.83 2.8 1 1.6 1.6 1 0.8 1.83 0.8 1 2 2 2 10 4.87 2.7 nH A CX 1.8 nH ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) ™ Test Board (Unit in mm) ™ Return Loss/With Matching Circuits 4.87 40 20 Ground No Ground 10 Antenna ACX Advanced Ceramic X ™ Radiation Patterns XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal XY-V/XY-H 180 o 270 o 0 o 90 o X Z Y XY-cut scanning direction 180 o 270 o 0 o 90 o X Z Y XZ-cut scanning direction 180 o 270 o 0 o 90 o X Z Y YZ-cut scanning direction ACX Advanced Ceramic X AT7020-E3R0HBA on mobile phone layout ™ Evaluation board (Unit in mm) ™ Return Loss/With Matching Circuits 2 40 100 5 9 Ground No ground Via Antenna 3.3 nH 1.5 nH ACX Advanced Ceramic X ™ Radiation Patterns Advanced Ceramic X Corp. 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan TEL:886-3-5987008 FAX:886-3-5987001 E-mail: [email protected] http://www.acxc.com.tw XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal XY-V/XY-H 180 o 270 o 0 o 90 o X Z Y XY-cut scanning direction 180 o 270 o 0 o 90 o X Z Y XZ-cut scanning direction 180 o 270 o 0 o 90 o X Z Y YZ-cut scanning direction

FCC ID : X5HS102 Product : BonSayON S102 Bone Conduction Bluetooth Sunglasses Model : S102 To whom it may concern: We, the undersigned, hereby certify that we responsible to comply with the relevant provisions of the Bluetooth device specification and certificate program as bellows: Declaration for Bluetooth Device acc to Part 15.247 1 Output power and channel separation of a Bluetooth device in the different operating modes: The different operating modes (data-mode, acquisition-mode) of a Bluetooth devicehas no influence on the output power and the channel spacing. There is only onetransmitter which is driven by identical input parameters concerning these two parameters.Only a different hopping sequence will be used. For this reason the check of these RF parameters in one op-mode is sufficient. 2 Frequency range of a Bluetooth device: Hereby we declare that the maximum frequency of this device is: 2402 – 2480 MHz. This is according to the Bluetooth Core Specification (+ critical errata) for devices which will be operated in the USA.This was checked during the Bluetooth Qualification tests (Test Case: TRM/CA/04E). Other frequency ranges ( e.g. for Spain, France, Japan) which are allowed according the Core Specification are not supported by this device. 3 Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters: Bluetooth units which want to communicate with other units must be organised in astructure called piconet. This piconet consist of max. 8 Bluetooth units. One unit isthe master the other seven are the slaves. The master co-ordinates frequency occupation in this piconet for all units. As the master hop sequence is derived from its BD address which is unique for each Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. 4 Example of a hopping sequence in data mode: Example of a 79 hopping sequence in data mode:40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68, 02, 70, 06, 01, 51, 03, 55, 05, 04 5 Equally average use of frequencies in data mode and behaviour for short transmissions: The generation of the hopping sequence in connection mode depends essentiallyon two input values: 1. LAP/UAP of the master of the connection 2. Internal master clock shift between RX and TX time slot according to the clock of the master.Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and itsTX/RX timing according to the packet type of the connection. Also the slave of the connection will use these settings.Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case.That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence. The LAP (lower address part) are the 24 LSB’s of the 48 BD_ADDRESS. The BD_ADDRESS is an unambiguous number of every Bluetooth unit. The UAP (upper address part) are the 24 MSB’s of the 48 BD_ADDRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronisation with other units onlyoffset are used. It has no relation to the time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30).In most case it is implemented as 28 bit counter. For the deriving of the hopping sequence the entireLAP (24 bits), 4 LSB’s (4 bits) (Input 1) and the 27 MSB’s of the clock (Input 2) are used. With this input values different mathematical procedures (permutations,additions, XOR- operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions the Bluetooth system has the following behaviour:The first connection between the two devices is established, a hopping sequence was generated. For transmitting the wanted data the complete hopping sequencewas not used. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the periodbetween the two transmission is longer (and it cannot be shorter) than the minimum resolution of the clock (312.5 μs). The hopping sequence will always differ from the first one. 6 Receiver input bandwidth and behaviour for repeated single or multiple packets: The input bandwidth of the receiver is 1 MHz. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see chapter 5). The slave follows this sequence. Both devices 7 Dwell time in data mode The dwell time of 0.3797s within a 30 second period in data mode is independent from the packet type (packet length). The calculation for a 30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels *30s Example for a DH1 packet (with a maximum length of one time slot) Dwell time =625 μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced according to the length of the packet. Example for a DH5 packet (with a maximum length of five time slots) Dwell time = 5 * 625 μs * 1600 * 1/5 *1/s / 79 * 30s = 0.3797s (in a 30s period). This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for all Bluetooth devices. Therefor all Bluetooth devices comply with the FCC dwell time requirement in data mode. This was checked during the Bluetooth Qualification tests. The Dwell time in hybrid mode is measured and stated in the test report. 8 Channel Separation in hybrid mode Th…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.：T100119402 External Photo

Compliance Certification Services Inc. Report No.：T100119402 Internal Photo Compliance Certification Services Inc. Report No.：T100119402

Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 1 of 75 FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4 : 2003 TEST REPORT For BonSayON S102 Bone Conduction Bluetooth Sunglasses Model : S102 Trade Name : BonSayOn Issued for NeoVictory Technology Co., Ltd. 2F, No.562, Dongning Rd., East Dist., Tainan City 70165, Taiwan (R.O.C.) Issued By Compliance Certification Services Inc. Tainan Laboratory No. 8, Jiu Cheng Ling, Jiaokeng Village, Sinhua Township, Tainan Hsien 712, Taiwan R.O.C. TEL: 886-6-580-2201 FAX: 886-6-580-2202 Issued Date: February 24, 2010 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 2 of 75 REVISION HISTORY Rev. Issue Date Revisions Effect Page Revised By 00 February 24, 2010 Initial Issue ALL Selena.Chong Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 3 of 75 TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ........................................................................................ 4 2. EUT DESCRIPTION................................................................................................................. 5 2.1 DESCRIPTION OF EUT & POWER................................................................................... 5 3. DESCRIPTION OF TEST MODES ........................................................................................ 6 4. TEST METHODOLOGY ......................................................................................................... 7 5. FACILITIES AND ACCREDITATIONS ............................................................................... 8 5.1 FACILITIES ......................................................................................................................... 8 5.2 EQUIPMENT ....................................................................................................................... 8 5.3 LABORATORY ACCREDITATIONS LISTINGS ............................................................. 8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS............................................................ 9 6. SETUP OF EQUIPMENT UNDER TEST .............................................................................. 10 7. APPLICABLE LIMITS AND TEST RESULTS .................................................................... 11 7.1 20dB BANDWIDTH FOR HOPPING ................................................................................. 11 7.2 MAXIMUM PEAK OUTPUT POWER............................................................................... 17 7.3 HOPPING CHANNEL SEPARATION ............................................................................... 23 7.4 NUMBER OF HOPPING FREQUENCY USED................................................................. 26 7.5 DWELL TIME ON EACH CHANNEL ............................................................................... 29 7.6 CONDUCTED SPURIOUS EMISSION.............................................................................. 35 7.7 RADIATED EMISSIONS .................................................................................................... 42 7.7.1 TRANSMITTER RADIATED SUPURIOUS EMSSIONS ........................................... 42 7.7.2 WORST-CASE RADIATED EMISSION BELOW 1 GHz ........................................... 46 7.7.3 TRANSMITTER RADIATED EMISSION ABOVE 1 GHz ......................................... 48 7.7.4 RESTRICTED BAND EDGES ...................................................................................... 60 7.8 POWERLINE CONDUCTED EMISSIONS........................................................................ 68 8. APPENDIX SETUP PHOTOS ................................................................................................. 72 Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 4 of 75 1. TEST REPORT CERTIFICATION Product: BonSayON S102 Bone Conduction Bluetooth Sunglasses Model: S102 Brand Name: BonSayOn Applicant: NeoVictory Technology Co., Ltd. 2F, No.562, Dongning Rd., East Dist., Tainan City 70165, Taiwan (R.O.C.) Manufacturer: NeoVictory Technology Co., Ltd. 2F, No.562, Dongning Rd., East Dist., Tainan City 70165, Taiwan (R.O.C.) Tested: December 11, 2009 ~ February 24, 2010 APPLICABLE STANDARD STANDARD TEST RESULT FCC Part 15 Subpart C AND ANSI C63.4 : 2003 PASS Approved by: Reviewed by: Jeter Wu Section Manager Eric Yang Senior Engineer Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 5 of 75 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product BonSayON S102 Bone Conduction Bluetooth Sunglasses Model Number S102 Brand Name BonSayOn Frequency Range 2402 ~ 2480 MHz Power Source 5Vdc (From Adapter) Transmit Peak Power -0.69dBm Transmit Data Rate GFSK (1Mbps), π/4-DQPSK(2Mbps), 8-DPSK(3Mbps) Modulation Technique Frequency Hopping Spread Spectrum Number of Channels 79 Channels Channels Low : 2402 MHz Channels Mid : 2441 MHz Channels High : 2480 MHz Channel Spacing 1 MHz Antenna Specification Gain : 1.3 dBi Antenna Designation Chip Antenna Temperature Range -10 ~ +50°C Remark: 1. Client consigns only one model sample to test (Model Number: S102). Therefore, the testing Lab. just guarantees the unit, which has been tested. 2. For more details, please refer to the User’s manual of the EUT. Power Adapter : No. Manufacturer Model No. Power Input Power Output 1 NeoVictory FRA05-S05-1 100-240V, 50/60Hz, 0.3A5V, 1A Compliance Certification Services Inc. FCC ID ：X5HS102 Report …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 62 of 65 8. APPENDIX SETUP PHOTOS RADIATED MEASUREMENT SETUP Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 63 of 65 RADIATED RF MEASUREMENT SETUP Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 64 of 65 ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP Compliance Certification Services Inc. FCC ID ：X5HS102 Report No.：T100119402-RP1 Page 65 of 65 POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP END OF REPORT
