X82-BLST-SP765Electronic Ballast for Fluorescent Lamp

Electronic Ballast For Electrodeless Fluorescent Lamp 1．Product code. 50W SP765-Y01A AJA-LINEAGE-WJY-QB7C 2．Outside characteristic. The outside picture of Electronic Ballast For Electrodeless Fluorescent Lamp as below, there are three wires at input port, L line is Brown，N line is Blue, GND line is yellow and green. There are two white wires at output port. The input wires connect to the power grid, and the output wires connect to the Electrodeless Fluorescent Lamp. Outside picture Size： Size picture 3．Electrical characteristic. 1) Input Voltage 100V-277V 2）Input Rating Current 0.6/0.5/0.25/0.23A @100/120V/230V/277V--electrodeless lamp 50W 3）Output Rating Current 0.5A (load, electrodeless lamp 50W) 4）Output Rating Voltage 105V (load, electrodeless lamp 50W) 5）Start Trigger Voltage 1450±100Vop (load, electrodeless lamp 50W) 6）Output Frequency 230K±30kHz (load, electrodeless lamp 50W) 7）Not load, removing lamp and load short protection 4．Ambient temperature. Generally the ballast is set up in the lamps and lanterns to use, the ambient temperature of ballast is -40--60°C in lamps and lanterns. 5. This device has been evaluated to comply with the requirements of FCC Part 18, UL935, CAN/CSA C22.2 No.74-96, IEC61347-1, IEC61347-2-3, EN55015, EN61547, EN61000-3-2, EN61000-3-3, GB19510.1-2004, GB19510.4-2005, GB17743-2007, GB17625.1-2003 and ROHS. Warning: This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45–30 MHz.

August 11, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Agent Authorization Letter for FCC ID: X82-BLST-SP765 To Whom it May Concern: Please be advise that Lineage Power (Shanghai) Co., Ltd., authorizes Mr. Gu Weikang of TÜV Rheinland (Shanghai) Co., Ltd. to act on our behalf on all matters relating to applications for equipment authorization before the Federal Communications Commission, including signing of documents related to these matters. Lineage Power (Shanghai) Co., Ltd., certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is valid until further written notice from Lineage Power (Shanghai) Co., Ltd. Sincerely, Lineage Power (Shanghai) Co., Ltd. 1-2F, Building #58, No. 461 Hongcao Road, Caohejing Hi-Tech Park Shanghai 200233, P.R. China

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: X82-BLST-SP765 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams Block Diagrams.pdf Schematics Schematics.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Sincerely, Huang Donghai

Photo Documentation Report Number: 15038995 001 Model: SP765-Y01A AJA-LINEAGE-WJY-QB7C - Page 1 of 3 -

Photo Documentation Report Number: 15038995 001 Model: SP765-Y01A AJA-LINEAGE-WJY-QB7C - Page 2 of 4 - Photo Documentation Report Number: 15038995 001 Model: SP765-Y01A AJA-LINEAGE-WJY-QB7C - Page 3 of 4 - Photo Documentation Report Number: 15038995 001 Model: SP765-Y01A AJA-LINEAGE-WJY-QB7C - Page 4 of 4 -

Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 2 von 22 Page 2 of 22 TEST SUMMARY 4.1.1 CONDUCTED EMISSION ON AC POWER PORT Result: Passed 4.1.2 RADIATED EMISSION UP TO 30MHZ Result: Passed 4.2.1 RADIATED EMISSION ABOVE 30MHZ Result: Passed Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 3 von 22 Page 3 of 22 Contents 1 TEST SITES ...................................................................................................................................................... 4 1.1 TEST FACILITIES......................................................................................................................................... 4 1.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS...................................................................................... 4 2 GENERAL PRODUCT INFORMATION ...................................................................................................... 5 2.1 PRODUCT FUNCTION AND INTENDED USE................................................................................................... 5 2.2 RATINGS AND SYSTEM DETAILS................................................................................................................. 5 2.3 INDEPENDENT OPERATION MODES............................................................................................................. 5 2.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS................................................................................ 5 2.5 SUBMITTED DOCUMENTS............................................................................................................................ 5 3 TEST SET-UP AND OPERATION MODES ................................................................................................. 6 3.1 PRINCIPLE OF CONFIGURATION SELECTION................................................................................................ 6 3.2 PHYSICAL CONFIGURATION FOR TESTING.................................................................................................. 6 3.3 TEST OPERATION AND TEST SOFTWARE..................................................................................................... 6 3.4 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT................................................................................. 6 3.5 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE................................................................................ 6 4 TEST RESULTS E M I S S I O N ................................................................................................................. 7 4.1 EMISSION IN THE FREQUENCY RANGE UP TO 30 MHZ................................................................................ 7 4.1.1 Conducted Emission on AC power port ................................................................................................ 7 4.1.2 Radiated Emission up to 30MHz ......................................................................................................... 12 4.2 EMISSION IN THE FREQUENCY RANGE ABOVE 30 MHZ............................................................................. 15 4.2.1 Radiated Emission above 30MHz........................................................................................................ 15 5 PHOTOGRAPHS OF THE TEST SET-UP .................................................................................................. 20 6 LIST OF TABLES...........................................................................................................................................22 7 LIST OF FIGURES......................................................................................................................................... 22 8 LIST OF PHOTOGRAPHS ........................................................................................................................... 22 Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 4 von 22 Page 4 of 22 1 Test Sites 1.1 Test Facilities Laboratory: TÜV Rheinland (Shanghai) Co., Ltd. Address: 10-15/F, Huatsing Building, No. 88, Lane 777, West Guangzhong Road, Zhabei District, Shanghai 200072, P.R. China (FCC registration No.: 657274) The used test equipment is in accordance with CISPR 16-1 series standards for measurement of radio interference. 1.2 List of Test and Measurement Instruments Table 1: List of test and measurement equipment No. Equipment Model Serial no. Cal. due date 1. 3m modified semi-anechoic chamber SAC N/A 25.04.2011 2. HF loop antenna HLA6120 22137 18.01.2011 3. Broadband antenna BTA-H 040005H 10.03.2012 4. EMI test receiver ESCI 100280 26.11.2010 5. EMI test receiver ESIB26 100227 10.06.2011 6. Artificial mains network NNB 42 04/10048 24.02.2011 7. Frequency variable power source APW-150N 930376 04.11.2010 Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 5 von 22 Page 5 of 22 2 General Product Information 2.1 Product Function and Intended Use The EUT (equipment under test) is electronic ballast for fluorescent lamp for lighting and similar use. For the further information, refer to the user’s manual. 2.2 Ratings and System Details System input voltage : AC 100-277V Frequency : 47-63Hz Rated wattage for lamp : 50W Rated current : 0.2-0.6A Protection class : I 2.3 Independent Operation Modes The basic operation modes are: “On”, “Off”. 2.4 Noise Generating and Noise Suppressing Parts Refer to circuit diagram for further information. 2.5 Submitted Documents Circuit diagram and label. Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 6 von 22 Page 6 of 22 3 Test Set-up and Operation Modes 3.1 Principle of Configuration Selection Emission: The equipment under test (EUT) was configured to measure its highest possible emission level. The test conditions were adapted accordingly in reference to the instructions for use. Refer to the related paragraph of this report. 3.2 Physical Configuration fo…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 20 von 22 Page 20 of 22 5 Photographs of the Test Set-Up Photograph 1: Set-up for conducted emission Produkte Products Prüfbericht - Nr.: Test Report No.: 15038675 001 Seite 21 von 22 Page 21 of 22 Photograph 2: Set-up for radiated emission 9kHz-30MHz 30-1000MHz
