X82-BLST-SPXXXElectronic Ballast for Fluorescent Lamp

Electronic Ballast For Electrodeless Fluorescent Lamp 1．Product code. 80W SP758-Y01A AJA-LINEAGE-WJY-QB7C 100W-120W SP759-Y01A AJA-LINEAGE-WJY-QB7C 2．Outside characteristic. The outside picture of Electronic Ballast For Electrodeless Fluorescent Lamp as below, there are three wires at input port, L line is blue，N line is gray, GND line is yellow and green. There are two white wires at output port. The input wires connect to the power grid, and the output wires connect to the Electrodeless Fluorescent Lamp. Outside picture Inside picture Size： Size picture 3．Electrical characteristic. 1) Input Voltage 100V-277V 2）Input Rating Current 0.92/0.75/0.40/0.33A @100/120V/230V/277V--electrodeless lamp 80W 1.13/0.94/0.5/0.41A @/100/120V/230V/277V--electrodeless lamp 100W 1.36/1.13/0.59/0.49A @100/120V/230V/277V--electrodeless lamp 120W 3）Output Rating Current 0.63A (load,electrodeless lamp 80W) 0.65A (load,electrodeless lamp 100W) 0.68A (load,electrodeless lamp 120W) 4）Output Rating Voltage 134V (load,electrodeless lamp 80W) 180V (load,electrodeless lamp 100W) 185V (load,electrodeless lamp 120W) 5）Start Trigger Voltage 1500±100Vop (load,electrodeless lamp 80W) 1650±100Vop (load,electrodeless lamp 100W) 1690±100Vop (load,electrodeless lamp 120W) 6）Output Frequency 230K±30kHz(load,electrodeless lamp 80W) 230K±30kHz(load,electrodeless lamp 100W) 230K±30kHz(load,electrodeless lamp 120W) 7）Not load, removing lamp and load short protection 4．Ambient temperature. Generally the ballast is set up in the lamps and lanterns to use, the ambient temperature of ballast is -40--60°C in inin in lamps and lanterns. 5. Those devices have been evaluated to comply with the requirements of FCC Part 18, UL935, CAN/CSA C22.2 No.74-96, IEC61347-1, IEC61347-2-3, EN55015, EN61547, EN61000-3-2, EN61000-3-3, GB19510.1-2004, GB19510.4-2005, GB17743-2007, GB17625.1-2003 and ROHS. Warning: This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45–30 MHz.

Photo Documentation Report Number: 15035540 001 Model: SP758-Y01A AJA-LINEAGE-WJY-QB7C SP759-Y01A AJA-LINEAGE-WJY-QB7C - Page 1 of 5 - Photo Documentation Report Number: 15035540 001 Model: SP758-Y01A AJA-LINEAGE-WJY-QB7C SP759-Y01A AJA-LINEAGE-WJY-QB7C - Page 2 of 5 -

Photo Documentation Report Number: 15035540 001 Model: SP758-Y01A AJA-LINEAGE-WJY-QB7C SP759-Y01A AJA-LINEAGE-WJY-QB7C - Page 3 of 5 - Photo Documentation Report Number: 15035540 001 Model: SP758-Y01A AJA-LINEAGE-WJY-QB7C SP759-Y01A AJA-LINEAGE-WJY-QB7C - Page 4 of 5 - Photo Documentation Report Number: 15035540 001 Model: SP758-Y01A AJA-LINEAGE-WJY-QB7C SP759-Y01A AJA-LINEAGE-WJY-QB7C - Page 5 of 5 -

Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 2 von 32 Page 2 of 32 TEST SUMMARY 4.1.1 CONDUCTED EMISSION ON AC POWER PORT Result: Passed 4.1.2 RADIATED EMISSION UP TO 30MHZ Result: Passed 4.2.1 RADIATED EMISSION ABOVE 30MHZ Result: Passed Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 3 von 32 Page 3 of 32 Contents 1 TEST SITES ...................................................................................................................................................... 4 1.1 TEST FACILITIES......................................................................................................................................... 4 1.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS...................................................................................... 4 2 GENERAL PRODUCT INFORMATION ...................................................................................................... 5 2.1 PRODUCT FUNCTION AND INTENDED USE................................................................................................... 5 2.2 RATINGS AND SYSTEM DETAILS................................................................................................................. 5 2.3 INDEPENDENT OPERATION MODES............................................................................................................. 5 2.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS................................................................................ 5 2.5 SUBMITTED DOCUMENTS............................................................................................................................ 5 3 TEST SET-UP AND OPERATION MODES ................................................................................................. 6 3.1 PRINCIPLE OF CONFIGURATION SELECTION................................................................................................ 6 3.2 PHYSICAL CONFIGURATION FOR TESTING.................................................................................................. 6 3.3 TEST OPERATION AND TEST SOFTWARE..................................................................................................... 6 3.4 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT................................................................................. 6 3.5 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE................................................................................ 6 4 TEST RESULTS E M I S S I O N ................................................................................................................. 7 4.1 EMISSION IN THE FREQUENCY RANGE UP TO 30 MHZ................................................................................ 7 4.1.1 Conducted Emission on AC power port ................................................................................................ 7 4.1.2 Radiated Emission up to 30MHz ......................................................................................................... 16 4.2 EMISSION IN THE FREQUENCY RANGE ABOVE 30 MHZ............................................................................. 21 4.2.1 Radiated Emission above 30MHz........................................................................................................ 21 5 PHOTOGRAPHS OF THE TEST SET-UP .................................................................................................. 30 6 LIST OF TABLES...........................................................................................................................................32 7 LIST OF FIGURES......................................................................................................................................... 32 8 LIST OF PHOTOGRAPHS ........................................................................................................................... 32 Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 4 von 32 Page 4 of 32 1 Test Sites 1.1 Test Facilities Laboratory: TÜV Rheinland (Shanghai) Co., Ltd. Address: 10-15/F, Huatsing Building, No. 88, Lane 777, West Guangzhong Road, Zhabei District, Shanghai 200072, P.R. China (FCC registration No.: 657274) The used test equipment is in accordance with CISPR 16-1 series standards for measurement of radio interference. 1.2 List of Test and Measurement Instruments Table 1: List of test and measurement equipment No. Equipment Model Serial no. Cal. due date 1. 3m modified semi-anechoic chamber SAC N/A 25.04.2011 2. HF loop antenna HLA6120 22137 18.01.2011 3. Broadband antenna BTA-H 040005H 20.03.2010 4. EMI test receiver ESCI 100280 26.11.2010 5. EMI test receiver ESIB26 100227 10.06.2010 6. Artificial mains network NNB 42 04/10048 25.02.2010 7. Frequency variable power source APW-150N 930376 04.11.2010 Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 5 von 32 Page 5 of 32 2 General Product Information 2.1 Product Function and Intended Use The EUT (equipment under test) is electronic ballast for fluorescent lamp for lighting and similar use. For the further information, refer to the user’s manual. 2.2 Ratings and System Details System input voltage : AC 120-277V Frequency : 50/60Hz Rated wattage for lamp : 80W (SP758) 100-120W (SP759) Rated current : 0.63 (SP758) 0.56-0.68A (SP759) Protection class : I 2.3 Independent Operation Modes The basic operation modes are: “On”, “Off”. 2.4 Noise Generating and Noise Suppressing Parts Refer to circuit diagram for further information. 2.5 Submitted Documents Circuit diagram and label. Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 6 von 32 Page 6 of 32 3 Test Set-up and Operation Modes 3.1 Principle of Configuration Selection Emission: The equipment under test (EUT) was configured to measure its highest possible emission level. The test conditions were adapted accordingly in reference to the instructions for use. Refer to the related paragra…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 30 von 32 Page 30 of 32 5 Photographs of the Test Set-Up Photograph 1: Set-up for conducted emission Produkte Products Prüfbericht - Nr.: Test Report No.: 15036843 001 Seite 31 von 32 Page 31 of 32 Photograph 2: Set-up for radiated emission 9kHz-30MHz 30-1000MHz
