X8WLR68ELoRa transceiver Module

LR68E LoRa Modules Draft Ver 0.90, Nov. 2025 1 LoRa Modules with Power Amplifier LR68E series LoRa modules use a Semtech LLCC68 sub-GHz radio transceiver. They operate in the 902 to 928 MHz frequencies. LR68E2 series operate in the 869.40 MHz to 869.65 MHz frequencies, allowing up to +27 dBm radiated transmission power by CE for maximum ranges. Fanstel provides source codes for Nordic nRF54L modules to route LoRa data to cloud servers through WiFi, PoE Ethernet, and LTE interfaces. FCC Certified, LR68E Series LR68E and LR68C are certified for FCC and ISED. CE Compliant, LR682E Series LR68E2 and LT68C2 are CE compliant. M268E20C/M2682E20C Specifications: • BM20C, a Nordic nRF54LM20A Bluetooth 6.0 module. • nRF5LM20A with ARM Cortex M33 at 128 MHz. • 2036 KB non-volatile memory, 512 KB RAM. • High-speed USB (480 Mbps), Full speed (12 Mbps), and low speed (1.5 Mbps) • A global real-time counter can run is System OFF mode. • Seven 32 bit timers with counter mode. • Six fully featured serial interfaces with EasyDMA, supporting I 2 C, SPI controller/peripheral, and UART. • One high speed capable SPIM (32 MHz) or UART with EasyDMA. • Three PWM units with EasyDMA. • Time Division Multiplexed (TDM) sound interface. • Two pulse density modulated (PDM) microphone interface, 48x, 50x, 64x, 80x, 96x, 150x, and 192x decimation ratios. • ADC Sith up to 8 programmable gain channels. 14-bit at 31.25 ksps, 12 bit at 250 ksps, and up to 10 bit at 2 maps. • Over-the-Air (OTA) firmware update • 66 GPIOs • NFC • Size: 30x42 mm for M.2 connector, B -key • Operation temperature: - 40°C to +85°C Evaluation Boards • EV-LR62X1E is a BLE-LoRa bridge without an M.2 module. Need M.2 module with the LoRa module, not included. Module Summaries Module LR68E LR68C LR682E LR682C Antenna conn. u.FL Integrated u.FL Integrated Size,mm 10.0x15.0 12.6x22.1 10.0x15.0 12.6x22.1 TX,conducted +21.63 dBm +21.63 dBm +21.82 dBm +21.82 dBm Antenna ANT088 Chip ANT022 Chip MaxTX, radiated +27.45 dBm +22.95 dBm +26.92 dBm +23.09 dBm Certifications FCC, ISED FCC, ISED CE CE EV, LR62X1E plus M268E20C M268C20C M2682E20C M2682C20C Availability M.2 Modules M.2 Module M268E20C M268E20C M2682E20C M26282C20C BLE module BM20C BM20C BM20C BM20C LoRa module LR68E LR68C LR682E LR682C Availability LR68E LoRa Modules Draft Ver 0.90, Nov. 2025 2 Table Of Contents 1. Introduction ....................................................................................................................................................... 3 2. Product Overview ............................................................................................................................................. 4 Semtech LLCC68 .............................................................................................................................................. 4 Module Descriptions ......................................................................................................................................... 5 LR68E and LR682E ...................................................................................................................................... 5 LR68C and LR682C ...................................................................................................................................... 5 Antennas Certified with LoRa Modules ......................................................................................................... 5 Module for M.2 Connector ............................................................................................................................. 7 Mechanical Drawings ........................................................................................................................................ 8 LR68E Pin Functions ...................................................................................................................................... 10 LR68E and LR682E Pin Functions .............................................................................................................. 10 M268E20C Pin Functions ............................................................................................................................... 11 3. Transmission Power Setting ........................................................................................................................... 14 Transmission Parameters for FCC and ISED Certifications ........................................................................... 14 Transmission Parameters For CE Compliant Testing ..................................................................................... 14 4. Evaluation Board EV-LR62X1E ...................................................................................................................... 15 Loading Firmware into Evaluation Board Through a Nordic DK ..................................................................... 16 Nordic Development Environment .................................................................................................................. 16 Download and set up Basic Software tools for EV-LR62X1E ...................................................................... 16 Evaluation Board EV-LR62X1E Schematics ................................................................................................... 17 M268E20C Module Schematics ...................................................................................................................... 18 Battery Power Application ............................................................................................................................... 19 5. Miscellaneous ................................................................................................................................................. 20 Soldering Temperature-Time Profile for Re-Flow Soldering ........................................................................... 20 Cautions, Design Notes, and Installation…
