X9V-CN-F-PG20-11TF-PG20-11 WIRELESS TRANSMITTER

F-PG20-11 USERS MANUAL 1. Insert 1 piece battery (12V) in remote; insert 2 pieces batteries (1.5V N # ) into vibrator, the device enter “standby” mode. 2. Press the “ON/OFF” button on remote for one time, the vibrator start to vibrate; Press the “mode switch” button on remote for the first time, vibrator are in stronger vibration; Press the ““mode switch” button for the second time, vibration are strongest; press the ““mode switch” button for the third time, vibrator enter into the vibration mode of “weak to strong”; each time when user press the ““mode switch” button, vibrator will have a vibration mode of one special frequency. This unit has seven different vibration modes. 3. Press “ON/OFF” button on remote for one time, the vibrator stop vibration. VIBRATOR CARE INSTRUCTION 1) Take care when using the Vibrator for the first time. Vibration can be intense. 2) Clean your vibrator after every use. 3) Take care when cleaning your vibrator. Remember it is an electrical item. Moisture can damage the product and also react with the batteries. Always remove the batteries before cleaning and after using your vibrator in order to keep it in optimum condition. 4) Keep your vibrator clean and dry. Store in a non-damp environment. Moisture can damage batteries and motor. 5) Always store your vibrator separately. Different materials have different chemical configurations and may react with each other. 6) Always allow your vibrator to cool down before storing in a safe place. Vibrators are electrical and motors grow warm with use. 7) Excessive usage of the vibrator will wear out the motor and may cause the motor to overheat. If you feel your vibrator is getting unduly hot, switch it off and allow it to cool down, before continuing to use. 8) Take care when using oils and lubricants so that they do not enter the battery compartment as they can react with the batteries. BATTERY CARE INSTRUCTIONS 1) Batteries must be inserted with the correct polarity. 2) Remove batteries when the product is not in use. 3) The supply terminals should not be short-circuited i.e. do not bridge terminal switch metallic pieces. 4) Only use the recommended batteries. 5) Only operate when fully assembled in accordance with the instructions. 6) Do not mix different types or new and used batteries. WA R N I N G To avoid injury and aggravation of pre-existing conditions, this device should not be used on swollen or inflamed areas or skin lacerations. Do not use on unexplained calf pain. No medical claims are warranted or implied by the use of this product. FCC INFORMATION FOR THE CONSUMER This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

TX Block Diagram IC U6:TM57PE11 CPU INTERNAL OSCILLATION 4MHz MANOSTAT DC 5V POWER DC 12V KEY LED OSCILLATION 315MHz RADIOAMPLI FIER ANT 315Mhz

J.B. Industrial (Shen Zhen) Co., Ltd. J.B. Industrial Center, Beishandao YanTian, Shenzhen P.R.China. AGENCY AUTHORIZATION LETTER FCC ID: X9V-CN-F-PG20-11T Date: February 26, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Shenzhen CTL Electromagnetic Technology Co., Ltd.(MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen CTL Electromagnetic Technology Co., Ltd. (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on December 31, 2011. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, J.B. Industrial (Shen Zhen) Co., Ltd. are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Fenny Tseng / Director

External and Internal Photos of the EUT External Photos

FCC ID Label Information 1. Label location: 2. FCC ID Label: J.B. Industrial (Shen Zhen) Co., Ltd. Model: CN-F-PG20-11T FCC ID: X9V-CN-F-PG20-11T

Internal Photos

1. TX Technical Description Technical Description Description Function Component Antenna Transmit modulation RF signal Ant Low Pass Filter Suppression of spurious emissions C16, L3 RF Power Amplifier and Modulation Modulate the carrier and amplify the modulated RF signal Q4 Constant voltage power supply Constant voltage to 5V Q6,R20,R21 Oscillator Generate 315MHz carrier T1 Encode IC Generate code signal to modulator IC Press ON/OFF once, MCU (TM57PE11) 8 pins emit 4.5 Sec signals, loading on the 315MHz high frequency oscillation circuit (composed by transistor 3356 and resonator T1) generate carrier and transmit through ANT. The IC request input power is 5V, the modulation is ASK. The antenna type is integral without external RF port.

PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

Shenzhen CTL Electromagnetic Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-89486187 FCC PART 15 SUBPART C TEST REPORT FCC PART 15C Report Reference No......................: CTL1102006-T Compiled by ( position+printed name+signature)..: File administrators Andy Zhang Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Kendy Wang Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: February 28, 2011 Testing Laboratory Name..............: Shenzhen CTL Electromagnetic Technology Co., Ltd. Address.............................................: Zone B，4/F, Block 20，Guangqian Industrial Park, Longzhu Road,Nanshan,Shenzhen 518055 China. Test Firm..........................................: Bontek Compliance Testing Laboratory Ltd Address.............................................: 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Applicant’s name............................: J.B. Industrial (Shen Zhen) Co., Ltd. Address.............................................: J.B. Industrial Center, Beishandao YanTian, Shenzhen P.R.China. Test specification: Standard ...........................................: FCC Part 15C ANSI C63.4: 2003 TRF Originator ..................................: Shenzhen CTL Electromagnetic Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Electromagnetic Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electromagnetic Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electromagnetic Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : F-PG20-11 Operation Frequency........................: 315MHz Modulation mode: ............................: ASK Trade Mark .......................................: Model/Type reference.......................: CN-F-PG20-11T Listed Models ..................................: / Power Supply..............................: DC 12V Anttenna Type..............................: Integral without external RF Port Result................................................: Positive FCC ID............................................. : X9V-CN-F-PG20-11T V1.0 Page 2 of 17 Report No.: CTL1102006-T T E S T R E P O R T Test Report No. : CTL1102006-T Februay 28, 2011 ______________________________________________________________________________________________ Date of issue Equipment under Test : F-PG20-11 Model /Type : CN-F-PG20-11T Listed Models : / Difference description: / Applicant : J.B. Industrial (Shen Zhen) Co., Ltd. Address : J.B. Industrial Center, Beishandao YanTian, Shenzhen P.R.China. Manufacturer : J.B. Industrial (Shen Zhen) Co., Ltd. Address : J.B. Industrial Center, Beishandao YanTian, Shenzhen P.R.China. Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 17 Report No.: CTL1102006-T Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. Test Result Summary 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. Radiated Emission Test 9 4.2. Occupied Bandwidth 12 5. TEST SETUP PHOTOS OF THE EUT .......................................... 15 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 16 V1.0 Page 4 of 17 Report No.: CTL1102006-T 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15 Subpart C Section 15.231 ANSI C63.4-2003 V1.0 Page 5 of 17 Report No.: CTL1102006-T 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : February 21, 2011 Testing commenced on : February 23, 2011 Testing concluded on : February 25, 2011 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz z 12 V DC o 24 V DC o Other (specified in blank below) Not applicable 2.3. Short description of the Equipment under Test (EUT) 315MHz Wireless Transmitter For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: o - supplied by the manufacturer o - supplied by the lab o Power Cable Length (m) : / Shield : / Detachable : / o Multimeter Manufacturer : / Model No. : / V1.0 Page 6 of 17 Report No.: CTL1102006-T 2.6. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: X9V-CN-F-PG20-11T filing to comply with the FCC Part 15, Subpart C Rules. 2.7. Modifications No modifications were implemented to meet testing criteria. 2.8. Test Result Summary Test Item Test RequirementStandard Paragrph Result Radiated Emission (25MHz to 4000MHz) FCC PART 15 Section 15.231(b) PASS Occupled Bandwidth FCC PART 15 Section 15.231(c…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
