XEG-MIXCAST4Podcast Recording Console

TASCAM Mixcast 4 – Bedienungsanleitung 81 DEUTSCH Bluetooth Sendeklasse2 (ca. 10 m* freie Übertragungsstrecke) Unterstütztes ProfilA2DP Unterstützte A2DP-CodecsSBC, AAC Unterstützter A2DP- Kopierschutzmechanismus SCMS-T * Die angegebene Übertragungsdistanz ist ein ungefährer Wert. Sie kann je nach Umgebungsbedingungen abweichen. Systemvoraussetzungen Computer Das Gerät wurde mit handelsüblichen Computersystemen getestet, die den unten genannten Anforderungen entsprechen. Das ist jedoch keine Garantie dafür, dass es mit jedem Computer funktioniert, der diese Anforderungen erfüllt. Aktualisierte Hinweise zur Kompatibilität mit verschiedenen Betriebssystemen finden Sie gegebenenfalls auf unserer Website (https://tascam.de/). 8 Windows Unterstützte BetriebssystemeWindows 11 Windows 10, 64 Bit Hardware-AnforderungenWindows-Computer mit einem USB-Anschluss (2.0 oder höher); Der Betrieb des Tascam-Treibers mit ARM64-CPUs ist nicht garantiert. 8 Mac Unterstützte BetriebssystememacOS Monterey (12.0) macOS Big Sur (11.0) macOS Catalina (10.15) Hardware-AnforderungenMac mit einem USB-Anschluss (2.0 oder höher) 8 Android-Geräte Unterstützte BetriebssystemeAndroid 8 oder höher; Kompatibilität mit dieser Version ist keine Garantie für korrekte Funktion mit jedem Gerät. 8 iOS/iPadOS-Geräte Unterstützte BetriebssystemeiOS 15 / iPadOS 15 iOS 14 / iPadOS 14 iOS 13 / iPadOS 13 Stromversorgung und sonstige Daten StromversorgungSpezieller Wechselstromadapter (Tascam PS-P1220E NUT), DC 12 V Leistungsaufnahme12,5 W (maximal) Gewicht2,55 kg Betriebstemperaturbereich0–40 °C Abmessungen (B × H × T)375 mm × 57 mm × 264 mm (ohne vorstehende Teile) 375 mm × 71 mm × 267 mm (über alles) 82 TASCAM Mixcast 4 – Bedienungsanleitung Maßzeichnung 266.7 263.6 374.871.2 56.5 i Abbildungen können teilweise vom tatsächlichen Erscheinungsbild des Produkts abweichen. i Änderungen an Konstruktion und technischen Daten vorbehalten. TASCAM Mixcast 4 83 ITALIANO Manuale di istruzioni Introduzione Grazie per aver acquistato TASCAM Mixcast 4. Questa interfaccia audio USB progettata per il podcasting include funzioni di sound pad integrate e consente, per esempio, di aggiungere suoni di effetti alle conversazioni con più partecipanti. Questo modello può essere utilizzato anche per la registrazione e l'editing. Prima di utilizzare questa unità, leggere attentamente questo manuale di istruzioni in modo da poterla utilizzare correttamente e divertirsi a lavorarci per molti anni. Dopo aver terminato la lettura di questo manuale, si prega di conservarlo in un luogo sicuro per future consultazioni. Questo documento (il manuale di istruzioni) spiega le funzioni principali dell'unità. Consultare il manuale di riferimento per informazioni su tutte le funzioni dell'unità. È possibile scaricare questo manuale di istruzioni e il manuale di riferimento dal sito Web TASCAM. Mixcast 4 https://tascam.jp/int/product/mixcast_4/docs Articoli inclusi Questo prodotto include i seguenti articoli. Fare attenzione quando si apre la confezione per evitare di danneggiare gli articoli. Conservare i materiali di imballaggio e la scatola per il trasporto in futuro. Contattare il negozio in cui è stata acquistata questa unità se uno qualsiasi di questi articoli manca o è stato danneggiato durante il trasporto. Mixcast 4x1 Adattatore AC dedicato (PS-P1220E DADO) o Cavo di 1,5 m di lunghezza x1 cavo USB (Da tipo C a tipo C) o Lunghezza del cavo x1 Manuale di istruzioni (questo documento) inclusa la garanziax1 Guida alla registrazione di TASCAM IDx1 Le informazioni sui prodotti in questo manuale sono fornite solo a scopo esemplificativo e non indicano alcuna garanzia contro le violazioni dei diritti di proprietà intellettuale di terzi e altri diritti ad essi correlati. TEAC Corporation non si assume alcuna responsabilità per violazioni dei diritti di proprietà intellettuale di terzi o altre responsabilità che si verificano a seguito dell'uso di questo prodotto. Le proprietà protette da copyright di terzi non possono essere utilizzate per scopi diversi dal godimento personale e simili senza l'autorizzazione dei titolari dei diritti riconosciuti dalla legge sul copyright. Utilizzare sempre questa attrezzatura in modo appropriato. TEAC Corporation non si assume alcuna responsabilità per violazioni dei diritti commesse dagli utenti di questo prodotto. Contents Introduzione ........................................................................................83 Articoli inclusi ......................................................................................83 IMPORTANTI ISTRUZIONI DI SICUREZZA ...........................................84 Nomi delle parti ...................................................................................87 Panello superiore e posteriore ..........................................................................87 Retro ............................................................................................................................88 Preparativi ............................................................................................89 Collegamento dell'equipaggiamento audio ................................................89 Collegamento dell'alimentazione elettrica ...................................................90 Accensione e spegnimento: ...............................................................................90 Panoramica del tutorial ........................................................................................90 Caricamento di card SD .......................................................................................91 Impostazione della lingua, della data e dell'ora .........................................91 Panoramica del menu touchscreen .................................................................92 Effettuare le impostazioni del microfono ......................................................93 Connessione con dispositivi Bluetooth ..................................................…

Text truncated - open the document above for the full version.

TASCAM Mixcast 4 41 FRANÇAIS Caractéristiques USB Connecteur: USB Type-C Formats: USB 2.0 High-Speed, Classe de stockage de masse/USB audio Classe 2.0 (nativement compatible USB) USB audio Fréquence d’échantillonnage: 48 kHz Résolution en bits: 24 bit Nombre d'entrées: 14 canaux (sortant de cette unité) Nombre de sorties: 2 canaux (entrant dans cette unité) Bluetooth Classe de sortie : 2 (distance de transmission sans obstacle d’environ 10 m*) Profil pris en charge : A2DP Codecs A2DP pris en charge : SBC, AAC Protection de contenu A2DP prise en charge : SCMS-T *Cette distance de transmission est une estimation. La distance de transmission peut varier en fonction de l'environnement et des ondes radio présentes. Configurations informatiques requises Consultez le site mondial TEAC pour les informations les plus récentes sur les systèmes d'exploitation pris en charge. https://teac-global.com Le fonctionnement avec chaque système d'exploitation a été confirmé sur des configurations de système standard répondant aux conditions suivantes. Le fonctionnement n'est cependant pas garanti avec tous les systèmes remplissant ces conditions. Windows Systèmes d'exploitation pris en charge Windows 11 Windows 10 64 bit Configurations informatiques requises Ordinateur sous Windows avec USB 2.0 (ou supérieur) *Le fonctionnement n'est pas garanti en cas d’utilisation du pilote TASCAM avec des processeurs ARM64. Mac Systèmes d'exploitation pris en charge macOS Monterey (12) macOS Big Sur (11) macOS Catalina (10.15) Configurations informatiques requises Mac avec USB 2.0 (ou supérieur) Appareils iOS/iPadOS iOS 15/iPadOS 15 iOS 14/iPadOS 14 iOS 13/iPadOS 13 Périphériques Android Android 12 Android 11 Android 10 *La compatibilité a été confirmée, mais cela ne garantit pas le fonctionnement avec tous les appareils. Autres Alimentation Adaptateur secteur dédié (PS-P1220E NUT), CC 12 V Consommation électrique 12,5 W (maximum) Poids 2,55 kg Plage de température de fonctionnement 0–40 °C Dimensions 374,8 x 56,5 x 263,6 mm (L x H x P, sans parties saillantes) 374,8 x 71,2 x 266,7 mm (L x H x P, avec parties saillantes) 42 TASCAM Mixcast 4 Dessins avec cotes 266.7 263.6 374.871.2 56.5 o Les illustrations de ce mode d'emploi peuvent partiellement différer du produit réel. o Caractéristiques et aspect externe sont sujets à modifications sans préavis. TASCAM Mixcast 4 43 ESPAÑOL Manual de instrucciones Introducción Felicidades y gracias por la compra de su TASCAM Mixcast 4. Este interface audio USB audio diseñados para podcasting incluye funciones de parches de sonido internos y permite, por ejemplo, añadir efectos de sonido a conversaciones con varios participantes. Este modelo también puede ser usado para grabación y edición. Antes de empezar a utilizar esta unidad, lea detenidamente este manual para saber cómo configurar y conectar esta unidad correctamente y cómo utilizar sus funciones. Una vez que lo haya leído, conserve este manual a mano para cualquier consulta en el futuro. Este documento (el Manual de instrucciones) explica las funciones principales de la unidad. Consulte el Manual de referencia para más información acerca de todas las funciones disponibles. También puede descargarse este manual de instrucciones y el de referencia desde la página web global de TASCAM. Mixcast 4 https://tascam.jp/int/product/mixcast_4/docs Elementos incluidos Dentro del embalaje encontrará los siguientes elementos. Tenga cuidado de no dañar estos objetos al abrir el embalaje. Conserve la caja y las protecciones por si alguna vez necesita transportar el aparato. Póngase en contacto con su distribuidor si echa en falta alguno de estos elementos o si observa que alguno de ellos ha resultado dañado durante el transporte. Mixcast 4× 1 Adaptador de corriente específico (PS-P1220E NUT) o Cable de 1.5 m × 1 Cable USB (tipo C a tipo C) o Cable de 1 m × 1 Manual de instrucciones (este documento) incluyendo garantía× 1 Guía de registro de ID TASCAM× 1 En este documento aparece información relativa a otros productos únicamente a modo de ejemplo y no supone ninguna garantía contra posibles infracciones de los derechos intelectuales de terceros, así como otros derechos relacionados. TEAC Corporation no asume ninguna responsabilidad por la posible infracción de estos derechos por el uso de este aparato por parte del usuario. Con la excepción del disfrute personal y usos similares, y de acuerdo a las leyes del copyright, los materiales propiedad de terceras personas protegidos por copyright no pueden ser usados sin la autorización expresa de los propietarios. Use este aparato de forma correcta. TEAC Corporation no asume ninguna responsabilidad por la posible infracción de estos derechos por el uso de este aparato por parte del usuario. Contents Introducción .........................................................................................43 Elementos incluidos ............................................................................43 INSTRUCCIONES IMPORTANTES DE SEGURIDAD ..............................44 PRECAUCIONES IMPORTANTES DE SEGURIDAD ...............................45 Precauciones de los aparatos inalámbricos ......................................46 Nombre y función de las partes ..........................................................47 Panel superior ..........................................................................................................47 Panel trasero ............................................................................................................48 Preparativos .........................................................................................49 Conexión de equipos audio ...............................................................................49 Alimentación............................................................................................................49 Encendido y apagado ...........................................................................................50 Resu…

Text truncated - open the document above for the full version.

D01382200F Podcast Recording Console OWNER’S MANUAL MODE D’EMPLOI MANUAL DEL USUARIO BEDIENUNGSANLEITUNG MANUALE DI ISTRUZIONI 取扱説明書 Please see the Reference Manual for information about all the unit’s functions. You can download the Reference Manual from the TASCAM website. Veuillez consulter le manuel de référence pour des informations sur toutes les fonctions de l’unité. Vous pouvez télécharger le manuel de référence depuis le site de TASCAM. Consulte en el Manual de referencia la información completa acerca de todas las funciones de esta unidad. Puede descargar el Manual de referencia desde la página web de TASCAM. Links zur digitalen Version dieser Anleitung und des Referenzhandbuchs finden Sie auf der deutschen Website (https://tascam.de/downloads/). Consultare il manuale di riferimento per informazioni su tutte le funzioni dell’unità. È possibile scaricare il manuale di riferimento dal sito TASCAM. 各機能の詳細については、リファレンスマニュアルをご覧ください。 リファレンスマニュアルは、TASCAMのウェブサイトからダウンロードすることができます。 Mixcast 4 https://tascam.jp/int/product/mixcast_4/docs ENGLISH FRANÇAIS ESPAÑOL DEUTSCH ITALIANO 日本語 oTASCAM is a registered trademark of TEAC Corporation. oSDXC Logo is a trademark of SD-3C, LLC. oThe Bluetooth® word mark and logo are the property of Bluetooth SIG, Inc. and are used by TEAC Corporation with permission. oMicrosoft and Windows either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. oApple, Mac, macOS, iPad, iPadOS and iTunes are trademarks of Apple Inc. in the United States and other countries. oLightning is a trademark of Apple Inc. oApp Store is a service mark of Apple Inc. oIOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. oAndroid, Google Play and Google Play logo are trademarks of Google Inc. oASIO is a trademark and software of Steinberg Media Technologies GmbH. oOther company names, product names and logos in this document are the trademarks or registered trademarks of their respective owners. 2 TASCAM Mixcast 4 TASCAM Mixcast 4 3 ENGLISH Owner's Manual Introduction Thank you very much for purchasing the TASCAM Mixcast 4. This USB audio interface designed for podcasting includes built-in sound pad functions and allows effect sounds, for example, to be added to conversations with multiple participants. This model can also be used for recording and editing. Before using this unit, read this Owner's Manual carefully so that you will be able to use it correctly and enjoy working with it for many years. After you have finished reading this manual, please keep it in a safe place for future reference. This document (the Owner's Manual) explains the main functions of the unit. Please see the Reference Manual for information about all the unit's functions. You can also download this Owner’s Manual and the Reference Manual from the TASCAM website. Mixcast 4 https://tascam.jp/int/product/mixcast_4/docs Included items This product includes the following items. Take care when opening the package to avoid damaging the items. Keep the box and packing materials for transportation in the future. Please contact the store where you purchased this unit if any of these items are missing or have been damaged during transportation. Mixcast 4× 1 Dedicated AC adapter (PS-P1220E NUT) o 1.5m cable length × 1 USB cable (Type-C to Type-C) o 1m cable length × 1 Owner's Manual (this document) including warranty× 1 TASCAM ID registration guide× 1 Information is given about products in this manual only for the purpose of example and does not indicate any guarantees against infringements of third-party intellectual property rights and other rights related to them. TEAC Corporation will bear no responsibility for infringements on third-party intellectual property rights or other liabilities that occur as a result of the use of this product. Properties copyrighted by third parties cannot be used for any purpose other than personal enjoyment and the like without the permission of the right holders recognized by copyright law. Always use this equipment properly. TEAC Corporation will bear no responsibility for rights infringements committed by users of this product. Contents Introduction ...........................................................................................3 Included items .......................................................................................3 IMPORTANT SAFETY INSTRUCTIONS ...................................................4 Wireless equipment precautions .........................................................6 Names of Parts .......................................................................................7 To p ..................................................................................................................................7 Back ................................................................................................................................8 Preparation ............................................................................................9 Connecting audio equipment ..............................................................................9 Connecting the power ............................................................................................9 Turning the power on and off............................................................................10 Tutorial overview ....................................................................................................10 Loading SD cards ....................................................................................................10 Setting the language, date and time ..............................................................11 Touchscreen overview ..........................................................................................12 Making mic settings ..............................................................................................13 Co…

Text truncated - open the document above for the full version.

ReportNo.ENS2508040302W008Page7of12Ver.1.0 ReportNo.ENS2508040302W008Page8of12Ver.1.0 ReportNo.ENS2508040302W008Page9of12Ver.1.0 ReportNo.ENS2508040302W008Page10of12Ver.1.0 ReportNo.ENS2508040302W008Page11of12Ver.1.0 ReportNo.ENS2508040302W008Page12of12Ver.1.0

ReportNo.ENS2508040302W008Page1of2Ver.1.0 FCCID:XEG-MIXCAST4 ReportNo.ENS2508040302W008Page2of2Ver.1.0

Report No.: BL-SZ2580370-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: TEAC CORPORATION Address: 1-47 Ochiai, Tama-shi, Tokyo, Japan Equipment Type: Podcast Recording Console Model Name: Mixcast 4 Brand Name: TASCAM Test Standard: IEEE Std 149-2021 Sample Arrival Date: Aug. 08, 2025 Test Date: Aug. 12, 2025 Date of Issue: Sep. 12, 2025 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Xia Long Approved by: Sunny Zou (Technical Director) _______________ _______________ _______________ Report No.: BL-SZ2580370-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Sep. 12, 2025 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................... 3 1.1 Test Laboratory .................................................................................................................... 3 1.2 Test Location ........................................................................................................................ 3 2 PRODUCT INFORMATION ......................................................................................................... 4 2.1 Applicant Information ............................................................................................................ 4 2.2 Manufacturer Information ..................................................................................................... 4 2.3 General Description for Equipment under Test (EUT) .......................................................... 4 2.4 Ancillary Equipment .............................................................................................................. 4 3 SUMMARY OF TEST RESULTS ................................................................................................. 5 3.1 Test Standards ..................................................................................................................... 5 3.2 Test Verdict .......................................................................................................................... 5 3.3 Test Uncertainty ................................................................................................................... 5 4 GENERAL TEST CONFIGURATIONS ........................................................................................ 6 4.1 Test Condition ...................................................................................................................... 6 4.2 Test Equipment List .............................................................................................................. 6 4.3 Test Setup ............................................................................................................................ 7 4.4 Test Frequencies .................................................................................................................. 7 ANNEX A TEST RESULTS ............................................................................................................ 8 A.1 Gain and Efficiency ............................................................................................................... 8 A.2 VSWR ................................................................................................................................... 9 ANNEX B RADIATION PATTERN ............................................................................................... 10 ANNEX C TEST SETUP PHOTOS .............................................................................................. 13 ANNEX D EUT PHOTO ............................................................................................................... 13 Report No.: BL-SZ2580370-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ2580370-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant TEAC CORPORATION Address 1-47 Ochiai, Tama-shi, Tokyo, Japan 2.2 Manufacturer Information Manufacturer Dongguan TEAC Electronics Co., Ltd. Address Building D 5-6 floors No.1 Shangxing Lu Shangjiao Chang-an Town, Dongguan City, Guangdong, Province, CHina 2.3 General Description for Equipment under Test (EUT) EUT Name Podcast Recording Console Model Name Under Test Mixcast 4 Antenna Type PCB Antenna Dimensions 12.5*6.5 mm 2.4 Ancillary Equipment Note: Not applicable. Report No.: BL-SZ2580370-901 Tel: +86-755-…

Text truncated - open the document above for the full version.

ReportNo.ENS2508040302W00801RPage40of73Ver.1.0 2DH5-Ant1-Hop-PASS ReportNo.ENS2508040302W00801RPage41of73Ver.1.0 3DH1-Ant1-Hop-PASS ReportNo.ENS2508040302W00801RPage42of73Ver.1.0 3DH3-Ant1-Hop-PASS ReportNo.ENS2508040302W00801RPage43of73Ver.1.0 3DH5-Ant1-Hop-PASS ReportNo.ENS2508040302W00801RPage44of73Ver.1.0 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER 9.5.1ApplicableStandard AccordingtoFCCPart15.247(b)(1)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-247.5.4andRSS-Gen6.12 9.5.2ConformanceLimit ThemaxForfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels:1watt.Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband: 0.125watts. 9.5.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.5.4TestProcedure Asanalternativetoapeakpowermeasurement,compliancewiththelimitcanbebasedonameasurementofthe maximumconductedoutputpower. Usethefollowingspectrumanalyzersettings: SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel(about8MHz) SetRBW>the20dBbandwidthoftheemissionbeingmeasured(about3MHz) SetVBW  RBW SetSweep=auto SetDetectorfunction=peak SetTrace=maxhold Allowthetracetostabilize.Usethemarker-to-peakfunctiontosetthemarkertothepeakoftheemissionto determinethepeakamplitudelevel. TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Test Mode AntennaFrequency[MHz] ConductedPeak Powert[dBm] Conducted Limit[dBm] Verdict DH5Ant124026.74≤20.97PASS DH5Ant124416.11≤20.97PASS DH5Ant124806.20≤20.97PASS 2DH5Ant124028.31≤20.97PASS 2DH5Ant124417.70≤20.97PASS 2DH5Ant124807.78≤20.97PASS 3DH5Ant124029.10≤20.97PASS 3DH5Ant124418.50≤20.97PASS 3DH5Ant124808.52≤20.97PASS ReportNo.ENS2508040302W00801RPage45of73Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS ReportNo.ENS2508040302W00801RPage46of73Ver.1.0 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS ReportNo.ENS2508040302W00801RPage47of73Ver.1.0 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS ReportNo.ENS2508040302W00801RPage48of73Ver.1.0 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS ReportNo.ENS2508040302W00801RPage49of73Ver.1.0 3DH5-Ant1-2480-PASS ReportNo.ENS2508040302W00801RPage50of73Ver.1.0 9.6CONDUCTEDSUPRIOUSEMISSION 9.6.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-2475.5 9.6.2ConformanceLimit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumintentionalradiatoris operating,theradiofrequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dBbelowthat inthe100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheran RFconducted,providedthetransmitterdemonstratescompliancewiththepeakconductedpowerlimits. 9.6.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.6.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDSSchannelcenterfrequency. SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel. SettheRBW=100kHz.SettheVBW≥3xRBW. SetDetector=peak.SetSweeptime=autocouple. SetTracemode=maxhold.Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumMaximumconducetedlevel. Notethatthechannelfoundtocontainthemaximumconducetedlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttotheband-edge, aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighestmodulation productoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethemarker-deltafunction, thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-bandemission.Themarker-delta valuenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Now,usingthesameinstrumentsettings,enablethehoppingfunctionoftheEUT.Allowthetracetostabilize. Followthesameprocedurelistedabovetodetermineifanyspuriousemissionscausedbythehoppingfunction alsocomplywiththespecifiedlimit. Emissionlevelmeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeaklevelofthein-bandemissionandallspuriousemissions(e.g.,harmonics) fromthelowestfrequencygeneratedintheEUTupthroughthe10thharmonic.(30MHzto25GHz).SetRBW= 100kHzSetVBW  RBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkeronthepeakofanyspuriousemissionrecorded.Theleveldisplayed mustcomplywiththelimitspecifiedinthisSection. ReportNo.ENS2508040302W00801RPage51of73Ver.1.0 9.6.5TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Alltheantennaandmodesmodehavebeentested,andtheworstresultrecordedwasreportasbelow: Bandedgemeasurements TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1Low24025.73-44.93≤-14.27PASS DH5Ant1High24805.27-45.52≤-14.73PASS DH5Ant1LowHop_24025.63-44.63≤-14.37PASS DH5Ant1HighHop_24805.44-44.25≤-14.56PASS ReportNo.ENS2508040302W00801RPage52of73Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS ReportNo.ENS2508040302W00801RPage53of73Ver.1.0 DH5-Ant1-Hop_2402-PASS DH5-Ant1-Hop_2480-PASS ReportNo.ENS2508040302W00801RPage54of73Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant124020~Reference5.725.72---PASS DH5Ant1240230~10005.72-57.97≤-14.28PASS DH5Ant124021000~265005.72-47.01≤-14.28PASS …

Text truncated - open the document above for the full version.
