XENTA99Keyboard

User Manual Technical Specification
USB interface
Input currency: < 200mA
Storage temperature: -40°~+60°
Ambient temperature: +25°
Humindity:20%~90% Installation and operation - Install the driver contained in the attached CD-ROM - Plug the USB-A connector into the USB port of PC and it can work momentarily. - For RFID card, set the serial port as follow: Baud Rate: 9600, Data Bit: 8, Stop Bit:1, Verify and Flow control: None. - For smart card reader, run “SC sample.exe” program and the following window will be shown. Then insert proper smart card into the card slot and we may get the information by the program accordingly Appendix Changes or Modifications not expressly approved by the party responsible could void the user’s authority to operate this device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Hereby, Heng Yu Electronic Manufacturer Co., Ltd, declares that this keyboard is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Date :05 August 15 FCC ID: XENTA99 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, Heng Yu Electronic Manufacturing Company Limited requests that the following materials be withheld from public inspection under 47CFR 0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1) detailed circuit schematic of unit under test (2) parts list (3) block diagram (4) Circuit Description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, H.K. Chan, R&D Manager 05 August 15

FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT

STC Test Report Date : 2015-09-30 Page 1 of 23 No. : HM170019 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc-group.org This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant Heng Yu Electronic Manufacturing Company Limited. Room 3-5, 15/F., Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Hong Kong. Manufacturer: Zhuhai Heng Yu New Technology Company Limited. Heng Ke Campus, Jin Hai Avenue, San Zao, Zhuhai, Guang Dong, P.R.C.: 8109040 Description of Sample(s): Product: Keyboard Brand Name: Wincor Nixdorf Model No.: TA99A-SU-0007 FCC ID: XENTA99 Date Sample(s) Received: 2015-04-02 Date Tested: 2015-04-17 to 2015-09-04 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 and ANSI C63.10: 2013 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): This report is a supplement to Test Report, number HM169764 issued on 2015-09-11. The original page(s) of the same test report is hereby superseded. _______________________________ CHEUNG Chi, Kenneth Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2015-09-30 Page 2 of 23 No. : HM170019 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc-group.org This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. CONTENT: Cover Page 1 of 23 Content Page 2 of 23 1.0 General Details 1.1 Test Laboratory Page 3 of 23 1.2 Equipment Under Test [EUT] Page 3 of 23 Description of EUT operation 1.3 Date of Order Page 3 of 23 1.4 Submitted Sample Page 3 of 23 1.5 Test Duration Page 3 of 23 1.6 Country of Origin Page 3 of 23 1.7 RF Module Details Page 4 of 23 1.8 Antenna Details Page 4 of 23 2.0 Technical Details 2.1 Investigations Requested Page 5 of 23 2.2 Test Standards and Results Summary Page 5 of 23 2.3 Table for Test Modes Page 6 of 23 3.0 Test Results 3.1 Emission Page 7 - 14 of 23 Appendix A List of Measurement Equipment Page 15 of 23 Appendix B Ancillary Equipment Page 16 of 23 Appendix C Photographs Page 17 - 23 of 23 STC Test Report Date : 2015-09-30 Page 3 of 23 No. : HM170019 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc-group.org This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Keyboard Manufacturer: Zhuhai Heng Yu New Technology Company Limited. Heng Ke Campus, Jin Hai Avenue, San Zao, Zhuhai, Guang Dong, P.R.C.: 8109040 Brand Name: Wincor Nixdorf Model Number: TA99A-SU-0007 Input Voltage: 5.0Vd.c. (powered by USB) 120Va.c. (for PC) 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is USB keyboard of Heng Yu Electronic Manufacturing Company Limited. The keyboard consists with a 125kHz contactless card interface. 1.3 Date of Order 2015-04-02 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2015-04-17 to 2015-07-21 1.6 Country of Origin China STC Test Report Date : 2015-09-30 Page 4 of 23 No. : HM170019 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc-group.org This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.7 RF Module Details Module Model Number: N/A Module FCC ID: N/A Frequency range: 119 – 135kHz Operating Frequency: 125kHz Channel Spacing: Wideband Carrier Power: 4.7 dBμA/m at 10 m ITU Designation: 10K0A1D Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: Loop antenna – Integrated Antenna Length: around 3500mm Antenna Gain: -2.5dBi STC Test Report Date : 2015-09-30 Page 5 of 23 No. : HM170019 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc-group.org This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 Re…

Text truncated - open the document above for the full version.

FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP FCC ID: XENTA99 PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF CONDUCTED EMISSION TEST SET UP
