XF6-RS9110N1124802.11 bgn Connection MODULE

Redpine Signals, Inc. Proprietary and Confidential. Connect-io-n™ RS9110-N-11-24 E E v v a a l l u u a a t t i i o o n n B B o o a a r r d d U U s s e e r r G G u u i i d d e e V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 April 2013 Redpine Signals, Inc. 2107 N. First Street, #680 San Jose, CA 95131. Tel: (408) 748-3385 Fax: (408) 705-2019 Email: [email protected] Website: www.redpinesignals.com Redpine Signals, Inc. 2107 N. First Street, #680 San Jose, CA 95131. Tel: (408) 748-3385 Fax: (408) 705-2019 Email: [email protected] Website: www.redpinesignals.com Redpine Signals, Inc. Page 2 Connect-io-n™ RS9110-N-11-24 Evaluation Board User Guide V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 Part Number Description Device Number Description TCP/IP Enabled Option for TCP/IP Bypass RS9110-N-11-24 Part with UART as Host Interface Yes No RS9110-N-11-24-02 Part with SPI as Host Interface Yes Yes RS9110-N-11-24-04 Part with UART/SPI as Host Interface Yes Yes RS9110-N-11-24-04 will replace RS9110-N-11-24 and RS9110-N-11-24-02. RS9110-N-11-24-04 is feature compatible with RS9110-N-11-24 and RS9110- N-11-24-02. Redpine Signals, Inc. Page 3 Connect-io-n™ RS9110-N-11-24 Evaluation Board User Guide V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 Table of Contents 1 Introduction ........................................................................ 6 2 Components on the EVBs ..................................................... 7 3 Using the Evaluation Board in UART mode ......................... 10 3.1 Configure Serial port in computer .........................................10 3.2 Configure Serial Port Monitor in the PC .................................14 3.3 Evaluating the Module in Infrastructure mode .......................18 3.3.1 Configuration and Test Procedure .................................................... 18 3.4 Evaluating the Modules in Ad-hoc mode ................................24 3.5 Upgrading Firmware .............................................................25 3.5.1 Firmware Upgrade Using UART Interface without wireless firmware upgrade feature ............................................................................ 25 3.5.2 Firmware Upgrade Using UART Interface with wireless firmware upgrade feature’ ........................................................................................ 30 3.5.3 Firmware Upgrade from 4.7.x to a higher version Wirelessly ............... 32 3.6 Using the Wireless Configuration Feature..............................35 3.6.1.1 Wireless Configuration in AP Mode.............................................. 35 3.6.1.2 Wireless Configuration When the Module is Connected to an AP ..... 40 3.7 General Operation of the Modules .........................................44 4 Using the Evaluation Board in SPI mode ............................ 46 4.1 TCP/IP Stack Usage in RS9110-N-11-24–SPI mode ...............47 4.1.1 Using the Wi-Fi module with TCP/IP stack enabled ............................. 47 4.1.2 Using the Wi-Fi module with TCP/IP stack bypassed ........................... 48 4.2 SPI Operations .....................................................................49 5 FCC and IC Declaration ...................................................... 53 Redpine Signals, Inc. Page 4 Connect-io-n™ RS9110-N-11-24 Evaluation Board User Guide V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 Table of Figures Figure 1: Evaluation Set-up - Infrastructure Mode ..................................... 18 Figure 2: Hyperterminal Messages ............................................................. 21 Figure 3: Messages in Laptop (C) ............................................................... 21 Figure 4: General Sequence of Commands ................................................. 23 Figure 5: Evaluation Set-up – Ad-hoc Mode ................................................ 24 Figure 6: Wireless Firmware Upgrade Set-up ............................................. 32 Figure 7: Configuration GUI ....................................................................... 33 Figure 8: Wireless Configuration Set-up ..................................................... 36 Figure 9: Configuration GUI ....................................................................... 37 Figure 10: Wireless Configuration Set-up ................................................... 40 Figure 12: Firmware Upgrade and General Operation in UART modules ..... 45 Figure 13: Connections in SPI mode ........................................................... 46 Figure 14: Architecture with TCP/IP Enabled ............................................. 48 Figure 15: Architecture with TCP/IP Bypassed .......................................... 49 Redpine Signals, Inc. Page 5 Connect-io-n™ RS9110-N-11-24 Evaluation Board User Guide V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 List of Tables Table 1: UART Header Pins ........................................................................... 8 Table 2: SPI Header Pins .............................................................................. 9 Table 3: DIP Switch Setting (6 switches) ..................................................... 9 Redpine Signals, Inc. Page 6 Connect-io-n™ RS9110-N-11-24 Evaluation Board User Guide V V e e r r s s i i o o n n 3 3 . . 1 1 3 3 1 Introduction This document describes how to use the RS9110-N-11-24 EVB. It describes the sequence of commands and set-up requirements to quickly evaluate the major functions of the modules. Chapters Using the Evaluation Board in UART mode to Evaluating the Module in Infrastructure mode describe operation using the UART interface. Using the Evaluation Board in SPI mode describes operation using the SPI interface. Upgrading Firmware describes the firmware upgrade procedure. Even if the user does not plan to use the UART interface, it is recommended to go through the UART section because all the set-ups to evaluate different functionalities of the module in UART mode are directly reusab…

Text truncated - open the document above for the full version.

2107 North First Street, Suite 680, San Jose CA 95131 Phone: 408-748-3385 Fax: 408-705-2019 Redpine Signals, Inc. Redpine Signals, Inc. Gate No. 395, Plot No. 87 & 88 Sagar Society, Banjara Hills Road No. 2 Hyderabad – 500034, India Ph: +91-40-23550722 Date: 27June2013 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: XF6-RS9110N1124 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential Treatment of information accompanying this application as outlined below: a) Block Diagram. – Long term confidential. b) Operational Description. – Long term confidential. c) Parts List or BOM. – Long term confidential. d) Schematics. – Long term confidential. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, For Redpine Signals, inc. Chandra Sekhar Abburi Vice President – Systems & Software

Applicant/Grantee Redpine Signals Inc FCC ID: XF6-RS9110N1124 IC ID: 8407A-RS9110N1124 Section 15.212 Modular Transmitters Request for Single Modular Approval Request for Limited Single Modular approval SI. No Requirements EUT Conditions Comply (Y/N) 01 The radio elements of the modular transmitter must have their own Shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements The Module has its own shielding. Please refer External Photographs Yes 02 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation All modulation and data input(s) are buffered.” The EUT has buffered data inputs, it is integrated on chip RS9110 Yes 03 The modular transmitter must have its Own power supply regulation. PMU is built into RS9110 chip. Yes 04 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and The antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited Modular approvals under paragraph (b) of this section. The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. Yes 05 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance With Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the Module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Equipment. Any accessories, peripherals, or support equipment connected to the The modular transmitter was tested in a stand-alone configuration via a SDIO interface. Yes module during testing shall be Unmodified and commercially available (see Section 15.31(i)). 06 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC Identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is Installed must also display a label referring to The enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording That expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate Instructions along with the module which explain This requirement. In the latter case, a copy of these instructions must be included in the Application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the Device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed Module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same Meaning may be used. The user manual must include instructions on how to access the Electronic display. A copy of these instructions Must be included in the application for equipment authorization. In the exhibition OEM manual, there are instructions given to the OEM on how to label the end product. Yes 07 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a . The EUT is compliant with all applicable FCC rules. Detail Yes complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such Requirements. A copy of these Instructions must be included in the application for equipment authorization. instructions for maintaining compliance are given in the OEM Manual. 08 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration Please see maximum permissible exposure information report Yes A full modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured Sincerely, A. Chandrasekhar Vice President–Systems Redpine Signals Inc.

www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 1 von 3 Page 1 of 3 EUT Top View EUT Dimensional View www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 2 von 3 Page 2 of 3 EUT Dimensional View External Antenna www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 3 von 3 Page 3 of 3 External Antenna Connector External Antenna Dimensional View

www.tuv.com Appendix 4 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 1 von 1 Page 1 of 1 Label Diagram Label Location

www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 1 von 2 Page 1 of 2 Module- Shielding Removed External Antenna Connector www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 2 von 2 Page 2 of 2 External Antenna and Cable Showing RP Connector External Antenna Cable- UFL Connector

www.tuv.com Appendix 10 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 1 von 2 Page 1 of 2 RF Exposure Report RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over- prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz www.tuv.com Appendix 10 Prüfbericht - Nr.: Test Report No. 19660011 001 Seite 2 von 2 Page 2 of 2 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Test Results 1. Chip Antenna Gain (G) = 0.5 802.11 Protocol Data Rate (Mbps) Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm²) Limit (mW/cm²) b 11 2412 110 0.0109 1.000 g 24 2442 118 0.0117 1.000 n 39 2442 124 0.0123 1.000 2. External Antenna Gain (G) = 2 802.11 Protocol Data Rate (Mbps) Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm²) Limit (mW/cm²) b 11 2412 110 0.0437 1.000 g 24 2442 118 0.0469 1.000 n 39 2442 124 0.0493 1.000

Produkte Products TÜV Rheinland LGA Products GmbH  Tillystraße 2  D - 90431 Nürnberg  Tel.: +49 911 655 5225  Fax: +49 911 655 5226 Mail: [email protected]  Web: www.tuv.com Rev.:1.2 2009-12-29 / approved: M.Jungnitsch Prüfbericht - Nr.: 19660011 001 Seite 1 von 91 Test Report No.: Page 1 of 91 Auftraggeber: Client: Redpine Signals Inc 2107 N.First Street, Suite 680, San Jose, CA 95131-2019 United States Gegenstand der Prüfung: Test item: 802.11 bgn Connection MODULE Bezeichnung: Identification: RS9110-N-11-24 Serien-Nr.: Serial No. Engineering Sample Wareneingangs-Nr.: Receipt No.: 1803006281 Eingangsdatum: Date of receipt: 28.05.2013 Prüfort: Testing location: Refer Page 4 of 91 for test facilities Prüfgrundlage: Test specification: FCC Part 15: Subpart C Section 15.247 ANSI C63.4-2003 Prüfergebnis: Test Result: Der Prüfgegenstand entspricht oben genannter Prüfgrundlage(n). The test items passed the test specification(s). Prüflaboratorium: Testing Laboratory: TÜV Rheinland (India) Pvt. Ltd. 82/A, 3rd Main, West Wing, Electronic City Phase 1 Hosur Road, Bangalore – 560 100. India FCC Registration No.: 176555 geprüft / tested by: kontrolliert / reviewed by: 28.06.2013 Vinay N Test Engineer 01.07.2013 Raghavendra Kulkarni Manager Datum Date Name/Stellung Name/Position Unterschrift Signature Datum Date Name/Stellung Name/Position Unterschrift Signature Sonstiges /Other Aspects: FCC ID : XF6-RS9110N1124 Abkürzungen: P(ass) = entspricht Prüfgrundlage F(ail) = entspricht nicht Prüfgrundlage N/A = nicht anwendbar N/T = nicht getestet Abbreviations: P(ass) = passed F(ail) = failed N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any safety mark on this or similar products. www.tuv.com Test Report No.: 19660011 001 Date: 28.06.2013 Page 2 of 91 Test Result Summary Clause Test Item Result FCC 15.247(b) (3) Maximum Peak Conducted Output Power Pass FCC 15.247(a) (2) 6dB Bandwidth Pass FCC 15.247(e) Maximum Power Spectral Density Pass FCC 15.247(d) Band-edge compliance Pass FCC 15.209 / FCC 15.205 Spurious Radiated Emissions and Restricted Bands of Operation Pass www.tuv.com Test Report No.: 19660011 001 Date: 28.06.2013 Page 3 of 91 Content List of Test and Measurement Instruments .............................................................. 4 General Product Information ..................................................................................... 5 Product Function and Intended Use .......................................................................................................... 5 Ratings and System Details ........................................................................................................................ 5 Operation Descriptions .............................................................................................. 6 Test Set-up and Operation Mode ............................................................................... 7 Principle of Configuration Selection ......................................................................................................... 7 Test Operation and Test Software ............................................................................................................. 7 Test Modes – Data Rates and Modulations .............................................................................................. 7 Test Methodology ....................................................................................................... 8 Radiated Emission Test .............................................................................................................................. 8 Test Results ................................................................................................................. 9 Maximum Peak Conducted Output Power Section 15.247(b) (3) ............................. 9 Maximum Power Spectral Density Section 15.247(e) ................................. 23 6 dB Bandwidth Section 15.247(a) (2) ............................ 37 Band-edge Compliance Section 15.247(d) ................................ 63 Spurious Radiated Emissions and........................................................................................................... 81 Restricted Bands of Operation Section 15.209 and 15.205 .................. 81 Appendix 1: Test Setup Photo Appendix 2: EUT External Photo Appendix 3: EUT Internal Photo Appendix 4: FCC Label and Label Location Appendix 5: Block Diagram Appendix 6: Specification of EUT Appendix 7: Schematic Diagrams Appendix 8: Bill of Material Appendix 9: User Manual Appendix 10: Maximum Permissible Exposure Calculation www.tuv.com Test Report No.: 19660011 001 Date: 28.06.2013 Page 4 of 91 List of Test and Measurement Instruments TUV Rheinland (India) Pvt. Ltd. , Bangalore Equipment Manufacturer Model S/N Calibration Due Date EMI Test Receiver Rohde &Schwarz ESU 40 100288 04.10.2013 Hybrid Log Periodic antenna ETS Lindgren 3142D 00081354 26.07.2013 Broadband Horn Antenna Frankonia HAX-18 HAX18-802 23.03.2014 Double-Ridged Waveguide Horn Antenna ETS Lindgren 116794 00133356 01.09.2013 Emission Horn Antenna ETS Lindgren 116706 00107323 24.08.2013 Active Loop Antenna Frankonia LAX-10 LAX-10-800 11.04.2014 Spectrum Analyser Agilent Technologies E4407B US41192772 21.03.2014 Testing Facilities: 1) TUV Rheinland (India) Private Limited No. 108, West Wing Electronic city Phase I Bangalore – 560100 www.tuv.com Test Report No.: 19660011 001 Date: 28.06.2013 Page 5 of 91 General Product Information Product Function and Intended Use The RS9110-N-11-24 module is a IEEE 802.11bgn based WLAN device…
