XIA-4GM3W3G/4G Dual Band AC Wifi Router

3G/4G Dual Band AC WiFi Router 4GM3W-01 USER GUIDE 2 NetComm Wireless 4GM3W User Guidewww.netcommwireless.com Copyright Copyright©2014 NetComm Wireless Limited. All rights reserved. The information contained herein is proprietary to NetComm Wireless Limited. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without prior written consent of NetComm Wireless Limited. Note: This document is subject to change without notice. Save Our Environment When this equipment has reached the end of its useful life, it must be taken to a recycling centre and processed separately from domestic waste. The cardboard box, the plastic contained in the packaging, and the parts that make up this device can be recycled in accordance with regionally established regulations. Never dispose of this electronic equipment along with your household waste. You may be subject to penalties or sanctions under the law. Instead, ask for disposal instructions from your municipal government. Please be responsible and protect our environment. This manual covers the following products: NetComm Wireless 4GM3W 3G/4G Dual Band AC WiFi Router DOCUMENT VERSION DATE 1.0 - Initial document release November2013 1.1 – Updated Safety and product care section June 2014 www.netcommwireless.comNetComm Wireless 4GM3W User Guide 3 Table of Contents Overview .............................................................................................................................................5 Introduction ....................................................................................................................................................................................................... 5 Target Audience................................................................................................................................................................................................ 5 Prerequisites ..................................................................................................................................................................................................... 5 Notation............................................................................................................................................................................................................. 5 Product Introduction ...............................................................................................................................6 Product Overview.............................................................................................................................................................................................. 6 Package Contents............................................................................................................................................................................................. 6 Product Features .............................................................................................................................................................................................. 6 Physical Dimensions and Indicators ..............................................................................................................7 LED Indicators .................................................................................................................................................................................................. 7 Physical Dimensions ......................................................................................................................................................................................... 8 4GM3W Default Settings .................................................................................................................................................................................. 8 Interfaces ............................................................................................................................................9 Safety and Product Care ......................................................................................................................... 10 Transport and Handling .......................................................................................................................... 10 Installation and Configuration of the 4GM3W ................................................................................................ 11 Placement of your 4GM3W ............................................................................................................................................................................. 11 Avoid obstacles and interference .................................................................................................................................................................... 11 Cordless Phones............................................................................................................................................................................................. 11 Choose the “Quietest” Channel for your Wireless Network ............................................................................................................................ 11 Hardware installation ...................................................................................................................................................................................... 12 Connecting via Ethernet cable ........................................................................................................................................................................ 12 Connecting wirelessly ..................................................................................................................................................................................... 12 Web Based Configuration Interface ...........................................…

Text truncated - open the document above for the full version.

www.netcommwireless.comNetComm Wireless 4GM3W User Guide 21 Mobile Broadband The Mobile Broadband tab in Basic view allows you to configure the country, service provider and network name (APN) options of your mobile broadband connection. If your SIM is PIN locked, you can also use this page to unlock it with the PIN. You should contact your mobile broadband carrier for the correct APN and PIN if you do not know them. When you have made changes to the settings on this tab, remember to click the Save and apply the changes button to store the new settings on the router. 22 NetComm Wireless 4GM3W User Guidewww.netcommwireless.com Advanced configuration To access the advanced configuration pages, you must first log in to the router and change to the Advanced view. Click on the Switch to advanced view link at the bottom of the basic view screen. www.netcommwireless.comNetComm Wireless 4GM3W User Guide 23 24 NetComm Wireless 4GM3W User Guidewww.netcommwireless.com ITEM DESCRIPTION IPv4 System Status IP Address The current WAN IP address of the router Subnet Mask The current subnet mask in use by the router Gateway The gateway in use by the router to access the internet Domain Name Server The Domain name server converts Connection Time The time the current connection to the internet has been active IPv6 System Status WAN Link-Local Address The current WAN IPv6 address Global IPv6 Address The current IPv6 subnet mask in use LAN IPv6 Link-Local Address The current LAN IPv6 address of the 4GM3W Link Status The current IPv6 WAN connection status Wireless Modem Information Card Info The name of the 3G USB modem connected to the 4GM3W Link Status The current status of your connection to a 3G Broadband service Signal Strength The current available 3G signal strength Network Name The name of the 3G network you are connecting to Wireless 2.4GHz Status Wireless 2.4GHz mode The current status of the 2.4GHzwireless network (enabled or disabled) SSID The current 2.4GHzwireless network name is use by the router Channel The current 2.4GHzwireless channel in use on your wireless network Security The currently selected 2.4GHz wireless security in use on your wireless network Wireless 5GHz Status Wireless 5GHz mode The current status of the 5GHz wireless network (enabled or disabled) SSID The current 5GHz wireless network name is use by the router Channel The current 5GHz wireless channel in use on your wireless network Security The currently selected 5GHz wireless security in use on your wireless network Statistics Information Octets The number of data packets which have passed into and out of the router Unicast Packets The number of unicast packets which have passed into and out of the router Multicast packets The number of multicast packets which have passed into and out of the router. Network Setup Network Setup This page allows you to configure the WAN (Wide Area Network) connection. You can select from the following types of WAN connection: Mobile Broadband WiFi Hotspot Note: If you are using an Ethernet WAN connection, please ensure the “4G/WAN” switch is set to “WAN”. www.netcommwireless.comNetComm Wireless 4GM3W User Guide 25 Mobile Broadband OPTION DEFINITION WAN Type Select from Mobile Broadband or Wi-Fi Hotspot Country Select your country from the list. This will shorten the APN list to those in your selected country. Select Your Service Provider Select your 3G/4G service provider from the list. This will then enable you toselect the correct APN for the 3G/4G service in use. APN Enter the APN for your 3G/4G service. This should be automatically filled in after selecting your country and 3G provider name. If the wrong APN is shown, enter the correct APN for your 3G/4G service PIN Code Enter the Pin Code for your SIM card (if required). Dial Number This number is required to connect to your 3G service. (Unless advised otherwise by NetComm Technical Support, this setting should not be changed) Username The username provided by your 3G/4G service provider to enable access to your 3G/4G service. Password The password provided by your 3G/4G service provider to enable access to your 3G/4G service. Authentication Type Choose the appropriate authentication type for your 3G/4G service. Primary DNS Manually assign a Primary DNS Server. Secondary DNS Manually assign a Secondary DNS Server. Connection Control There are 3 modes to select from: ƒ Connect-on-demand: The 4GM3W will connect to the internet when a client sends outgoing packets. ƒ Auto Reconnect (Always-on): The 4GM3W will automatically reconnect to the internet until the connection is manually disconnected. ƒ Manually: The 4GM3W will not connect to the internet until someone clicks the connect button on 26 NetComm Wireless 4GM3W User Guidewww.netcommwireless.com the Status-page. Keep Alive There are three keep alive options to select from: ƒ Disable: Disable the keep alive function. ƒ LCP Echo Request: The 4GM3W will automatically verify the connection is active. Set the interval and Max. number of failures to determine when the connection is up or down. ƒ Ping Remote Host: The 4GM3W will ping the chosen host IP to verify the connection is active. Set the host IP address and the interval between ping tests. Multicast Allows you to select the method of multicast or disable it. IGMP Snooping Allows you to enable or disable IGMP Snooping. IGMP Snooping configures the router to listen to IGMP conversations between hosts and routers and maintain a map of the links that need IP multicast streams. VLAN TAG VLAN tagging is primarily used in virtual networks which span over multiple switches. VLAN tagging involves the router inserting a VLAN ID into a packet header in order to identify which CLAN the packet belongs to. You may enable VLAN tagging and specify the ID with a value between 1 and 4094. WiFi Hotspot This WAN type turns the router into a repeater. The 4GM3W connects to a wireless access point and wireless clients connect to the 4GM3Wfor internet access…

Text truncated - open the document above for the full version.

Company Name: NetComm Wireless Limited Address: Level 2, 18-20 Orion Road, Lane Cove, NSW 2066 City: Sydney Country: Australia To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: XIA-4GM3W Reference number: Dear FCC TCB, Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Date: May 31, 2014 Name and signature of applicant: Casey Mak

Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A1 / 11 External Photo (4GM3W-01) Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A2 / 11 Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A3 / 11

Diagram Label location FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Marked in the Manual

Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A4 / 11 Internal Photo (4GM3W-01) Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A5 / 11 Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A6 / 11 Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A7 / 11 2.4G_1.5dBi 5G_2dBi Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A8 / 11 2.4G_1.5dBi Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A9 / 11 Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A10 / 11 Compliance Certification Services Inc. Report No.T140528N02 Date of IssueJune 12, 2014 Page A11 / 11

Compliance Certification Services Inc. Report No.: T140528N02-MF Date of Issue: June 12, 2014 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT 3G/4G Dual Band AC WiFi Router Model 4GM3W-01 Brand NetComm Wireless RF Module MediaTek Model: 2.4G: MT7620A 5G: MT7610EN Frequency band (Operating) 802.11b/g/n HT20: 2.412GHz ~ 2.462GHz 802.11n HT40: 2.422GHz ~ 2.452GHz 802.11a, 802.11n HT20 : 5180MHz ~ 5240MHz; 5745 ~ 5825MHz 802.11n HT40 : 5190MHz ~ 5230MHz; 5755 ~ 5795MHz 802.11ac VHT80 : 5210MHz; 5755MHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification Antenna Gain 2.4GHz 1.5 dBi (Numeric gain: 1.41) Antenna Gain 5GHz 2.0 dBi (Numeric gain: 1.58) Maximum Average output power IEEE 802.11b Mode : 19.07 dBm (80.724 mW) IEEE 802.11g Mode : 21.80 dBm (151.356 mW) IEEE 802.11n HT20 Mode : 22.54 dBm (179.473 mW) IEEE 802.11n HT40 Mode : 22.19 dBm (165.577 mW) IEEE 802.11a Mode : 17.09 dBm (51.168 mW) IEEE 802.11n HT20 Mode: 17.05 dBm (50.699 mW) IEEE 802.11n HT40 Mode: 13.48 dBm (22.284 mW) IEEE 802.11AC HT80 Mode: 12.62 dBm (18.281 mW) Evaluation applied MPE Evaluation* SAR Evaluation N/A Compliance Certification Services Inc. Report No.: T140528N02-MF Date of Issue: June 12, 2014 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 June Initial Issue ALL Sunny Chang Compliance Certification Services Inc. Report No.: T140528N02-MF Date of Issue: June 12, 2014 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d GP E   30 & 377 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   22 0796.0 100/377 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: GPS000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T140528N02-MF Date of Issue: June 12, 2014 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. IEEE 802.11b mode: IEEE 802.11b Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 6 2437 80.724 1.41 20 0.0227 1 Pass IEEE 802.11g Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 6 2437 151.356 1.41 20 0.0425 1 Pass IEEE 802.11n HT 20 Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 1 2452 179.473 2.83 20 0.1009 1 Pass IEEE 802.11n HT 40 Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 9 2452 165.577 2.83 20 0.0931 1 Pass IEEE 802.11a Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 149 5745 51.168 1.58 20 0.0161 1 Pass IEEE 802.11n HT20 Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 149 5745 50.699 1.58 20 0.0160 1 Pass IEEE 802.11n HT40 Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 151 5755 22.284 1.58 20 0.0070 1 Pass IEEE 802.11AC HT80 Mode: Ch. Frq.(MHz) P (mW)Gain (num.) D (cm)Power density in mW / cm 2 Limit (mW/cm2) Result 155 5775 18.281 1.58 20 0.0058 1 Pass

G G a a i i n n F F o o r r c c e e T T e e c c h h n n o o l l o o g g y y C C o o . . , , L L t t d d 嘉光科技股份有限公司 R&D / PE / QC /PURCHASE / VENDOR 版次.: A 版 承認書 A A P P P P R R O O V V A A L L S S H H E E E E T T 品 名： Antenna MODEL NAME AT3216 料 號： AT3216-B5R5HAAT/LF PART NUMBER 11320Y11161A1 客戶名稱： 永 洋 CUSTOMER 供 應 商： GainForce VENDOR 使用機種： MODEL 聯 絡 人： 尹 廣 汶 聯絡電話： （02）2880-1838 附 件： ACCESSORIES ■規格書 ■樣品 SPECIFICATION SAMPLE ■圖樣 ■檢驗報告 DRAWING TEST REPORT 認可狀況： （APPROVED STATUS） 1. 零件基本資料--------------------------------------------------------------------P3 2. 圖面(mechanical drawing) ------------------------------------------------------P4 3. 規格(specification)---------------------------------------------------------------P3~P10 4. 性能檢測報告(Performance Test Report) 甲. 可靠度測試報告(Rellabibility test)--------------------------------------P7 乙. 各項性能測試報告(performance report)--------------------------------P7 5. 包裝方式(Packing information)------------------------------------------------P9 6. ROHS 檢測報告(ROHS Test Report)-----------------------------------------P24~P30 7. 物質成份分析表------------------------------------------------------------------P16 8. 物質成份元素表------------------------------------------------------------------P15 9. 永洋ROHS值管制標-----------------------------------------------------------.P17 10. 永洋有害物質調查表------------------------------------------------------------P13~P14 11. 製程溫度資訊(ThermalProfile),-------------------------------------------------P8 12. 54階承認書Check List----------------------------------------------------------P20 13. Product Hazardous Substance Report.........................................................P11~P12 ACX Advanced Ceramic X AT3216 Series Multilayer Chip Antenna Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™5~6GHz wireless communication system Specifications Part Number Frequency Range (MHz) Peak Gain (XZ-V) Average Gain (XZ-V) VSWR Impedance AT3216 -B5R5HAA_ 5150~5875 2.0 dBi typ. -2.5 dBi typ. 2 max. 50 Ω Q’ty/Reel (pcs) : 3,000 pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 500mW max. Part Number AT 3216 - B 5R5 HAA ‡ ‡ ghfe dc i c Type AT : Antenna d Dimensions ( L × W ) 3.2× 1.6 mm e Material Code B f Frequency Range 5R5=5500MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Unit : mm a W T L Mark L W T a Dimensions 3.20.2 1.60.2 1.3+ 0.1/-0.2 0.50.3 (a) Without Matching Circuits 2.6 * 4.2 1.6 1.9 0.4 0 0 (b) With Matching Circuits 2.6 * 4.2 1.6 1.9 0.4 0 0 2.2nH *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) ™Test Board 33.5mm 6.5mm 19mm Matching Circuit Antenna No Ground Ground 50Ω Feed Line 39.5mm 6.5mm ™Return Loss (a) Without Matching Circuits (b) With Matching Circuits ACX Advanced Ceramic X Radiation Patterns 180 o 270 o 0 o 90 o X Z Y XY-cut scanning direction 180 270 o 0 o 90 o X Z Y XZ-cut scanning direction 180 270 0 o 90 o X Z Y YZ-cut scanning direction XY-V/XY-H XZ-V/XZ-H YZ-V/YZ-H YZ cut @5.5GHz Vertical Horizontal XY cut @5.5GHz Vertical Horizontal XZ cut @5.5GHz Vertical Horizontal Advanced Ceramic X Corp. 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan TEL:886-3-5987008 FAX:886-3-5987001 E-mail: [email protected] http://www.acxc.com.tw ACX Adv anced Ceram ic X Item Requirements Procedure Solderability 1. No apparent damage 2. More than 75% of the terminal electrode shall be covered with new solder 1. Preheat: 120± 5 o C 2. Solder: 230± 5 o C for 5± 1 sec Thermal shock (Temperature Cycle) 1. No apparent damage 2. Fulfill the electrical specification after test 1. One cycle/ step 1: 85 ± 5 o C for 20sec step 2: -40 ± 3 o C for 20sec 2. Cycle time: 30min 3. No. of cycles: 100 4. Recovery: 1-2hrs Heat Resistance 1. No apparent damage 2. Fulfill the electrical specification after test 1. Temperature: 85± 2 o C 2. Duration: 24±2hrs 3. Recovery: 1-2hrs Low Temperature Resistance 1. No apparent damage 2. Fulfill the electrical specification after test 1. Temperature: -40 o ± 5 o C 2. Duration: 24 ±2hrs 3. Recovery: 1-2hrs Humidity Resistance 1. No apparent damage 2. Fulfill the electrical specification after test 1. Temperature: 85± 2 o C 2. Humidity: 80% ~ 85% RH 3. Duration: 1000±48hrs 4. Recovery: 1-2hrs Soldering strength (Push strength) 1. 9.8N minimum 1. Solder specimen onto test jig. 2. Apply push force at 0.5mm/s until electrode pads are peeled off or ceramic are broken. Pushing force is applied to longitude direction Deflection (Bending) 1. No apparent damage 2. Fulfill the electrical specification 1. Solder specimen onto test jig (FR4, 0.8mm) using the recommend soldering profile. 2. Apply a bending force of 2mm deflection ` Drop Shock 1. No apparent damage 1. Dropped onto hard wood from height of 50 cm for 3 times ; each x,y and z direction except terminal direction Mechanical & Environmental Characteristics R230 Pressure Rod 90mm ACX Adv anced Ceram ic X Typical Soldering Profile ™Typical Soldering Profile for Lead-free Process Flow Soldering : Reflow Soldering : T e m p erature ( o C) 20s. 230 o C 180 o C 260C 5s, max. Time (s.) 60s, min. Pre-heating 30s. 230 o C 180 o C 250 o C 10s, max. Time (s.) 60s, min. Pre-heating T e m p erature ( o C) The sample must be pre-heated before soldering .The temperature difference between preheating and soldering must be within 150 . Notes ™The contents of this data sheet are subject to change without notice. Please confirm the specifications and delivery conditions when placing your order. ACX Advanced Ceramic X Taping Specifications ™Tape Dimensions (Unit: mm) φ1.55 +0.05 A’ t D 7.5 ± 0.1 1.75 ± 0.1 C T A B 16± 0.2 A A’ B C D t T 4.…

Text truncated - open the document above for the full version.

Reference No.T130909N91-RP1-1 FCC IDXIA-4GM3W Report No.T140528N02-RP1-1 Page 1 / 149 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART E: 2012 AND ANSI C63.4:2009 TEST REPORT For 3G/4G Dual Band AC WiFi Router Model: 4GM3W-01 Brand Name : NetComm Wireless Issued for NetComm Wireless Limited Level 2, 18-20 Orion Road, Lane Cove, NSW 2066, Sydney, Australia Issued by Compliance Certification Services Inc. Tainan Lab. No.8,Jiucengling, Xinhua Dist., Tainan City 712, Taiwan (R.O.C.) TEL: 886-6-580-2201 FAX: 886-6-580-2202 Issued Date: June 12, 2014 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. Reference No.T130909N91-RP1-1 FCC IDXIA-4GM3W Report No.T140528N02-RP1-1 Page 2 / 149 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 June 12, 2014 Initial Issue ALL Sunny Chang 01 June 27, 2014 Update data Page 5; 32 Sunny Chang Reference No.T130909N91-RP1-1 FCC IDXIA-4GM3W Report No.T140528N02-RP1-1 Page 3 / 149 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 7 4. TEST METHODOLOGY ............................................................................................... 9 5. FACILITIES AND ACCREDITATION ........................................................................... 10 5.1 FACILITIES............................................................................................................ 10 5.2 ACCREDITATIONS................................................................................................ 10 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 10 6. SETUP OF EQUIPMENT UNDER TEST...................................................................... 11 7. FCC PART 15.407 REQUIREMENTS.......................................................................... 15 7.1 26dB BANDWIDTH ................................................................................................ 15 7.2 MAXIMUM CONDUCTED OUTPUT POWER ........................................................ 27 7.3 PEAK POWER SPECTRAL DENSITY ................................................................... 42 7.4 PEAK EXCURSION ............................................................................................... 54 7.5 DUTY CYCLE......................................................................................................... 66 7.6 CONDUCTED SPURIOUS EMISSION .................................................................. 76 7.7 RADIATED EMISSION........................................................................................... 87 7.8 CONDUCTED EMISSION ...................................................................................... 130 7.9 FREQUENCY STABILITY...................................................................................... 135 APPENDIX II SETUP PHOTOS ....................................................................................... 145 Reference No.T130909N91-RP1-1 FCC IDXIA-4GM3W Report No.T140528N02-RP1-1 Page 4 / 149 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant NetComm Wireless Limited Address Level 2, 18-20 Orion Road, Lane Cove, NSW 2066, Sydney, Australia Manufacturer NetComm Wireless Limited Address Level 2, 18-20 Orion Road, Lane Cove, NSW 2066, Sydney, Australia Equipment Under Test 3G/4G Dual Band AC WiFi Router Model 4GM3W-01 Trade Name NetComm Wireless Tested Date May 29, 2014 ~ June 06, 2014 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart E: 2012 AND ANSI C63.4: 2009 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system,…

Text truncated - open the document above for the full version.
