XIA-NWL11CDMA M2M IP Router

CDMA M2M Router NWL-11 USER GUIDE Copyright Copyright© 2013 NetComm Wireless Limited. All rights reserved. The information contained herein is proprietary to NetComm Wireless. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without prior written consent of NetComm Wireless. Note: This document is subject to change without notice. Save our environment When this equipment has reached the end of its useful life, it must be taken to a recycling centre and processed separately from domestic waste. The cardboard box, the plastic contained in the packaging, and the parts that make up this device can be recycled in accordance with regionally established regulations. Never dispose of this electronic equipment along with your household waste. You may be subject to penalties or sanctions under the law. Instead, ask for disposal instructions from your municipal government. Please be responsible and protect our environment. This manual covers the following products: NetComm Wireless NWL-11 CDMA M2M Router DOCUMENT VERSION DATE Initial document release Table 1 - Document Revision History 2 NetComm Wireless CDMA M2M Router www.netcommwireless.com Table of contents Table of contents .................................................................................................................................3 Overview ...........................................................................................................................................4 Introduction ................................................................................................................................................................................................... 4 Target audience ............................................................................................................................................................................................ 4 Prerequisites ................................................................................................................................................................................................ 4 Notation ........................................................................................................................................................................................................ 4 Product introduction .............................................................................................................................5 Product overview .......................................................................................................................................................................................... 5 Package contents ......................................................................................................................................................................................... 5 Product features ........................................................................................................................................................................................... 6 Physical dimensions and indicators ............................................................................................................7 Physical dimensions ..................................................................................................................................................................................... 7 LED indicators .............................................................................................................................................................................................. 8 Interfaces.................................................................................................................................................................................................... 10 Placement of the router ....................................................................................................................... 11 Mounting options ........................................................................................................................................................................................ 11 Installation and configuration of the CDMA M2M router ................................................................................... 18 Powering the router .................................................................................................................................................................................... 16 Power consumption .................................................................................................................................................................................... 17 Installing the router ..................................................................................................................................................................................... 18 Advanced configuration........................................................................................................................ 20 Status ............................................................................................................................................ 20 Internet .......................................................................................................................................... 22 Data connection .......................................................................................................................................................................................... 22 Dial on Demand .......................................................................................................................................................................................... 27 LAN ..............................................................................................................................................…

Text truncated - open the document above for the full version.

Date: May 10, 2013 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement To whom it may concern, We, NetComm Wireless Limited, hereby authorized Intertek Testing Services to act as our agent for the purpose of preparing application for FCC ID XIA-NWL11 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is May 2013. The limited agency agreement expires end of 2013 unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Contact Person: Casey Mak, Production Manager Company: NetComm Wireless Limited E-mail: [email protected]

Date: May 10, 2013 Federal Communications Commission Application Examiner Request for Permanent Confidentiality Applicant: NetComm Wireless Limited FCC ID: XIA-NWL11 To whom it may concern, Request is hereby submitted by NetComm Wireless Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:
Schematics
Block Diagram
Parts List
Operation/Functional Description
Tune Up Procedure NetComm Wireless Limited have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Sincerely, ________________________ Casey Mak Production Manager, NetComm Wireless Limited [email protected]

Date: May 10, 2013 Federal Communications Commission Application Examiner Request for Short-term Confidentiality Applicant: NetComm Wireless Limited FCC ID: XIA-NWL11 To whom it may concern, Request is hereby submitted by NetComm Wireless Limited to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization: • Test setup photos • External photos • Internal photos • User manual NetComm Wireless Limited has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. Sincerely, ________________________ Casey Mak Production Manager, NetComm Wireless Limited [email protected]

731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com MPE Calculation § 1.1310: The criteria listed in table 1 shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093 of this chapter. Part 1.1310 Limits for Maximum Permissible Exposure (MPE) 1.1 Test Procedure An MPE evaluation for was performed in order to show that the device was compliant with §2.1091. The maximum power density was calculated for each transmitter at a separation distance of 20cm. For each transmitter the maximum RF exposure at a 20 cm distance using the formula: 10/ )( 10 dBmowerConductedP mW PowerConducted = 2 )20(4 . cm mW GainAntPowerConducted tyPowerDensi × × = π 731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com 1.2 Results: The device contains a cellular transmitter which does transmit simultaneously with any other radios in the device. The following calculations show that the total power density from transmitter in each band at 20cm is less than the limit for general population / un-controlled exposure. The MPE calculations are less than the applicable limit. CDMA Cell Band Transmitter – External Antenna: Frequency 824 MHz Limit 0.5493 mW/cm^2 Distance 20 cm Conducted Power 24.5 dBm 281.83829 mW TX Ant Gain 9.40 dBi EIRP 33.90 dBm 2454.7089 mW ERP = EIRP - 2.15 31.75 dBm 1496.2357 mW Power Density 0.1984 mW/cm^2 at 20cm CDMA PCS Band Transmitter – External Antenna: Frequency1880MHz Limit1.0000mW/cm^2 Di sta n ce20cm Conducted Power24.5dBm 281.83829mW TX Ant Gain8.4 dBi EIRP32.9dBm1949.8446mW Power Density0.3879mW/cm^2 at 20cm CDMA Cell Band Transmitter – Internal Antenna: Frequency 836.52 MHz Limit 0.5577 mW/cm^2 Distance 20 cm Conducted Power 24.5 dBm 281.83829 mW TX Ant Gain 6.28 dBi EIRP 30.78 dBm 1196.7405 mW ERP = EIRP - 2.15 28.63 dBm 729.45751 mW Power Density 0.2382 mW/cm^2 at 20cm 731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com CDMA PCS Band Transmitter – Internal Antenna: Frequency 1851.25 MHz Limit 1.0000 mW/cm^2 Distance 20 cm Conducted Power 24.5 dBm 281.83829 mW TX Ant Gain 6.00 dBi EIRP 30.50 dBm 1122.0185 mW Power Density 0.2233 mW/cm^2 at 20cm

731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com TEST REPORT Report Number: 101159665LEX-001 Project Number: G101159665 Report Issue Date: 6/3/13 Product Name: CDMA M2M IP Router FCCID: XIA-NWL11 Standards: FCC Part 22 Subpart H FCC Part 24 Subpart E Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Drive Lexington, KY 40510 NetComm 18-20 Orion Road Lane Cove N.S.W. , Australia 2066 Report prepared by Report reviewed by Toby Carrier, Technician Jason Centers, Senior Project Engineer This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report for NetComm on the CDMA M2M IP Router Page 1 of 34 Intertek Report Number: 101159665LEX-001 Issued: 6/3/13 TABLE OF CONTENTS 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Description of Equipment Under Test ............................................................................................... 4 4 Conducted Output Power.................................................................................................................... 6 5 Occupied Bandwidth ........................................................................................................................... 9 6 Conducted Spurious Emissions at Antenna Terminals ................................................................. 12 7 Radiated Output Power ..................................................................................................................... 24 8 Radiated Spurious Emissions (Transmitter) ................................................................................... 26 9 Frequency Stability ............................................................................................................................ 31 10 Measurement Uncertainty.............................................................................................................. 33 11 Revision History ............................................................................................................................. 34 EMC Report for NetComm on the CDMA M2M IP Router FCCID:XIA-NWL11; ICID: Page 2 of 34 Intertek Report Number: 101159665LEX-001 Issued: 6/3/13 1 Introduction and Conclusion The tests indicated in section 2 were performed on the product constructed as described in section 3. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test method, a list of the actual test equipment used, documentation photos, results and raw data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complied with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. The INTERTEK-Lexington is located at 731 Enterprise Drive, Lexington Kentucky, 40510. The radiated emission test site is a 10-meter semi-anechoic chamber. The chamber meets the characteristics of CISPR 16-1 and ANSI C63.4. For measurements, a remotely controlled flush-mount metal-top turntable is used to rotate the EUT a full 360 degrees. A remote controlled non-conductive antenna mast is used to scan the antenna height from one to four meters. The test site is listed with the FCC under registration number 485103. The test site is listed with Industry Canada under site number IC 2042M-1. 2 Test Summary Page Test full name FCC Reference Result 6 Conducted Output Power §2.1046 §24.232(d) Pass 9 Occupied Bandwidth §2.1049, §22.917(b)(d), and §24.238(a) Pass 12 Conducted Spurious Emissions §2.1049, §2.1051, §22.917(a)(b), and § 24.238(a)(b) Pass 24 Radiated Output Power § 22.913(a) and § 24.232(c) Pass 26 Radiated Spurious Emissions (Transmitter) §2.1053, §22.917(a)(b), and §24.238(a)(b) Pass 31 Frequency Stability §2.1055, §22.355, and §24.235 Pass EMC Report for NetComm on the CDMA M2M IP Router FCCID:XIA-NWL11; ICID: Page 3 of 34 Intertek Report Number: 101159665LEX-001 Issued: 6/3/13 3 Description of Equipment Under Test Equipment Under Test Manufacturer NetComm Model Number NWL-11 Serial Number Not Labeled FCC Identifier XIA-NWL11 Receive Date 5/3/13 Test Start Date 5/3/13 Test End Date 5/15/13 Device Received Condition Good Test Sample Type Production Frequency Band 824MHz - 849MHz (CDMA Cell Band) 1850MHz – 1910MHz (CDMA PCS Band) Modulation Type CDMA Transmission Control Base Station Simulator Maximum Output Power (Conducted) (Cell Band) – 24.02 dBm (PCS Band) – 23.52 dBmc Test Channels 1013, 384, and 777 (CDMA Cell Band) 25, 600, and 1075 (CDMA PCS Band) Antenna Type Internal & External Operating Voltage 120VAC Description of Equipment Under Test The NWL-11 is M2M IP Router. Operating modes of the EUT: No. Descriptions of EUT E…

Text truncated - open the document above for the full version.
