XIA3GT1WNNetComm 3G Travel Router tl

NetComm Liberty SerieS 3G Travel Router 1. Gently insert the supplied battery into the battery compartment on the back of the 3G router. 2. Connect the supplied power adapter to a wall power outlet and to the micro USb port of the 3G router to charge the battery. the battery is fully charged when the Power LeD lights up Solid Green. 3. Switch the 3G router on and wait around 2 minutes to allow the device to power up. 1 Hardware installation NetComm Liberty SerieS 3G Travel Router Hardware installation you can use the 3G router to create a Wireless Local Area Network (WLAN) to provide internet access to wireless-enabled devices. Using the 3G Router with a 3G Mobile Broadband Internet Service • Connect a compatible 3G USB Modem to the 3G USB port of the 3G router. • The 3G Router will automatically attempt to detect the connection details from the Sim card of your 3G USb modem. Simply wait for 2 minutes to allow the 3G router to apply the settings. 2 Connecting your device • If the 3G APN 1 connection details were successfully detected, you will now be able to access the Internet. Note: Please refer to the ‘Setting up your 3G Router’ section in the user guide (on the CD) if you have any problems connecting to the Internet, or if: • Your SIM card requires a PIN code • Your 3G broadband Internet service provider requires you to input the username/password for your 3G connection • You wish to use other alternate 3G connection details (such as a special APN 1 ) 1 APN stands for Access Point Name Connecting your device 1. Using your wireless-enabled device, scan the wireless networks in your area and select the network called NetComm Wireless, then click connect. 2. enter the following default security key: a1b2c3d4e5 Note: For optimal wireless security, we recommend that you change the default settings through the web interface. For more details, please consult the User Guide located on the supplied on the CD. WiFi PDA Laptop USB Modem 3G Tower Wi-Fi phone 3 establishing Wireless Connection ADSL Modem WiFi PDA Laptop Wi-Fi phone Using the 3G Router with a fixed line Broadband Internet Service (DSL/Cable) • Connect your DSL or cable modem with the supplied Ethernet cable to the WAN/LAN port of your 3G router. • On your computer open a web-browser (such as Internet Explorer, Firefox, or Safari) and type in 192.168.20.1 into the address bar. • At the login screen type admin into both the username and password fields. then click submit. • Move your mouse over Internet Settings and click on WAN. • Select your WAN connection type from the drop box. 4 establishing a WAN connection • Enter the relevant information in this screen as supplied by your ISP • Click on Apply to save the settings • Wait 2 minutes for the 3G router to apply the settings • The Internet connection status can be determined by clicking on status from the menu after logging in to the 3G router. establishing a WAN connection 5 establishing a LAN connection you can establish a LAN connection to your 3G router using the WAN/LAN port by following these three basic steps. 1. With the device turned on, simply press the reset button on the side of the 3G Router quickly for less than 2 seconds and release. 2. With the supplied Ethernet cable, connect your computer to WAN/LAN port of the 3G router. 3. Wait for 2 minutes to allow the 3G Router’s DHCP server to assign an IP address. establishing a LAN connection Charging your battery if you use the 3G router until the battery has completely drained, it will power off. if this occurs, let the unit charge overnight. Note: The battery must be fully charged before using your 3G Router for the first time. to charge your battery please complete the following steps: 1. With the battery inserted into your 3G router connect the supplied power adapter to the wall power outlet and to the micro USB socket on the 3G router. 2. Leave it to charge until the power LED lights up solid Green. 6 Charging your battery 7 NetComm Velocity Series Accessories for your product NP910n Wireless N 150, this product is perfect for users wishing to extend their network with the convenience of a miniature USb Adapter NP900n Wireless N 150, this product is perfect for home users NP901n Wireless N 300, perfect for data intensive applications within a SoHo environment. the included USb dock gives you the ability to move the USb Adapter so you always receive the best possible wireless signal NP902n Wireless N 300, perfect for SoHo, business users and gamers. the NP902n features a cable to allow you to position the adapter, a removable hook to neatly attach to the rear of your monitor and 2 detachable external antennas ensuring you receive the best possible wireless signal at all times. * Maximum wireless signal rate and coverage values are derived from IEEE Standard 802.11g and 802.11n Draft 2.0 specifications. Actual wireless speed and coverage are dependent on network and environmental conditions included but not limited to volume of network traffic, building materials and construction/layout. NP900n NP901n NP902n NP910n Charging your battery

永洋 Test Data 2009/12/2 Te s t M e m b e r B e n s o n 一、 Return Loss & VSWR 測試線焊接示意圖 Antenna 二、 Radiation Pattern Measurement XY YZ XZ 0° Right Up Up 90° Back Back Right 180° Left Down Down 270° Front Front Left Left Right Down Up Back Front Z X Y DUT待測物 Gain Horn Antenna X-Z Plane (E-total) Y-Z Plane (E-total) X-Y Plane (E-total) 三、Te s t Va l u e 1‐1 Return Loss (dB) 2.40 GHz ‐16.024 2.45 GHz ‐11.741 2.50 GHz ‐15.325 1‐2 Peak Gain Gain (dBi) Efficiency (%) 2.40GHz 0.12 38.26 2.45GHz 0.31 36.50 2.50GHz -1.12 24.42

NetComm Limited 2-6 Orion Rd. Lane Cove, NSW,Australia 1 Date: 2009-11-30 Attestation FCC ID: XIA3GT1WN Product: NetComm 3G Travel Router t1 Model: 3GT1Wn Statement: We, the undersigned, hereby certify that only 11 channels from 2412-2462MHz will be used in USA, other channels will be disabled by software. Sincerely yours, _______________________________ Casey Mak/ Production Manager NetComm Limited DDI: +64 9 913 1708 Fax : +64 9 448 5549 Email: [email protected]

NetComm Limited 2-6 Orion Rd. Lane Cove, NSW,Australia 1 Date: 2009-11-30 Confidentiality Request FCC ID: XIA3GT1WN Product: NetComm 3G Travel Router t1 Model: 3GT1Wn Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: • Schematics • Block Diagram • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ___________________________ Casey Mak/ Production Manager NetComm Limited DDI: +64 9 913 1708 Fax : +64 9 448 5549 Email: [email protected]

NetComm Limited 2-6 Orion Rd. Lane Cove, NSW,Australia 1 Date: 2009-11-30 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern I, the undersigned, hereby authorize Mr. Alex Chiu / Director of Compliance Certification Services Inc. and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Alex Chiu / Director of Compliance Certification Services Inc. on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; NetComm Limited 2-6 Orion Rd. Lane Cove, NSW,Australia 2 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely yours, _______________________________ Casey Mak/ Production Manager NetComm Limited DDI: +64 9 913 1708 Fax : +64 9 448 5549 Email: [email protected]

Compliance Certification Services Inc. Report No.：91116401 Page 1 External Photo (MODEL: 3GT1Wn) Compliance Certification Services Inc. Report No.：91116401 Page 2 Compliance Certification Services Inc. Report No.：91116401 Page 3 Compliance Certification Services Inc. Report No.：91116401 Page 4

3GT1Wn Diagram Label Location FCC ID: XV3AVK01 FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Compliance Certification Services Inc. Report No.：91116401 Page 5 Internal Photo Compliance Certification Services Inc. Report No.：91116401 Page 6 Compliance Certification Services Inc. Report No.：91116401 Page 7

!!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!2! FCC 47 CFR PART 15 SUBPART C: 2008 AND ANSI C63.4: 2003 TEST REPORT For NetComm 3G Travel Router tl Model Number: 3GT1Wn Brand Name: NetComm Issued for NetComm Limited A.B.N. 85 002 490 486 2-6 Orion Road , Lane Cove, NSW 2066 Sydney Australia Issued by Compliance Certification Services Inc. Tainan Lab. No. 8, Jiu Cheng Ling, Jiaokeng Village,Sinhua Township, Tainan Hsien 712, Taiwan R.O.C. TEL: 886-6-580-2201 FAX: 886-6-580-2202 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document Total Page: 110 !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!3! REVISION HISTORY Rev. Issue Date Revisions Effect Page Revised By 00 December 4, 2009 Initial Issue ALL Leah Peng !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!4! ! TABLE OF CONTENTS 1. TEST REPORT CERTIFICATION ........................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................... 5 2.1 DESCRIPTION OF EUT & POWER ......................................................................................................5 3. DESCRIPTION OF TEST MODES............................................................................................ 6 4. TEST METHODOLOGY.............................................................................................................7 5. FACILITIES AND ACCREDITATIONS................................................................................... 7 5.1 FACILITIES.............................................................................................................................................7 5.2 EQUIPMENT ...........................................................................................................................................7 5.3 LABORATORY ACCREDITATIONS LISTINGS.................................................................................7 5.4 TABLE OF ACCREDITATIONS AND LISTINGS ...............................................................................8 6. CALIBRATION AND UNCERTAINTY .................................................................................... 9 6.1 MEASURING INSTRUMENT CALIBRATION....................................................................................9 6.2 MEASUREMENT UNCERTAINTY ......................................................................................................9 7. SETUP OF EQUIPMENT UNDER TEST ................................................................................. 10 7.1 SETUP CONFIGURATION OF EUT .....................................................................................................10 7.2 SUPPORT EQUIPMENT ........................................................................................................................10 7.3 EUT OPERATING CONDITION............................................................................................................11 8. APPLICABLE LIMITS AND TEST RESULTS........................................................................ 12 8.1 6DB BANDWIDTH .................................................................................................................................12 8.2 MAXIMUM PEAK OUTPUT POWER ..................................................................................................23 8.3 MAXIMUM PERMISSIBLE EXPOSURE .............................................................................................34 8.4 POWER SPECTRAL DENSITY .............................................................................................................36 8.5 CONDUCTED SPURIOUS EMISSION .................................................................................................46 8.6 RADIATED EMISSIONS........................................................................................................................57 8.7 POWERLINE CONDUCTED EMISSIONS ...........................................................................................103 9. ANTENNA REQUIREMENT...................................................................................................... 107 9.1 STANDARD APPLICABLE ...................................................................................................................107 9.2 ANTENNA CONNECTED CONSTRUCTION ......................................................................................107 APPENDIX SETUP PHOTOS......................................................................................................... 108 !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!5! 1. TEST REPORT CERTIFICATION Applicant Κ NetComm Limited Address Κ A.B.N. 85 002 490 486 2-6 Orion Road , Lane Cove, NSW 2066 Sydney Australia Equipment Under Test Κ NetComm 3G Travel Router tl Model Number Κ 3GT1Wn Brand Name Κ NetComm Date of Test Κ November 23, 2009 ~ November 30, 2009 APPLICABLE STANDARD STANDARD TEST RESULT FCC Part 15 Subpart C : 2008 AND ANSI C63.4 : 2003 No non-compliance noted Approved by: Reviewed by: ! ! ! ! Jeter Wu Eric Yang Section Manager Senior Engineer Compliance Certification Services Inc. Compliance Certification Services Inc. !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!6! 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name NetComm 3G Travel Router tl Model Num…

Text truncated - open the document above for the full version.

!!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!219! APPENDIX SETUP PHOTOS CONDUCTED EMISSION TESTʳ˦ ̆˧˨ˣ !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!21:! RADIATED EMISSION MEASUREMENT SETUP ! ! ! ! !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!221! RADIATED RF MEASUREMENT SETUP !!Compliance Certification Services Inc.!! Report No.Κ91116401-RP1 FCC IDΚXIA3GT1WN Date of Issue: December 4, 2009 ! Qbhf!222! ! POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP ! End of report
