XJLWPS001WPS001

m WARNING PERSONAL INJURY DO NOT USE these products as safety or emergency stop devices or in any other application where failure of the product could result in personal injury. Failure to comply with these instructions could result in death or serious injury. Quick Start Guide for the WPS Series Wireless Pressure Sensor Sensing and Control Issue 1 50095585 m WARNING Honeywell does not recommend using devices for critical control applications where there is, or may be, a single point of failure or where single points of failure may result in an unsafe condition. It is up to the end-user to weigh the risks and benefits to determine if the products are appropriate for the application based on security, safety and performance. Additionally, it is up to the end-user to ensure that the control strategy results in a safe operating condition if any crucial segment of the control solution fails. Honeywell customers assume full responsibility for learning and meeting the required Declaration of Conformity, Regulations, Guidelines, etc. for each country in their distribution market. m WARNING RF EXPOSURE To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation To ensure compliance, operation at closer than this distance is not recommended. The antenna used for this transmission must not be co-located in conjunction with any other antenna or transmitter. Failure to comply with these instructions could result in death or serious injury. m WARNING The WPS must be installed in accordance with the requirements specified in this document in order to comply with the specific Country Communication Agency requirements (i.e., FCC, IC, ETSI, ACMA, etc.). See Section 3 as this requires choosing the correct Country Use Code and thus allowable antenna and/or cable usage. 2 Honeywell Sensing and Control Quick Start Guide for the WPS Series Wireless Pressure Sensor ISSUE 1 50095585 Notices and Trademarks While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied warranties of merchant- ability and fitness for a particular purpose and makes no express warranties except as may be stated in its written agreement with and for its customers. In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and specifications in this document are subject to change without notice. Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc. Other brand or product names are trademarks of their respective owners. About this Document This document describes mounting, installation and wiring of the WPS Series Wireless Pressure Sensors and antennae. Configura- tion, authentication and operation are covered in other documents. Honeywell does not recommend using devices for critical control where there is a single point of failure or where single points of fail- ure result in unsafe conditions. OneWireless is targeted at open loop control, supervisory control, and controls that do not have environ- mental or safety consequences. As with any process control solu- tion, the end-user must weigh the risks and benefits to determine if the products used are the right match for the application based on security, safety, and performance. Additionally, it is up to the end- user to ensure that the control strategy sheds to a safe operating condition if any crucial segment of the control solution fails. Revision Information Document nameDocument IDPublication Date WPS Series Wireless Pressure Sensor Quick Start Guide 50095585February 2014 New50095585, Issue 1 February 2014 References The following list identifies all documents that may be sources of reference for material discussed in this publication. Document titleDocument No. Getting Started with Honeywell OneWireless Solutions OW-CDX010 Wireless Device Manager User's GuideOW-CC0020 Field Device Access Point User’s GuideOW-CC0030 WPS-Series Professional Install Guide50095583 WPS-Series User's Manual50095584 OneWireless Wireless Builder User’s GuideOW-CDX060 OneWireless Builder Parameter ReferenceOW-CDX070 OW R210 Hardware Planning and Installation Guide OW-CC0010 OneWireless R210 Parameter Reference Dictionary OW-CC0050 OneWireless R210 Migration Users GuideOW-CC0080 OW R210 Software Change NoticeOW-CCSCN1 Honeywell Sensing and Control i Quick Start Guide for the WPS Series Wireless Pressure Sensor ISSUE 1 50095585 TABLE OF CONTENTS 1 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 1.1 to come ii Honeywell Sensing and Control Quick Start Guide for the WPS Series Wireless Pressure Sensor ISSUE 1 50095585 Honeywell Sensing and Control iii Quick Start Guide for the WPS Series Wireless Pressure Sensor ISSUE 1 50095585 List of Figures Figure 1. to come List of Tables Table 1 – to come iv Honeywell Sensing and Control Quick Start Guide for the WPS Series Wireless Pressure Sensor ISSUE 1 50095585 Symbol Definitions The following table lists those symbols used in this document to denote certain conditions. Table 1 – Table Symbol Definitions Symbol Definition , ATTENTION: Identifies information that requires special consideration. CAUTION Indicates a situation which, if not avoided, may result in equipment or work (data) on the system being damaged or lost, or may result in the inability to properly operate the process. m CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moder- ate injury. It may also be used to alert against unsafe practices. m CAUTION symbol on the equipment refers the user to the product manual for additional information. The symbol appears next to required information in the manual. m WARNING: Indicates a potentially hazardous situation, which, if…

Text truncated - open the document above for the full version.

Honeywell Page 1 of 10 External Photos WPS sensor Front Back Note: Product with label is not shown.

12345678 D C B A E F D C B A E F 12345678 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MM HONEYWELL CONFIDENTIAL THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR ANY PURPOSE, NOR USED FOR MANUFACTURING PURPOSE'S WITHOUT WRITTEN PERMISSION FROM HONEYWELL RELEASE DATE DRW: RDE: QA: CHK: MATERIAL FINISH SIZE TITLE REV DWG NO CAGE CODE TYPE SCALE SHEET REF WT: ()69.5 ()31.6 REVISION HISTORY APPROVEDDATECHG'D BYDESCRIPTIONDOCUMENTREV S. MOHAN2014-03-12SBHINITIAL RELEASE0108613A --SR--A1 PART NUMBER 50092513-001 THIRD ANGLE PROJECTION DECIMAL TOL NO PLACE ---
#0.5 1 PLACE ---
#0.3 2 PLACE ---
#0.15 3 PLACE ---
#0.05 ANGULAR TOL -
#2
$ CHAMFER -
#5
$ 2014-03-12 B. SANGANNA2014-03-12 S. MOHAN2014-03-12 G. ESZTER2014-03-12 R. SADYOJATHA2014-03-12 APPLICABLE DOCUMENTS: ASME Y14.100-2004 ASME Y14.5-2009 COMPUTER GENERATED DRAWING: PRO/ENGINEER LABEL WIRELESS PRESSURE SENSOR A3- 50092513EA1 2:1 1 of 1 NOTES: 1 - MADE FROM 014-0260-01 2 - ALL TEXT AND SYMBOLS TO BE APPROXIMATE SIZE AND LOCATION AS SHOWN 3 - MUST BE RoHS AND REACH COMPLIANT MODEL: WIRELESS PRESSURE SENSOR P/N: ____________________ S/N: ____________________ FCC ID: XJLWPS001 IC ID: 9832A-WPS001IC RANGE: _____ PSI__ IP65, IP67 MADE IN USA PATENT PENDING DATE SPACE FOR BAR CODE XXXX PRELIMINARY INFORMATION ONLY THIS DRAWING IS NOT RELEASED. SUBJECT TO CHANGE WITHOUT REVISION LEVEL. SEE HONEYWELL CONFIDENTIAL FOR PROPRIETARY INFORMATION CONCERNING THIS DRAWING.

Honeywell Page 2 of 10 Internal sub-assembly photos WPS Front cover assembly WPS LCD Frame and front cover assembly WPS LCD and Interface assembly Honeywell Page 3 of 10 Internal sub-assembly photos Back cover, Battery, Pressure port and Random assembly Battery and Body assembly Honeywell Page 4 of 10 Internal Photos Interface board Top Interface board Bottom Interface board cables Honeywell Page 5 of 10 Internal Photos LCD screen LCD Mounting Honeywell Page 6 of 10 Internal Photos Battery holder Battery Pressure port Honeywell Page 7 of 10 Internal Photos Radio Board Top Radio board Bottom Radio board cable Radio board Antenna Honeywell Page 8 of 10 Internal Photos Housing Front Cover with Gasket LCD protection shield LCD frame Honeywell Page 9 of 10 Internal Photos Housing Back Cover with Gasket Housing Body and cover

Honeywell Technology Solutions Wireless Pressure Sensor Model No.: WPS1B121AGP1A1N Date: 09/06/2014 Report Prepared By: Gulshan Kumar. B EMC Test Report Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 1 of 32 Version: 1.2 Honeywell Technology Solutions TEST SUMMARY # Name Specification Test Method Pass Fail NA Transmitter Tests 1 *Occupied Bandwidth (OBW) RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 2 Duty cycle RSS Gen Issue 3 FCC Part 15.247 DA 00-705 3 Transmitter Output Power RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 4 Transmitter Frequency Stability RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 5 +AC Power line Conducted Emissions RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 6 Transmitter Spurious Emissions RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 7 *Band Edge Measurements RSS Gen Issue 3 RSS-210, Issue 6 RSS Gen Issue 3 *Note: Occupied Bandwidth and Band Edge Measurements are not performed as these are covered in Radio Module Testing. + Since EUT is Battery powered, AC power line Conducted Emission Test is Not applicable Receiver Tests EUT is only a Transmitter. Receiver Tests are not applicable. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels has been estimated for tests performed on the EUT as specified in CISPR 16-4 The Expanded measurement uncertainty (K=2) is provided below # Name Value 1 AC Power line Conducted Emission 3.5 dB 2 Radiated Spurious Emission < 1GHz 4.9dB 3 Radiated Spurious Emission > 1GHz 6.3dB 4 Transmitter Output Power 6.3dB Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 3 of 32 Version: 1.2 Honeywell Technology Solutions 1 PRODUCT DETAILS PRODUCT OPERATION AND INTENDED USE Wireless pressure sensor used for industrial purpose, operates in ISM band with operating frequency 2.4GHz. RATINGS AND SYSTEM DETAILS Operating Frequency 2405MHz to 2475MHz Number of Channels 15 Channel Bandwidth (20dB) 3MHz Transmitted Power 15dBm Modulation Type DTS Data Rate 250kbps Antenna Type Omni directional No. of Antenna One Antenna Gain 2.0dBi peak Supply Voltage 7.2VDC (Battery operated) Dimensions L x W x H = 256 x 99 x 95 (all dimensions in mm) Environmental Conditions -40°C to +85°C Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 4 of 32 Version: 1.2 Honeywell Technology Solutions TEST CONFIGURATION Config # Description 1 Configured in continuous transmission mode with transmission power level of 15dBm OPERATING MODES Mode # Description 1 Product will be operating in Low Channel with 2405Mhz operating frequency(channel 1) 2 Product will be operating in Mid Channel with 2440Mhz operating frequency (channel 7) 3 Product will be operating in High Channel with 2475Mhz operating frequency(channel 15) INPUT AND OUTPUT CABLES Port # Name Port Type Cable Length Cable type Shielded/ Unshielded Comments Not applicable *Note : AC = AC Power Port DC = DC Power Port TP = Telecommunication Ports (E.g. Ethernet) DI / DO = Digital Input / Output N /E = Non Electrical AI / AO = Analog Input / Output SUPPORT EQUIPMENTS AND ACCESSORIES USED # Item Description Make Model Part No. / Sl. No Cal Due Date Not applicable Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 5 of 32 Version: 1.2 Honeywell Technology Solutions CONNECTION DIAGRAM AND SETUP DIAGRAM Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 6 of 32 Version: 1.2 Honeywell Technology Solutions 2 Transmitter Tests 2.1 Duty Cycle EUT Nomenclature Wireless Pressure Sensor Test Report No. EMC -0055-3 Model No. WPS1B121AGP1A1N Serial No. EMC-55-1 Test Start Date 21/04/2014 Temperature ( ̊C) 22 ̊C Test End Date 21/04/2014 Humidity RH (%) 52% Tested By Gulshan Kumar Pressure (mbar) NR Input Voltage / Freq 24 Vdc Operating Mode Refer Page 5 for Operating Mode Table Test configuration Refer Page 5 for Test Configuration Table Deviation from Std NA Applicable standard FCC Part 15.247 & RSS Gen Issue 3 Test Method DA 00-705 Comment TEST DETAILS Method Conducted Radiated TEST PARAMETERS Antenna Height 1m to 4m Turntable Rotation 0 to 360°C Equipment Class NA Measurement Distance NA TEST EQUIPMENT Y/N Equipment Make Model Sl. No. Cal Due Date Y EMI Test Receiver R&S ESU26 100525 7-Oct-14 Y 3m Semi Anechoic Chamber ETS Lindgren DKE 6X7 DBL.DR 1625 31-Dec-2015 Y Double Ridge Guide Horn Antenna ETS Lindgren 3117 00064055 14-Nov-2014 N Bilog Antenna ETS Lindgren HLP3003C 130525 16-Nov-2014 N Loop Antenna ETS Lindgren 6507 00154266 23-Sep-14 N RF cable (9KHz to 1GHz) COLEMAN RG214 RE-1A 09-May-2014 N RF cable (9KHz to 1GHz) COLEMAN RG214 RE-1B 09-May-2014 Y RF cable (1GHz to 18GHz) AH Systems SAC-18G-06 RE-2A 09-May-2014 Y RF cable (1GHz to 18GHz) AH Systems SAC-18G-06 RE-2B 09-May-2014 N Signal Conditioning unit R&S SCU-18 10178 13-June-2014 N High Pass Filter Micro tronics BRM50702-01 1 NA Y EMC32 Software R&S 8.30.0 820-OT101248 NA Note: Switch ON /OFF the Internal Preamplifier based on carrier level and or noise floor without overloading the receiver Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 7 of 32 Version: 1.2 Honeywell Technology Solutions TEST GRAPHS Channel 1 (2405MHz) Channel 7 (2440MHz) Ref 87 dBμVAtt 10 dB* A PS 3DB RBW 3 MHz VBW 10 MHz AC Center 2.405 GHz10 ms/ SWT 100 ms SGL 1 PK MAXH -10 0 10 20 30 40 50 60 70 80 1 Marker 1 [T1 ] 37.12 dBμV 43.910256 ms 2 Delta 2 [T1 ] -0.72 dB 19.871795 ms Date: 9.JUL.2014 13:44:17 Ref 87 dBμVAtt 10 dB* A PS Center 2.44 GHz10 ms/ 3DB RBW 3 MHz VBW 10 MHz SWT 100 ms AC SGL 1 PK MAXH -10 0 10 20 30 40 50 60 70 80 1 Marker 1 [T1 ] 37.44 dBμV 45.512821 ms 2 Delta 2 [T1 ] 0.30 dB 19.711538 ms Date: 9.JUL.2014 13:54:41 Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 8 of 32 Version: 1.2 Honeywell Technology Solutions TEST SETUP PHOTOGRAPHS Refer Annexure-1 Duty Cycle Channel 15 (2475MHz) TEST RESULT Channel Channel Frequency Measured Duty Cycle No. of bursts Total Duty cycl…

Text truncated - open the document above for the full version.

Test Setup Photos

Produkte Products TÜV Rheinland LGA Products GmbH  Tillystraße 2  D - 90431 Nürnberg  Tel.: +49 911 655 5225  Fax: +49 911 655 5226 Mail: [email protected]  Web: www.tuv.com Rev.:1.2 2009-12-29 / approved: M.Jungnitsch Prüfbericht - Nr.: 02422841 001 Seite 1 von 58 Test Report No.: Page 1 of 58 Auftraggeber: Client: Honeywell Inc Automation and Control Solutions Honeywell International 1985 Douglas Drive North Dock 1 Golden Valley, MN 55422 USA Gegenstand der Prüfung: Test item: Low Cost ISA100 Radio Module (51306799-001) Bezeichnung: Identification: LCRM Serien-Nr.: Serial No. Engineering Sample Wareneingangs-Nr.: Receipt No.: 1403011599 Eingangsdatum: Date of receipt: 09-09-2010 Prüfort: Testing location: Refer Page 4 of 58 for test facilities Prüfgrundlage: Test specification: FCC 15, Subpart C Prüfergebnis: Test Result: Der Prüfgegenstand entspricht oben genannter Prüfgrundlage(n). The test item passed the test specification(s). Prüflaboratorium: Testing Laboratory: TÜV Rheinland (India) Pvt. Ltd. Alpha Tower, Sigma Soft Tech Park, # 7, Whitefield Main Road, Varthur Kodi, Bangalore – 560066, India geprüft / tested by: kontrolliert / reviewed by: 12-01-2011 Vinay N Engineer 12-01-2011 Varma Kalyan Manager Datum Date Name/Stellung Name/Position Unterschrift Signature Datum Date Name/Stellung Name/Position Unterschrift Signature Sonstiges /Other Aspects: FCC ID: S5751306799 Abkürzungen: P(ass) = entspricht Prüfgrundlage F(ail) = entspricht nicht Prüfgrundlage N/A = nicht anwendbar N/T = nicht getestet Abbreviations: P(ass) = passed F(ail) = failed N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any safety mark on this or similar products. www.tuv.com Test Report No.:02422841 001 Date: 12.01.2011 Page 2 of 58 Test Result Summary Clause Test Item Result 15.247(b) (3) Conducted Peak RF Output Power Pass 15.247 (a) (2) 6dB Bandwidth Pass 15.247 (e) Power Spectral Density Pass 15.247 (d) Band-edge Compliance Pass 15.209 Spurious Radiated Emissions Pass www.tuv.com Test Report No.:02422841 001 Date: 12.01.2011 Page 3 of 58 Content List of Test and Measurement Instruments .............................................................. 4 General Product Information ..................................................................................... 5 Product Function and Intended Use ............................................................................................. 5 Ratings and System Details ........................................................................................................... 5 Operation Descriptions .............................................................................................. 6 Test Set-up and Operation Mode ............................................................................... 7 Principle of Configuration Selection ............................................................................................ 7 Test Operation and Test Software ................................................................................................ 7 Special Accessories and Auxiliary Equipment ............................................................................ 7 Countermeasures to achieve EMC Compliance .......................................................................... 7 Table of carrier frequencies........................................................................................................... 7 Antennas Used ............................................................................................................ 8 Test Methodology ....................................................................................................... 9 Radiated Emission Test ................................................................................................................. 9 Test Results ............................................................................................................... 10 Conducted Peak Output Power Section 15.247(b)(3) ......................... 10 6 dB Bandwidth Section 15.247(a)(2) ......................... 17 Power Spectral Density Section 15.247(e) ............................ 28 Band-edge Compliance Section 15.247 (d) ........................... 35 Spurious Radiated Emissions Section 15.209 ................................. 38 Conducted Emission Test on a.c. Power Line Section 15.207 .................................. 57 Appendix 1: Test Setup Photo Appendix 2: EUT External Photo Appendix 3: EUT Internal Photo Appendix 4: Label and Label Location Appendix 5: Block Diagram Appendix 6: Specification of EUT Appendix 7: Schematic Diagrams Appendix 8: Bill of Material Appendix 9: User Manual Appendix 10: Maximum Permissible Exposure Information www.tuv.com Test Report No.:02422841 001 Date: 12.01.2011 Page 4 of 58 List of Test and Measurement Instruments Wipro Technologies, Bangalore Equipment Manufacturer Type S/N Calibration Due Date EMI Test Receiver Rohde & Schwarz ESIB40 100306 24.07.2011 Hybrid Log Periodic Antenna TDK HLP3003C 130334 17.02.2011 Broadband Horn Antenna Schwarzbeck Mess- Electronik BBHA9170 9170- 344,2007 14.02.2011 Double Ridged Horn Antenna Schwarzbeck Mess- Electronik BBHA9120D 2008 14.08.2011 Pre-Amplifier TDK-RFSolution PA-02 100008 15.02.2011 Testing Facilities 1) Wipro Technologies Survey No. 70, 77, 78 / 8A, Dodda Kannelli, Sarjapur Road, Bangalore – 560 035 India www.tuv.com Test Report No.:02422841 001 Date: 12.01.2011 Page 5 of 58 General Product Information Product Function and Intended Use The Low Cost ISA100 Radio Module is a easy to use wireless platform solut…

Text truncated - open the document above for the full version.

Honeywell Technology Solutions Radiated Emission Setup –30 MHz to 1GHz [Horizontal Polarization ] Radiated Emission Setup –30 MHz to 1GHz [Vertical Polarization ] Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 30 of 32 Version: 1.2 Honeywell Technology Solutions Radiated Emission Setup –1 GHz to 18GHz [Horizontal Polarization ] Radiated Emission Setup –1 GHz to 18GHz [Vertical Polarization ] Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 31 of 32 Version: 1.2 Honeywell Technology Solutions Test Setup : Transmitter Output Power and Dwell Time Report Format No: RPT-EMC-02 Honeywell Confidential and Proprietary Page 32 of 32 Version: 1.2
