XLA48500RX49R/C Toys

Declaration The the cover of R/C Toys（Model Name: MT24） was fixed on the device, could not be easily removed. Signature： 2012-07-09

EXTERNAL PHOTOGRAPHS OF EUT View of EUT-1 View of EUT-2

INTERNAL PHOTOGRAPHS OF EUT View of EUT-1 View of EUT-2 View of EUT-3

Report No. : EESZE06140007-2 Page 2 of 22 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..........................................................................................3 2. TEST SUMMARY .........................................................................................................3 3. MEASUREMENT UNCERTAINTY ...............................................................................3 4. PRODUCT INFORMATION AND TEST SETUP ..........................................................4 4.1. PRODUCT INFORMATION........................................................................................................................ 4 4.2. TEST SETUP CONFIGURATION.............................................................................................................. 4 5. FACILITIES AND ACCREDITATIONS .........................................................................4 5.1. TEST FACILITY............................................................................................................................................ 4 5.2. TEST EQUIPMENT LIST............................................................................................................................. 4 6. SYSTEM TEST CONFIGURATION...............................................................................6 6.1. JUSTIFICATION........................................................................................................................................... 6 6.2. EUT EXERCISING SOFTWARE................................................................................................................ 6 7. CONDUCTED EMISSION TEST ..................................................................................7 7.1. LIMITS............................................................................................................................................................ 7 7.2. BLOCK DIAGRAM OF TEST SETUP....................................................................................................... 7 7.3. PROCEDURE OF CONDUCTED EMISSION TEST............................................................................... 7 7.4. GRAPHS AND DATA.................................................................................................................................. 8 8. RADIATED EMISSION TEST.....................................................................................10 8.1. LIMITS.......................................................................................................................................................... 10 8.2. BLOCK DIAGRAM OF TEST SETUP ................................................................................................... 10 8.3. PROCEDURE OF RADIATED EMISSION TEST.................................................................................. 10 8.4. GRAPHS AND DATA................................................................................................................................12 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP............................................................18 APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT ......................................................20 APPENDIX 3 INTERNAL PHOTOGRAPHS OF EUT .......................................................21 (Note: N/A means not applicable) Report No. : EESZE06140007-2 Page 3 of 22 1. GENERAL INFORMATION Applicant: The Maya Group, Inc. 19823 Hamilton Ave, Torrance, California, 90502, USA Manufacturer: The Maya Group, Inc. 19823 Hamilton Ave, Torrance, California, 90502, USA Equipment Authorization: FCC Part 15 Certification FCC ID: XLA48500RX49 Product: R/C Toys Trade mark: MaxTech Model/Type reference: MT24 Serial Number: Not Applicable Report Number: EESZE06140007-2 Date of Test: June 14, 2012 to July 04, 2012 2. TEST SUMMARY The EUT has been tested according to the following specifications: Standard Test Item Test FCC 15.107 Conducted Emission Yes FCC 15.109 Radiated Emission Yes 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Test item Value (dB) Conducted Emission 3.2 Radiated Emission 4.5 Report No. : EESZE06140007-2 Page 4 of 22 4. PRODUCT INFORMATION AND TEST SETUP 4.1. PRODUCT INFORMATION Ratings: DC 9.6V Adapter information: Model No.: HJ-UL-096250 Input: AC120V 60Hz Output: DC 9.6V 250mA Product Description: The equipment under test (EUT) is a receiver for a RC Car operating at 49.860 MHz. The EUT is powered by 9.6V DC. The EUT has a power switch. When the power switch is “ON”, the EUT can be controlled to run forward, backward, turning left and right directions by the corresponding controller. Related Submittal(s) Grants: This is a single application for certification of a receiver. The transmitter for this receiveris authorized by Certification procedure with FCC ID: XLA48500TX49. 4.2. TEST SETUP CONFIGURATION See test photographs attached in Appendix 1 for the actual connections between EUT and support equipment. Notes: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 5. FACILITIES AND ACCREDITATIONS 5.1. TEST FACILITY All test facilities used to collect the test data are located at Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4, CISPR 16-1-1 and other equivalent standards. 5.2. TEST EQUIPMENT LIST Instrumentation: The following list contains equipments used at CTI for testing. The calibrations of the measuring instruments, including any accessories that may effect such cal…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF TEST SETUP CONDUCTED EMISSION TEST SETUP (FOR CHARGING MODE) RADIATED EMISSION TEST SETUP (FOR CHARGING MODE) RADIATED EMISSION TEST SETUP (FOR RECEIVING MODE)
