XMK-MMXTRNB005800MHz Tornado Transceiver

© MiMOMax Wireless Ltd Tornado Product Manual 1 TORNADO RADIO UNIT PRODUCT MANUAL This document contains proprietary information and must not be provided or copied to third parties without express permission from MiMOMax Wireless Ltd © MiMOMax Wireless Ltd Tornado Product Manual 2 MiMOMax Wireless Ltd Issue 7 - June 2017 Product Manual for the Tornado Radio Unit Firmware version 4.3.1 Disclaimer Whilst every precaution has been taken in the preparation of this literature and it is believed to be correct at time of issue, MiMOMax Wireless Ltd assumes no liability for errors or omissions or for any damages resulting from the use of this information. Due to a policy of continuous technical improvement the contents of this document and any specifications contained therein are subject to revision and may change without notice. © MiMOMax Wireless Ltd Tornado Product Manual 3 TABLE OF CONTENTS ABBREVIATIONS AND ACRONYMS ................................................................................................................................... 5 1 TORNADO SYSTEM OVERVIEW ................................................................................................................................. 7 1.1 NETWORK DIGITAL LINKS (NDL) .......................................................................................................................................7 1.2 MULTIPOINT DIGITAL LINKS (MDL) ...................................................................................................................................8 1.3 OPTIMISED PROTECTION VARIANT (OPV) ..........................................................................................................................9 2 SAFETY WARNINGS ................................................................................................................................................ 11 2.1 MODIFICATIONS ..........................................................................................................................................................11 2.2 TRANSMITTER ANTENNA ...............................................................................................................................................11 2.3 SAFETY DISTANCE ........................................................................................................................................................11 2.4 FCC RF EXPOSURE STATEMENT .....................................................................................................................................11 2.5 ELECTRICAL SAFETY CABLE SCREENING ..............................................................................................................................11 2.6 MAINS CONNECTION ....................................................................................................................................................11 2.7 FCC 15.19 STATEMENT ...............................................................................................................................................12 2.8 FCC 15.105(B) STATEMENT .........................................................................................................................................12 3 TORNADO RADIO UNIT OVERVIEW ........................................................................................................................ 13 3.1 CONNECTORS .............................................................................................................................................................13 3.2 DIGITAL PROCESSING SYSTEM ........................................................................................................................................14 3.2.1 Power supply ..................................................................................................................................................14 3.2.2 Central Processor Unit ....................................................................................................................................14 3.2.3 FPGA ...............................................................................................................................................................14 3.2.4 Receive Converters .........................................................................................................................................14 3.2.5 Transmit Converters .......................................................................................................................................14 3.2.6 Reference & Clock Synthesisers ......................................................................................................................14 3.2.7 Dual Ethernet ..................................................................................................................................................14 3.2.8 Dual Serial ......................................................................................................................................................15 3.2.9 GPIO ................................................................................................................................................................15 3.2.10 Alarm ..............................................................................................................................................................15 3.2.11 Front Panel LEDs .............................................................................................................................................15 3.3 RECEIVER RF/IF SECTIONS ............................................................................................................................................15 3.3.1 Front End ........................................................................................................................................................15 3.3.2 Mixer and LO Buffer ......................................…

Text truncated - open the document above for the full version.

FCC ID:XMK-MMXTRNB005 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view

1. Label 2. Label location At the bottom of the product.

Tornado open in chassis Digital board in chassis Digital board bottom side no shields Digital board bottom side with shields Digital board top side no shields Digital board top side with shields and interface board Digital board top side with shields RF board in chassis RF board bottom side no shields RF board bottom side with shields RF board top side no shields RF board top side with shields Duplexer 800MHz

NOTE: This document is issued by MORLAB, the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ18080066S01 RF EXPOSURE EVALUATION REPORT APPLICANT : MiMOMax Wireless Limited PRODUCT NAME : 800MHz Tornado Transceiver MODEL NAME : MWL-TORNADO-*E A/B/C* BRAND NAME : MiMOMax Wireless FCC ID : XMK-MMXTRNB005 RECEIPT DATE : 2018-08-16 ISSUE DATE : 2020-03-03 Edited by: Gan Yueming (Rapporteur) Approved by: Peng Huarui (Supervisor) MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page2 0f 7 REPORT No.：SZ18080066S01 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment Under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 2. Standards ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 3. RF Exposure Evaluation ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 Change History Version Date Reason for change 1.0 2020-03-03 First edition MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page3 0f 7 REPORT No.：SZ18080066S01 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: MiMOMax Wireless Limited Applicant Address: 540 Wairakei Road, Christchurch, 8053 New Zealand Manufacturer: MiMOMax Wireless Limited Manufacturer Address: 540 Wairakei Road, Christchurch, 8053 New Zealand 1.2 Equipment Under Test (EUT) Description Product Name: 800MHz Tornado Transceiver Serial No: UUT 1:23001213 UUT2:23001212 Hardware Version: IP001 Software Version: R04.03.04 Operating Frequency Range: 806.0~824.0MHz; 851.0~869.0MHz Channel Bandwidth: 12.5kHz; 25kHz Modulation Type: QPSK,16QAM,64QAM,256QAM Operating Voltage: 10.5-60Vdc(Isolated) Antenna Type: Omni Antenna; External Panel antenna Emission Designator: 12.5kHz:10K5W1W 25.0kHz:21K2W1W MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page4 0f 7 REPORT No.：SZ18080066S01 2. Standards The objective of the report is to perform testing according to 47 CFR Part 1.1310 for the EUT FCC ID Certification: No Identity Document Title 1 47 CFR Part 1.1310 Radio frequency exposure limits 2 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page5 0f 7 REPORT No.：SZ18080066S01 3. RF Exposure Evaluation 3.1.1. Requirement Devices that operate under CFR47 Part 90 are subject to routine environmental evaluation for RF exposure prior to equipment authorization or use if they operate at frequencies of 1.5 GHz or below and limit for power density for general population/uncontrolled exposure is f/1500 mW/cm 2 . The output power range by Manufacturer statement is 24dBm. (B) Limits for General Population/Uncontrolled Exposure Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Note: f=frequency in MHz; *=Plane-wave equivalent power density Prediction of MPE limit at given distance, equations from OET Bulletin 65, Edition 97‐01: S = (P * G) / (4 * π * R²) (where PG = EIRP) Where: S = power density P= power input to antenna G= numeric gain of the antenna R= distance to the center of radiation of the antenna MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page6 0f 7 REPORT No.：SZ18080066S01 3.2.2 Result for RF safety distance Antenna Type Gain(dBi) Max Gain(numeric)Safe Distance(cm) Omni 5.0 3.2 10.9 8.0 6.3 15.3 External Panel 10.0 10.0 19.3 12.0 15.8 24.3 16.0 39.8 38.5 A sample for 16dBi calculation for the safe distance would be: d = √(P * G) /4 * π * S d = √251*39.8/(4*3.14*0.537) d = 38.5cm Result: Complies if the safe distances defined above are applied. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page7…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No:STS2003164W01 Issued for MiMOMax Wireless Limited 540 Wairakei Road, Christchurch, 8053 New Zealand Product Name: 800MHz Tornado Transceiver Brand Name: MiMOMax Wireless Model Name: MWL-TORNADO-*E A/B/C* Series Model: N/A FCC ID: XMK-MMXTRNB005 Test Standard: FCC Part 90 Rules S T L A B S Page 2 of 77 Report No.: STS2003164W01 TEST RESULT CERTIFICATION Applicant’s name .................... : MiMOMax Wireless Limited Address .................................... : 540 Wairakei Road, Christchurch, 8053 New Zealand Manufacture's Name .............. : MiMOMax Wireless Limited Address .................................... : 540 Wairakei Road, Christchurch, 8053 New Zealand Product description Product Name ........................ : 800MHz Tornado Transceiver Brand Name ......................... : MiMOMax Wireless Model Name ........................... : MWL-TORNADO-*E A/B/C* Series Model .......................... : N/A Test Standards ..................... : FCC Part 90 Rules Test procedure .......................... : C63.26-2015 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................. : Date of performance of tests ................... : 30 Aug. 2018 ~12 Sept. 2018 Date of Issue ........................................... : 04 Mar. 2020 Test Result ............................................... : Pass Testing Engineer : (Chris chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 77 Report No.: STS2003164W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 EUT OPERATION MODE 10 2.3 DESCRIPTION OF TEST MODES 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.5 DESCRIPTION OF SUPPORT UNITS 13 2.6 TEST EQUIPMENT 14 3. MAXIMUM TRANSMITTER POWER 15 3.1 LIMITS 15 3.2 TEST PROCEDURE 15 3.3 DEVIATION FROM TEST STANDARD 15 3.4 TEST SETUP BLOCK DIAGRAM 15 3.5 TEST RESULT 15 4. OCCUPIED BANDWIDTH 16 4.1 LIMIT 16 4.2 MEASUREMENT PROCEDURE 16 4.3 TEST SETUP BLOCK DIAGRAM 16 4.4 TEST RESULT 16 5. EMISSION MASK 30 5.1 PROVISIONS APPLICABLE 30 5.2 MEASUREMENT PROCEDURE 30 5.3 TEST SETUP BLOCK DIAGRAM 30 5.4 MEASUREMENT RESULT 31 6. ADJACENT CHANNEL POWER 35 6.1 PROVISIONS APPLICABLE 35 6.2 MEASUREMENT PROCEDURE 35 6.3 TEST SETUP BLOCK DIAGRAM 35 6.4 TEST RESULT 36 7. TRANSMITTER RADIATED SPURIOUS EMSSION 44 7.1 PROVISIONS APPLICABLE 44 7.2 TEST PROCEDURE 44 7.3 TEST CONFIGURATION 45 Page 4 of 77 Report No.: STS2003164W01 Table of Contents Page 7.4 TEST RESULT 46 8. SPURIOUS EMSSION ON ANTENNA PORT 48 8.1 PROVISIONS APPLICABLE 48 8.2 MEASUREMENT PROCEDURE 48 8.3 TEST SETUP BLOCK DIAGRAM 48 8.4 TEST RESULT 49 9. FREQUENCY STABILITY 73 9.1 PROVISIONS APPLICABLE 73 9.2 MEASUREMENT PROCEDURE 73 9.3 TEST SETUP BLOCK DIAGRAM 73 9.4 TEST RESULT 74 10. PHOTOS OF TEST SETUP 77 Page 5 of 77 Report No.: STS2003164W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 14 Sept. 2018 STS1809014W01 ALL Initial Issue 00 04 Mar. 2020 STS2003164W01 ALL Updated Product Name. Page 6 of 77 Report No.: STS2003164W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 90 Standard Item Result Remarks FCC Part 90.205 Maximum Transmitter Power PASS FCC Part 90.209 Occupied Bandwidth PASS FCC Part 90.210 Emission Mask PASS FCC Part 90.221 Adjacent channel power PASS FCC Part 90.210 Transmitter Radiated Spurious Emssion PASS FCC Part 90.210 Spurious Emssion on Antenna Port PASS FCC Part 90.213 Frequency Stability Test PASS NOTE: (1)“N/A” denotes test is not applicable in this Test Report Page 7 of 77 Report No.: STS2003164W01 1.1 TEST FACILITY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF power, conducted ±0.70dB 2 Spurious emissions, conducted ±1.19dB 3 Spurious emissions, radiated((>1G) ±2.83dB 4 Spurious emissions, radiated(<1G) ±3.01dB 5 Temperature ±0.5°C 6 Humidity ±2% Page 8 of 77 Report No.: STS2003164W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: 800MHz Tornado Transceiver Brand Name: MiMOMax Wireless Model Name: MWL-TORNADO-*E A/B/C* Series Model: N/A Model Difference description: N/A Operation Frequency Range Frequency Range: 806MHz ~ 869MHz Maximum Transmitter Power: 24.228dBm Channel Separation: 12.5KHz and 25.0KHz Modulation type: QPSK,16QAM,64QAM,256QAM Emission Designator: 12.5KHz: 10K5W1W 25KHz: 21K2W1W Power Rating: Input: DC 24V/1.1A Temperature Range: -30°C-70°C Test frequency list: See Note 5 Software version number: R04.03.04 Hardware version number: IP001 Note: 1. For a …

Text truncated - open the document above for the full version.

FCC ID:XMK-MMXTRNB005 Test Setup Photos 1. RFmeasurementsetup 2. RadiatedSpuriousEmission(30MHz-1GHz) 3. RadiatedSpuriousEmission(above1GHz)
