XMK-MMXTRNB009MiMOMax MWL-TORNADO- A Fixed Digital Microwave Transceiver

Product Manual for Tornado Radio Unit 1 TORNADO RADIO UNIT PRODUCT MANUAL Issue 13 – [MONTH YEAR] This document contains proprietary information and must not be provided or copied to third parties without express permission from Mimomax Wireless Ltd (Trading as Ubiik Mimomax) FCC ID: XMK-MMXTRNB009 Product Manual for Tornado Radio Unit 2 Mimomax Wireless Ltd (Trading as Ubiik Mimomax) Issue 13 – [MONTH] Product Manual for Tornado Radio Unit Copyright © [YEAR] Mimomax Wireless Ltd. Disclaimer While precaution has been taken in the preparation of this literature and it is believed to be correct at the time of issue, Mimomax Wireless Ltd (trading as Ubiik Mimomax) assumes no liability for errors or omissions or for any damages resulting from the use of this information. Due to a policy of continuous technical improvement, the contents of this document and any specifications contained therein are subject to revision and may change without notice. Product Manual for Tornado Radio Unit 3 WARRANTY Mimomax Wireless Limited trading as Ubiik Mimomax ("Ubiik Mimomax”) warrants for a period of 15 months from the date of delivery that its hardware items ("Equipment") will be free from defects due to defective design, workmanship or materials subject the conditions below ("Warranty"). CONDITIONS OF WARRANTY This Warranty is strictly subject to the following conditions: (a) Ubiik Mimomax will not be liable for breach of Warranty unless the customer (i) notifies Ubiik Mimomax of the alleged defects within 30 days after the defect would have become reasonably apparent, and (ii) promptly returns the Equipment carriage paid with a full written report on the alleged defects. (b) The Warranty is not transferable. (c) Ubiik Mimomax's liability under this Warranty is dependent on an assessment by Ubiik Mimomax to determine and validate the defect in design, workmanship or materials. (d) The customer shall refund to Ubiik Mimomax the cost to Ubiik Mimomax of any replacement, repair or redelivery of any Equipment effected by Ubiik Mimomax where the failure is not within the terms of this Warranty. (e) Ubiik Mimomax does not guarantee that any service performed under this Warranty will be carried out within any particular timeframe. (f) To the fullest extent permitted by law, Ubiik Mimomax's liability under this Warranty is limited to (at Ubiik Mimomax's option) replacing or repairing the Equipment or the relevant part thereof without charge provided that its liability shall in no event exceed the purchase price of the Equipment or the relevant part thereof. Where Ubiik Mimomax authorises the customer to undertake Warranty repairs, no reimbursement will be made in respect of labour. GENERAL EXCLUSIONS Ubiik Mimomax shall not be liable under this Warranty: (a) where the Equipment has not been stored, installed, maintained and used properly having regard in particular to Ubiik Mimomax's and (if any) other agreed applicable specifications and instructions including (without limitation) in relation to the installation of engineering changes or enhancements; (b) where the Equipment has not been used in accordance with interference-free power, suitable environment (including but not limited to free from electronic or radio interference and pests) and correct maintenance of the Equipment; (c) for third party interference, fair wear and tear, abuse, damage or misuse, correction or repairs or modifications made other than by Ubiik Mimomax or any repairs required due to events beyond the control of Ubiik Mimomax; (d) for abnormal conditions (electrical, thermal, chemical or otherwise), including (without limitation) factors outside the operational parameters for the Equipment; (e) for any defect caused by or arising from use of any software not licensed or supplied by Ubiik Mimomax, or otherwise caused by or arising from the customer's acts or omissions. LIMITATION OF LIABILITY Except as set out in this Warranty and to the maximum extent permitted by law: (a) all warranties, conditions, liabilities and obligations with respect to any Ubiik Mimomax product, software or services (including as to merchantability, description quality, or fitness for a specific purpose) are expressly excluded; and (b) Ubiik Mimomax shall not be liable for any losses or damages (whether direct or indirect) including property damage or personal injury, consequential loss, economic loss or loss of profits or other economic advantage, however caused which may be suffered or incurred by the customer or any third person, or which may arise directly or indirectly out of or in respect of any Ubiik Mimomax product, software or services or by reason of any act or omission on the part of Ubiik Mimomax. CUSTOMER ACKNOWLEDGEMENT The customer acknowledges that: (a) if the Consumer Guarantees Act 1993 ("CGA") applies, this Warranty shall be read subject to customer's rights under the CGA. Where the customer uses the Equipment for business purposes, the provisions of CGA, or any other relevant consumer protection legislation, shall not apply; (b) the Equipment is not designed or intended for use in on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; intrinsically safe environments or in the design, construction, operation or maintenance of any nuclear facility. Ubiik Mimomax disclaims any express or implied warranty of fitness for such uses. The customer will not use or resell Equipment for such purposes; (c) any software supplied by Ubiik Mimomax cannot be tested in every possible permutation and accordingly Ubiik Mimomax does not warrant that software supplied will be free of all defects or that its use will be uninterrupted. Table of Contents Product Manual for Tornado Radio Unit 4 Abbreviations And Acronyms.................................................................................................................................... 6 1 Tornado System Overview .......................................................…

Text truncated - open the document above for the full version.

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand To: Federal Communications Commission Date: 2024 September 12 FCC ID: XMK-MMXTRNB009 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) MiMOMax Wireless Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) MiMOMax Wireless Limited (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: 900MHz Tornado Transceiver FCC ID: XMK-MMXTRNB009 If you have any questions, please feel free to contact me Contact Person: James Dowle Position in the Company: R&D Manager Date of Signature: 2024.September.12 ___________________________ Signatory (signature of the applicant)

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand Date: 25 th September 2024 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Variants for FCC ID: XMK-MMXTRNB009 Model number for Approval MWL-TORNADO-*G?A, The * and ? are wildcards and are explained below. The * can be B or A, when the * = B this means the radio is encryption capable, when the * = A this means the radio is not encryption capable. For Example: The MWL-TORNADO-AGCA and MWL-TORADNO-BGCA differ only in that the MWL- TORNADO-BGCA radio uses a processor with a hardware encryption co-processor, whereas MWL- TORNADO-AGCA radio does not have this hardware encryption co-processer, all other parts and radio configuration parameters are identical. All Tornado radios use a strong whitener in the physical layer signal processing which ensures that the spectrum is not affected by the data regardless of the whiteness of the data, this also ensures that encryption or lack of encryption also has no effect on the spectrum and emissions from the product. The ? can be a A, B or C, when the ? = C this means the radio is fitted with a 60kHz bandwidth receiver filter, when the ? = B this means the radio is fitted with a 30kHz bandwidth receiver filter, when the ? = A this means the radio is fitted with a 15kHz bandwidth receiver filter For Example: The MWL-TORNADO-AGCA, MWL-TORADNO-AGBA and MWL-TORADNO-AGAA differ only in that the bandwidth of the crystal filter in the receiver intermediate frequency stage, all other parts and radio configuration parameters are identical. The bandwidth of the receiver intermediate frequency filter being 15kHz, 30kHz or 60kHz makes no difference to the spectrum and emissions from the product. Sincerely, James Dowle MiMOMax Wireless Limited (Trading as Ubiik Mimomax)

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand Date: 2024-October-3 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Frequencies of operation for FCC ID: XMK-MMXTRNB009 To Whom it may concern: The user Manual for the Ubiik Mimoamx Tornado radios covered by FCC ID: XMK-MMXTRNB009 covers a family of radios that includes other frequency bands and refers to operation at additional licensed frequencies. The Variants covered by FCC ID: XMK-MMXTRNB009 cover both USA frequency allocations and other countries frequency allocations. While the Radio can operate over the band 896-960 MHz, it will be authorised to be operated between 928 and 960MHz in the USA and the FCC rules are violated if the device operated on unauthorized frequencies. Signatory Name: James Dowle Company name: MiMOMax Wireless Limited, trading as Ubiik Mimomax Address: 540 Wairakei Road, Christchurch 8053, New Zealand Tel: +64-21-479-065 Email: [email protected]

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand Date: 2024-September-12 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality for FCC ID: XMK-MMXTRNB009 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act, MiMOMax Wireless Limited, trading as Ubiik Mimomax hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The requested Permanent Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 BOM The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory Name: James Dowle Company name: Mimomax Wireless Limited, trading as Ubiik Mimomax Address: 540 Wairakei Road, Christchurch 8053, New Zealand Tel: +64-21-479-065 Email: [email protected]

Mimomax Wireless Ltd trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand Date: 2024-September-12 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd to act on our behalf with regard FCC equipment authorization for FCC ID: XMK-MMXTRNB009. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: James Dowle Tel: +64-21-479-065 Email: [email protected] Company name: Mimomax Wireless Limited trading as Ubiik Mimomax

Mimomax Wireless Ltd trading as Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand Date: 2024-April-26 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I hereby authorize James Dowle, Development Manager of Mimomax Wireless Ltd to act on our behalf with regard FCC equipment authorization for Mimomax wireless Ltd products. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: Paul Reid Tel: +64-21 -327-468 Email: [email protected] Company name: MiMOMax Wireless Limited, trading as Ubiik Mimomax

_________________________________________________________________________________________________________________________________________________________________________ Page 52 of 58 Test Report No 240702.1 20 th September 2024 This report may not be reproduced except in full. 10. PHOTOGRAPHS Top face Side face FCC ID: XMK-MMXTRNB009 _________________________________________________________________________________________________________________________________________________________________________ Page 53 of 58 Test Report No 240702.1 20 th September 2024 This report may not be reproduced except in full. Side face Back face FCC ID: XMK-MMXTRNB009 _________________________________________________________________________________________________________________________________________________________________________ Page 54 of 58 Test Report No 240702.1 20 th September 2024 This report may not be reproduced except in full. Bottom face Connector face Label FCC ID: XMK-MMXTRNB009

Industry Canada ID: 8587A-TRNB003 1 MWL-TORNADO-BGCA_Bottom FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 2 MWL-TORNADO-BGCA_Front FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 3 MWL-TORNADO-BGCA_Label FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 4 MWL-TORNADO-BGCA_Left FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 5 MWL-TORNADO-BGCA_Rear FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 6 MWL-TORNADO-BGCA_Right FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 7 MWL-TORNADO-BGCA_Top FCC ID: XMK-MMXTRNB009

Industry Canada ID: 8587A-TRNB003 1 FCC ID: XMK-MMXTRNB009

Industry Canada ID: 8587A-TRNB003 1 MWL-TORNADO-BGCA digital back FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 2 MWL-TORNADO-BGCA digital top FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 3 MWL-TORNADO-BGCA Internal FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 4 MWL-TORNADO-BGCA Mez Bottom FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 5 MWL-TORNADO-BGCA Mez Top FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 6 MWL-TORNADO-BGCA RF Back FCC ID: XMK-MMXTRNB009 Industry Canada ID: 8587A-TRNB003 7 MWL-TORNADO-BGCA RF top FCC ID: XMK-MMXTRNB009

_________________________________________________________________________________________________________________________________________________________________________ Page 47 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. Exposure of humans to RF fields As per FCC KDB 447498 D01 and Section 2.1091 radio frequency transmitters are required to be operated in a manner that ensures the public is not exposed to RF energy levels. Calculations have been made using the General Public/Uncontrolled Exposure limits that are defined in Section 1.1310. For MPE calculations, 960.000 MHz has been selected. Limits for maximum permissible exposure (MPE) - General Population / Uncontrolled exposure is f/1500. At 928.000 MHz, the calculated limit is 0.6 2 mW/cm 2 - Occupational /Controlled exposure is f/300. At 9 28.000 MHz, the calculated limit is 3. 10 mW/cm 2 Minimum safe distances have been calculated below. For Uncontrolled Environment At 928.000 MHz, Power Density = 0.62 mW/cm 2 = E 2 /3770 E= √0.62*3770 E = 49.3 V/m FCC ID: XMK-MMXTRNB009 _________________________________________________________________________________________________________________________________________________________________________ Page 48 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. For Controlled Environment At 960.000 MHz, Power Density = 3.10 mW/cm 2 = E 2 /3770 E= √3.10*3770 E = 108.1 V/m The rated maximum transmitter power = 0.25 W (+24 dBm). A worst case scenario duty cycle of 100% has been used for the calculations. Shown below is the typical list of antennas (Information supplied by the client) that would be used with the product: The minimum distance from the antenna at which the MPE is met is calculated from the following Field strength in V/m (FS), Transmit power in watts (P) Transmit antenna gain (G) Transmitter duty cycle (DC) Separation distance in metres (D) The calculation is as follows: FS = (√ (30 * P * G * DC)) / D FCC ID: XMK-MMXTRNB009 _________________________________________________________________________________________________________________________________________________________________________ Page 49 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. The calculations have been shown with following scenarios: - MPE calculations for the product with both ports terminated in a 50 Ohm load - Using 8 dBi gain antenna - Using 9 dBi gain antenna - Using 11 dBi gain antenna - Using 12 dBi gain antenna - Using 15 dBi gain antenna - Using 16 dBi gain antenna a) For Uncontrolled environments, the minimum distance is: D = (√ (30 * P * G * DC)) / FS P = 0.25 W FS = E = 49.3 V/m Frequency (MHz) Antenna Gain (dBi) Antenna Gain Numeric Duty cycle Safe distance (metres) 928.000 No gain (0) 1.0 100% 0.06 8.0 6.3 100% 0.14 9.0 7.9 100% 0.16 11.0 12.6 100% 0.20 12.0 15.8 100% 0.22 15.0 31.6 100% 0.31 16.0 39.8 100% 0.35 FCC ID: XMK-MMXTRNB009 _________________________________________________________________________________________________________________________________________________________________________ Page 50 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. a) For Controlled environments, the minimum distance is: D = (√ (30 * P * G * DC)) / FS P = 0.25 W FS = E = 108.1 V/m Frequency (MHz) Antenna Gain (dBi) Antenna Gain Numeric Duty cycle Safe distance (metres) 928.000 No gain (0) 1.0 100% 0.02 8.0 6.3 100% 0.06 9.0 7.9 100% 0.07 11.0 12.6 100% 0.09 12.0 15.8 100% 0.10 15.0 31.6 100% 0.14 16.0 39.8 100% 0.16 Result: Complies if a safe distance shown in the calculations above is followed. FCC ID: XMK-MMXTRNB009

____________________________________________________________________________________________________________________________________________________________________________ Page 1 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd 47 Mackelvie St, Grey Lynn Auckland 1021 New Zealand Phone 09 360 0862 Fax 09 360 0861 E-Mail Address: [email protected] Web Site: www.emctech.co.nz TEST REPORT MiMOMax MWL-TORNADO-*G?A Fixed Digital Microwave Transceiver tested to the Code of Federal Regulations (CFR) 47 Part 15 - Radio Frequency Devices Subpart A and B – Unintentional Radiators for MiMOMax Wireless Ltd This Test Report is issued with the authority of: ________________________________________ Andrew Cutler- General Manager ____________________________________________________________________________________________________________________________________________________________________________ Page 2 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. Table of Contents 1. COMPLIANCE STATEMENT 3 2. RESULT SUMMARY 3 3. ATTESTATION 5 4. CLIENT INFORMATION 6 5. TEST SAMPLE DESCRIPTION 6 6. TEST RESULTS 10 7. TEST EQUIPMENT USED 15 8. ACCREDITATIONS 15 9. PHOTOGRAPHS 16 10. APPENDIX 1 – CLIENT LETTER’s 22 ____________________________________________________________________________________________________________________________________________________________________________ Page 3 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. 1. COMPLIANCE STATEMENT The MiMOMax MWL-TORNADO-*G?A Fixed Digital Microwave Transceiver complies with FCC Part 15 Subpart Subpart A + B as Class B devices when the methods as described in ANSI C63.4 – 2014 and ANSI C63.10–2020. Note: Please refer to Client’s letter appended to the test report for more details about the product’s model number nomenclature. 2. RESULT SUMMARY The results of testing carried out in 23 rd July and 5 th September 2024 are summarised below. Clause Parameter Result 15.101 Equipment authorisation requirement. Certification as per FCC part 90 is required. Contains transmitter. 15.103 Exempted devices. The Device is a receiver and not a digital device. 15.107 Conducted Emissions 0.15 - 30 MHz Not applicable. DC Powered device 15.109 Radiated Emissions 30 - 10000 MHz Complies, Class B limits applied. 15.111 Antenna Terminal Disturbance 30 – 950 MHz Complies. ____________________________________________________________________________________________________________________________________________________________________________ Page 4 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. To comply with the Supplier Declaration of Conformity process when this equipment is sold in the USA the following will need to be addressed: - Identify the product with a name, model number, serial number etc - The following statement needs to be applied to the product This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions (1) This device may not cause interference, and (2) This device must accept any interference that may cause undesired operation - The FCC logo may also be applied to the product. - Supply with the product the name, contact address, phone number, email address etc of the responsible party in the USA. ____________________________________________________________________________________________________________________________________________________________________________ Page 5 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. 3. ATTESTATION This report describes the tests and measurements performed for the purpose of determining compliance with the specification with the following conditions: The client selected the test sample. The report relates only to the sample tested. The corrections or erasures in the test report are indicated in the report revision table. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. In addition this equipment has been tested in accordance with the requirements contained in the appropriate Commission regulations. All compliance statements have been made with respect of the specification limit with no reference to the measurement uncertainty. To the best of my knowledge, these tests were performed using measurement procedures that are consistent with industry or Commission standards and demonstrate that the equipment complies with the appropriate standards. I further certify that the necessary measurements were made by EMC Technologies NZ Ltd, 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand. Andrew Cutler General Manager EMC Technologies NZ Ltd Report Revision Table Version Change Made Date 240702.3 Initial Issue. 25 th September 2024 ____________________________________________________________________________________________________________________________________________________________________________ Page 6 of 23 Test Report No 240702.3 25 th September2024 This report may not be reproduced except in full. 4. CLIENT INFORMATION Company Name MiMOMax Wireless Ltd Address 540 Wairakei Rd Burnside Christchurch 8053 Country New Zealand Contact James Dowle, Sha Luo 5. TEST SAMPLE DESCRIPTION Brand Name MiMOMax Model Number MWL-TORNADO-BGCA (Tested Sample) MWL-TORNADO-*G?A (Nomenclature as per Client) Product Fixed Digital Microwave Transceiver Manufacturer MiMOMAX Wireless Ltd Manufactured in New Zealand Serial Numbers 23004892 FCC ID XMK-MMXTRNB009 Rated Transmitter Output Power Two transmitters each outputting +24 dBm (0.25 Watt) average Transmitter FCC Frequency Bands 928.0-929.0 MHz 932.5-935.0 MHz 941.0-941.5 MHz 941.5-944.0 MHz 95…

Text truncated - open the document above for the full version.

_________________________________________________________________________________________________________________________________________________________________________ Page 1 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd 47 Mackelvie St, Grey Lynn Auckland 1021 New Zealand Phone 09 360 0862 E-Mail Address: [email protected] Web Site: www.emctech.co.nz TEST REPORT MiMOMax MWL-TORNADO-*G?A Fixed Digital Microwave Transceiver tested to the Code of Federal Regulations (CFR) 47 Part 101 –Fixed Microwave Services for MiMOMax Wireless Ltd This Test Report is issued with the authority of: ______________________________________ Andrew Cutler - General Manager _________________________________________________________________________________________________________________________________________________________________________ Page 2 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. Table of Contents 1. STATEMENT OF COMPLIANCE 3 2. RESULTS SUMMARY 3 3. INTRODUCTION 4 4. CLIENT INFORMATION 5 5. DESCRIPTION OF TEST SAMPLE 5 7. TEST RESULTS 10 8. TEST EQUIPMENT USED 51 9. ACCREDITATIONS 51 10. PHOTOGRAPHS 52 11. APPENDIX 1 – CLIENT LETTER 58 _________________________________________________________________________________________________________________________________________________________________________ Page 3 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. 1. STATEMENT OF COMPLIANCE The MiMOMax MWL-TORNADO-*G?A Fixed Digital Microwave Transceiver complies with CFR 47 Part 101 and 47 CFR Part 2, as detailed below, when tested in- accordance with the test methods described in 47 CFR Part 2 and ANSI / TIA-603-E: 2016 and ANSI C63.26 – 2015. Note: Please refer to Client’s letter appended to the test report for more details about the product’s model number nomenclature. 2. RESULTS SUMMARY The results of testing carried out between 23 rd July and 5 th September 2024 are summarised below. Clause Description Result Page No 101.107 Frequency tolerance Complies 10 101.109 Bandwidth Complies 12 101.111 Emission limitations Spurious emission at antenna port Standby/Receive emissions Spurious emissions field strength Complies Complies Complies Complies 22 35 38 40 101.113 Transmitter power limitations Complies 44 - Radiation Hazard Assessment Noted 47 _________________________________________________________________________________________________________________________________________________________________________ Page 4 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. 3. INTRODUCTION This report describes the tests and measurements performed for the purpose of determining compliance with the specification with the following conditions: The client selected the test sample. The report relates only to the sample tested. The corrections or erasures in the test report are indicated in the report revision table. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. All compliance statements have been made with respect of the specification limit with no reference to the measurement uncertainty. In addition this equipment has been tested in accordance with the requirements contained in the appropriate FCC regulations. To the best of my knowledge, these tests were performed using measurement procedures that are consistent with industry or Industry Canada standards and demonstrate that the equipment complies with the appropriate standards. I further certify that the necessary measurements were made by EMC Technologies NZ Ltd, 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand. Andrew Cutler General Manager EMC Technologies NZ Ltd Report Revision Table Version Change Made Date 240207.1 Initial Issue. 25 th September 2024 240207.1a Band of Operation changed on Page 6 Radiation Hazard Modification on Page 47 27 th September 2024 _________________________________________________________________________________________________________________________________________________________________________ Page 5 of 59 Test Report No 240702.1a 27 th September 2024 This report may not be reproduced except in full. 4. CLIENT INFORMATION Company Name MiMOMax Wireless Ltd Address 540 Wairakei Road Burnside Christchurch Country New Zealand Contact James Dowle, Sha Luo 5. DESCRIPTION OF TEST SAMPLE Brand Name MiMOMax Model Number MWL-TORNADO-BGCA (Tested Sample) MWL-TORNADO-*G?A (Nomenclature as per Client) Product Fixed Digital Microwave Transceiver Manufacturer MiMOMAX Wireless Ltd Manufactured in New Zealand Serial Numbers 23004892 FCC ID XMK-MMXTRNB009 Hardware version P001 Software version TRN_04.08.05 Rated Transmitter Output Power Two transmitters each outputting +24 dBm (0.25 Watt) average ________…
