XMK-MMXTRNB007MiMOMax MWL-Tornado - BCCA Digital Linking Radio

Product Manual for Tornado Radio Unit 1 TORNADO RADIO UNIT PRODUCT MANUAL Issue 12 – December 2023 This document contains proprietary information and must not be provided or copied to third parties without express permission from Mimomax Wireless Ltd (Trading as Ubiik Mimomax) Product Manual for Tornado Radio Unit 2 Mimomax Wireless Ltd (Trading as Ubiik Mimomax) Issue 12 – December 2023 Product Manual for Tornado Radio Unit Copyright © 2023 Mimomax Wireless Ltd. Disclaimer While precaution has been taken in the preparation of this literature and it is believed to be correct at the time of issue, Mimomax Wireless Ltd (trading as Ubiik Mimomax) assumes no liability for errors or omissions or for any damages resulting from the use of this information. Due to a policy of continuous technical improvement, the contents of this document and any specifications contained therein are subject to revision and may change without notice. Product Manual for Tornado Radio Unit 3 WARRANTY Mimomax Wireless Limited trading as Ubiik Mimomax ("Ubiik Mimomax”) warrants for a period of 15 months from the date of delivery that its hardware items ("Equipment") will be free from defects due to defective design, workmanship or materials subject the conditions below ("Warranty"). CONDITIONS OF WARRANTY This Warranty is strictly subject to the following conditions: (a) Ubiik Mimomax will not be liable for breach of Warranty unless the customer (i) notifies Ubiik Mimomax of the alleged defects within 30 days after the defect would have become reasonably apparent, and (ii) promptly returns the Equipment carriage paid with a full written report on the alleged defects. (b) The Warranty is not transferable. (c) Ubiik Mimomax's liability under this Warranty is dependent on an assessment by Ubiik Mimomax to determine and validate the defect in design, workmanship or materials. (d) The customer shall refund to Ubiik Mimomax the cost to Ubiik Mimomax of any replacement, repair or redelivery of any Equipment effected by Ubiik Mimomax where the failure is not within the terms of this Warranty. (e) Ubiik Mimomax does not guarantee that any service performed under this Warranty will be carried out within any particular timeframe. (f) To the fullest extent permitted by law, Ubiik Mimomax's liability under this Warranty is limited to (at Ubiik Mimomax's option) replacing or repairing the Equipment or the relevant part thereof without charge provided that its liability shall in no event exceed the purchase price of the Equipment or the relevant part thereof. Where Ubiik Mimomax authorises the customer to undertake Warranty repairs, no reimbursement will be made in respect of labour. GENERAL EXCLUSIONS Ubiik Mimomax shall not be liable under this Warranty: (a) where the Equipment has not been stored, installed, maintained and used properly having regard in particular to Ubiik Mimomax's and (if any) other agreed applicable specifications and instructions including (without limitation) in relation to the installation of engineering changes or enhancements; (b) where the Equipment has not been used in accordance with interference-free power, suitable environment (including but not limited to free from electronic or radio interference and pests) and correct maintenance of the Equipment; (c) for third party interference, fair wear and tear, abuse, damage or misuse, correction or repairs or modifications made other than by Ubiik Mimomax or any repairs required due to events beyond the control of Ubiik Mimomax; (d) for abnormal conditions (electrical, thermal, chemical or otherwise), including (without limitation) factors outside the operational parameters for the Equipment; (e) for any defect caused by or arising from use of any software not licensed or supplied by Ubiik Mimomax, or otherwise caused by or arising from the customer's acts or omissions. LIMITATION OF LIABILITY Except as set out in this Warranty and to the maximum extent permitted by law: (a) all warranties, conditions, liabilities and obligations with respect to any Ubiik Mimomax product, software or services (including as to merchantability, description quality, or fitness for a specific purpose) are expressly excluded; and (b) Ubiik Mimomax shall not be liable for any losses or damages (whether direct or indirect) including property damage or personal injury, consequential loss, economic loss or loss of profits or other economic advantage, however caused which may be suffered or incurred by the customer or any third person, or which may arise directly or indirectly out of or in respect of any Ubiik Mimomax product, software or services or by reason of any act or omission on the part of Ubiik Mimomax. CUSTOMER ACKNOWLEDGEMENT The customer acknowledges that: (a) if the Consumer Guarantees Act 1993 ("CGA") applies, this Warranty shall be read subject to customer's rights under the CGA. Where the customer uses the Equipment for business purposes, the provisions of CGA, or any other relevant consumer protection legislation, shall not apply; (b) the Equipment is not designed or intended for use in on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; intrinsically safe environments or in the design, construction, operation or maintenance of any nuclear facility. Ubiik Mimomax disclaims any express or implied warranty of fitness for such uses. The customer will not use or resell Equipment for such purposes; (c) any software supplied by Ubiik Mimomax cannot be tested in every possible permutation and accordingly Ubiik Mimomax does not warrant that software supplied will be free of all defects or that its use will be uninterrupted. Product Manual for Tornado Radio Unit 4 Table of Contents Abbreviations And Acronyms .................................................................................................................................. 6 1 Tornado System Overview ..........................................................................…

Text truncated - open the document above for the full version.

Mimomax Wireless Ltd 540 Wairakei Road PO Box 1645 Christchurch, New Zealand To: Federal Communications Commission Date: 2023 Nov 06 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) MiMOMax Wireless Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) MiMOMax Wireless Limited (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: 450MHz Tornado Transceiver FCC ID: XMK-MMXTRNB007 If you have any questions, please feel free to contact me Contact Person: Paul Reid Position in the Company: CEO Date of Signature: 2023.11.06 ___________________________ Signatory (signature of the applicant)

Ubiik Mimomax 540 Wairakei Road PO Box 20003 Christchurch, New Zealand 25 January 2024 To whom it may concern, The purpose of this letter is to explain why we have submitted only one radio for FCC Compliance for the 450-470MHz band. Ubiik Mimomax Tornado radios utilize the same digital and RF boards for the 450-470MHz band but use duplexers to separate the transmitter and receiver. The duplexer is a passive component in terms of transmitting. Typically, this duplexer will be tuned specifically according to the customer’s frequency requirement prior to dispatch. Once the duplexer is tuned, it can only operate within a certain range (usually ±1MHz) of the nominal frequency. The duplexer tuning process requires special equipment and must follow certain procedures to achieve a successful outcome. Due to the complexity of the tuning and the risk of damage to the duplexers or radio boards, it is recommended that this process is only carried out by trained and experienced technicians. For this reason, we prefer to not have the test house carry out the tuning and have instead submitted a radio tuned to 460MHz (the centre of the 450-470MHz band) as a sample. Based on the above information, we hope it is acceptable to have only one radio submitted for compliance. Best R egards, Paul Re id President FCC ID: XMK-MMXTRNB007

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 1645 Christchurch, New Zealand Date: 2023-Dec-07 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Frequencies of operation for FCC ID: XMK-MMXTRNB007 To Whom it may concern: The user Manual for the Ubiik Mimoamx Tornado radios covered by FCC ID: XMK-MMXTRNB007 covers a family of radios that includes other frequency bands and refers to operation at additional licensed frequencies. The Variants covered by FCC ID: XMK-MMXTRNB007 cannot be operated outside of the 440MHz to 470 MHz range, the user interface does not allow configuration outside of this frequency range on the product codes specified in the Equivalence letter for FCC ID: XMK-MMXTRNB007. Signatory Name: James Dowle Company name: MiMOMax Wireless Limited, trading as Ubiik Mimomax Address: 540 Wairakei Road, Christchurch 8053, New Zealand Tel: +64-21-479-065 Email: [email protected]

Mimomax Wireless Ltd 540 Wairakei Road PO Box 1645 Christchurch, New Zealand 13 November 2023 To whom it may concern Equivalence for FCC-ID: XMK-MMXTRNB007 Mimomax 440-470 MHz Tornado radios have been certification tested with during October/November 2023, Testing was carried out on an Encryption capable radio fitted with internal duplexers and 50kHz receiver filters. Equivalent radios with and without encryption capability, with internal vs external duplexers and with different bandwidth receiver filters are available in the Tornado Radios. Encryption capability or lack of encryption capability makes no impact on the signal transmitted from the Radio. Internal duplexers radios have less rejection of unwanted signals and are consequently the worst case for the signals out of the radio. A radio with a 50 kHz receiver filter was tested as it can support all the bandwidths required for testing and the receiver filter bandwidth has no impact on the signals out of the radio. Certification testing was complete on a MWL-TORNADO-BCCA model radio. The below models are equivalent to the MWL-TORNADO-BCCA: MWL-TORNADO-ACAA, MWL-TORNADO-ACBA, MWL-TORNADO-ACCA, MWL-TORNADO-BCAA, MWL-TORNADO-BCBA, MWL-TORNADO-ACAB, MWL-TORNADO-ACBB, MWL-TORNADO-ACCB, MWL-TORNADO-BCAB, MWL-TORNADO-BCBB, MWL-TORNADO-BCCB Model numbering follows the format MWL-TORNADO-1234 Where 1 = A for non-encryption capable radios, and B for encryption capable radios. Where 2 = C for 440-470 MHz Frequency band radios. Where 3 = A for 12.5kHz bandwidth Receiver filters, B for 25kHz bandwidth receiver filters and C for 50kHz bandwidth receiver filters. Where 4 = A for internal duplexer radios and B for external duplexer radios. Regards James Dowle, Development Manager

Mimomax Wireless Ltd, trading as Ubiik Mimomax 540 Wairakei Road PO Box 1645 Christchurch, New Zealand Date: 2023-Dec-07 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality for FCC ID: XMK-MMXTRNB007 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act, MiMOMax Wireless Limited, trading as Ubiik Mimomax hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality till date 11/28/2023(max time 180 days from grant date) as outlined in Public Notice DA04-1705. This provision will give MiMOMax Wireless Limited, trading as Ubiik Mimomax temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 BOM SHORT-TERM 5 Internal Photos 6 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory Name: James Dowle Company name: MiMOMax Wireless Limited, trading as Ubiik Mimomax Address: 540 Wairakei Road, Christchurch 8053, New Zealand Tel: +64-21-479-065 Email: [email protected]

Mimomax Wireless Ltd 540 Wairakei Road PO Box 1645 Christchurch, New Zealand Date: 2023-11-06 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd to act on our behalf with regard FCC equipment authorization for FCC ID: XMK-MMXTRNB007. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: Paul Reid Tel: +64-21-327-468 Email: [email protected] Company name: MiMOMax Wireless Limited

Mimomax Wireless Ltd trading as Ubiik Mimomax 540 Wairakei Road PO Box 1645 Christchurch, New Zealand Date: 2023-12-06 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I hereby authorize James Dowle, Development Manager of Mimomax Wireless Ltd to act on our behalf with regard FCC equipment authorization for Mimomax wireless Ltd products. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: Paul Reid Tel: +64-21-327-468 Email: [email protected] Company name: MiMOMax Wireless Limited, trading as Ubiik Mimomax

____________________________________________________________________________________________________________________________________________________________________________ Page 48 of 55 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. 9. PHOTOGRAPHS Top Face Connector face FCC ID: XMK-MMXTRNB007 ____________________________________________________________________________________________________________________________________________________________________________ Page 49 of 55 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. Side face with top face Side face FCC ID: XMK-MMXTRNB007 ____________________________________________________________________________________________________________________________________________________________________________ Page 50 of 55 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. Side face Bottom face FCC ID: XMK-MMXTRNB007 ____________________________________________________________________________________________________________________________________________________________________________ Page 51 of 55 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. Bottom side of the product showing label location Label of all samples FCC ID: XMK-MMXTRNB007

____________________________________________________________________________________________________________________________________________________________________________ Page 51 of 55 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. Bottom side of the product showing label location Label of all samples FCC ID: XMK-MMXTRNB007

FCC ID: XMK-MMXTRNB007 Page 1 of 6 Digital Board top face FCC ID: XMK-MMXTRNB007 Page 2 of 6 Digital Board back face FCC ID: XMK-MMXTRNB007 Page 3 of 6 Mez_Top Mez_Bottom FCC ID: XMK-MMXTRNB007 Page 4 of 6 RF board top FCC ID: XMK-MMXTRNB007 Page 5 of 6 RF board back FCC ID: XMK-MMXTRNB007 Page 6 of 6 Boards in Chassis

____________________________________________________________________________________________________________________________________________________________________________ Page 38 of 42 Test Report No 230907.3d 20 th December 2023 This report may not be reproduced except in full. Exposure of humans to RF fields As per FCC KDB 447498 D01 and Section 2.1091 radio frequency transmitters are required to be operated in a manner that ensures the public is not exposed to RF energy levels. Calculations have been made using the General Public/Uncontrolled Exposure limits that are defined in Section 1.1310. For worst case MPE calculations, 460.075 MHz has been selected. Limits for maximum permissible exposure (MPE) - General Population / Uncontrolled exposure is f/1500. At 460.075 MHz, the calculated limit is 0.3 mW/cm 2 - Occupational /Controlled exposure is f/300. At 460.075 MHz, the calculated limit is 1.53 mW/cm 2 Minimum safe distances have been calculated below. For Uncontrolled Environment At 460.075 MHz, Power Density = (460.075/1500)=0.30 mW/cm 2 = E 2 /3770 E= √0.3*3770 E = 33.6 V/m FCC ID: XMK-MMXTRNB007 ____________________________________________________________________________________________________________________________________________________________________________ Page 39 of 42 Test Report No 230907.3d 20 th December 2023 This report may not be reproduced except in full. For Controlled Environment At 460.075 MHz, Power Density = (460.075/300)=1.53 mW/cm 2 = E 2 /3770 E= √1.53*3770 E = 75.9 V/m The rated maximum transmitter power = 0.25 W (+24 dBm). A worst case scenario duty cycle of 100% has been used for the calculations. The following information about the antenna type and gain has been obtained from the client: Antenna Type Gain (dBi) Omni 10 dBi Panel 10 dBi Panel 15 dBi The minimum distance from the antenna at which the MPE is met is calculated from the following Field strength in V/m (FS), Transmit power in watts (P) Transmit antenna gain (G) Transmitter duty cycle (DC) Separation distance in metres (D) The calculation is as follows: FS = (√ (30 * P * G * DC)) / D The calculations have been shown with following scenarios: - MPE calculations for the product with both ports terminated in a 50 Ohm load - Using 10 dBi gain antenna - Using 15 dBi gain antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 40 of 42 Test Report No 230907.3d 20 th December 2023 This report may not be reproduced except in full. a) For Uncontrolled environments, the minimum distance is: D = (√ (30 * P * G * DC)) / FS P = 0.25 W FS = 33.6 V/m Frequency (MHz) Antenna Gain (dBi) Antenna Gain Numeric Duty cycle Safe distance (metres) 460.075 No gain (0) 1.0 100% 0.08 460.075 10.0 10.0 100% 0.26 460.075 15.0 31.6 100% 0.46 a) For Controlled environments, the minimum distance is: D = (√ (30 * P * G * DC)) / FS P = 0.25 W FS = 75.9 V/m Frequency (MHz) Antenna Gain (dBi) Antenna Gain Numeric Duty cycle Safe distance (metres) 460.075 No gain (0) 1.0 100% 0.04 460.075 10.0 10.0 100% 0.11 460.075 15.0 31.6 100% 0.20 Result: Complies if a safe distance shown in the calculations above is followed.

____________________________________________________________________________________________________________________________________________________________________________ Page 1 of 47 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd 47 Mackelvie St, Grey Lynn Auckland 1021 New Zealand Phone 09 360 0862 E-Mail Address: [email protected] Web Site: www.emctech.co.nz TEST REPORT MiMOMax MWL-Tornado - BCCA Digital Linking Radio Additional Variants: MWL-TORNADO-ACAA, MWL-TORNADO-ACBA, MWL- TORNADO-ACCA, MWL-TORNADO-BCAA, MWL-TORNADO-BCBA, MWL-TORNADO- ACAB, MWL-TORNADO-ACBB, MWL-TORNADO-ACCB, MWL-TORNADO-BCAB, MWL- TORNADO-BCBB, MWL-TORNADO-BCCB tested to the Code of Federal Regulations (CFR) 47 Part 90 –Private Land Mobile Services for MiMOMax Wireless Ltd This Test Report is issued with the authority of: ________________________________________ Andrew Cutler- General Manager ____________________________________________________________________________________________________________________________________________________________________________ Page 2 of 47 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. Table of Contents 1. COMPLIANCE STATEMENT 3 2. RESULT SUMMARY 3 3. ATTESTATION 4 4. CLIENT INFORMATION 5 5. TEST SAMPLE DESCRIPTION 5 6. TEST RESULTS 9 7. TEST EQUIPMENT USED 46 8. ACCREDITATIONS 46 9. PHOTOGRAPHS 48 ____________________________________________________________________________________________________________________________________________________________________________ Page 3 of 47 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. 1. COMPLIANCE STATEMENT The MiMOMax MWL-Tornado–BCCA Digital Linking Radio complies with the limits defined in 47 CFR Part 90 and 47 CFR Part 2 when tested in-accordance with the test methods described in 47 CFR Part 2, ANSI / TIA-603 -E: 2016 and ANSI C63.26: 2015. The client has requested for the addition of variants to this test report based on their technical assessment. At the end of the test report, the request letter has been appended for reference. The below models as per the client, are equivalent to the MWL-TORNADO-BCCA: MWL-TORNADO-ACAA, MWL-TORNADO-ACBA, MWL-TORNADO-ACCA, MWL-TORNADO-BCAA, MWL-TORNADO-BCBA, MWL-TORNADO-ACAB, MWL-TORNADO-ACBB, MWL-TORNADO-ACCB, MWL-TORNADO-BCAB, MWL-TORNADO-BCBB, MWL-TORNADO-BCCB RESULT SUMMARY The results of testing carried out between October 2023 and February 2024 are summarised below. Clause Description Result Page no 90.203 Complies Certification required Noted. 9 2.1046 Noted 90.205 Complies RF power output Power and antenna height limits Noted Complies 11 2.1049 Noted 2.202 Noted 90.207 Complies 90.209 Complies 90.210 90.221 Complies Occupied bandwidth Bandwidths Types of emissions Bandwidth limitations Emission masks Adjacent channel power Noted Noted Complies Complies Complies Complies 12 12 21 26 2.1051 Complies Spurious emissions at antenna terminals Complies 30 2.1053 Complies Field strength of spurious radiation Complies 33 2.1055 Noted 90.213 Complies Frequency stability Frequency stability Noted Complies 36 90.214 Complies Transient frequency behaviour Complies 38 1.1310 Radio frequency exposure limits Complies 43 ____________________________________________________________________________________________________________________________________________________________________________ Page 4 of 47 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. 2. ATTESTATION This report describes the tests and measurements performed for the purpose of determining compliance with the specification. The client selected the test sample. This report relates only to the sample tested. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. All compliance statements have been made with respect of the specification limit with no reference to the measurement uncertainty. All testing was carried out as per the standard in the worst-case configuration with no deviations being applied. In addition this equipment has been tested in accordance with the requirements contained in the appropriate Commission regulations. All compliance statements have been made with respect of the specification limit with no reference to the measurement uncertainty. To the best of my knowledge, these tests were performed using measurement procedures that are consistent with industry or Commission standards and demonstrate that the equipment complies with the appropriate standards. I further certify that the necessary measurements were made by EMC Technologies NZ Ltd, 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand. Andrew Cutler General Manager EMC Technologies NZ Ltd Report Revision Table Version Change Made Date 230907.3 Initial Issue. 31/10/2023 230907.3b FVIN added, Radiation hazard edited, 12.5 kHz transient plot added 28/11/2023 230907.3c Product photos excluded from Test report. Editorial correction on page 3 15/12/2023 230907.3d The antenna gain has been corrected on page 39 20/12/2023 230907.3e The FCC certification range corrected 21/12/2023 230907.3f Test results for 450 MHz and 469.5 MHz have been added 16/02/2024 ____________________________________________________________________________________________________________________________________________________________________________ Page 5 of 47 Test Report No 230907.3f 16 th February 2024 This report may not be reproduced except in full. 3. CLIENT INFORMATION Company Name MiMOMax Wireless Ltd Address 540 Wairakei Rd Burnside Christchurch 8053 Country New Zealand Contact James Dowle 4. TEST SAMPLE DESCRIPTION Brand Name MiMOMax Model Number MWL-Tornado-BCCA Product Digital Linking Radio Manufactur…

Text truncated - open the document above for the full version.

____________________________________________________________________________________________________________________________________________________________________________ Page 44 of 48 Test Report No 230907.3 31 st October 2023 This report may not be reproduced except in full. Radiated Emissions Test Setup FCC ID: XMK-MMXTRNB007 ____________________________________________________________________________________________________________________________________________________________________________ Page 45 of 48 Test Report No 230907.3 31 st October 2023 This report may not be reproduced except in full. Test Shed showing the use of a Biconical Antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 46 of 48 Test Report No 230907.3 31 st October 2023 This report may not be reproduced except in full. Test Shed showing the use of a Log periodic Antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 47 of 48 Test Report No 230907.3 31 st October 2023 This report may not be reproduced except in full. Test Antennas Used – Horn Antenna
