XMK-MMXTRNXB003900MHz TornadoXR Transceiver

Product Manual for Tornado X and Tornado XR 1 PRODUCT MANUAL FOR TORNADO X & TORNADO XR 900MHz Issue 1 – December 2022 This document contains proprietary information and must not be provided or copied to third parties without express permission from Mimomax Wireless Ltd Product Manual for Tornado X and Tornado XR 2 Mimomax Wireless Ltd Issue 1 – December 2022 Product Manual for Tornado X and Tornado XR Copyright © 2022 Mimomax Wireless Ltd. Disclaimer While precaution has been taken in the preparation of this literature and it is believed to be correct at the time of issue, Mimomax Wireless Ltd assumes no liability for errors or omissions or for any damages resulting from the use of this information. Due to a policy of continuous technical improvement, the contents of this document and any specifications contained therein are subject to revision and may change without notice. Product Manual for Tornado X and Tornado XR 3 WARRANTY Mimomax Wireless Limited ("Mimomax”) warrants for a period of 12 months from the date of delivery that its hardware items ("Equipment") will be free from defects due to defective design, workmanship or materials subject the conditions below ("Warranty"). CONDITIONS OF WARRANTY This Warranty is strictly subject to the following conditions: (a) Mimomax will not be liable for breach of Warranty unless the customer (i) notifies Mimomax of the alleged defects within 30 days after the defect would have become reasonably apparent, and (ii) promptly returns the Equipment carriage paid with a full written report on the alleged defects. (b) The Warranty is not transferable. (c) Mimomax's liability under this Warranty is dependent on an assessment by Mimomax to determine and validate the defect in design, workmanship or materials. (d) The customer shall refund to Mimomax the cost to Mimomax of any replacement, repair or redelivery of any Equipment effected by Mimomax where the failure is not within the terms of this Warranty. (e) Mimomax does not guarantee that any service performed under this Warranty will be carried out within any particular timeframe. (f) To the fullest extent permitted by law, Mimomax's liability under this Warranty is limited to (at Mimomax's option) replacing or repairing the Equipment or the relevant part thereof without charge provided that its liability shall in no event exceed the purchase price of the Equipment or the relevant part thereof. Where Mimomax authorises the customer to undertake Warranty repairs, no reimbursement will be made in respect of labour. GENERAL EXCLUSIONS Mimomax shall not be liable under this Warranty: (a) where the Equipment has not been stored, installed, maintained and used properly having regard in particular to Mimomax's and (if any) other agreed applicable specifications and instructions including (without limitation) in relation to the installation of engineering changes or enhancements; (b) where the Equipment has not been used in accordance with interference-free power, suitable environment (including but not limited to free from electronic or radio interference and pests) and correct maintenance of the Equipment; (c) for third party interference, fair wear and tear, abuse, damage or misuse, correction or repairs or modifications made other than by Mimomax or any repairs required due to events beyond the control of Mimomax; (d) for abnormal conditions (electrical, thermal, chemical or otherwise), including (without limitation) factors outside the operational parameters for the Equipment; (e) for any defect caused by or arising from use of any software not licensed or supplied by Mimomax, or otherwise caused by or arising from the customer's acts or omissions. LIMITATION OF LIABILITY Except as set out in this Warranty and to the maximum extent permitted by law: (a) all warranties, conditions, liabilities and obligations with respect to any Mimomax product, software or services (including as to merchantability, description quality, or fitness for a specific purpose) are expressly excluded; and (b) Mimomax shall not be liable for any losses or damages (whether direct or indirect) including property damage or personal injury, consequential loss, economic loss or loss of profits or other economic advantage, however caused which may be suffered or incurred by the customer or any third person, or which may arise directly or indirectly out of or in respect of any Mimomax product, software or services or by reason of any act or omission on the part of Mimomax. CUSTOMER ACKNOWLEDGEMENT The customer acknowledges that: (a) if the Consumer Guarantees Act 1993 ("CGA") applies, this Warranty shall be read subject to customer's rights under the CGA. Where the customer uses the Equipment for business purposes, the provisions of CGA, or any other relevant consumer protection legislation, shall not apply; (b) the Equipment is not designed or intended for use in on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; intrinsically safe environments or in the design, construction, operation or maintenance of any nuclear facility. Mimomax disclaims any express or implied warranty of fitness for such uses. The customer will not use or resell Equipment for such purposes; (c) any software supplied by Mimomax cannot be tested in every possible permutation and accordingly Mimomax does not warrant that software supplied will be free of all defects or that its use will be uninterrupted. Product Manual for Tornado X and Tornado XR 4 Table of Contents 1 Tornado X System Overview........................................................................................................................... 9 1.1 Network Digital Links (NDL) .................................................................................................................... 9 1.2 Multipoint Digital Links (MDL) ................................................................................................................ 10 1.3 Optimize…

Text truncated - open the document above for the full version.

MiMOMaxWirelessLimited To: Federal Communications CommissionDate: 2023/02/08 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section2.911(d)(5)(ii) (KDB986446D01CoveredEquipment) MiMOMax Wireless Limited certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. MiMOMax Wireless Limited certifies that, as of the date of the filing of theapplication, the applicantis notidentified on the Covered Listas an entity producing “covered” equipment. Type of Equipment subject to FCC Certification:900MHz TornadoXR Transceiver FCC ID:XMK-MMXTRNXB003 If you have any questions, please feel free to contact me Contact Person:Paul Reid Position in the Company: CEO Date of Signature:2023-02-08 ___________________________ Signatory (signature of the applicant)

MiMOMax Wireless Limited To: Federal Communications CommissionDate: 2023/02/08 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Certification designating a U.S. Agent for Service of Process Section 2.911(d)(7) (KDB 986446 D01 Covered Equipment) MiMOMax Wireless Limitedas required by section 2.911(d)(7), designate below contact located in the United States for purposes of acting as the applicant’s agent for service of process. The applicantalso acceptance to maintain an agentfor no less than one year after the grantee hasterminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Type of Equipment subject to FCC Certification:900MHz TornadoXR Transceiver FCC ID:XMK-MMXTRNXB003 Sincerely yours, Applicant/GranteeUS Agent ____________________________________ (Signature)(Signature) MiMOMax Wireless LimitedMimomax Wireless Inc. Paul ReidFabian Deelen CEOGeneral Manager [email protected]@mimomax.com 4630 East Elwood Street, Suite 4, Phoenix, AZ 85040

MiMOMax Wireless Limited Date: 2022-12-05 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The MiMOMax Wireless Limited, the undersigned, hereby authorizesMiss. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the MiMOMax Wireless Limited solely in matters relating to the application for an FCC equipment authorization for FCC ID: XMK-MMXTRNXB003including the signing of documents in connection with this Application. Necessary acts carried outShenzhen Morlab Communications Technology Co., Ltd.on our behalf of the MiMOMax Wireless Limited in connection with the Application shall have the same effect as acts of the MiMOMax Wireless Limited. MiMOMax Wireless Limited also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Paul Reid Title: CEO Tel:+64-21-327-468 Email:[email protected] Company name: MiMOMax Wireless Limited

MiMOMaxWirelessLimited Date:2022-12-05 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality forFCC ID: XMK-MMXTRNXB003 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act,MiMOMax Wireless Limitedhereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might beharmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-TermConfidentiality for 180 days after the grant as outlined in Public Notice DA04-1705. This provision will giveMiMOMax Wireless Limitedtemporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listedas follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription PERMANENT 1Block Diagram 2Operational Description 3Schematics 4BOM 5Tuneupprocedure SHORT-TERM 6External Photos 7Internal Photos 8Test-Setup Photos 9User Manual The Applicant understands that pursuantto Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory: Name:Paul Reid Company name:MiMOMax Wireless Limited Address:540 Wairakei Road, Christchurch 8053, New Zealand Tel: +64-21-327-468 Email: [email protected]

FCC ID: XMK-MMXTRNXB003 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

Label： Location： BackView

FCC ID: XMK-MMXTRNXB003 Internal Photos 1. EUT uncover view 2. Antenna view Antenna

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen ,GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 36 REPORT No.：SZ22110153E01 TEST REPORT APPLICANT : MiMOMax Wireless Limited PRODUCT NAME : 900MHz TornadoXR Transceiver MODEL NAME : MWL-TORNADOX-*G*A/B/C BRAND NAME : MiMOMax Wireless FCC ID : XMK-MMXTRNXB003 STANDARD(S) : 47 CFR Part 15 Subpart A and B RECEIPT DATE : 2022-11-30 TEST DATE : 2023-01-10 ISSUE DATE : 2023-02-03 Edited by: Chen Bilian(Rapporteur) Approved by: Xiao Xiong(Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen ,GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 36 REPORT No.：SZ22110153E01 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1. Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2. Equipment Under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 2. Test Results ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2.1. Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2.2. EUT Setup and Operating Conditions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. 47 CFR Part 15B Requirements ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 3.1. Conducted Emission ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 3.2. Radiated Emission ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 3.3. Antenna Terminal Disturbance ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 20 Annex A Test Uncertainty ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 33 Annex B Testing Laboratory Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 34 Change History Version Date Reason for change 1.0 2023-02-03 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen ,GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 36 REPORT No.：SZ22110153E01 1. Technical Information Note: Provide by applicant 1.1. Applicant and Manufacturer Information Applicant: MiMOMax Wireless Limited Applicant Address: 540 Wairakei Road, Christchurch 8053, New Zealand Manufacturer: MiMOMax Wireless Limited Manufacturer Address: 540 Wairakei Road, Christchurch 8053, New Zealand 1.2. Equipment Under Test (EUT) Description Product Name: 900MHz TornadoXR Transceiver EUT No.: 1# Hardware Version: P001 Software Version: TRN_04.08.00.HPT76 Frequency Range: 901 MHz ~902MHz; 930 MHz ~931MHz; 940 MHz ~941 MHz Operating Voltage: 10.5V~60V DC Note: For a more detailed description, please refer to specification or user’s manual supplied by the applicant and/or manufacturer. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen ,GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 36 REPORT No.：SZ22110153E01 2. Test Results 2.1. Applied Reference Documents The objective of the report is to perform testing according to 47 CFR Part 15 Subpart A and B: No. Identity Document Title 1 47 CFR Part 15 Radio Frequency Devices Test detailed items/section required by FCC rules and results are listed as below: No. Section Description Test Date Test Engineer Result Method Determination Remark 1 15.101 Equipment authorization requirement Receiver contained within a FCC Part 24 transceiver that has been certified. The receiver has therefore been verified. No deviation 2 15.103 Exempted devices Device is not exempt as it is a receiver that contains a digital device No deviation 3 15.107 Conducted Emission 2023.01.10 Fan Zehang PASS No deviation 4 15.109 Radiated Emissions 2023.01.10 Lin Jiayong PASS No deviation 5 15.111 Antenna Terminal Disturbance 2023.01.10 Fan Zehang PASS No deviation Note 1:Additions to, deviation, or exclusions from the method shall be judged in the “method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 2: TORNADOX TRANSCEIVER complies with FCC Part 15 Subparts A and B as a Class B Unintentional Radiator. Tests were performed according to the method of measurements prescribed in ANSI C63.4-2014. Note 3: When the test result is a critical value,we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen ,GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.m…

Text truncated - open the document above for the full version.

FCC ID: XMK-MMXTRNXB003 Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (30MHz-1GHz) 4. Radiated emission (above 1GHz)
