XR3-NOTE3Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E-reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Statement 3

ONYX INTERNATIONAL INC. Add: ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Tel: (86)0755-86966884 Fax: (86)0755-86966884 Date: 2020-09-08 Dear Sir/Madam, We, ONYX INTERNATIONAL INC. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E-reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet Model no.: Note3, Note3 Color, Note3 Pro, Note3 Plus, Note3 Lite, Note3 Color Plus, Note3 Color Pro Sincerely, Client’s name: Lifen Yu Company: ONYX INTERNATIONAL INC. Address: ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Phone: (86)0755-86966884 Fax: (86)0755-86966884 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/09/08 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name XR3-NOTE3 Note3, Note3 Color, Note3 Pro, Note3 Plus, Note3 Lite, Note3 Color Plus, Note3 Color Pro For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Lifen Yu Company: ONYX INTERNATIONAL INC. Address: ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Phone: (86)0755-86966884 Fax: (86)0755-86966884 E-Mail: [email protected]

ONYX INTERNATIONAL INC. ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Tel: (86)0755-86966884 Fax: (86)0755-86966884 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/8/2020 To whom it may concern: We, ONYX INTERNATIONAL INC.the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: XR3-NOTE3 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Lifen Yu Company: ONYX INTERNATIONAL INC. Address: ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Phone: (86)0755-86966884 Fax: (86)0755-86966884 E-Mail: [email protected]

ONYX INTERNATIONAL INC. ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Tel: (86)0755-86966884Fax: (86)0755-86966884 Date: 2020/09/08 FCC ID: XR3-NOTE3 Model Number: Note3, Note3 Color, Note3 Pro, Note3 Plus, Note3 Lite, Note3 Color Plus, Note3 Color Pro To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, ONYX INTERNATIONAL INC., declare that this EUT (FCC ID: XR3-NOTE3) doesn’t have Ad Hoc mode function on“non-US/Canada frequencies”. Inaddition.The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name: LifenYu Company: ONYX INTERNATIONAL INC. Address: ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Phone: (86)0755-86966884 Fax: (86)0755-86966884 E-Mail: [email protected]

FCC ID: XR3-NOTE3 FCC ID: XR3-NOTE3

FCC ID: XR3-NOTE3 FCC ID: XR3-NOTE3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: XR3-NOTE3 WIFI/BTAntenn a FCC ID: XR3-NOTE3 FCC ID: XR3-NOTE3

FCC ID: XR3-NOTE3 1) Standalone SAR test exclusion According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: 2) Manufacturing Tolerance Bluetooth GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.0 -1.0 0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -3.0 -3.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -3.0 -3.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 BLE 1Mbps GFSK Channel Channel 0 Channel 19 Channel 39 Target (dBm) -1.0 -1.0 0 Tolerance ±(dB) 1.0 1.0 1.0 BLE 2Mbps GFSK Channel Channel 0 Channel 19 Channel 39 Target (dBm) -1.0 -1.0 0 Tolerance ±(dB) 1.0 1.0 1.0 2.4GHz WLAN IEEE 802.11b (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 8.5 8.5 8.5 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11g (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 8.0 8.0 8.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11n(HT20) (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 8.0 8.0 8.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11n(HT40) (Peak) Channel Channel 03 Channel 06 Channel 09 Target (dBm) 8.0 8.0 8.0 Tolerance ± (dB) 1.0 1.0 1.0 5GHz WLAN 5GHz WLAN Band 1 5GHz WLAN Band 4 IEEE 802.11a (Average) Frequency (MHz) 5180 5200 5240 5745 5785 5825 Target (dBm) 6.0 6.0 6.0 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT20 (Average) IEEE 802.11n HT20 (Average) Frequency (MHz) 5180 5200 5240 5745 5785 5825 Target (dBm) 6.0 6.0 6.0 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT20 (Average) IEEE 802.11ac VHT20 (Average) Frequency (MHz) 5180 5200 5240 5745 5785 5825 Target (dBm) 6.0 6.0 6.0 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT40 (Average) IEEE 802.11n HT40 (Average) Frequency (MHz) 5190 5230 5755 5795 Target (dBm) 6.0 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT40 (Average) IEEE 802.11ac VHT40 (Average) Frequency (MHz) 5190 5230 5755 5795 Target (dBm) 6.0 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT80 (Average) IEEE 802.11ac VHT80 (Average) Frequency (MHz) 5210 5775 Target (dBm) 6.0 6.0 Tolerance ± (dB) 1.0 1.0 According to the output power measurement, and the tune-up statement by manufacturer, the calculated value can obtained. Mode Test Frequency (MHz) Minimum Separation Distance (mm) Max. Output Power (dBm) Output Power with tune up (dBm) Output Power (mW) calculated value exclusion thresholds BT 2480.00 5.0 -0.268 1.0 1.259 0.4 3 BLE 2480.00 5.0 -0.516 1.0 1.259 0.4 3 WIFI 2.4G 2437.00 5.0 9.21 9.5 8.913 2.8 3 WIFI 5G B1 5190.00 5.0 6.71 7.0 5.012 2.3 3 WIFI 5G B4 5755.00 5.0 6.65 7.0 5.012 2.4 3 3) Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20200828013-1-4-1 XR3-NOTE3 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Aug. 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : ONYX INTERNATIONAL INC. Address ............................................ : ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E- reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet Trade Mark ....................................... : BOOX Manufacturer ................................... : ONYX INTERNATIONAL INC. Model/Type reference....................... : Note3 Listed Models .................................. : See next page Ratings ............................................. : 5V3A Modulation ....................................... : CCK/DSSS, OFDM Hardware version ............................. : BOOX_M2_NOTE3_V0.2 Software version .............................. : V1.0 Frequency .......................................... From 2412MHz-2462MHz Result................................................ : PASS Report No.: GTS20200828013-1-4-1 Page 2 of 43 T E S T R E P O R T Test Report No. : GTS20200828013-1-4-1 Aug. 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E-reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet Model /Type : Note3 Listed Models : Note3 Color, Note3 Pro, Note3 Plus, Note3 Lite, Note3 Color Plus, Note3 Color Pro Applicant : ONYX INTERNATIONAL INC. Address : Room 301, No.215,Qiaozhongzhong Road, Liwan District, Guangzhou, Guangdong Province, China Manufacturer : ONYX INTERNATIONAL INC. Address : Room 301, No.215,Qiaozhongzhong Road, Liwan District, Guangzhou, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200828013-1-4-1 Page 3 of 43 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Test Sample 5 2.4 Equipment Under Test 5 2.5 Short description of the Equipment under Test (EUT) 5 2.6 EUT operation mode 6 2.7 Block Diagram of Test Setup 6 2.8 Special Accessories 6 2.9 Related Submittal(s) / Grant (s) 6 2.10 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 9 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 14 4.3 Maximum Conducted Output Power 21 4.4 Power Spectral Density 22 4.5 6dB Bandwidth 25 4.6 Out-of-band Emissions 28 4.7 Antenna Requirement 37 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 38 6 P H O T O S O F T H E E U T ........................................................... 39 Report No.: GTS20200828013-1-4-1 Page 4 of 43 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20200828013-1-4-1 Page 5 of 43 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : July 25, 2020 Testing commenced on : July 26, 2020 Testing concluded on : Aug. 20, 2020 2.2 Product Description Product Description: Smart E Ink Tablet, ePaper Ta…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20200828013-1-4-4 XR3-NOTE3 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Aug. 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : ONYX INTERNATIONAL INC. Address ............................................ : ROOM C301, BUILDING 2, #21 HEJING SOUTH ROAD, LIWAN DISTRICT, GUANGZHOU, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E- reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet Trade Mark ....................................... : BOOX Manufacturer ................................... : ONYX INTERNATIONAL INC. Model/Type reference....................... : Note3 Listed Models .................................. : See next page Ratings ............................................. : 5V3A Modulation ....................................... : GFSK Hardware version ............................. : BOOX_M2_NOTE3_V0.2 Software version .............................. : V1.0 Frequency .......................................... From 2402MHz to 2480MHz Result................................................ : PASS Report No.: GTS20200828013-1-4-4 Page 2 of 32 T E S T R E P O R T Test Report No. : GTS20200828013-1-4-4 Aug. 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E-reader Tablet, Eyes protection E Ink Tablet, E-paper Tablet, Color E Ink Tablet, Color ePaper Tablet Model /Type : Note3 Listed Models : Note3 Color, Note3 Pro, Note3 Plus, Note3 Lite, Note3 Color Plus, Note3 Color Pro Applicant : ONYX INTERNATIONAL INC. Address : Room 301, No.215,Qiaozhongzhong Road, Liwan District, Guangzhou, Guangdong Province, China Manufacturer : ONYX INTERNATIONAL INC. Address : Room 301, No.215,Qiaozhongzhong Road, Liwan District, Guangzhou, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200828013-1-4-4 Page 3 of 32 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Test Sample 5 2.4 Equipment Under Test 5 2.5 Short description of the Equipment under Test (EUT) 5 2.6 EUT operation mode 6 2.7 Block Diagram of Test Setup 6 2.8 Special Accessories 6 2.9 Related Submittal(s) / Grant (s) 6 2.10 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 30 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 31 6 P H O T O S O F T H E E U T ........................................................... 32 Report No.: GTS20200828013-1-4-4 Page 4 of 32 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20200828013-1-4-4 Page 5 of 32 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : July 25, 2020 Testing commenced on : July 26, 2020 Testing concluded on : Aug. 20, 2020 2.2 Product Description Product Description: Smart E Ink Tablet, ePaper Tablet, E-bag Tablet, E-book Tablet, E-reader Tablet, Eyes protection E I…

Text truncated - open the document above for the full version.

FCC ID: XR3-NOTE3
