XV6SS6560EcoTouch

EcoWave Featuring the EcoTouch Installation, Operation & Maintenance Guide Table of Contents Table of Contents ............................................................................................................... i Introduction...................................................................................................................... 1 Conventions Used in this Guide............................................................................................. 1 The EcoSmart Energy Managem ent System ............................................................................... 2 R eg ulato ry Com p lianc e ...................................................................................................... 2 Overview: EcoWave Remote Thermostat/Controller Pa ckage.......................................................... 3 EcoS our ce ........................................................................................................................ 5 Wiring .......................................................................................................................... 5 High/Low Vo ltage Optio ns .................................................................................................. 6 High Voltage Installation .................................................................................................... 6 Low Vo ltage Insta llation ................................................................................................... 14 Instructions Common to A ll Three Low Voltage Options .............................................................. 21 EcoTou ch ....................................................................................................................... 24 EcoTouch Location Pla nning .............................................................................................. 24 Installation .................................................................................................................. 26 EcoTou ch Gu es t S creen C ontro ls & Us er Inte rface..................................................................... 29 Device Association ............................................................................................................ 31 Pair EcoTouch with EcoSource............................................................................................ 31 EcoTouch Configura tion Changes ........................................................................................... 32 Change Channel ............................................................................................................ 32 Unpair EcoTou ch............................................................................................................ 32 Activate “Displa y Mode” O ption .......................................................................................... 32 System Status Screen ...................................................................................................... 32 Regular Maintenance ......................................................................................................... 33 T roub leshooting ............................................................................................................... 34 Troubleshooting ............................................................................................................... 35 Troubleshooting ............................................................................................................... 36 Index ......................................................................................................................... 37 Appendix A .................................................................................................................. 39 EcoWave Featur ing EcoTouch IO&M Guide Telkonet, Inc. For Use w ith Fir mw ar e Ver sion 2.x 20800 Sw enson Dr ive, Suite 175 Table of Contents Waukesha, WI 53186 Revision 2 (800) 380-9640 Page i www.telkonet.com Company Headquarters: Customer Support: EcoSmart Sales: Telkonet, Inc. (800) 380-9640 (888) 703-9398 20800 Swenson Drive Email: Email Suite 175 [email protected] [email protected] Waukesha, WI 53186 P (414) 223-0473 F (414) 258-8307 EcoWave Featur ing EcoTouch IO&M Guide Telkonet, Inc. For Use w ith Fir mw ar e Ver sion 2.x 20800 Sw enson Dr ive, Suite 175 Table of Contents Waukesha, WI 53186 Revision 2 (800) 380-9640 Page ii www.telkonet.com Introduction Conv entions Used in this Guide This is an informational tip, used to convey relevant but not necessarily urgent information. This is a warning, used to convey important information. This is a strong warning, used to convey urgent and often safety-related information. Chapter Names Main chapters in this manual will have headings in large green font as shown above. Main chapter names also appear in the footer. Sub-C h ap ter Na me s Within the main chapters will be relevant sub-chapters, which are presented with bold, black headings as shown above. Footers Footers contain the document name, chapter name, document version number and page number, as shown here: Pro c edure: Ste ps De scribed He re Procedural Steps are indicated as such in the heading, which begins with the word, “Pro c edure:” as shown above. The steps are outlined as shown in the following example: Ste p 1 Navigate to the Config Menu > Alert Setup. Ste p 2 C li c k t h e A dd Ne w A lert Trigger button in the top left corner of the Alert Setup Screen. Ste p 3 Enter a descriptive A lert Name . Introducing a New Screen When a screen is introduced, a screen print is provided. Below the screen print will be its location and an explanation of the screen’s intended purpose as shown in this example: Sc reen and Tab Names Screen and Tab names are underlined, as shown in this example: The Thermostat Status Screen shows all rooms and their status information at a glance. Field Names Field names appear in bold font;…

Text truncated - open the document above for the full version.

Size: 20x4mm

SAR Exclusion Justification This device FCC ID: is excluded from SAR testing by the following justification The maximum power that the transmitter is capable of is 1.22 mW Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 100.00% V alue 1-g (mW) 10-g (mW) 0.38 (355) -212 "Value" is  3 , the SAR test exclusion threshold 1-g power limit 10-g power limit 95 238 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission < 50mm power limits for above caclulation using specified frequency XV6SS6560 Max Peak Power (dBm) Min Separation distance (mm) Frequency (Ghz) When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.48 5 0.86 SAREXJUST-B-0-43 REV A 01/21/2014

Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 18 FCC PART 15, SUBPART B and C TEST REPORT for ECOTOUCH MODEL: SS6560 Prepared for TELKONET, INC. 10200 INNOVATION DRIVE, SUITE 300 MILWAUKEE, WISCONSIN 53226 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: AUGUST 28, 2015 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 2 20 40 84 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - Emissions 9 4.1.1 Cable Constructions and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab B 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test – Lab D 15 7.1.3 Conducted Emissions Test 16 7.1.4 RF Emissions Test Results 17 8. CONCLUSIONS 18 Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Site 3 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES FIGURE TITLE 1.0 Conducted Emissions Test Results 2.0 Radiated Emissions Test Results Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 18 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: EcoTouch Model: SS6560 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during testing. Customer: Telkonet, Inc. 10200 Innovation Drive, Suite 300 Milwaukee, Wisconsin 53226 Test Dates: July 22 and 23, 2015 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 18 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 10 kHz – 25,000 MHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209 and 15.249 2 Conducted RF Emissions, 150 kHz to 30 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207 Report Number: B50723D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EcoTouch Model: SS6560 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (…

Text truncated - open the document above for the full version.

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE TELKONET, INC. ECOTOUCH MODEL: SS6560, FCC ID: XV6SS6560 The fundamental was maximized on the Lab B test site using a normal test setup with the AC Adapter of the laptop connected directly to the AC public mains (115 Vac). Next, the power supply of the EUT was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The AC Adapter of the laptop was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: DM25XT, Serial Number: 40209875, Calibration Due Date: May 27, 2016. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.
