XVE-TRX1029TQi RADIO SYSTEM

Visite la página TRAXXAS.com/manuals para descargar el Manual del usuario en su idioma. Auf TRAXXAS.com/manuals können Sie eine Bedienungsanleitung in Ihrer Sprache downloaden. owner ’ s manual manuel du propriétaire MODELS / MODÈLES 6507R, 6509R 2 • TQ i RADIO SYSTEM Important Radio System Precautions• For maximum range, always point the front of the transmitter toward the model. • Do not kink the receiver’s antenna wire. Kinks in the antenna wire will reduce range. • DO NOT CUT any part of the receiver’s antenna wire. Cutting the antenna will reduce range. • Extend the antenna wire in the model as far as possible for maximum range. It is not necessary to extend the antenna wire out of the body, but wrapping or coiling the antenna wire should be avoided. • Do not allow the antenna wire to extend outside the body without the protection of an antenna tube, or the antenna wire may get cut or damaged, reducing range. It is recommended to keep the wire inside the body (in the antenna tube) to prevent the chance of damage. • To prevent loss of radio range do not kink or cut the black wire, do not bend or cut the metal tip, and do not cut the white wire at the end of the metal tip. Warranty InformationTraxxas warrants your Traxxas electronic components to be free from defects in materials or workmanship for a period of thirty (30) days from the date of purchase. Before returning any product for warranty service, please contact our service department at 1-888-TRAXXAS ( U.S. residents only ) to discuss the problem you are having with the product. After contacting Traxxas, send the defective unit along with your proof of purchase indicating the date purchased, your return address, e-mail, a daytime phone number, and a brief description of the problem to:Traxxas, 6250 Traxxas Way, McKinney, Texas 75070 Phone: 972-549-3000 Internet: Traxxas.com E-mail: [email protected] Detailed Limitations for Electronic Components: • Allowing water, moisture, or other foreign material to enter the component or get onto the PC board. • Exceeding the maximum input voltage of the electronic component. • Reverse voltage application.• Incorrect installation or wiring.• Components worn from use.• Splices to the input or switch harnesses.• Disassembling the case.• Excessive force when adjusting, pressing, or turning any of the controls. • Tampering with the internal electronics.• Incorrect wiring of an FET servo.• Allowing exposed wiring to short circuit.• Any damage caused by crash, flooding, or act of God.LimitationsAny and all warranty coverage does not cover replacement of parts and components damaged by abuse, neglect, improper or unreasonable use, crash damage, water or excessive moisture, chemical damage, improper or infrequent maintenance, accident, unauthorized alteration or modification, or items that are considered consumable. Traxxas will not pay for the cost of shipping or transportation of a defective component from you to us. Limitations of LiabilityTraxxas makes no other warranties expressed or implied. Traxxas shall not be liable for any special, indirect, incidental, or consequential damages arising out of the assembly, installation, or use of their products or any accessory or chemical required to use their products. By the act of operating/using the product, the user accepts all resulting liability. In no case shall Traxxas’ liability exceed the actual purchase price paid for the product. Traxxas reserves the right to modify warranty provisions without notice. All warranty claims will be handled directly by Traxxas. The Traxxas warranty gives the customer specific legal rights and possibly other rights that vary from state to state. All dollar amounts stated are in United States WARRANTY AND PRECAUTIONS Entire contents ©2019 Traxxas. Other brand names and marks are the property of their respective holders and are used only for purposes of identification. No part of this manual may be reproduced or distributed in print or electronic media without the express written permission of Traxxas. Specifications are subject to change without notice. 1/16 Models All Other Traxxas Models No No 4 TRANSMITTER AND RECEIVER 5 GETTING STARTED Basic Adjustments ........................5 Battery Installation .......................6 Model Profiles ................................6 7 USING THE RADIO SYSTEM Range Testing ................................7 Binding Instructions .....................8 Traxxas Stability Management ..8 9 ADVANCED TUNING GUIDE Available Tuning Adjustments ... 9 Traxxas Link Wireless Module ..12 Transmitter LED Codes ...............14 Traxxas Link Model Memory .....15 16 MENU TREE5 TQ i RADIO SYSTEM • 3 dollars. The term “lifetime” shall refer to the product’s production life at Traxxas. Traxxas is not obligated to provide upgraded products at a reduced rate when a previous product’s production cycle has ended.Traxxas encourages you to register your model online at Traxxas.com/register.Traxxas Lifetime Electronics WarrantyAfter the expiration date of the free warranty period, Traxxas will repair electronic components for a flat rate. The electronic products covered by this extended service plan include electronic speed controls, transmitters, receivers, servos, and battery chargers. Motors, batteries, and mechanical speed controls are not covered. The covered repairs are limited to non-mechanical components that have NOT been subjected to abuse, misuse, or neglect. Products damaged by intentional abuse, misuse, modification, or neglect, may be subject to additional charges. Visit Traxxas.com or call 1-888-TRAXXAS (1-888-872-9927) for details on extended warranty service and rates.FCC ComplianceThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 External Photos for SZEM1906015331CR FCC ID: XVE-TRX1029 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 EUT Constructional Details Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

Label 1: Label 2: Location 1: Location 2:

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 2 Internal Photos for SZEM1906015331CR FCC ID: XVE-TRX1029 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 2 1 EUT Constructional Details

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533101 Page: 1 of 60 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM1906015331CR Applicant: Traxxas LP Address of Applicant: 6250 Traxxas Way Mckinney, Tx 75070, USA Manufacturer: JASON TOYS & ELECTRONICES CO., LTD Address of Manufacturer: NO.133 Wugong Road, Wugu District, New Taiei City 24886, Taiwan Equipment Under Test (EUT): EUT Name: TQi RADIO SYSTEM Model No.: 6533B Trade mark: Traxxas FCC ID: XVE-TRX1029 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2019-06-18 Date of Test: 2019-06-19 to 2019-06-28 Date of Issue: 2019-07-02 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533101 Page: 2 of 60 Revision Record Version Chapter Date Modifier Remark 01 2019-07-02 Original Authorized for issue by: Harry Wu /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533101 Page: 3 of 60 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Carrier Frequencies Separation 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533101 Page: 4 of 60 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 DETAILS OF E.U.T. ............................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 6 4.4 TEST LOCATION .................................................................................................................................... 7 4.5 TEST FACILITY ...................................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ............................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 7 5 EQUIPMENT LIST ...................................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 12 6.1 ANTENNA REQUIREMENT .................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................... 12 6.2 OTHER REQUIREMENTS FREQUENCY HOPPING SPREAD SPECTRUM SYSTEM HOPPING SEQUENCE ........ 13 6.2.1 Test Requirement: ....................................................................................................................... 13 6.2.2 Conclusion ................................................................................................................................... 13 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 15 7.1 CONDUCTED PEAK OUTPUT POWER .................................................................................................... 15 7.1.1 E.U.T. Operation ...................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 1 of 7 Keny Xu EMC Laboratory Manager 1 Cover page SAR Evaluation Report Application No.: SZEM1906015331CR Applicant: Traxxas LP Address of Applicant: 6250 Traxxas Way Mckinney, Tx 75070, USA Manufacturer: JASON TOYS & ELECTRONICES CO., LTD Address of Manufacturer: NO.133 Wugong Road, Wugu District, New Taiei City 24886, Taiwan Equipment Under Test (EUT): EUT Name: TQi RADIO SYSTEM Model No.: 6533B Trade mark: Traxxas FCC ID: XVE-TRX1029 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2019-06-18 Date of Test: 2019-06-19 to 2019-06-28 Date of Issue: 2019-07-02 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 2 of 7 2 Version Revision Record Version Chapter Date Modifier Remark 01 2019-07-02 Original Authorized for issue by: Harry Wu /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 3 of 7 3 Contents Page 1 COVER PAGE .............................................................................................................................................. 1 2 VERSION ...................................................................................................................................................... 2 3 CONTENTS .................................................................................................................................................. 3 4 GENERAL INFORMATION .......................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION ...................................................................................................................................... 5 4.3 TEST FACILITY ........................................................................................................................................ 5 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 6 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 6 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ............................................................................. 6 5 SAR EVALUATION ...................................................................................................................................... 7 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................ 7 5.1.1 Standard Requirement ..................................................................................................................... 7 5.1.2 Limits ................................................................................................................................................ 7 5.1.3 EUT RF Exposure ............................................................................................................................ 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 4 of 7 4 General Information 4.1 General Description of EUT Power supply: DC 6.0V(4 x 1.5V "AA" Batteries) System: Frequency hopping system & Digital modulation technique Operation Frequency: 2414-2453MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 1MHz Antenna Type: Integral Antenna Antenna Gain: 0dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 5 of 7 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0006. IC#: 4620C. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 6 of 7 4.4 Deviation from Standards None. 4.5 Abnormalities from Standard Conditions None. 4.6 Other Information Requested by the Customer None. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM190601533103 Page: 7 of 7 5 SAR Evaluation 5.1 RF Exposure Compliance Requirement 5.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 2 Setup Photos for SZEM1906015331CR FCC ID: XVE-TRX1029 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 2 1 Photographs 1.1 Radiated Spurious Emissions Test Setup
