XWBEB60MID EBOOK READER

TEL: +86 (755) 8179 ‐ 0960 FAX: +86 (755) 8179 ‐ 408 Model No. EB60 Demension 216mm(L) × 143 mm(W) × 15mm(H) Function Electronic Book Reader Music Player VIDEO Player Web Browser File Explorer Office Viewer (Words,Excel, PPT) Colour Photo Viewer CalendarCalculatorGamesPAGE JUMP BOOKMARK, SAVE BOOKMARK, DELETE BOOKMARK FONT SIZE ZOOMING, FONT Colour Changing SDK & API (Linux) provided Processor ARM 11 (Samsung) S3C6410 667MHz/FBGA ‐ 424 Operating System Mameo OS 2008 RAM 128MB Mode of Operation Buttons & Touch Panel Interaction Touch Screen LCD Screen Type TFT Resolution 800 x 480 pixels Dimension 7.0 Inch Diagonal Driver Element aSi TFT active Matrix Display Mode Normally White Transmissive Dot Pitch 0.0635 W x 0.1905 H mm Active Area 152.4 W x 91.44 H mm Module Size 165 W x 104.44 H x 5.3 D mm Surface Treatment Anti Glare Color Arrangement RGB stripe Interface Digital MemoryVIGORHOOD PHOTOELECTRIC SHENZHEN CO., LTD. HongFa Tech Industrial Park ， Shiyan Town, Baoan District, Shenzhen, P.R. China ELECTRONIC BOOK READER SPECIFICATIONS Internal Memory 1 GB External Memory T ‐ Flash/MicroSD card Support Up to 16GB Content Format Supported E Book Formats EPUB/FB2/plucker/Mobipocket/Open E ‐ Book/OpenReader/html/txt/chm/rtf/doc Adobe DRM Supported (Epub & PDF) Image Formats JPEG, BMP, GIF, BMP Music Formats MP3 (8Kbps~320Kbps), WMA (5Kpbs~320Kbps), MIDI, WAV, OGG and AAC Video Format MPEG4 (AVI), FLV, RMVB, FLV, WMV Audio Audio Output 3.5 MM STEREO AUDIO JACK, REAR ‐ MOUNTED STEREO SPEAKERS, BUILT ‐ IN MICROPHONE Repeat Modes Once, Repeat One, All Once, All Repeat Playback Modes Order, Shuffle Audio Display Information ID3 SUPPORTED ( a ll ows tit l e, artist, a lb um, trac k num b er, an d ot h er in f ormation a b out t h e f i l e to be stored in the file itself) Battery Battery Type Built in Li Polymer (3500 mAH) Support APO ‐ Auto Power Off Battery Life 4 Hrs Charge Time approx. 4 hours AUTO POWER ‐ OFF TIMINGS A UTO POWER-OFF ： OFF ， 3M ， 5M ， 10M ， 15M ， 20M Device Voltage 5V Current 500 mAh Power 2.5W Frequency 667 mhz Supported Languages English, Simplified Chinese, Dutch, Spanish, Italian, Portugese, French and German Connectivity Connectivity 1 WiFi 802.11b/g Documentation User Manual Provided Others USB INTERFACE Mini USB2.0 POWER INPUT DC IN （ DC 5.0V/2.0A ） In Accessories Mini USB2.0 Cable (Data Transfer) and AC Adapter (Battery Charging) FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not caus e harmful interference, and (2) this device must accept any interference received, in cluding interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communicatio ns. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harm ful interference to radio or te levision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications not expressly approved by the manufacturer could void the us er’s authority to operate the equipment. NOTE 3: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equip ment. Such modifications could void the user’s authority to operate the equipment.

55 44 33 22 11 D D C C B B A A TitleSize Document Number Rev Date: Sheet of Tiltle V1.0 EB60-V1.0 A 113 Tuesday, April 20, 2010 TitleSize Document Number Rev Date: Sheet of Tiltle V1.0 EB60-V1.0 A 113 Tuesday, April 20, 2010 TitleSize Document Number Rev Date: Sheet of Tiltle V1.0 EB60-V1.0 A 113 Tuesday, April 20, 2010 01. Tiltle02. CPU IO03. CPU (Addr,Data)04. CPU (Power)05. CPU (Function)06. DDR07. Booting Clock08. Nand TF_card USB09. Display10. Audio11. WIFI12. Power 13.KEY Connect S3C6410 DDR 64M*8DDR 64M*8 NAND 2GMMC1 TF Card USB OTG WIFI USB1.1 IIS Audio 7 TFT Lcd

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: XWBEB60 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Contain FCC ID: WABWTUSB2070 Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: XWBEB60 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Contain FCC ID: WABWTUSB2070 Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View Solder Board-Component View 1 Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B Solder Board-Component View 2 Solder Board-Component View 3 Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B Solder Board-Component View 4 Solder Board-Component View 5 Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B Solder Board-Component View 6

Circuit Description 1. The IC-S3C6410 is master micro controller, it include U2A, U2B, U2C, U2D four part, the oscillate component X1, X2, X3, X4 shall generate a 32.768kHz, 12MHz, 27MHz, 48MHz clock frequency, and input to micro controller as base clock signal. 2. The IC-K4H511638D is SDRAM memory, and the U13, U6 is TF card, U8 is nona flash, it can storage a lot of data file, for example the music file, word file etc, its capability is 2G byte. 3. The mobile internet terminal device, with Wi-Fi communications technology, TF card, 7” TFT LCD display, touch panel, USB port and connect to PC etc. function, and headphone output. 4. The work voltage is DC 3.7V, supply by battery and a DC 5V USB power or external supply by power adapter.

55 44 33 22 11 D D C C B B A A XEINT15XEINT13XEINT14 XEINT4 XnRESETXEINT4 XTRSTnXTMSXTCKXTDIXTDOXRTCK XREXT XEXTCLK XnRESET VDD_3V3 VDD_3V3 VDD_3V3 VDD_3V3 VDD_3V3 VDD_3V3 VDD_3V3 VDD_3V3 XusbhDP 11 XusbhDM 11 XnRESET XTDO 7 CHGSTAT_gpn0 12 XVBUS 13 XotgID 13 XotgTI 7 XTRSTn 7 XTMS 7 XSELNAND 7 XnRSTOUT 7 XTCK 7 XOM4 7 XOM3 7 XOM2 7 XOM1 7 XOM0 7 XDBGSEL 7 UART0_RXD 7 UART0_TXD 7 xotgDP 13 xotgDM 13 XotgTO 7 LAN_INT 7 POKEY_DET_gpn1 12DC_DET_gpn2 12POWER_gpn7 12XXTI 7 X27MXTI 7 XPWRRGTON 12XrtcXTI 7 XXTO 7 Xmmc1_CLK 8 Xmmc1_CMD 8 Xmmc1_DATA0 8 Xmmc1_DATA1 8 Xmmc1_DATA2 8 Xmmc1_DATA3 8 X27MXTO 7 XrtcXTO 7 Xmmc1_CDN 8 XRTCK 7 BACKLIHT_pwm1 9 XTDI 7 WIFI_KEY_gpn9 12 WIFI_EN_gpc7 11 i2sDO 10 i2sDI 10 i2sLRCK 10 i2sCDCLK 10 I2sCLK 10 Xi2cSCL 8,10 Xi2cSDA 8,10 S_INT_gpn12 8 TitleSize Document Number Rev Date: Sheet of CPU (IO) V1.0 EB60-V1.0 A3 213 Friday, September 10, 2010 TitleSize Document Number Rev Date: Sheet of CPU (IO) V1.0 EB60-V1.0 A3 213 Friday, September 10, 2010 TitleSize Document Number Rev Date: Sheet of CPU (IO) V1.0 EB60-V1.0 A3 213 Friday, September 10, 2010 0 active GPN2 未使用 改用 GPL9 0 active 0 active C10.1uF/50VC10.1uF/50V R1 100K/5% R1 100K/5% TP1TP1 C21uF/25VC21uF/25V R6 100K/5% R6 100K/5% U2BS3C6410U2BS3C6410 XuRXD0/GPA0 D20 XuTXD0/GPA1 A23 XuCTSn0/GPA2/ADDR_CF0 G16 XuRTSn0/GPA3/ADDR_CF1 A22 XuRXD1/GPA4 J15 XuTXD1/GPA5 B22 XuCTSn1/GPA6/ADDR_CF0 H15 XuRTSn1/GPA7/ADDR_CF1 C22 XuRXD2/ExdREQ/IrRXD/GPB0/ADDR_CF0 D19 XuTXD2/ExdACK/IrTXD/GPB1/ADDR_CF1 A21 XuRXD3/IrRXD/ExdREQ/GPB2/ADDR_CF2 J14 XuTXD3/IrTXD/ExdACK/GPB3 B21 XirSDBW/BUF_DIR/GPB4 G15 Xi2cSCL/GPB5 A20 Xi2cSDA/GPB6 G14 XspiMISO0/ADDR_CF0/GPC0 B20 XspiCLK0/ADDR_CF1/GPC1 H14 XspiMOSI0/ADDR_CF2/GPC2 A19 XspiCS0/GPC3 C20 XspiMISO1/mmcCMD2/GPC4 B19 XspiCLK1/mmcCLK2/GPC5 H12 XspiMOSI1/GPC6 C19 XspiCS1/GPC7 D17 XusbDP N22 XusbDN P22 XotgDP AE10 XotgDM AE9 XotgTI AD7 XotgTO AD8 XREXT AC8 XVBUS AD9 XotgID AD10 XotgDRV_VBUS AE11 XmmcCLK0/ADDR_CF0/GPG0 A18 XmmcCMD0/ADDR_CF1/GPG1 G13 XmmcDATA0_0/ADDR_CF2/GPG2 B18 XmmcDATA0_1/GPG3 H13 XmmcDATA0_2/GPG4 C18 XmmcDATA0_3/GPG5 G12 XmmcCDN0/mmcCDN1/GPG6 A17 XmmcCLK1/kpCOL0/ADDR_CF0/GPH0 J11 XmmcCMD1/kpCOL1/ADDR_CF1/GPH1 A16 XmmcDATA1_0/kpCOL2/ADDR_CF2/GPH2 H11 XmmcDATA1_1/kpCOL3/GPH3 C17 XmmcDATA1_2/kpCOL4/GPH4 B16 XmmcDATA1_3/kpCOL5/GPH5 H10 XmmcDATA1_4/mmcDATA2_0/kpCOL6/ADDR_CF0/GPH6 A15 XmmcDATA1_5/mmcDATA2_1/kpCOL7/ADDR_CF1/GPH7 G11 XmmcDATA1_6/mmcDATA2_2/ADDR_CF2/GPH8 C16 XmmcDATA1_7/mmcDATA2_3/GPH9 H9 XpcmDCLK0/i2sCLK/BITCLK/ADDR_CF0/GPD0 D7 XpcmEXTCLK0/i2sCDCLK/RESETn/ADDR_CF1/GPD1 B5 XpcmFSYNC0/i2sLRCK/SYNC/ADDR_CF2/GPD2 D6 XpcmSIN0/i2sDI/SDI/GPD3 B4 XpcmSOUT0/i2sDO/SDOGPD4 A3 XpcmDCLK1/i2sCLK/BITCLK/GPE0 C5 XpcmEXTCLK1/i2sCDCLK/RESETn/GPE1 B3 XpcmFSYNC1/i2sLRCK/SYNC/GPE2 C4 XpcmSIN1/i2sDI/SDI/GPE3 B2 XpcmSOUT1/i2sDO/SDO/GPE4 C3 XEINT0/kpROW0/GPN0 AE17 XEINT1/kpROW1/GPN1 V10 XEINT2/kpROW2/GPN2 AD17 XEINT3/kpROW3/GPN3 AB17 XEINT4/kpROW4/GPN4 AE18 XEINT5/kpROW5/GPN5 AC18 XEINT6/kpROW6/GPN6 V11 XEINT7/kpROW7/GPN7 AC19 XEINT8/ADDR_CF0/GPN8 W12 XEINT9/ADDR_CF1/GPN9 AE19 XEINT10/ADDR_CF2/GPN10 AB18 XEINT11/GPN11 AD19 XEINT12/GPN12 V12 XEINT13/GPN13 AE20 XEINT14/GPN14 W13 XEINT15/GPN15 AD20 XpwmTOUT1/GPF15 D23 XpwmTOUT0/SCLKOUT/GPF14 H16 XpwmECLK/GPF13 C23 XrtcXTI AB9 XrtcXTO AD12 X27MXTI AB15 X27MXTO AB14 XXTI AC16 XXTO AC17 XEXTCLK W11 XnRSTOUT AD16 XWRESET AD15 XnRESET V9 XEFFVDD T7 XSELNAND AB16 XnBATF AE15 XPWRRGTON AD14 XOM0 AD13 XOM1 W9 XOM2 AC13 XOM3 V8 XOM4 AE14 XTRSTn AB10 XTMS AE12 XTCK AB11 XTDI AB12 XTDO AC12 XRTCK AE13 XDBGSEL AB13 U1NC/DS2431U1NC/DS2431 GND 1 I/O 2 NC2 3 NC1 4 NC0 5 VDD 6 R1044.2R/1%R1044.2R/1% R9 100K/5% R9 100K/5% R41K/5%R41K/5% 12 R30R/5%R30R/5% 12 R8 100K/5% R8 100K/5% R5 100K/5% R5 100K/5% TP2TP2 R7 100K/5% R7 100K/5% R2 100K/5% R2 100K/5% 55 44 33 22 11 D D C C B B A A Xm1ADDR12Xm1ADDR11Xm1ADDR10Xm1ADDR9Xm1ADDR8Xm1ADDR7Xm1ADDR6Xm1ADDR5Xm1ADDR4Xm1ADDR3Xm1ADDR2Xm1ADDR1Xm1ADDR0 Xm1DATA31 Xm1DATA30 Xm1DATA29 Xm0ADDR2 Xm1DATA28 Xm1DATA27 Xm1DATA26 Xm0DATA0Xm0DATA1Xm0DATA2 Xm1DATA25 Xm1DATA24 Xm1DATA23 Xm0DATA3Xm0DATA4Xm0DATA5Xm0DATA6Xm0DATA7Xm0DATA8Xm0DATA9 Xm1DATA22 Xm1DATA21 Xm1DATA20 Xm0DATA10Xm0DATA11Xm0DATA12Xm0DATA13Xm0DATA14Xm0DATA15 Xm1DATA19 Xm1DATA18 Xm1DATA17 Xm1DATA16 Xm1DATA15 Xm1DATA14 Xm1DATA13 Xm1DATA12 Xm1DATA11 Xm1DATA10 Xm1DATA9 Xm1DATA8 Xm1DATA7 Xm1DATA6 Xm1DATA5 Xm1DATA4 Xm1DATA3 Xm1DATA2 Xm1DATA1 Xm1DATA0 Xm1ADDR15Xm1ADDR14 Xm0CSn2 8 Xm0CSn3 8 Xm0RDY0/ALE 8 Xm0RDY1/CLE 8 Xm0INTsm0/FWEn 8 Xm0INTsm1/FREn 8 Xm0RPn/RnB 8 Xm0WEn/nIOWR_CF 7 Xm1DQS3 6 Xm1DQS2 6 Xm1DQS1 6 Xm1DQS0 6 Xm1DQM3 6 Xm1DQM2 6 Xm1DQM1 6 Xm1DQM0 6 Xm0CSn1 7 Xm1WEn 6 Xm1CASn 6 Xm1RASn 6 Xm1SCLKn 6 Xm1SCLK 6 Xm1CKE0 6 Xm0ADDR2 7 Xm1DATA[31:0] 6 Xm0DATA[15:0] 7,8 Xm1ADDR[12:0] 6 Xm0OEn/nIORD_CF 7 Xm1CSn0 6 Xm1ADDR15 6Xm1ADDR14 6 TitleSize Document Number Rev Date: Sheet of addr Data V1.0 EB60-V1.0 A3 313 Saturday, June 26, 2010 TitleSize Document Number Rev Date: Sheet of addr Data V1.0 EB60-V1.0 A3 313 Saturday, June 26, 2010 TitleSize Document Number Rev Date: Sheet of addr Data V1.0 EB60-V1.0 A3 313 Saturday, June 26, 2010 TP4TP4 U2AS3C6410U2AS3C6410 Xm0ADDR0 C1 Xm0ADDR1 E3 Xm0ADDR2 D1 Xm0ADDR3 D2 Xm0ADDR4 H7 Xm0ADDR5 E1 Xm0ADDR6/GPO6 F2 Xm0ADDR7/GPO7 G4 Xm0ADDR8/GPO8 F1 Xm0ADDR9/GPO9 J8 Xm0ADDR10/GPO10 G2 Xm0ADDR11/GPO11 G1 Xm0ADDR12/GPO12 H4 Xm0ADDR13/GPO13 H2 Xm0ADDR14/GPO14 J4 Xm0ADDR15/GPO15 H3 Xm0DATA0 N2 Xm0DATA1 N1 Xm0DATA2 M7 Xm0DATA3 N3 Xm0DATA4 M8 Xm0DATA5 P2 Xm0DATA6 N4 Xm0DATA7 P3 Xm0DATA8 M2 Xm0DATA9 M4 Xm0DATA10 L7 Xm0DATA11 M3 Xm0DATA12 L8 Xm0DATA13 L2 Xm0DATA14 K4 Xm0DATA15 K1 Xm0OEn/nIORD_CF L4 Xm0WEn/nIOWR_CF J2 Xm0ADV/GPP0 Y2 Xm0SMCLK/GPP1 L3 Xm0CSn0 N7 Xm0CSn1 R3 Xm0CSn2/GPO0 P4 Xm0CSn3/GPO1 R2 Xm0CSn4/GPO2 T3 Xm0CSn5/GPO3 N8 Xm0CSn6/GPO4 T2 Xm0CSn7/GPO5 P7 Xm0WAITn/IORDY/GPP2 R4 Xm0RDY0/ALE/GPP3 R8 Xm0RDY1/CLE/GPP4 W2 Xm0INTsm0/FWEn/GPP5 Y3 Xm0INTsm1/FREn/GPP6 U4 Xm0RPn/RnB/GPP7 Y1 Xm0INTata/GPP8 R7 Xm0RSTata/GPP9 W3 Xm0INPACKata/GPP10 AA2 Xm0REGata/GPP11 AA3 Xm0WEata/GPP12 V4 Xm0OEata/GPP13 AB3 Xm0CData/GPP14 U7 Xm0DQM0/BE0 L1 Xm0DQM1/BE1 K7 X…

Text truncated - open the document above for the full version.

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I PAGE 1 OF 15 FCC PART 15B FCC PART 15B MEASUREMENT AND TEST REPORT FOR Vigorhood Photoelectric Shenzhen Co., Ltd F Building, Hongfa Tech Industrial Park, Songbai Rd. Shiyan Town, Baoan District, Shenzhen, China FCC ID: XWBEB60 Report Concerns: Original Report Equipment Type: MID Ebook Reader Model: EB 60 Report No.: STR10108173I Test Date: 2010-10-23 to 2010-11-06 Issue Date: 2010-11-22 Tested By: Silin Chen / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: SEM.Test Compliance Service Co., Ltd 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by SEM.Test Compliance Service Co., Ltd . Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I PAGE 2 OF 15 FCC PART 15B TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)...............................................................................3 1.2 TEST STANDARDS...................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S) .......................................................................................................................3 1.4 TEST METHODOLOGY.............................................................................................................................................4 1.5 TEST FACILITY.......................................................................................................................................................4 1.6 EUT EXERCISE SOFTWARE....................................................................................................................................4 1.7 ACCESSORIES EQUIPMENT LIST AND DETAILS.......................................................................................................4 1.8 EUT CABLE LIST AND DETAILS.............................................................................................................................4 2. SUMMARY OF TEST RESULTS ...........................................................................................................................5 3. §15.107 (A)- CONDUCTED EMISSION .................................................................................................................6 3.1 MEASUREMENT UNCERTAINTY..............................................................................................................................6 3.2 TEST EQUIPMENT LIST AND DETAILS.....................................................................................................................6 3.3 TEST PROCEDURE...................................................................................................................................................6 3.4 BASIC TEST SETUP BLOCK DIAGRAM.....................................................................................................................6 3.5 ENVIRONMENTAL CONDITIONS..............................................................................................................................7 3.6 TEST RECEIVER SETUP...........................................................................................................................................7 3.7 SUMMARY OF TEST RESULTS/PLOTS......................................................................................................................7 4. §15.109(A)- RADIATED EMISSION ....................................................................................................................10 4.1 MEASUREMENT UNCERTAINTY............................................................................................................................10 4.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................10 4.3 TEST PROCEDURE.................................................................................................................................................10 4.4 TEST RECEIVER SETUP.........................................................................................................................................11 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION............................................................................................11 4.6 ENVIRONMENTAL CONDITIONS............................................................................................................................11 4.7 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................11 Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I PAGE 3 OF 15 FCC PART 15B 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Vigorhood Photoelectric Shenzhen Co., Ltd Address of applicant: F Building, Hongfa Tech Industrial Park, Songbai Rd. Shiyan Town, Baoan District, Shenzhen, China Manufacturer: Vigorhood Photoelectric Shenzhen Co., Ltd Address of manufacturer: F Building, Hongfa Tech Industrial Park, Songbai Rd. Shiyan Town, Baoan District, Shenzhen, China General Description of E.U.T Items Description EUT Description: MID Ebook Reader Trade Name: ATiger Model No.: EB 60 Rated Voltage: 5V DC Rated Current: 500mAh Rated Power: 2.5W Size: 21.0x13.5x2.0 cm For more information refer to the circuit diagram form and the user’s manual. The tes…

Text truncated - open the document above for the full version.

Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted emission Radiation Emission Test Setup (30MHz to 1GHz) Connect to PC Vigorhood Photoelectric Shenzhen Co., Ltd Model: EB 60 REPORT NO.: STR10108173I FCC PART 15B Charging and Playing
