XYFD8TD8R2.4GHz Radio System

FinePrint Software, LLC 16 Napier Lane San Francisco, CA 94133 Tel: 415-989-2722 Fax: 209-821-7869 www.fineprint.com Manual of Two-Way Radio System www.FrSky-rc.com P1of7 2.4GHz Two-Way Radio System 1. Introduction: The Two-way Radio System developed by FrSky provides an additional return link that would be used for monitoring the Rx’s voltage, temperature, location, speed and so on. 2. Overviews 2.1 Transmitter modules: a) Model: DFT Compatible with the following transmitters: Futaba: 3PM, 3PK, 7U, 8U, 8J, 9C, 9Z, 10C, FN series, T10C, FC-18, FC-28. Hitec: Optic 6, Eclipse 7, Prism 7. WFLY: WFT09, WFT08. b) Model: DJT Compatible with the following transmitters: JR: 347/388/783/U8/PCM10/PCM10S/PCM10SX/ PCM10IIS/8103/J9303/MX-22/MX-24S/PX/9XII. 2.2 Receiver module: a) Model: D8R, D8RHV Compatible with FrSky Two Way module DFT/DJT. b) Model: V8R, V8RHV, V8R7, V8R7HV, V8R4 V8 receivers work with DFT/DJT, just in receive-only mode. 3. Features a) Advanced Continuous Channel Shifting Technology (ACCST SYSTEM) achieves high reliable link in interference rich environments. b) Easy to bind and instant link-up. c) Excellent reboot times. d) All channels failsafe. e) Quick response. Manual of Two-Way Radio System www.FrSky-rc.com P2of7 f) Very smooth servo movement. g) Alarm on events of receiver (low battery voltages, poor reception, etc.) h) Error-free link, by using 48bits CRC algorithm. i) Low power consumption. j) True two-antenna diversity. k) Firmware upgradable. 4. Function of Two Way communication a) Two way communication between receiver and transmitter b) Receiver is able to accept 2 analog inputs, which can be used to monitor battery voltage, temperature sensor, etc., and transfer them to transmitter. Users can set the Alarm Point of these analog voltages, when exceed or below these points, sound alarm is presented. c) Receiver is able to accept serial data streams from simple 3-wire RS232 port, such information as GPS, altitude, and user developed data can be transferred to Tx without error, and presented at the RS232 port on the Tx. 5. Specifications 5.1 Receiver specifications: Model: D8R Weight: 16.2g Dimension: 54*27*17mm Operating Voltage Range: 4.0V-7.2V Operating Current: 100mA Specified Range: 1.5km (Ground Range) Resolution: 11bit (3072) Latency: 22ms Number of Channels: 8CH Analog voltage: 0~3.3V 5.2 Transmitter module specifications: Model: DFT, DJT PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn Manual of Two-Way Radio System www.FrSky-rc.com P3of7 Operating Voltage Range: 6.0V-13.0V Operating Current: 50mA Output Power: 60mW Resolution: 11bit (3072) Important! The effective range of control refers to the distance between the transmitter and the receiver clear of obstruction. All data was tested and verified by FrSky. However this is not guaranteed due to many factors such as the flying environment and the weather, which can greatly affect the effective range of control. It is extremely important to range check your models prior to each flying session! 6. How To Use 6.1 Setup 6.1.1 Installation of the transmitting module: a) Remove the original transmitting module. b) Put the FrSky 2.4GHz transmitter module into the module port of your RC transmitter and screw on the transmitting antenna. c) Check the MODE switch to its corresponding position. Mode Switch 1 Switch 2 Mode 1 OFF OFF Two-way Mode 2 OFF ON V8 Mode 3 ON OFF Not Defined 4 ON ON Firmware Upgrade d) Turn the transmitter power on and check the LED status on the module. 6.1.2 Installation of receivers: The D8R receiver incorporates two separate antennas which enable them to receive the radio signal at two different locations. please make sure that the two antennas be apart placed and 90 degrees crossed. Please note: As the wave length of 2.4GHz is shorter than older RC systems, its ability Manual of Two-Way Radio System www.FrSky-rc.com P4of7 to go around solid obstacles is weaker than 72 or 36 MHz. So the antennas must avoid objects with high conductivity, such as metal parts, servos, ESC’s, battery packs, wires, and carbon fiber structures. If possible put the tip of the antennas outside of the fuselage for maximum reception. 6.1.3 Receiver and Transmitter Setup Instructions: Follow the steps below to properly set up your system. a) Turn your FUTABA or JR transmitter on and switch it to PPM mode, power off the TX. b) Check the working mode of the Tx module. c) Turn the transmitter on while holding the programming button. Release it a few seconds later. The RED LED on the transmitter module will flash indicating the transmitter is ready to bind the receivers. d) Connect the battery to the receiver while holding the receiver’s button. The LED on the receiver will flash indicating the binding process is complete. Turn off the receiver. e) Turn off the transmitter and receiver to finish the binding procedure. f) Turn on the transmitter. g) Connect the battery to the receiver, the Green LED on the receiver will indicate the receiver is receiving commands from the transmitter. After the steps above are completed, both the transmitter and receiver are ready to be used. 6.2 Range check For safe operation, it is necessary to perform pre-flight range check. Caution must be paid when the units in the environment of metal fences, concrete buildings, or rows of trees. Loss of signal may be experienced. Perform a range check as follows (Note: this would be done with the receiver installed in the model): a) Place the model at least two feet (60cm) above non-metal contaminated ground; for example a wooden bench. b) Place the receiver’s antenna apart. Do NOT let the antenna touch the ground. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn Manual of Two-Way Radio System www.FrSky-rc.com P5of7 c) Place the antenna of the transmitter in a vertical position. d) Turn on the transmitter and receiver. e) To enter Range Check Mode, press and hold the “F/S Range” button of the transmitter for 4 second, the RED LED of the transmitter mo…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 FriSky Electronic Co.,Ltd. (November 17, 2010) To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ____FriSky Electronic Co.,Ltd.___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: 2.4G Radio System Model name: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF-8M,TF- 14M We affirm that between SIEMIC and __FriSky Electronic Co.,Ltd.__, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Signature Bryan Shao /Manager Title: Manager Telephone: +86-0510-82606377 Email: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 FriSky Electronic Co.,Ltd. (November 17, 2010) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: XYFD8TD8R We hereby request confidential treatment of information accompanying this application as outlined below: - Schematic - Operational Description - Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Bryan Shao /Manager Title: Manager Telephone: +86-0510-82606377 Email: [email protected]

Annex B.i. Photograph : EUT External Photo

FCC ID: XYFD8TD8R

Labbel Locatioon

Annnex B.ii. Photograph : EUT IInternal Photo

FRSKY ELECTRONIC CO., LTD 2.4G RADIO SYSTEM Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M Nov 01th 2010 Report No.: 1002720(SAR_FCC) Rev1.0 (This report supersedes 1002720(SAR_FCC)) This Test Report is Issued Under the Authority of: David Zhang Compliance Engineer Leslie Bai Director of Certification Modifications made to the product : None This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of FrSky Electronic Co., Ltd Model : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M To C95.1, IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) Serial# 1002720(SAR_FCC) Rev1.0 Issue Date Nov 01th 2010 Page 2 of 88 www.siemic.com Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB, NIST EMC,RF,Safety,Telecom Title: RF Test Report of FrSky Electronic Co., Ltd Model : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M To C95.1, IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) Serial# 1002720(SAR_FCC) Rev1.0 Issue Date Nov 01th 2010 Page 2 of 88 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of FrSky Electronic Co., Ltd Model : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M To C95.1, IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) Serial# 1002720(SAR_FCC) Rev1.0 Issue Date Nov 01th 2010 Page 2 of 88 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .............................................................................................................. 6 2 TECHNICAL DETAILS ................................................................................................................................................... 7 3 INTRODUCTION ........................................................................................................................................................... 8 4 SAR MEASUREMENT SETUP ....................................................................................................................................... 9 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT ............................................................................................................ 19 6 SYSTEM AND LIQUID VALIDATION ............................................................................................................................ 20 7 TYPE A MEASUREMENT UNCERTAINTY ................................................................................................................... 24 8 OUTPUT POWER VERIFICATION ................................................................................................................................ 26 9 SAR TEST RESULTS .................................................................................................................................................. 27 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................................ 40 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................................... 42 ANNEX C CALIBRATION REPORTS .................................................................................................................................. 45 Title: RF Test Report of FrSky Electronic Co., Ltd Model : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M To C95.1, IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) Serial# 1002720(SAR_FCC) Rev1.0 Issue Date Nov 01th 2010 Page 2 of 88 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of FrSky Electronic Co., Ltd Model : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R, TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M To C95.1, IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) Serial# 1002720(SAR_FCC) Rev1.0 Issue Date Nov 01th 2010 Page 2 of 88 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programmed was to demonstrate compliance of the FrSky Electronic Co., Ltd Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M against the current Stipulated Standards. The 2.4G Radio System have demonstrated compliance with the C95.1 , IEEE 1528, OET Bulletin 65 Supplement C(Edition 01-01) , and Safety Code 6. The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : Remote control model Model No : V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF…

Text truncated - open the document above for the full version.

FrSky Electronic Co.,Ltd. 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7, D8R,TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M Nov 15 2010 Report No.: 1002720 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Alex Wang Compliance Engineer Will Yang Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M To: FCC 15.247:2009 Serial#: 1002720 Issue Date: Nov 15 2010 Page 2 of 63 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/RegionAccreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M To: FCC 15.247:2009 Serial#: 1002720 Issue Date: Nov 15 2010 Page 3 of 63 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M To: FCC 15.247:2009 Serial#: 1002720 Issue Date: Nov 15 2010 Page 4 of 63 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ............................................................................................................. 5 2 TECHNICAL DETAILS .................................................................................................................................................. 6 3 MODIFICATION ............................................................................................................................................................ 7 4 TEST SUMMARY .......................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ........................................................................................ 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................................ 40 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................................... 44 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................................... 48 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ....................................................................... 51 ANNEX E. SIEMIC ACCREDITATION CERTIFICATES .......................................................................................................... 52 Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M To: FCC 15.247:2009 Serial#: 1002720 Issue Date: Nov 15 2010 Page 5 of 63 www.siemic.com.cn 1 Executive Summary & EUT information The purpose of this test programme was to demonstrate compliance of the FrSky Electronic Co.,Ltd., 2.4G Radio System, and model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF-8M,TF-14M against the current Stipulated Standards. The 2.4G Radio System have demonstrated compliance with the FCC 15.247:2009. EUT Information EUT Description Remote control model Model No V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M Input Voltage 6-13VDC Classification Per Stipulated Test Standard Spread Spectrum System/Device Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4,TFR6,TFR14,TF- 8M,TF-14M To: FCC 15.247:2009 Serial#: 1002720 Issue Date: Nov 15 2010 Page 6 of 63 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Radio FHSS Module with stipulated standard Applicant / Client FrSky Electronic Co.,Ltd. Manufacturer FrSky Electronic Co.,Ltd. No.100 Jinxi Road ,Wuxi,Jiangsu,China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 1002720 Date EUT received Aug 02 2010 Standard applied FCC 15.247:2009 Dates of test (from – to) Aug 15-25 2010 No of Units: 2 Equipment Category: DSS RF Operating Frequency (ies) 2403.940 MHz -2448.305MHz Number of Channels : 50 Modulation : FSK FCC ID： XYFD8TD8R Title: RF Test Report for 2.4G Radio System Model: V8FT,V8JT,V8HT,DFT,DHT,DJT,V8FR,V8R4,V8R7,D8R,TFR8,TFR4…

Text truncated - open the document above for the full version.

Annex B.iii. Photograph: Test Setup Photo
