XYOEC-P11Wireless Energy Controller

1 / 13 www.asiatelco.com Wireless Energy Controller V1.8 model number：EC-P11 INDEX 1 DESCRIPTION --------------------------------------------------------------------------------------------- 3 2 BENEFIT ---------------------------------------------------------------------------------------------- 4 3 FEATURES ---------------------------------------------------------------------------------------------- 4 4 HARDWARE CONFIGURATION ---------------------------------------------------------------------- 5 5 ELECTRICAL SPECIFICATION ---------------------------------------------------------------------- 5 6 SIGNAL DEFINE ----------------------------------------------------------------------------------------- 7 7 DIMENSION ----------------------------------------------------------------------------------------------- 8 8 QUICK USER GUIDE ------------------------------------------------------------------------------------ 9 9 SOFTWARE USER GUIDE ------------------------------------------------------------------------------ 10 2 / 13 www.asiatelco.com IMPORTANT ANNOUNCEMENT ** High voltage in the controller, operators must be with professional knowledge. ** The wire named “E‐gnd” must be connected with the earth ground all the time. FCC Warning Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: ***WIFI Channel 12 & Channel 13 is not available in final product. The hardware is disabled inside. ***This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. ***Be sure to leave the human body more than 20cm when using this product. ***The country code is not supported by this product. 3 / 13 www.asiatelco.com 1 DESCRIPTION The Wireless Energy Controller （model number：EC-P11）works as a controller with LED-fixture, and achieve remote control through WIFI wireless. The controller has 2* 0-10V signal for dimming usage, and current sensor is also integrated. 4 / 13 www.asiatelco.com 2 BENEFIT ---- Control and Schedule ON/OFF/DIM for individual fixture or groups of fixtures ---- Remote control and self programmable control mode ---- Customer defined continuous dimming ---- Adjust ON/OFF times and night trimming schedules ---- Monitor the work status & the Energy consumption of every fixture in every minute ---- Track burn hours to verify LED fixture life ---- Detect LED fixture malfunctions remotely ---- Works with any manufactures’ outdoor LED lighting fixture ---- Reduce Energy Costs ---- Reduce Carbon Emission ---- Reduce Manpower Costs ---- Reduce Maintenance Costs 3 FEATURES ---- Each device can works in Node/Hub/Mix-mode ---- Wide AC input flexibility, 110V/AC, 277 V/AC, 480V/AC ---- AC switch inside（ Low loss in AC switch, typical 16 mΩ） ---- Max output power 1000W ---- 2* 0-10V Dimming signal for LED-fixture ---- AC Current Sensor integration ---- 1*10M/100M Ethernet port ---- WIFI 802.11b/g/n ---- Ublox GPS ---- 1*Button for customer ---- 1*USB device port (reserved ) ---- 4*LED for work status indicated ---- 1* Interface for General Interrupt input (reserved) ---- 1* Interface for ADC signal input (reserved) ---- 12V/0.5A DC power output (reserved) ---- Easy to install & configure 5 / 13 www.asiatelco.com 4 HARDWARE CONFIGURATION HARDWARE CONFIGURATION STANDARD LIST Remark WIFI & WIFI antenna port GPS & GPS antenna port 1 * 0-10V Dimming signal output 1 * AC switch inside OPTIONAL LIST 2nd * 0-10V Dimming signal output 2nd * AC switch Interface for Motion sensor input (reserved , not available now ) Interface for Light sensor input (reserved , not available now ) 1*USB device port (reserved , not available now ) 5 ELECTRICAL SPECIFICATION AC/AC PART Absolute Maximum Ratings Items Unit Value Max input value V / AC 500 Max output current A 2 Max output power W 1000 Operating Temperature Range °C -40°C to 85°C Storage Temperature Range °C -65°C to 145°C Electrical Characteristics 6 / 13 www.asiatelco.com Items Unit Value Nominal input value V / AC 277 Input value range V / AC 100V/AC to 500V/AC AC Input Frequency range Hz 50 / 60 Switch Output value V / AC same value as input Accuracy of AC current sensor ±10% RMS (load current<150mA) ±5% RMS (load current>150mA) GPS SPECIFICATION Items SPEC Receiver type 50 channel GPS L1 C/A TTFF Cold start-----29 s Warm start-----28 s Hot start-----2 s Sensitivity tracking: -160 dBm acquisition: -147 dBm Horizontal position accuracy * ＜ 10 meters * Test environment: Open sky, 24 hours static, Qty of satellite>6, all of satellite signal strength>-130dBm 7 / 13 www.asiatelco.com 6 SIGNAL DEFINE 8 / 13 www.asiatelco.com 7 DIMENSION 9 / 13 www.asiatelco.com 8 QUICK USER GUIDE Case—drive 1xFixture Case—drive 2xFixture 10 / 13 www.asiatelco.com 9 SOFTWARE USER GUIDE  Software Architecture  Important Function Using  system() SYNOPSIS #inclu…

Text truncated - open the document above for the full version.

External photo:

Internal photo Adapter Module

Report No. 2014SR0011 Page 2 of 8 CONTENTS 1. TEST LABORATORY ........................................................................................................................ 3 1.1. TESTING LOCATION ........................................................................................................................ 3 1.2. PROJECT DATA .................................................................................................................................. 3 1.3. SIGNATURE ......................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ........................................................................................................... 4 2.2. MANUFACTURER INFORMATION ................................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ......................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ........................................ 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ........................................... 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. APPLICABLE STANDARDS .............................................................................................................. 6 4.2. TEST LIMITS ....................................................................................................................................... 6 5. TEST RESULTS ................................................................................................................................... 7 5.1. CONDUCTED RF POWER OUTPUT ............................................................................................... 7 5.2. CALCULATION INFORMATION .................................................................................................... 7 5.3. RESULT OF WIFI 802.11B/G/N.......................................................................................................... 8 Report No. 2014SR0011 Page 4 of 8 2. Client Information 2.1. Applicant Information Company Name: AsiaTelco Technologies Co. Address /Post: Building-8, 3F, #289 Bisheng Road, Zhangjiang Hi-Tech Park, Pudong, Shanghai, China Country: China Telephone: 86-021-51688806 Postal Code: 201204 Contact Certification 2.2. Manufacturer Information Company Name: AsiaTelco Technologies Co. Address /Post: Building-8, 3F, #289 Bisheng Road, Zhangjiang Hi-Tech Park, Pudong, Shanghai, China Country: China Telephone: 86-021-51688806 Postal Code: 201204 Contact Certification Report No. 2014SR0011 Page 5 of 8 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT EUT Description Wireless Energy Controller Model name EC-P11 WiFi 802.11b/g/n Antenna Type External Antenna FCC ID: XYOEC-P11 Note: Photographs of EUT are shown in ANNEX A of this test report. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version: N01 IMEI:N/A P1 ECP-11_S1.0.2 *EUT ID: is used to identify the test sample in the lab internally. Note: the EUT has no earphone. 3.3. Internal Identification of AE used during the test AE ID* Description Model SN Manufacturer AE1 N/A N/A N/A N/A AE2 N/A N/A N/A N/A *AE ID: is used to identify the test sample in the lab internally. Report No. 2014SR0011 Page 6 of 8 4. Reference Documents 4.1. Applicable Standards The MPE report was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 2.1091. The limits standard is based on the Council Recommendation 1999/519/EC. FCC CFR 47, Part 2, FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS, Oct 1,2011 Section 2.1091 Radiofrequency radiation exposure evaluation: mobile devices, Oct 1,2011 4.2. Test Limits Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. Limits for Occupational / Controlled Exposure Frequency Range [MHz] Electric Field Strength (E) [V/m] Magnetic Field Strength (H) [A/m] Power Density (S) [mW/cm2] Averaging Times |E|2, |H|2 or S [miniutes] 0.3 – 3.0 614 1.63 (100)* 6 3.0 – 30 1824/f 4.89/f (900/f)* 6 30 – 300 61.4 0.163 1.0 6 300 – 1500 -- -- F/300 6 1500 - 100000 -- -- 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range [MHz] Electric Field Strength (E) [V/m] Magnetic Field Strength (H) [A/m] Power Density (S) [mW/cm2] Averaging Times |E|2, |H|2 or S [miniutes] 0.3 – 1.34 614 1.63 (100)* 30 1.34 – 30 824/f 2.19/f (180/f)* 30 30 – 300 27.5 0.073 0.2 30 300 – 1500 -- -- F/1500 30 1500 - 100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density For the DUT, the limits for General Population / Uncontrolled Exposure are applicable. Report No. 2014SR0011 Page 7 of 8 5. Test Results 5.1. Conducted RF Power Output Table 5.1: The Conducted Power For WiFi The average conducted power for WiFi is as following: 802.11b（dBm） Channel\data rate 1Mbps 2Mbps 5.5Mbps 11Mbps 1 16.45 16.53 16.25 16.75 7 16.32 16.21 16.34 16.47 13 16.27 16.23 16.31 16.43 802.11g（dBm） Channel\d ata rate 6Mbps 9Mbps 12Mb ps 18Mb ps 24Mb ps 36Mb ps 48Mb ps 54Mb ps 1 15.16 16.61 16.25 16.46 15.72 16.46 16.14 15.91 7 15.56 16.41 16.37 15.84 15.95 15…

Text truncated - open the document above for the full version.

Report No. 2014WL0011 Page 2 of 81 CONTENTS 1. GENERAL INFORMATION .................................................................................... 3 1.1 N OTES ..................................................................................................................... 3 1.2 S TATEMENTS ............................................................................................................ 3 1.3 T EST LABORATORY .................................................................................................. 4 1.3.1. Testing Location ............................................................................................... 4 1.3.2. Testing Environment ........................................................................................ 4 1.3.3. Project data ....................................................................................................... 4 1.3.4. Signature ........................................................................................................... 4 1.4 D ETAILS OF APPLICANT OR MANUFACTURER .............................................................. 5 1.4.1. Applicant Information ....................................................................................... 5 1.4.2. Manufacturer Information ................................................................................ 5 2. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ........... 5 2.1. ABOUT EUT .......................................................................................................... 5 2.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ...................... 5 2.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ........................ 5 3. REFERENCE DOCUMENTS ................................................................................. 6 3.1. REFERENCE DOCUMENTS FOR TESTING ........................................................ 6 4. SUMMARY OF TEST RESULTS ........................................................................... 7 5. TEST RESULT ....................................................................................................... 9 5.1. MAXIMUM OUTPUT POWER ................................................................................ 9 5.1.1. MAXIMUM PEAK OUTPUT POWER-CONDUCTED ......................................... 9 5.1.2. MAXIMUM AVERAGE OUTPUT POWER-CONDUCTED ................................ 11 5.2. PEAK POWER SPECTRAL DENSITY ................................................................ 11 5.3. OCCUPIED 6DB BANDWIDTH ........................................................................... 21 5.4. BAND EDGES COMPLIANCE ............................................................................ 31 5.5. TRANSMITTER SPURIOUS EMISSION-CONDUCTED ..................................... 37 5.6. TRANSMITTER SPURIOUS EMISSION-RADIATED .......................................... 56 5.7. AC POWERLINE CONDUCTED EMISSION ....................................................... 72 6. TEST EQUIPMENTS AND ANCILLARIES USED FOR TESTS .......................... 77 7. TEST ENVIRONMENT ......................................................................................... 78 ANNEX A DEVIATIONS FROM PRESCRIBED TEST METHODS ................................. 81 Report No. 2014WL0011 Page 3 of 81 1. General Information 1.1 Notes All reported tests were carried out on a sample equipment to demonstrate limited compliance with section 3. The test results of this test report relate exclusively to the item(s) tested as specified in section 5. The following deviation from, additions to, or exclusions from the test specifications have been made. See section 3. 1.2 Statements The product EC-P11, supporting WLAN, manufactured by AsiaTelco Technologies Co. is a new product for testing. ECIT has verified that the compliance of the tested device specified in section 5 of this test report is successfully evaluated according to the procedure and test methods as defined in type certification requirement listed in section 5 of this test report. Report No. 2014WL0011 Page 5 of 81 1.4 Details of applicant or manufacturer 1.4.1. Applicant Information Company Name: AsiaTelco Technologies Co. Address /Post: Building-8, 3F, #289 Bisheng Road, Zhangjiang Hi-Tech Park, Pudong, Shanghai, China Country: China 1.4.2. Manufacturer Information Company Name: AsiaTelco Technologies Co. Address /Post: Building-8, 3F, #289 Bisheng Road, Zhangjiang Hi-Tech Park, Pudong, Shanghai, China Country: China 2. Equipment Under Test (EUT) and Ancillary Equipment (AE) 2.1. About EUT EUT Description Wireless Energy Controller Model name EC-P11 WLAN Frequency 2412MHz-2462MHz WLAN Channel Channel1-Channel11 WLAN type of modulation 802.11b:DSSS 802.11g/n: OFDM Nominal Voltage 277 V Extreme High Voltage 110 V Extreme Low Voltage 480 V Note: Photographs of EUT are shown in ANNEX A of this test report. 2.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version Date of receipt N01 ---- P1 ECP-11_S1.0.2 2014-01-19 *EUT ID: is used to identify the test sample in the lab internally. 2.3. Internal Identification of AE used during the test AE ID* Description SN AE1 RF cable --- AE2 --- --- Report No. 2014WL0011 Page 6 of 81 3. Reference Documents 3.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title FCC Part15 FCC CFR 47, Part 15,Subpart C: 15.205 Restricted bands of operation; 15.209 Radiated emission limits, general requirements; 15.247 Operation within the bands 902-928MHz, 2400-2483.5MHz, and 5725-5850MHz. ANSI C63.10 American National Standard for Testing Unlicensed Wireless Devices Report No. 2014WL0011 Page 7 of 81 4. Summary of Test Results A brief summary of the tests carried out is shown as following. Measurement Items Sub-clause of Part15C Sub-claus e of IC Verdict Maximum Peak Output Power 15.247(a) / P Peak Power Spectral Density 15.247(e) / …

Text truncated - open the document above for the full version.

Teat Photograph Description: Conducted Emission test setup
