XZOIM01Mobile Tablet PC

User’s Manual TPC-2A-PLUS (090708) i-Mobile Technology Corporation Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. Disclaimer: The manufacturer makes no representations or warranties with respect to the contents hereof and specifically disclaim any implied warranties of merchantability or fitness for any particular purpose. The manufacturer is not liable for technical and editorial error for this guide. The manufacturer reserves the right to revise or make changes to this publication without notice or obligation of the manufacturer to notify any person of such revision or changes. Software Licenses The software included with the product and referenced in this document is furnished under a License Agreement. This Agreement specifies permitted and prohibited uses of this product. General Guidelines ® Read all of the instructions carefully. ® Save the instructions for future use. ® To ensure follow all warnings and instructions marked in the product documentation and within the computer. ® Except as explained elsewhere in this manual, do not attempt to service the computer yourself. Opening or removing covers might expose you to dangerous voltage points or other risks. Refer all servicing of marked components to qualified personnel. Power Cord Requirements The power cord you received with this computer conforms to local specifications for use in the country where you purchased it. Power cord use in other countries may require an additional adapter and/or separate power cord. For additional information on local power requirements, contact an authorized dealer, reseller, or service provider. About the AC Adapter The AC adapter will automatically recognize any compatible power supply connected to the computer. The AC adapter can also be used to recharge the battery, which begins immediately after the AC Adapter cord is connected. A green LED will light to confirm charging is in progress. The ideal range for safe operation of the computer is from 100 ~ 240V AC. 1. AC Power Cord / 2. AC Adapter / 3. DC (Direct Current) Cord Warning : ∑ Using the AC adapter to power other devices can damage the adapter or the device. This AC adapter is only designed for use with the product. ∑ Be sure to only use the AC adapter that comes provided with this product or a compatible option from the manufacturer. Other adapters may cause damage to the computer and will not be covered under the warranty. ∑ Grasp the adapter plug and not the cord, when unplugging the adapter from an electrical outlet. ∑ If the power cord becomes damaged (exposed or frayed, etc.), replace with a new AC adapter. Using a damaged cord may cause an electrical shock and may result in fire. ∑ Power off and unplug the AC adapter from the computer before unplugging it from the electrical outlet. Battery (Lithium-Ion) NOTE: Refer to following hazard statement within the service and operating documentation or on the adjacent label to the battery. 1. English CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY INSTALLED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD OF USED BATTERIES IN ACCORDANCE WITH THE MANUFACTURER'S INSTRUCTIONS. 2. French IL Y A DANGER D'EXPLOSION S'IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE. REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D'UN TYPE RECOMMANDÉ PAR LE CONSTRUCTEUR. METTER AU RÉBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT. 3. German VORSICHT ! Explisionsgefahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. 4. Swedish Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. 5. Danish Lithiumbatteri- Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kum ske med batteri af samme fabrikat og type. Lever det brugte batteri tilbage til leverandoren. 6. Norwegian Ekspolsjonsafe ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabriknten. Brukte batterier kasseres I henhold til fabrikantens instruksjoner. 7. Finnish Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainostaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käyteet paristo valmistajan ohjeiden mukaisesti. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may case harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ® Reorient or relocate the receiving antenna. ® Increase the separation between the equipment and receiver. ® Connect the equipment into an outlet on a circuit different from that to which to receiver is connected. ® Consult the dealer or an experienced radio/TV technician for help. Use of shielded cord is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules. Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or mo…

Text truncated - open the document above for the full version.

Page: 1 Page: 2

FCC ID: XZOIM01 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page: 3 Page: 4 Page: 5 Page: 6 Page: 7 Page: 8 Page: 9 Page: 10 Page: 11 Page: 12 Page: 13 Page: 14 Page: 15 Page: 16 Page: 17 Page: 18 Page: 19 Page: 20 Page: 21 Page: 22 Page: 23 Page: 24 Page: 25

Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 香港商立 香港商立德國際商品試驗有限公司桃園分公司 14th Ling, Chiapau Tsuen, Linkou, Taipei, Taiwan, R.O.C. 台北縣林口鄉嘉寶村14鄰47號 http://www.adt.com.tw/ E-mail: [email protected] TEL: 886-2-26052180 FAX: 886-2-26051924 服務項目 EMC/ SAFETY/ RADIO CERTIFICATION、ID/ MECH. DESIGN、GRAPHICS/TECH. WRITING SERVICES 您產品開發的最佳伙伴 YOUR BEST PARTNER IN PRODUCT DEVELOPMENT 誠信確實‧專業第一‧顧客至上 INTEGRITY‧PROFESSIONALISM‧CUSTOMER SATISFACTION Antenna Location Date: December 22, 2009 The distance between the WLAN antenna and Bluetooth antenna is 6.9cm. Please refer to following photo for antenna location: This equipment should be operated with minimum distance 20cm between the radiator & user's body. 張嘉宴 Annie Chang Senior Specialist, Linkou Reporting Section 立德集團 (BV) Bureau Veritas ADT Tel: +886 2 2605 2180 Ext. 3322 Fax: +886 2 2605 1924 E-mail: [email protected] Website: www.adt.com.tw Bluetooth Antenna WLAN Antenn a 6.9cm WLAN Antenn a Bluetooth Antenna

FCC ID: XZOIM01 Report No.: RF980611A09 Operational Description This device is a Mobile Tablet PC with 802.11b/g and Bluetooth function. The 802.11b/g and Bluetooth could transmit at the same time. For 802.11b/g: 802.11g which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by battery. The antenna is PCB antenna. For Bluetooth: The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is PCB Antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the users manual.

Report No: SA980611A09-1 1 Report Format Version 3.0.0 RF EXPOSURE REPORT REPORT NO.: SA980611A09-1 MODEL NO.: TPC-2A Plus ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT : i-Mobile Technology Corporation ADDRESS : 8F., No.8, Alley 15, Lane 120, Sec. 1, Neihu Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan Report No: SA980611A09-1 2 Report Format Version 3.0.0 Conclusion No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.58 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power 5.0 3.2 EIRP Power 7.4 5.5 *Note: The antenna is PCB Antenna with 2.4 dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 5.5mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold ---END---

Report No.: SA980611A09 1 Report Format Version 3.0.0 SAR TEST REPORT REPORT NO.: SA980611A09 MODEL NO.: TPC-2A Plus RECEIVED: Jun. 11, 2009 TESTED: Dec. 02, 2009 ISSUED: Dec. 04, 2009 APPLICANT: i-Mobile Technology Corporation ADDRESS: 8F., No.8, Alley 15, Lane 120, Sec. 1, Neihu Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch AB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 35 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: SA980611A09 2 Report Format Version 3.0.0 TABLE OF CONTENTS 1. CERTIFICATION................................................................................................................3 2. GENERAL INFORMATION.................................................................................................4 2.1 GENERAL DESCRIPTION OF EUT...................................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS.....................................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM...........................................................6 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION...........................9 3. DESCRIPTION OF SUPPORT UNITS.............................................................................12 4. DESCRIPTION OF TEST MODES AND CONFIGURATIONS..........................................13 4.1. DESCRIPTION OF TEST MODE.....................................................................................13 4.2. SUMMARY OF TEST RESULTS......................................................................................13 4.3. ENHANCED ENERGY COUPLING AT INCREASED SEPARATION DISTANCES...........14 5. TEST RESULTS...............................................................................................................15 5.1 TEST PROCEDURES......................................................................................................15 5.2 MEASURED SAR RESULTS...........................................................................................17 5.3 SAR LIMITS.....................................................................................................................18 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS..............................................................19 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY...............................................................22 6. SYSTEM VALIDATION.....................................................................................................23 6.1 TEST EQUIPMENT..........................................................................................................23 6.2 TEST PROCEDURE........................................................................................................24 6.3 VALIDATION RESULTS...................................................................................................26 6.4 SYSTEM VALIDATION UNCERTAINTIES........................................................................27 7. MEASUREMENT SAR PROCEDURE UNCERTAINTIES................................................28 7.1. PROBE CALIBRATION UNCERTAINTY..........................................................................28 7.2. ISOTROPY UNCERTAINTY.............................................................................................29 7.3. BOUNDARY EFFECT UNCERTAINTY............................................................................29 7.4. PROBE LINEARITY UNCERTAINTY...............................................................................30 7.5. READOUT ELECTRONICS UNCERTAINTY....................................................................30 7.6. RESPONSE TIME UNCERTAINTY..................................................................................30 7.7. INTEGRATION TIME UNCERTAINTY..............................................................................31 7.8. PROBE POSITIONER MECHANICAL TOLERANCE.......................................................32 7.9. PROBE POSITIONING....................................................................................................32 7.10. PHANTOM UNCERTAINTY.............................................................................................33 7.11. DASY4 UNCERTAINTY BUDGET....................................................................................34 8. INFORMATION ON THE TESTING LABORATORIES......................................................35 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA980611A09 3 Report Format Version 3.0.0 1. CERTIFICATION PRODUCT: Mobile Tablet PC MODEL: TPC-2A Plus APPLICANT: i-Mobile Technology Corporation TESTED: Dec. 02, 2009 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) RSS-102 The above equipment (model: TPC-2A Plus) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Dec. 04, 2009 Polly Chien / Specialist TECHNICA…

Text truncated - open the document above for the full version.

D2: DOSIMETRIC E-FIELD PROBE D3: DAE

D4: SYSTEM VALIDATION DIPOLE

Report No.: RF980611A09-1 1 Report Format Version 3.0.0 FCC TEST REPORT REPORT NO.: RF980611A09-1 MODEL NO.: TPC-2A Plus RECEIVED: June 11, 2009 TESTED: Oct. 19 ~ Nov 5, 2009 ISSUED: Nov. 6, 2009 APPLICANT: i-Mobile Technology Corporation ADDRESS: 8F., No.8, Alley 15, Lane 120, Sec. 1, Neihu Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF980611A09-1 2 Report Format Version 3.0.0 TABLE OF CONTENTS 1. CERTIFICATION.............................................................................................4 2. SUMMARY OF TEST RESULTS.....................................................................5 2.1 MEASUREMENT UNCERTAINTY..................................................................6 3. GENERAL INFORMATION.............................................................................7 3.1 GENERAL DESCRIPTION OF EUT................................................................7 3.2 DESCRIPTION OF TEST MODES..................................................................9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................10 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................11 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................13 3.2.4 DESCRIPTION OF SUPPORT UNITS..........................................................13 4. TEST TYPES AND RESULTS.......................................................................14 4.1 CONDUCTED EMISSION MEASUREMENT................................................14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..............................14 4.1.2 TEST INSTRUMENTS..................................................................................15 4.1.3 TEST PROCEDURES...................................................................................16 4.1.4 DEVIATION FROM TEST STANDARD.........................................................16 4.1.5 TEST SETUP................................................................................................16 4.1.6 EUT OPERATING CONDITIONS..................................................................17 4.1.7 TEST RESULTS............................................................................................18 4.2 RADIATED EMISSION MEASUREMENT.....................................................20 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................20 4.2.2 TEST INSTRUMENTS..................................................................................21 4.2.3 TEST PROCEDURES...................................................................................22 4.2.4 DEVIATION FROM TEST STANDARD.........................................................22 4.2.5 TEST SETUP................................................................................................23 4.2.6 EUT OPERATING CONDITIONS..................................................................24 4.2.7 TEST RESULTS............................................................................................25 4.3 NUMBER OF HOPPING FREQUENCY USED.............................................35 4.3.1 LIMIT OF HOPPING FREQUENCY USED...................................................35 4.3.2 TEST INSTRUMENTS....................................................................................35 4.3.3 TEST PROCEDURES...................................................................................35 4.3.4 DEVIATION FROM TEST STANDARD.........................................................36 4.3.5 TEST SETUP................................................................................................36 4.3.6 TEST RESULTS............................................................................................36 4.4 DWELL TIME ON EACH CHANNEL.............................................................39 4.4.1 LIMIT OF DWELL TIME USED......................................................................39 4.4.2 TEST INSTRUMENTS..................................................................................39 4.4.3 TEST PROCEDURES...................................................................................39 4.4.4 DEVIATION FROM TEST STANDARD.........................................................39 4.4.5 TEST SETUP................................................................................................40 4.4.6 TEST RESULTS............................................................................................40 4.5 CHANNEL BANDWIDTH...............................................................................48 4.5.1 LIMITS OF CHANNEL BANDWIDTH............................................................48 4.5.2 TEST INSTRUMENTS..................................................................................48 4.5.3 TEST PROCEDURE.....................................................................................48 4.5.4 DEVIATION FROM TEST STANDARD.........................................................49 Report No.: RF980611A09-1 3 Report Format Version 3.0.0 4.5.5 TEST SETUP................................................................................................49 4.5.6 EUT OPERATING CONDITION....................................................................49 4.5.7 TEST RESULTS............................................................................................50 4.6 HOPPING CHANNEL SEPARATION........................…

Text truncated - open the document above for the full version.

Report No.: RF980611A09 1 Report Format Version 3.0.0 FCC TEST REPORT REPORT NO.: RF980611A09 MODEL NO.: TPC-2A Plus RECEIVED: June 11, 2009 TESTED: Nov. 2 ~ 5, 2009 ISSUED: Nov. 6, 2009 APPLICANT: i-Mobile Technology Corporation ADDRESS: 8F., No.8, Alley 15, Lane 120, Sec. 1, Neihu Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan This test report consists of 51 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample Report No.: RF980611A09 2 Report Format Version 3.0.0 TABLE OF CONTENTS 1. CERTIFICATION.......................................................................................4 2. SUMMARY OF TEST RESULTS...............................................................5 2.1 MEASUREMENT UNCERTAINTY.............................................................5 3. GENERAL INFORMATION........................................................................6 3.1 GENERAL DESCRIPTION OF EUT..........................................................6 3.2 DESCRIPTION OF TEST MODES............................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.......................................9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...........10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..........................12 3.4 DESCRIPTION OF SUPPORT UNITS....................................................12 4. TEST TYPES AND RESULTS.................................................................13 4.1 RADIATED EMISSION MEASUREMENT................................................13 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT.............................13 4.1.2 TEST INSTRUMENTS.............................................................................14 4.1.3 TEST PROCEDURES.............................................................................15 4.1.4 DEVIATION FROM TEST STANDARD....................................................15 4.1.5 TEST SETUP...........................................................................................16 4.1.6 EUT OPERATING CONDITIONS............................................................16 4.1.7 TEST RESULTS......................................................................................17 4.2 CONDUCTED EMISSION MEASUREMENT...........................................25 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................25 4.2.2 TEST INSTRUMENTS.............................................................................25 4.2.3 TEST PROCEDURES.............................................................................26 4.2.4 DEVIATION FROM TEST STANDARD....................................................26 4.2.5 TEST SETUP...........................................................................................27 4.2.6 EUT OPERATING CONDITIONS............................................................27 4.2.7 TEST RESULTS......................................................................................28 4.3 6dB BANDWIDTH MEASUREMENT.......................................................30 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT....................................30 4.3.2 TEST INSTRUMENTS.............................................................................30 4.3.3 TEST PROCEDURE................................................................................30 4.3.4 DEVIATION FROM TEST STANDARD....................................................30 4.3.5 TEST SETUP...........................................................................................31 4.3.6 EUT OPERATING CONDITIONS............................................................31 4.3.7 TEST RESULTS......................................................................................32 4.4 MAXIMUM PEAK OUTPUT POWER.......................................................34 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.......34 4.4.2 INSTRUMENTS.......................................................................................34 4.4.3 TEST PROCEDURES.............................................................................34 4.4.4 DEVIATION FROM TEST STANDARD....................................................34 4.4.5 TEST SETUP...........................................................................................35 4.4.6 EUT OPERATING CONDITIONS............................................................35 4.4.7 TEST RESULTS......................................................................................36 4.5 POWER SPECTRAL DENSITY MEASUREMENT..................................37 Report No.: RF980611A09 3 Report Format Version 3.0.0 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT................37 4.5.2 TEST INSTRUMENTS.............................................................................37 4.5.3 TEST PROCEDURE................................................................................37 4.5.4 DEVIATION FROM TEST STANDARD....................................................37 4.5.5 TEST SETUP...........................................................................................37 4.5.6 EUT OPERATING CONDITION...............................................................37 4.5.7 TEST RESULTS......................................................................................38 4.6 BAND EDGES MEASUREMENT............................................................40 4.6.1 LIMITS OF BAND EDGES MEASUREMENT..........................................40 4.6.2 TEST INSTRUMENTS...............................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST- MODE A 2 RADIATED EMISSION TEST - MODE A 3 RADIATED EMISSION TEST - MODE B

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST- MODE A 2 RADIATED EMISSION TEST - MODE A 3 RADIATED EMISSION TEST - MODE B

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (SAR Test Set Up Photos) BODY POSITION: A. BOTTOM B. TIP SETUP PHOTO DESCRIPTION OF ANTENNA LOCATION:
