Y3K-PORT908.4MHz Z-Wave Module in a USNAP form factor

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 26 of 35 Appendix K: Manual Please refer to the following pages. EvolveNet Portal™ User Manual Version 1.12.10 BuLogics, Inc. Introduction: The EvolveNet Portal™ by BuLogics, Inc., is an integral portion of the Evolve Guest Controls comprehensive energy management solution. Each EvolveNet Portal controls an entire network of Z-Wave devices and communicates with the EvolveNet Router™ to send device management messages. Nothing works more accurately or efficiently to share information about energy status than the EvolveNet Portal. Important Information: • Do not insert the EvolveNet Portal into any other device other than the receiving slots of the licensed EvolveNet Router. • Do NOT submerge the EvolveNet Portal in water or place in a high humidity area. • Store any unused EvolveNet Portals away from heat sources in a dry location. Installation Instructions: 1) If using only one EvolveNet Portal, always place the EvolveNet Portal into the back receiving slot of the EvolveNet Router first (next to the antenna). Additional EvolveNet Portals can be inserted into either of the other receiving slots. 2) Press the EvolveNet Portal into the slot gently but firmly until it cannot go any farther. 3) Once the EvolveNet Portal is inserted, LEDs will illuminate as defined below. EvolveNet Portal LED Definition • Red LED blinks to show that the EvolveNet Portal is receiving commands. • Blue LED blinks to show the network health. o <50% = slow blink o >50% = fast blink Z-Wave: This device uses Z-Wave and can communicate with other Z-Wave devices regardless of the manufacturer. For more information, visit www.z-wave.com. FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Evolve Guest Controls Inc. could void the user’s authority to operate the equipment. Support: • Email: [email protected] • Phone: 215-798-1017, ext 5.

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 15 of 35 Appendix A: ATCB Agency Authorization Letter Please refer to the following page.

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 16 of 35 Appendix B: FCC Confidentiality Request Letter Please refer to the following page.

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 17 of 35 Appendix C: FCC Modular Approval – DA 00-1407 Please refer to the following page. Application for Limited Modular Approval of Y3K-PORT Evolve Guest Controls (FCC grantee code Y3K) is applying for limited modular approval of their device with the FCC ID Y3K-PORT. This module will be limited to use with products produced by Evolve Guest Controls that also comply with the electrical standards and physical form factor of the USNAP standard. Shielding: The module was tested to comply with FCC standards on its own to meet FCC shielding requirements. I/O Buffering: The module was tested to comply with FCC standards on its own to meet I/O Requirements. Power Supply: The power supply for this module is supplied by a USNAP compliant connector that will always be supplied at a regulated 3.3V as per the standard. Antenna: The antenna for this module is a permanent PCB trace antenna Testing: Testing for this module conducted in a stand-alone configuration Label: The module will be labeled with its FCC ID in a manner that cannot be visible when it is installed. Because of this the FCC ID of the module is included as part of the FCC label of the enclosure it is inserted into. Operating Requirements: There are no special operating requirements for this device. Exposure Requirements: There are no special exposure requirements for this device.

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 31 of 35 Appendix M: External Photographs Photograph 8: Top of PCB Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 32 of 35 Photograph 9: Bottom of PCB Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 33 of 35 Photograph 10: Sample Enclosure

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 21 of 35 Appendix G: Label and Label Location Photograph 1: ID Label Sample for Module Photograph 2: ID Label Location on PCB Bottom ID Label Here Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 22 of 35 Photograph 3: Sample “Contains FCC ID.....” Label Sample for Host Contains FCC ID: Y3K-PORT IC: XXXX-YYYYYYYYYYY

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 34 of 35 Appendix N: Internal Photographs Photograph 11: Top of PCB Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 35 of 35 Photograph 12: Bottom of PCB

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Tel: 703-689-0368 Fax: 703-689-2056 Certification Application Report for Full Modular Approval FCC Part 15.249 & Industry Canada RSS-210 Test Lab: Rhein Tech Laboratories, Inc. Tel: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 www.rheintech.com Herndon, VA 20170 E-Mail: [email protected] Applicant: Evolve Guest Controls Inc. Tel: 516-328-6900 85 Denton Avenue Fax: 516-238-6622 New Hyde Park, NY 11040 www.eguestcontrols.com FCC ID/ IC: Y3K-PORT/ TBD Test Report Date: November 18, 2010 Platform: N/A RTL Work Order #: 2010226 Model: EvolveNet Portal RTL Quote #: QRTL10-459 American National Standard Institute: ANSI C63.4-2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Classification: DXX – Part 15 Low Power Communication Device Transmitter FCC Rule Part(s)/Guidance: Part 15.249: Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz, and 24.0-24.25 GHz (10-01-09) Industry Canada: RSS-210 Issue 7: Low Power License-Exempt Communications Devices Digital Interface Information: Digital Interface was found to be compliant Frequency Range (MHz) Output Power (W)* Frequency Tolerance Emission Designator 908.4 0.0005 N/A 392KFXD * power is converted from radiated measurement I, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described in this test report. No modifications were made to the equipment during testing in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to, or exclusions from, the applicable parts of FCC Part 2, FCC Part 15, Industry Canada RSS-210 and ANSI C63.4. Signature: Date: November 18, 2010 Typed/Printed Name: Desmond A. Fraser Position: President This report may not be reproduced, except in full, without the written approval of Rhein Tech Laboratories, Inc. and Evolve Guest Controls Inc. The test results relate only to the item(s) tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 2 of 35 Table of Contents 1 General Information ............................................................................................................................... 5 1.1 Scope ............................................................................................................................................ 5 1.2 Description of EUT ........................................................................................................................ 5 1.3 Test Facility ................................................................................................................................... 5 1.4 Related Submittal(s)/Grant(s) ....................................................................................................... 5 1.5 Required Grant Notes ................................................................................................................... 5 1.6 Modifications ................................................................................................................................. 5 2 Test Information ..................................................................................................................................... 6 2.1 Test Justification ........................................................................................................................... 6 2.2 Exercising the EUT ....................................................................................................................... 6 2.3 Test Result Summary .................................................................................................................... 6 2.4 Test System Details ...................................................................................................................... 6 2.5 Configuration of Tested System .................................................................................................... 7 3 Conducted AC Emissions – FCC §15.207 ............................................................................................ 8 3.1 Site and Test Description .............................................................................................................. 8 3.2 Test Limits ..................................................................................................................................... 8 3.3 Conducted AC Emissions Test Data ............................................................................................. 9 4 Radiated Emission Limits Fundamental Emissions – FCC §15.249 ................................................... 10 4.1 Radiated Emission Limits Test Procedure .................................................................................. 10 4.2 Radiated Emission Limits Test Data ........................................................................................... 10 5 Radiated Emission Limits Radiated Harmonics – FCC §15.249 ......................................................... 11 5.1 Radiated Emission Limits Test Procedure .................................................................................. 11 6 In-Band Emissions Requirement – FCC 15.215(c) ............................................................................. 13 6.1 Test Procedure ............................................................................................................................ 13 6.2 FCC 15.21…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 27 of 35 Appendix L: Test Photographs Photograph 4: Radiated Emissions Testing – Front View Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 28 of 35 Photograph 5: Radiated Emissions Testing – Back View Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 29 of 35 Photograph 6: Conducted Emissions Testing – Front View Rhein Tech Laboratories, Inc. Client: Evolve Guest Controls Inc. 360 Herndon Parkway Model: EvolveNet Portal Suite 1400 Standards: FCC 15.249 / IC RSS-210 Herndon, VA 20170 http://www.rheintech.com ID’s: Y3K/PORT / TBD Report #: 2010226 Page 30 of 35 Photograph 7: Conducted Emissions Testing – Back View
