Y4P-N86BD-9618Wireless mouse

Changes or modifications not expressly approved by the partyresponsible for compliance could void your authority to operate the equipment.

Label Location Label location

FCC ID:Y4P-N86BD-9618 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison EIRP = pt x gt = (EXd) 2 /30 Where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unit less), E = electric field strength in V/m, ---10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (Exd) 2 / 30 x gt Field strength = 85.06 dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1.00 So pt={ [10 (85.06/20) /10 6 x 3] 2 / 30 x 1.00 } x 1000 mW = 0.096mW So (0.096mW /5mm) x √2.474 = 0.030<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE14070126601 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Shenzhen Bondidea Technology Co., LTD Address of Applicant: 10th building, Honghualing Industrial Park, Qingsh, Shenzhen, China Equipment Under Test (EUT) Product Name: Wireless mouse Model No.: N86(BD-9618) Trade Mark: bondidea FCC ID: Y4P-N86BD-9618 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2013 Date of sample receipt: July 23, 2014 Date of Test: July 23-30, 2014 Date of report issued: July 31, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE14070126601 Global United Technology Services Co., Ltd. Project No.: GTSE14070126601 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 27 2 Version Version No. Date Description 00 July 31, 2014 Original Prepared By: Date: July 31, 2014 Project Engineer Check By: Date: July 31, 2014 Reviewer Report No.: GTSE14070126601 Global United Technology Services Co., Ltd. Project No.: GTSE14070126601 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 27 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1C LIENT INFORMATION ......................................................................................................................... 5 5.2G ENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3T EST MODE ........................................................................................................................................ 7 5.4D ESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.5T EST FACILITY .................................................................................................................................... 7 5.6T EST LOCATION ................................................................................................................................. 7 5.7O THER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 7 6TEST INSTRUMENTS LIST ..................................................................................................................... 8 7TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1A NTENNA REQUIREMENT: .................................................................................................................... 9 7.2R ADIATED EMISSION METHOD ........................................................................................................... 10 7.2.1Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2Spurious emissions .................................................................................................................... 13 7.2.3Bandedge emissions.................................................................................................................. 17 7.320 DB OCCUPY BANDWIDTH .............................................................................................................. 18 8TEST SETUP PHOTO ............................................................................................................................ 20 EUT CONSTRUCTIONAL DETAILS .............................................................................................................. 21 Report No.: GTSE14070126601 Global United Technology Services Co., Ltd. Project No.: GTSE14070126601 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 …

Text truncated - open the document above for the full version.

Radiated Emission
