Y9AWTHWTH

SEBINE Technology, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 01, 2012
Application Purpose: Original Equipment
Date of Application: Feb 01, 2012
Equipment Note: WTH
Frequency Range: 2412.00000000 - 2462.00000000
Company: SEBINE Technology, Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

WTH WTH_ENG_20120201.hwp1 WTH System Manual Ver 1.00 SEBINE Technology, Inc. WTH WTH_ENG_20120201.hwp2 CONTENTS 1. Summary 1.1 Product Introduction 1.2 Specification 2. Device Summary 2.1 Power Supply 2.2 USB communication connection 2.3 LED Indicator 3. Wi-Fi wireless communication environmental setting 3.1 Wireless LAN(AP) setting 3.2 WTH setting Appendix 1. WTH USB Driver Installation Appendix 2. WTH UDP Server Installation Appendix 3. Document History Appendix 4. Dimension WTH WTH_ENG_20120201.hwp4 1. Outline 1.1 Product Introduction WTH is a sensor to detect temperature and humidity wirelessly by using ISM 2.4GHz frequency bandwidth. WTH transmits the temperature. humidity, and smoke detection data at each user set-up period via UDP communication method. Users can configure their own setting for WTH via serial communication program. ※ Keep the filter of a sensor clean. WTH WTH_ENG_20120201.hwp5 1.1.1 Product Application Examples Product Application Examples 1.1.2 Product Application Area lDepartment Store, Public Office, Gymnasium lMuseum, School, Manufacturing Factory lOffice Building, Movie Theater, Shipbuilding/Marine 1.1.3 Product Package WTH main body, USB cable, User manuel, Utility CD WTH WTH_ENG_20120201.hwp6 1.2 Specification ItemSpecification Name WTH Dimension 110mm(L)×80mm(W)×33mm(H) Housing ABS Weight 300g (w/o Battery, Antenna) Power Supply AA size 3.6Volt LITHIUM BATTERY 1EA or 2EA Current Consumption Tx 190mA, Rx 140mA (@3.6Vdc) Operating Temperature -40°C ~ +85°C RF Features • Frequency : 2412 ~ 2472 MHz • Standard Supported: IEEE 802.11b • Transmitter Power : Max. 7mW • Modulation : IEEE 802.11b : DSSS : 1Mb/s and 2Mb/s IEEE 802.11b : CCK : 5.5Mb/s and 11Mb/s • Channels: Europe – 13 channels USA – 11 channels Performance • RF Data Rate: 1Mb/s to 11Mbps I/O Interface • USB Connector Antenna Interface • SMA(Female, Reverse) • Impedance 50Ω Sensor Temperature /Humidity • Accuracy Humidity : ±3.0 Temperature : ±0.4 @°C WTH Specification WTH WTH_ENG_20120201.hwp7 2. Device Summary WTH inside 2.1 Power Supply WTH operates using on or two AA size 3.6Volt LITHIUM BATTERIES. Be careful with battery orientation. 2.2 USB communication connection To use WTH, proper setting is necessary for wireless environment to be installed. For setting, connect PC and WTH using USB cable provided in the package. For detailed settings after USB communication connection, see section 3.2. 2.3 LED Indicator LED turns on during operation when serially connected battery power drops below 3.4V. The WTH may malfunction under 3.4V so batteries need to be changed. WTH WTH_ENG_20120201.hwp8 3. Wi-Fi wireless communication environmental setting 3.1 Wireless LAN(AP) setting To use WTH, wireless LAN(AP) setting is needed for WTH connection. 3.1.1 SSID setting(required) When WTH is connected to wireless LAN(AP), SSID is being searched. Thus, SSID must be set on AP and SSID(network) notification function should be used. 3.1.2 Password disabled setting for AP(required) WTH does not use encrypted method for minimizing the system correct consumption. Thus, set password disabled for AP. 3.1.3 DHCP disabled(option) WTH does not use DHCP. Wireless LAN(AP) executes or stops DHCP server setting. 3.1.4 MAC Address registration(option) When password is disabled for wireless LAN(AP), the Mac address of WTH is registered to wireless LAN(AP) so that only the registered Mac Address is permitted. This prevents network overflow. WTH WTH_ENG_20120201.hwp9 3.2 WTH setting To use WTH, Wi-Fi wireless communication environment setting is necessary. 3.2.1 Connection between WTH and PC To set the wireless communication environment for WTH, connect PC with WTH using the USB cable provided at product purchase. The connection sequence is shown below. ※ Before connection, install USB driver of WTH.[See Appendix 1. USB driver installation] Step 1. With batter inserted at WTH, set System Power SW OFF. WTH setting - POWER SW Step 2. Connect one port of USB cable to PC, and the other port to WTH. Step 3. Switch Mode Selection SW to USB side. WTH setting - Mode Selection SW WTH WTH_ENG_20120201.hwp10 Step 4. Execute the serial communication program. ▶ Serial communication program setting - Baud Rate : 115200 - Data Bit : 8 - Stop Bit : 1 - Parity Bit : None Step 5. Set the System Power SW of WTH ON. When correctly connected, data are shown on serial communication program shown below. Data output via serial communication program WTH WTH_ENG_20120201.hwp11 3.2.2 Wi-Fi wireless communication environment setting of WTH Step 1. SSID setting Insert the SSID of wireless LAN(AP) to be connected with WTH. ▶ Data Format : <SSID> ▶ Example : sebinetech WTH setting - SSID Input WTH WTH_ENG_20120201.hwp12 Step 2. Static Configuration of Network Parameters setting Insert the information for WTH for connection to wireless LAN(AP). ▶ Data Format : <Src Address>,<Net-mask>,<Gateway> ▶ Example : 192.168.30.21,255.255.255.0,192.168.0.1 WTH setting - Network Parameters Input WTH WTH_ENG_20120201.hwp13 Step 3. Static Configuration of DNS setting Insert DNS server info for WTH for connection to wireless LAN(AP). ▶ Data Format : <DNS1 IP>,<DNS2 IP> ▶ Example : 168.126.63.1,168.126.63.2 WTH setting - DNS Server Input WTH WTH_ENG_20120201.hwp14 Step 4. UDP Clients setting Insert IP and Port number of server to which WTH sends data. ▶ Data Format : <Dest-Address>,<Port> ▶ Example : 192.168.0.50,3030 WTH setting - UDP Clients Input WTH WTH_ENG_20120201.hwp15 Step 5. Period setting Insert a period for WTH to send data. ▶ Data Format : <time><time unit> ※ <time> must be 2 digit ▶ Example : 30s ▶ s : sec m : min h : hour WTH setting - Period Input WTH WTH_ENG_20120201.hwp16 3.2.3 Disconnection between WTH and PC When all settings are done, a message “Please Reboot!!" appears. Serial communication program is terminated. When necessary, device manager removes the device. Step 1. Shut down the serial communication program. Step 2. Set the System Power SW of WTH off. Ste…

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 SEBINE Technology, Inc. January 30, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SEBINE Technology, Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID : Y9AWTH We affirm that between SIEMIC and SEBINE Technology, Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Eun-Seong Yoo / Manager SEBINE Technology, Inc. RN 302, Daedeok Radio Engineering Center, 604, Tamnip-dong, Yuseong-gu, Daejeon, Korea 305-510

Cover Letter(s)

Date : January 26, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: Y9AWTH Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Part list Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Eun-Seong, Yoo Manager of Development Team SEBINE Technology, Inc.

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Page: 1/2 Frequency range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (B) Limits for General Population/Uncontrolled Exposure 300-1500--f / 1 50030 1. RF Exposure Requirement 1.1 Method of Measurement This device is not exempted from compliance does not exceed the Commission’'s RF exposure guidelines. Unless a device operates at substantially low power levels, with a low gain antenna(s), supporting information is generally needed to establish the various potential operating configurations and exposure conditions of a transmitter and its antenna(s) in order to determine compliance with the RF exposure guidelines. In order to demonstrate compliance with MPE requirements (see Section 2.1091), the following information is typically needed: Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits Any other RF exposure related issues that may affect MPE compliance. 1.2 Limits FCC 1.1310:- The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) f = frequency in MHz ChannelFrequency(MHz)Power Density (mW/cm 2 ) L 2 4121.608 M 2 4371.624 H 2 4621.641 CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Page: 2/2 1.3 Test Results Frequency [MHz] Conducted Power [dBm] Antenna Gain [dBi] Calculated EIRP [mW] Laboratory’s Recommended Minimum RF Safety Distance r [Cm] Power Density in mW/cm 2 at Formula When r=20Cm [mW/cm 2 ] 2 4125.075.0610.302.020.002 0 2 4375.095.1410.542.050.002 1 2 4625.695.1712.192.200.002 4 Calculation Method of RF Safety Distance: S = 22 44r EIRP r PG ππ = P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator R: distance to centre of radiation in cm FCC radio frequency exposure limits may be exceeded at distances closer than r cm from the antenna of this device r = S EIRP S PG ππ44 =

Test Report

CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Report Number : CBTP-12R-0002 Page: 2/35 This report may not be reproduced without the full written approval of CHUNGBUK TECHNOPARK. TABLE OF CONTENTS 1. Test Laboratory ······················································································································· 3 1.1 General Information ········································································································································ 3 1.2 Location of Test Laboratory ························································································································· 3 1.3 Registration Information ································································································································· 3 2. Test Rule ································································································································· 4 2.1 Test Rule Part(s) ············································································································································ 4 2.2 Equipment Under Test(EUT) Modifications ································································································ 4 3. Description for Equipment Under Test(EUT) ····································································· 5 4. Test Equipment ······················································································································· 6 5. 6 dB bandwidth ······················································································································ 7 6. maximum peak conducted output power ··········································································· 10 7. antenna gain ·························································································································· 13 8. 100 kHz bandwidth outside the frequency band ······························································ 14 9. power spectral density conducted ······················································································· 24 10. Radiated Emissions ············································································································· 27 11. FCC Labelling Requirements ···························································································· 33 12. Test Setup Photographs ······································································································35 13. Photographs of Equipment Under Test(EUT) ································································· 38 CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Report Number : CBTP-12R-0002 Page: 3/35 This report may not be reproduced without the full written approval of CHUNGBUK TECHNOPARK. 1. Test Laboratory 1 . 1 Ge ne ral Inf o rmati o n Name of LaboratoryCHUNGBUK TECHNOPARK RepresentativeJongsung, Lim Address 685-1 Yangcheong-ri, Ochang-eup, Cheongwon-gun, Chungcheongbuk-do, Korea Telephone Number043-270-2000 Fax Number043-270-2099 Homepagewww.cbtp.or.kr 1.2 Location of Test Laboratory Address 685-3 Yangcheong-ri, Ochang-eup, Cheongwon-gun, Chungcheongbuk-do, Korea Telephone Number043-270-2500 Fax Number043-270-2599 1.3 Registration Information Test item(s)FacilityRegistration Number Radiated Emission Measurement10m semi-anechoic chamber 647924 Conducted Emission MeasurementShielded room CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Report Number : CBTP-12R-0002 Page: 4/35 This report may not be reproduced without the full written approval of CHUNGBUK TECHNOPARK. 2. Test Rule 2.1 Test Rule Part(s) Test item(s)Test Rule Part(s)Test Result 1. 6 dB bandwidth15.247 (a)(2) □ Pass□ Fail 2. maximum peak conducted output power15.247 (b)(3) □ Pass□ Fail 3. antenna requirement 15.247 (b)(4) 15.203 ■ Pass□ Fail 4. 100 kHz bandwidth outside the frequency band15.247 (d) ■ Pass□ Fail 5. power spectral density conducted15.207 (e) □ Pass□ Fail 6. Radiated emissions 15.247(d) 15.209(a) 15.205(a) ■ Pass□ Fail ※ The EUT contains Transmitter Module FCC ID : YOPGS1011MIE. 2.2 Equipment Under Test(EUT) Modifications No modifications were made to the EUT in order to achieve and maintain compliance to the standards described in this report. CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Report Number : CBTP-12R-0002 Page: 5/35 This report may not be reproduced without the full written approval of CHUNGBUK TECHNOPARK. 3. Description for Equipment Under Test(EUT) CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.or.kr Report Number : CBTP-12R-0002 Page: 6/35 This report may not be reproduced without the full written approval of CHUNGBUK TECHNOPARK. TypeModelManufactureS/NCAL. Due PSA Spectrum AnalyzerE4440AAgilent TechnologiesMY461880562012.05.28 Programmable D.C Power Supply PSS-3203GW InstekEH1709002012.05.26 Test ReceiverESIB26Rohde & Schwarz1003592012.05.28 Horn AntennaBBHA9120DSchwarzbeck9120D-5392013.04.13 AntennaCBL6112DSchaffner220222012.10.07 4. TEST EQUIPMENT 4.1 Operation of Equipment Under Test(EUT) The Equipment Under Test was configured for testing in a typical fashion (as a customer would normally use it). During the tests, the EUT and the supported equipments were installed to meet FCC requirement and operated in a manner and which tends to maximize its emission level in a typical application. ChannelFrequency(MHz) L 2 412 M 2 437 H 2 462 CHUNGBUK TECHNOPARK #685-3, Yangcheong, Ochang, Cheongwon, Chungbuk, Korea TEL:(043)270-2500 FAX:(043)270-2599 http://www.cbtp.…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Eun-Seong Yoo(Manager)

[email protected]+82-42-935-2085Fax: +82-42-935-2088

Test Firm

CHUNGBUK TECHNOPARKSeong-Uk Park

[email protected]82-43-270-2550Fax: +82-43-270-2599

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	80.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance..
