Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
10 English Hello, and thank you for having purchased the Smart&Green KEY remote control. It will allow you to control very easily your Smart & Green lights equipped with the KAMELEON TECHNOLOGY. CONTROL YOUR LAMPS WITH KEY kameleon technology TECHNICAL DATA BATTERY COMPARTMENT COVER ON / OFF COLOURS MODES LUMINOUS INDICATOR switches on or off the lamp or the group GROUP BUTTON FRONT PANEL SHOCK PROOF SPLASH PROOF 100 meters maximum without any obstacles. REMOTE CONTROL RANGE ip44, the remote control can be used or forgotten under the rain. Hereby, IPW Europe, declares that this KEY is in compliance with the essential require- ments and other relevant provisions of Directive 1999/5/EC. S&G-Manuel-kaméléon-KEY.indd 1028/08/12 16:49:00 11 CONTROL YOUR LAMPS WITH KEY kameleon technology BATTERY COMPARTMENT COVER LUMINOUS INDICATOR REAR PANEL BATTERY CHANGE PROCEDURE REAR PANEL - battery service life : 3 years for standard usage. - battery type : cr 2450 BATTERIES Insert a tip in the notch and turn to unscrew. careFully read this guide beFore using the device and Keep it handy For Future use. Use the remote control in conformity with the utilization precautions ; failure to do so will cancel any warranty. • If not used for an extended period, remove the battery from the remote control • Do not immerse it • Do not expose it to fi re • Keep it outside the reach of young children • Use the supplied battery reference • Do not expose it to sunlight for a long time • Do not try to dismount the remote control > For any questions about the proper operation of this product, please contact the point of sale where you purchased the product. The components of this remote control cannot be replaced ; if any part is damaged, the remote control must be discarded. S&G-Manuel-kaméléon-KEY.indd 1128/08/12 16:49:00 12 THE LIGHT PART OPERATION Thanks to this remote control, you will be able to apply many new functions. Two specifi c functions : the light part and the lamp group control part COLOUR CONTROL : 9 pre-recorded colours COLOUR CIRCLE FRESH Rotation of cold colours PASTEL Rotation of light colours FASHION Rotation of warm colours RAINBOW Scrolling of all the colours Candle effect fl ickering of the LEDS LOUNGE Rotation colour by colour (30 sec per colour) LUMINOUS COLOUR INDICATOR OF SELECTED MODE This colour fl ashes once before the cycle beginsne commence MODE CYCLE Candle effect fl ickering of the LEDS CANDLE EFFECT MODE CONTROL : 6 pre-recorded modes S&G-Manuel-kaméléon-KEY.indd 1228/08/12 16:49:01 13 - synchroniZation : perfect coordination between the modules - pairing : creation of links between the lamps. - control by area : creation of a lamp group to control the various areas. (example : a group for the basic room, a group of the VIP corner, etc...) - communication betWeen the modules : each lamp gives the order to the next one, without any limit in distance. LAMP GROUP CONTROL PART THE ADVANTAGES SEE EACH LAMP’S STATUS 5 seconds GROUP PART If the lamp lights red it means that it is in another group. If the lamp lights green it means that it is already grouped. If the lamp lights blue it means that it is available. long press (about 5 sec) the button to return to the group mode. = S&G-Manuel-kaméléon-KEY.indd 1328/08/12 16:49:01 14 Once in the group mode, pressing the button briefl y links the nearest 10 blue bulbs (as long as the operation is in progress the indicator lamp fl ashes green) Redo the same operation with the lamps that you want to integrate in this group. CREATE A LINK If you have two remote controls, use the remote control which allowed connecting them. Same procedure as for the green link, but using the appropriate remote control. BREAK A RED LINK When you press one of these 2 buttons, the light that you will control goes on in red and then goes off. 10 seconds this operation can be performed directly on the K bulb or K bulblite module.. DEGROUP A COMPLETE GROUP Your lamps go on then in blue (not associated with a group) long press 10 seconds and then 5 seconds The remote control lumi- nous indicator fl ashes green. S&G-Manuel-kaméléon-KEY.indd 1428/08/12 16:49:02 15 Your lamps go on then in blue (not associated with a group) EXIT THE GROUP MODE long press 5 seconds You can control all your lamps using your remote control, even those locked by the Hold mode. this function is to be enabled directly on the module 3 seconds or CONTROL THE HOLD MODULES S&G-Manuel-kaméléon-KEY.indd 1528/08/12 16:49:02 FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
IPW China Limited 5/F, Block B3, Xujingchang Industrial Park, Fuyong, Shenzhen, Guangdong, China --------------------------------------------------------------------------------------------------------------------- Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: Y9P-K-KEY-051 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Y9P-K-KEY-051_FCCID_Schematics Block Diagram Y9P-K-KEY-051_FCCID_BlockDiagram Operational Description Y9P-K-KEY-051_FCCID_OperationalDescripiton The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, IPW China Limited
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EUT View 3 EUT View 4 IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EUT View 5 EUT View 6
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: Y9P-K-KEY-051 Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: Y9P-K-KEY-051 Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 Solder Board-Component View 1 Solder Board-Component View 2 IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 Antenna View Ant. 905MHz
Operational Description The product is a remote control. it uses a radio frequency 905MHz U1 MSP430F5324IRGCR is a CPU of the product. C1101 is a transceiver designed for low-power wireless applications. It works with a crystal Q1 26MHz
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I PAGE 1 OF 17 FCC PART 15.249 FCC Part 15C Measurement and Test Report For IPW China Limited 5/F, Block B3, Xujingchang Industrial Park, Fuyong, Shenzhen, Guangdong, China FCC ID: Y9P-K-KEY-051 FCC Rules: FCC Part 15.249 Product Description: KEY/PEBBLE PRO Tested Model: S&G-051 Report No.: STR13038522I Tested Date: 2013-04-01 to 2013-04-16 Issued Date: 2013-04-17 Tested By: Seven Song / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: SEM.Test Compliance Service Co., Ltd 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R.C.(518101) Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by SEM.Test Compliance Service Co., Ltd IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I PAGE 2 OF 17 FCC PART 15.249 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 3 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 TEST METHODOLOGY ............................................................................................................................................. 4 1.4 TEST FACILITY ....................................................................................................................................................... 4 1.5 EUT SETUP AND TEST MODE ................................................................................................................................. 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. ANTENNA REQUIREMENTS ................................................................................................................................ 7 3.1 STANDARD APPLICABLE ......................................................................................................................................... 7 3.2 TEST RESULT.......................................................................................................................................................... 7 4. RADIATED EMISSIONS ......................................................................................................................................... 8 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 8 4.2 STANDARD APPLICABLE ......................................................................................................................................... 8 4.3 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 4.4 TEST PROCEDURE ................................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION .............................................................................................. 9 4.6 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 10 4.7 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 10 5. OUT OF BAND EMISSIONS ................................................................................................................................. 14 5.1 STANDARD APPLICABLE ....................................................................................................................................... 14 5.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 14 5.3 TEST PROCEDURE ................................................................................................................................................. 14 5.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 14 5.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 14 6. EMISSION BANDWIDTH ..................................................................................................................................... 16 6.1 STANDARD APPLICABLE ....................................................................................................................................... 16 6.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 16 6.3 TEST PROCEDURE ................................................................................................................................................. 16 6.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 16 6.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 16 IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I PAGE 3 OF 17 FCC PART 15.249 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Informat…
Text truncated - open the document above for the full version.
IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) IPW China Limited Model: S&G-051 REPORT NO.: STR13038522I FCC PART 15.249 Radiation Emission Test Setup (Above 1GHz)
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 905 MHz - 905 MHz | - |

LED Lamp
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
BULBLITE-IC
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Remote Control
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
K BULB/DELICES PRO
Equipment Class
DXX - Part 15 Low Power Communication Device TransmitterREMOTE CONTROL
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
