Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 1 of 93 FCC Radio Test Report FCC ID: YAE-L5200 This report concerns (check one) : Original Grant Class II Change Issued Date : Aug. 30, 2011 Project No. : 1108C157 Equipment : MOUSE Model Name : L5200 Applicant : Ergowerx International LLC Address : 39 Park Place Suite 201, Englewood, NJ 07631 USA Manufacturer : Shenzhen Fuyeda Industry Development Corp.,Ltd. Address : NO.1,NEWMEN ROAD,TONGSHENG VILLAGE,DALANG STREET,BAO’AN, SHENZHEN, CHINA Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Aug. 15, 2011 Date of Test: Aug. 15, 2011 ~ Aug. 29, 2011 Testing Engineer : (Ivan Cao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 2 of 93 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 3 of 93 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 18 4.2.3 TEST PROCEDURE 19 4.2.4 DEVIATION FROM TEST STANDARD 19 4.2.5 TEST SETUP 20 4.2.6 EUT OPERATING CONDITIONS 20 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 21 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 5 . NUMBER OF HOPPING CHANNEL 47 5.1 APPLIED PROCEDURES / LIMIT 47 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 47 5.1.2 TEST PROCEDURE 47 5.1.3 DEVIATION FROM STANDARD 47 5.1.4 TEST SETUP 47 5.1.5 EUT OPERATION CONDITIONS 47 5.1.6 TEST RESULTS 48 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 4 of 93 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 50 6.1 APPLIED PROCEDURES / LIMIT 50 6.1.1 MEASUREMENT INSTRUMENTS LIST 50 6.1.2 TEST PROCEDURE 50 6.1.3 DEVIATION FROM STANDARD 50 6.1.4 TEST SETUP 51 6.1.5 EUT OPERATION CONDITIONS 51 6.1.6 TEST RESULTS 52 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 64 7.1 APPLIED PROCEDURES / LIMIT 64 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 64 7.1.2 TEST PROCEDURE 64 7.1.3 DEVIATION FROM STANDARD 64 7.1.4 TEST SETUP 64 7.1.5 EUT OPERATION CONDITIONS 64 7.1.6 TEST RESULTS 65 8 . BANDWIDTH TEST 69 8.1 APPLIED PROCEDURES / LIMIT 69 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 69 8.1.2 TEST PROCEDURE 69 8.1.3 DEVIATION FROM STANDARD 69 8.1.4 TEST SETUP 69 8.1.5 EUT OPERATION CONDITIONS 69 8.1.6 TEST RESULTS 70 9 . PEAK OUTPUT POWER TEST 74 9.1 APPLIED PROCEDURES / LIMIT 74 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 74 9.1.2 TEST PROCEDURE 74 9.1.3 DEVIATION FROM STANDARD 74 9.1.4 TEST SETUP 74 9.1.5 EUT OPERATION CONDITIONS 74 9.1.6 TEST RESULTS 75 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 79 10.1 APPLIED PROCEDURES / LIMIT 79 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 79 10.1.2 TEST PROCEDURE 79 10.1.3 DEVIATION FROM STANDARD 79 10.1.4 TEST SETUP 79 10.1.5 EUT OPERATION CONDITIONS 79 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 5 of 93 Table of Contents Page 10.1.6 TEST RESULTS 80 11 . EUT TEST PHOTO 92 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1108C157 Page 6 of 93 1. CERTIFICATION Equipment : MOUSE Brand Name : Smartfish Model Name : L5200 A p p l i c a n t : Ergowerx International LLC Factory : Shenzhen Fuyeda Industry Development Corp.,Ltd. Address : NO.1,NEWMEN ROAD,TONGSHENG VILLAGE,DALANG STREET,BAO’AN, SHENZHEN, CHINA Date of Test : Aug. 15, 2011 ~ Aug. 29, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1108C157) were obtained utilizing the test procedures, test instruments, test site…
