YAM-TM628HVMobile Radio

RF Energy Exposure Compliance Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. Your radio complies with the following of RF energy exposure standards and guidelines ● United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J ● American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 ● Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition ● International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 Safety Information The following safety precautions shall always be observed during operation, service and repair of this equipment. z This equipment shall be serviced by qualified technicians only. z Do not modify the radio for any reason. z Use only HYT supplied or approved antenna. z Gain of antenna must not exceed 3.5dBi for VHF or 5.5dBi for UHF. z Mobile antenna Installation: Install the mobile antenna at least 100cm (34 inches) away from your body, in accordance with the requirements of the antenna manufacturer/supplier. z Transmit only when people inside and outside the vehicle are at least the minimum distance away from a properly installed, externally mounted antenna. z Mobile antenna substitution: Don’t substitute HYT supplied or approved antenna, or excessive radio frequency radiation will result. Please contact your dealer or the manufacturer for further instructions. z Please make sure there’s no stress on the antenna joint during transportation or installation. z To avoid electromagnetic interference and/or compatibility conflicts, turn off your radio in any area where posted notices instruct you to do so. Hospital or health facilities may be using equipment that is sensitive to external RF energy. z For vehicles with an air bag, do not place a radio in the area over an air bag or in the air bag deployment area. z Turn off your radio prior to entering any area with explosive and flammable materials. z Do not expose the radio to direct sunlight over a long time, nor place it close to heating source. ▇ Operation Guidelines For vehicles equipped with electronic anti-skid braking systems, electronic ignition systems or electronic fuel injection systems, interferences may occur during radio transmission. If the foregoing electronic equipments are installed on your vehicle, please contact your dealer for further assistance to make sure that radio transmission will not interfere with these equipments. For radio installation in vehicles fueled by LP gas with LP gas container within interior of the vehicles, the following precautions are recommended for personal safety. 1. Any space containing radio equipment shall be isolated by a seal from the space in which the LP gas container and its fittings are located. 2. Remote (outside) fitting connections shall be used. 3. Good ventilation is required for the container space. ▇ Installation Guidelines z Vehicle installation: The antenna can be mounted at the center of a vehicle metal roof or trunk lid if the minimum safe distance is observed. z Do not mount the mobile radio overhead or on a sidewall unless you take special precautions. z If the mobile radio is not properly installed, road shock could bump the radio loose, and the falling radio could, in some circumstances, cause serious injury to the driver or a passenger. In case of vehicle accidents, even when properly installed, the radio could break loose and become a dangerous projectile. 1 Preface Thank you for purchasing HYT TM-628H Mobile Radio. This easy-to-use radio will deliver you secure, instant and reliable communication at peak efficiency. To derive optimum performance from your radio, please read this manual and the supplied Safety Information Booklet carefully before use. 2 Icon Information The following icons are available through this manual: Caution: indicates situations that could cause damage to your radio. Note: indicates tips that can help you make better use of your radio. Copyright Information HYT and Hytera are trademarks or registered trademarks of HYT in the PRC and other countries and/or areas. HYT retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The HYT product described in this manual may include HYT computer programs stored in memory or other media. Laws in the PRC and/or other countries or areas preserve for HYT exclusive rights for HYT computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser with respect to HYT computer programs. Any HYT computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of HYT. Disclaimer HYT endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without prior notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of HYT. If you have any suggestions or would like to learn more details, please visit us at: http://www.hyt.cn . 3 Contents Checking Items in the Package ......................…

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAM-TM628HV to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Suzi Lan/Certification Engineer Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Justification Letter DATE: June 02, 2010 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAM-TM628HV Model: TM-628HV Dear Sir/Madam, We , Hytera Communications Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communications Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Suzi Lan/Certification Engineer Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

External photos of the EUT

Internal photos of the EUT

Main board PN 1301628V10020 Description TM-628HVHF main board (136-174MHz)(RoHS) P/N description number code position 3001050000000 Chip resistor RTT02/RC0402 0Ω J 1/16W -55~+155°C 04 02 R A 45 C177 B6C (RoHS) C404 B7F R106 T4C R419 B8F R448 B8J R451 B8J R455 B7J R457 T7D R485 B7J R510 T7F R513 T8F R518 T6H R520 T6I R521 T6I R522 T6I R564 T7M R577 T7I R580 T7I R584 T7I R586 T7I R595 T8I R598 T6J R599 T6J R605 B2L R616 T7I R618 T7I R625 B7J R627 T8F R644 B9I R645 T8J R646 T9H R654 T8I R655 T7I R823 B4J R824 B4I R825 B5I R908 B7I R909 B7I R910 B7I R912 B7I R913 B8I R919 T7H R921 T7H R922 T7I R923 T7H 3001051010000 Chip resistor RTT02/RC0402 100Ω J 1/16W -55~+155°C 0402 6 R168 B5F (RoHS) R173 B6I R174 B4E R197 T5A R501 T8F R649 B8I 3001051020010 Chip resistor RTT02/RC0402 1KΩ J 1/16W -55~+155°C 0 402 R 22 R121 B4A (RoHS) R123 B4A R145 T6B R200 T5B R439 B7J R453 B7J R476 T8E R503 T8G R504 T8F R505 T7F R506 T7F R609 T6G R610 T6F R611 T6G R612 T7F R613 T8L R632 T7F R802 B5I R826 B6I R906 T6F R933 T8H R934 T8H 3001051030000 Chip resistor RTT02/RC0402 10KΩ J 1/16W -55~+155°C 0402 20 R107 T4C (RoHS) R110 T4C R170 B6I R176 B5F R198 T4B R402 B7G R403 B7F R423 B7F R424 B7F R449 B8J R450 B8J R464 T6D R470 T8D R472 T8E R477 T8E R509 T7F R515 T8F R804 B5J R902 B9D R904 B9D 3001051040000 Chip resistor RTT02/RC0402 100KΩ F 1/16W -55~+155°C 040 2 2 R490 B7H (RoHS) R801 B6J 3001051040010 Chip resistor RTT02/RC0402 100KΩ J 1/16W -55~+155°C 040 2 24 R104 T4B (RoHS) R105 T4B R115 T4C R116 T4C R118 B5B R119 B4C R120 B4B R125 B5B R128 B4C R130 B5B R131 B5B R132 B5B R133 B6D R148 B5D R149 T6A R180 T2H R427 B7E R467 T8D R468 T8D R514 T6F R565 T7M R566 T7M R631 T7I R806 B5K 3001051050020 Chip resistor RTT02/RC0402 1MΩ J 1/16W -55~+155°C 0 402 R 3 R431 B8E (RoHS) R473 T8E R901 B8D 3001051230000 Chip resistor RTT02/RC0402 12KΩ J 1/16W -55~+155°C 0402 3 R152 T6B (RoHS) R416 B8G R471 T8D 3001051240000 Chip resistor RTT02/RC0402 120KΩ J 1/16W -55~+155°C 040 2 4 R135 B6D (RoHS) R136 B6D R437 B7D R827 B6K 3001051520010 Chip resistor RTT02/RC0402 1.5KΩ F 1/16W -55~+155°C 040 2 2 R138 B6D (RoHS) R151 T6C 3001051530000 Chip resistor RTT02/RC0402 15KΩ J 1/16W -55~+155°C 0402 5 R404 B7F (RoHS) R408 B7G R440 B7J R465 T6D R830 B6J 3001051540020 Chip resistor RTT02/RC0402 150KΩ J 1/16W -55~+155°C 040 2 2 R475 T8E (RoHS) R478 T8E 3001051810010 Chip resistor RTT02/RC0402 180Ω J 1/16W -55~+155°C 0402 4 R141 T6D (RoHS) R143 B5C R182 T3H R184 T3H 3001051830000 Chip resistor RTT02/RC0402 18KΩ J 1/16W -55~+155°C 0402 5 R175 B4F (RoHS) R418 B8G R428 B7E R434 B8D R435 B8D 3001051840000 Chip resistor RTT02/RC0402 180KΩ J 1/16W -55~+155°C 040 2 7 R134 B6D (RoHS) R413 B7G R459 T7D R460 T7D R461 T6E R807 B5J R832 B6K 3001052200000 Chip resistor RTT02/RC0402 22Ω J 1/16W -55~+155°C 0 402 R 2 R803 B6J (RoHS) R808 B4J 3001052210000 Chip resistor RTT02/RC0402 220Ω J 1/16W -55~+155°C 0402 3 R117 T4D (RoHS) R172 B6I R412 B7F 3001052220000 Chip resistor RTT02/RC0402 2.2KΩ J 1/16W -55~+155°C 040 2 1 R604 B2L (RoHS) 3001052230010 Chip resistor RTT02/RC0402 22KΩ J 1/16W -55~+155°C 0402 13 R158 T7C (RoHS) R159 T7B R161 T7B R162 T7C R409 B7G R441 B7J R442 B7J R445 B8K R452 B8K R458 T7D R466 T8D R491 B8H R829 B6K 3001052710010 Chip resistor RTT02/RC0402 270Ω J 1/16W -55~+155°C 0402 1 R204 B4B (RoHS) 3001052720000 Chip resistor RTT02/RC0402 2.7KΩ J 1/16W -55~+155°C 040 2 3 R407 B8F (RoHS) R818 B4I R935 T7H 3001058230000 Chip resistor RTT02/RC0402 82KΩ J 1/16W -55~+155°C 0402 3 R410 B7G (RoHS) R462 T6D R653 T6J 3001059130000 Chip resistor RTT02/RC0402 91KΩ F 1/16W -55~+155°C 0402 1 R443 B8K (RoHS) 3001052730000 Chip resistor RTT02/RC0402 27KΩ J 1/16W -55~+155°C 0402 1 R421 B7E (RoHS) 3001053030010 Chip resistor RTT02/RC0402 30KΩ J 1/16W -55~+155°C 0402 2 R154 T6B (RoHS) R414 B7G 3001053300010 Chip resistor RTT02/RC0402 33Ω J 1/16W -55~+155°C 0 402 R 3 R139 B6C (RoHS) R167 B6I R183 T3H 3001053310010 Chip resistor RTT02/RC0402 330Ω J 1/16W -55~+155°C 0402 2 R177 B4F (RoHS) R178 B5F 3001053320000 Chip resistor RTT02/RC0402 3.3KΩ J 1/16W -55~+155°C 040 2 2 R111 T5C (RoHS) R153 T6B 3001053330010 Chip resistor RTT02/RC0402 33KΩ J 1/16W -55~+155°C 0402 6 R432 B8F (RoHS) R433 B7D R436 B7D R482 B7D R516 T6G R563 T7L 3001053340000 Chip resistor RTT02/RC0402 330KΩ J 1/16W -55~+155°C 040 2 3 R108 T4C (RoHS) R406 B7F R422 B8F 3001053920010 Chip resistor RTT02/RC0402 3.9KΩ J 1/16W -55~+155°C 040 2 1 R155 T7B (RoHS) 3001053940000 Chip resistor RTT02/RC0402 390KΩ J 1/16W -55~+155°C 040 2 1 R463 T6D (RoHS) 3001054700000 Chip resistor RTT02/RC0402 47Ω J 1/16W -55~+155°C 0 402 R 2 R127 B6C (RoHS) R169 B5F 3001054720000 Chip resistor RTT02/RC0402 4.7KΩ J 1/16W -55~+155°C 040 2 17 R160 T6B (RoHS) R163 T7B R171 B6I R401 B7G R447 B8K R469 T8E R502 T8G R507 T7F R508 T7F R511 T8G R525 T8G R526 T8G R543 B6L R571 B6L R573 B8L R602 B4L R822 B6F 3001054730000 Chip resistor RTT02/RC0402 47KΩ J 1/16W -55~+155°C 0402 25 R101 T4B (RoHS) R102 T4B R103 T4B R144 T5B R179 B5E R199 T4A R202 T4B R405 B7G R438 T7D R454 B7J R489 B7H R492 B8H R517 T6G R519 T6G R523 T6H R524 T6H R544 B6L R545 B9L R550 B7K R562 T7L R567 T7M R572 B6L R601 B4L R603 B3L R905 T6F 3001055130010 Chip resistor RTT02/RC0402 51KΩ J 1/16W -55~+155°C 0402 2 R411 B7G (RoHS) R420 B7F 3001055600000 Chip resistor RTT02/RC0402 56Ω J 1/16W -55~+155°C 0 402 R 2 R203 B5I (RoHS) R828 B6K 3001055630000 Chip resistor RTT02/RC0402 56KΩ J 1/16W -55~+155°C 0402 2 R429 B8E (RoHS) R430 B8E 3001055640000 Chip resistor RTT02/RC0402 560KΩ J 1/16W -55~+155°C 040 2 1 R156 T6B (RoHS) 3001056820000 Chip resistor RTT02/RC0402 6.8KΩ J 1/16W -55~+155°C 040 2 2 R112 T5C (RoHS) R417 B8F 3001056830000 Chip resistor RTT02/RC0402 68KΩ J 1/16W -55~+155°C 0402 3 R444 B8K (RoHS) R456 B7E VR101 T5B 3001058220000 Chip resistor RTT02/RC0402 8.2KΩ J 1/16W -55~+155°C 040 2 1 R474 T8E (RoHS) 3001051820010 Chip resistor RTT02/RC0402 1.8KΩ F 1/16W -55~+155°C 040 2 2 R129 B4B (RoHS) R150 T6C 3001060000000 Chip resistor RTT03/RC0603 0Ω J 1/10W -55~+155°C 06 03 R A 13 D50…

Text truncated - open the document above for the full version.

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) FCC ID .............................................: YAM-TM628HV Compiled by ( position+printed name+signature)..: File administrators Xiankun Ding Supervised by ( position+printed name+signature)..: Test Engineer Wenliang Li Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: June 02, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Hytera Communications Corporation Ltd. Address.............................................: HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ...........................................: FCC Per 47 CFR 2.1091(b) TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Mobile Radio Trade Mark .......................................: HYT Manufacturer ....................................: Hytera Communications Corporation Ltd. Model/Type reference.......................: TM-628HV Listed Models ..................................: / Ratings..............................................: DC 13.60V Frequency Range 136 MHz -174 MHz Result................................................: Positive V1.0 Page 2 of 8 FCC ID: YAM-TM628HV MPE T E S T R E P O R T FCC ID : YAM-TM628HV June 02, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Radio Model /Type : TM-628HV Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 8 FCC ID: YAM-TM628HV Contents 1. MEASUREMENT UNCERTAINTY ................................................. 4 2. METHOD OF MEASUREMENT .................................................... 4 2.1. EME measurements made on trunk mounted antennas 4 2.1.1. External vehicle EME measurement ..............................................................................4 2.1.2. Internal vehicle EME measurement ...............................................................................4 2.2. EME measurements made on center roof mounted antennas 4 2.2.1. External vehicle EME measurement ..............................................................................4 2.2.2. Internal vehicle EME measurement ...............................................................................4 3. TEST RESULT ........................................................................ 5 4. CONCLUSION ........................................................................ 7 5. ANTENNA LOCATION DRAWING ................................................ 8 V1.0 Page 4 of 8 FCC ID: YAM-TM628HV 1. Measurement Uncertainty The information below presents an estimate of the possible errors that are associated with the measurement system. Description Error NARDA Survey Meter ± 3% Repeatability Accuracy ± 7% 2. Method of measurement 2.1. EME measurements made on trunk mounted antennas 2.1.1. External vehicle EME measurement (Antenna mounted in trunk center) With the survey meter and probe, take ten (10) measurements, at the standard test distance of 60 cm to the antenna, from the back of the vehicle in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters. 2.1.2. Internal vehicle EME measurement (Antenna mounted in trunk center) While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each location. After the highest level is found, scan vertically making two (2) additional measurements within an area approximately 40 cm wide (representing the width of a person) so as to have a total of three (3) measured points as indicated below that will be averaged . a) Head area b) Chest area c) Lower Trunk area 2.2. EME measurements made on center roof mounted antennas 2.2.1. External vehicle EME measurement With the survey meter and probe, take ten (10) measurements, at the standard test distance of 110 cm from the vehicle-mounted antenna, in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters; this would be representative of a person standing next to a vehicle during a mobile radio transmission. 2.2.2. Internal vehicle EME measurement While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each l…

Text truncated - open the document above for the full version.

FCC PART 90 and RSS-119 TEST REPORT FCC Part 90 and RSS-119 Report Reference No......................: FCC ID..............................................: IC. .....................................................: WE10050030 YAM-TM628HV 8913A-TM628HV Compiled by ( position+printed name+signature) .: File administrators Xiankun Ding Supervised by ( position+printed name+signature) .: Test Engineer Wenliang Li Approved by ( position+printed name+signature) .: Manager Jimmy Li Date of issue.....................................: June 01, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Hytera Communications Corporation Ltd. Address ............................................: HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ...........................................: FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES RSS-119 Issue 10: Land Mobile and Fixed Radio Transmitters and Receivers Operating in the Frequency Range 27.41-960 MHz TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mobile Radio Trade Mark .......................................: HYT Model/Type reference ......................: TM-628HV Listed Models .................................. : / Ratings ............................................. : DC 13.60V Modulation ....................................... : FM Result ............................................... : Positive T E S T R E P O R T Test Report No. : WE10050030 June 01, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Radio Model /Type : TM-628HV Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT Configuration 5 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Discription of Tested Modes 8 3.6. Statement of the measurement uncertainty 8 3.7. Test Description 9 3.8. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS 11 4.1. Conducted Emissions Test 11 4.2. Occupied Bandwidth Test 13 4.3. Transmitter Radiated Spurious Emssion 24 4.4. Spurious Emssion On Antenna Port 30 4.5. Modulation Charcateristics 43 4.6. Frequency Stability Test 49 4.7. Maximum Transmitter Power 54 4.8. Transmitter Frequency Behavior 58 4.9. Receiver Radiated Spurious Emssion 61 4.10. Receiver Conducted Spurious Emssion 67 4.11. RF Exposure Evaluation 74 5. TEST SETUP PHOTOS OF THE EUT 76 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 78 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. RSS-119 Issue 10 April 2010: Spectrum Management and Telecommunications Radio Standards Specification Land Mobile and Fixed Radio Transmitters and Receivers Operating in the Frequency Range 27.41-960 MHz. TIA/EIA 603: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. ANSI C63.4-2009 : American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : May 28, 2010 Testing commenced on : May 28, 2010 Testing concluded on : June 01 2010 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: TM-628HV or the “EUT” as referred to in this report is a single channel Mobile Radio designed for voice communication. It is designed by way of utilizing the FM modulation achieves the system operating. * The test data gathered are from typical production samples provided by the manufacturer. A major technical description of EUT is described as following: a). Modulation: FM b). Rated Transmitter Power: 50W/5W c). Antenna Designation: Detachable d). Power Supply: DC 13.60 V by battery e). Operating Frequency Range Frequency Range: 136-174MHz f). Maximum Transmitter Power: 52.00 W for 25 KHz channel separation 52.00 W for 12.5 KHz channel separation 2.3. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 13.60V from Battery 2.4. Short description of the Equipment under Test (EUT) 136-174MHz V frequency band Mobile Radio (TM-628HV). Fo…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
