1 Preface Thanks for your favor in our product. This manual is helpful for you to quickly know how to use the product. Please refer to the corresponding Feature Book for detailed features and operations. This manual is applicable to the following product: MD65X Digital Mobile Radio (X may represent 0,2, 5, 6 or 8) 2 Instructional Icons : Indicates functions that are available on digital channel only. : Indicates functions that are available on analog channel only. Functions marked with no function icons are available on both analog and digital channels. Disclaimer The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of us. We do not guarantee, for any particular purpose, the accuracy, validity, timeliness, legitimacy or completeness of the Third Party products and contents involved in this manual. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera.com. RF Radiation Information This product must be restricted to operations in an Occupational/Controlled RF exposure Environments. Users must be fully aware of the hazards of the exposure and able to exercise control over their RF exposure to qualify for the higher exposure limits. RF Radiation Profile Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are transmitted. RF technology is widely used in communication, medicine, food processing and other fields. It may generate radiation during use. RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999; 3 International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998. FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. such modifications could void the user's authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radi-ate radio frequency energy and, if not in-stalled and used in accordance with the in-structions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip-ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the fol-lowing measures: ● Reorient or relocate the receiving antenna. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/ TV technician for help. Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit not more than 50% of the time and always adhere to the following procedures: Antenna gain must not exceed 5.5dBi for UHF or 5.5dBi for VHF. The antenna installation must comply with the requirements of manufacturer or supplier, and it must be 1.08 meter away from human body. To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures; and should transmit no more than 4 50% of the time, although the hardware support transmission up to 100% of the time in analog mode and up to 50% in digital mode. EU Regulatory Conformance EU Regulatory Conformance The equipment is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. 5 1. Items in the Package Please unpack carefully and check that all items listed below are received. If any item is missing or damaged, please contact your dealer. Radio Unit Remote Speaker Microphone Hanger and Screws for Remote Speaker Microphone Mounting Bracket Kit Fuse GPS Antenna Power Cord Documentation Kit Note: The GPS antenna is the standard accessory for the MD65X with GPS feature. The frequency band is marked on the label of antenna; if not, please refer to the label on the radio for frequency band information. If not particularly specified, the remote speaker microphone mentioned in this manual indicates that in the item list. 6 2. Product Overview 2.1 Radio Unit Caution: GPS antenna connector is fo…
Text truncated - open the document above for the full version.
Hytera Communications Corporation Ltd. Unity Extended Frequency Range – Contiguous Frequency Listing DATE: Nov 18, 2013 FCC ID: YAMMD65XU1 Model: MD652 U(1), MD650 U(1),MD655 U(1), MD656 U(1), MD658 U(1) Dear Sir/Madam, We, Hytera Communications Corporation Ltd. acknowledge that this device is for use in Part 90, additionally, Federal end users are intended per Part 2.103 (a). The frequency bands are: 400 -470 MHz Part 2.106 has been used to construct the following table of frequency range capability intended for end users. Hytera Communications Corporation Ltd. acknowledges that operation on unauthorized frequencies is a violation of FCC rules. Hytera Communications Corporation Ltd. acknowledges the inclusion of Grant note code “EF”. Freq(MHz) Part 90 Federal 400-406.1 X 406.1-420 X 420-454 X 454-456 X 456-462.5375 X 462.5375-462.7375 X 462.7375-467.5375 X 467.5375-467.7375 X 467.7375-470 X Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]
Justification Letter DATE: Nov 18, 2013 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMMD65XU1 Model: MD652 U(1), MD650 U(1),MD655 U(1), MD656 U(1), MD658 U(1) Dear Sir/Madam, We , Hytera Communications Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communications Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]
Product Similarity Declaration FCC ID: YAMMD65XU1 DATE: Nov. 18 2013 To Whom It May Concern, We, Hytera Communication Corporation Ltd., hereby declare that our product (Digital Mobile Radio) Model Number: MD650 U(1), MD655 U(1), MD656 U(1) and MD658 U(1) are electrically identical with the Model MD652 U(1). MD652 U(1), MD650 U(1), MD655 U(1), MD656 U(1) and MD658 U(1) are named differently due to marketing purposes Please contact me if you have any question. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]
