  2013 Hytera Corp., Ltd . : !" #$%:&'(): - - :.. 9108 518057 400 830 7020 http //www hytera com 2014 *+,/01 OWNER'SMANUAL DIGITAL MOBILE RADIO 23456 Hytera Communications Corporation Limited. Hytera Communications Corporation Limited. Preface Thanks for your favor in our product. This manual is helpful for you to quickly know how to use the product. Please refer to the corresponding Feature Book for detailed features and operations. This manual is applicable to the following product: MD65X Digital Mobile Radio (X may represent 2, 5, 6 or 8) Instructional Icons : Indicates functions that are available on digital channel only. : Indicates functions that are available on analog channel only. Functions marked with neither the above icons are available on both analog and digital channels. Disclaimer Hytera Communications Corporation Limited (the Company) endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without th e express written permission of us. We do not guarantee, for any particular purpose, the accuracy, validity, timeliness, legitimacy or completeness of the Third Party products and contents involved in this manual. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera. com. RF Radiation Information This product must be restricted to operations in an occupational/controlled RF exposure environment. Users must be fully aware of the hazards of the exposure and able to exercise control over their RF exposure to qualify for the higher exposure limits. RF Radiation Profile Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are transmitted. RF technology is widely used in communication, medicine, food processing and other fields. It may generate radiation during use. RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: ● United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; ● American National Standards Institu te (ANSI)/ Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; ● Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999; ● International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998. FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit not more than 50% of the time and always adhere to the following procedures: ● Antenna gain must not exceed 5dBi for UHF or 3.5dBi for VHF. ● The antenna installation must comply with the requirements of manufacturer or supplier, and it must be 1.08 meter away from human body. This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. such modifications could void the user's authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radi-ate radio frequency energy and, if not in-stalled and used in accordance with the in-structions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip-ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the fol-lowing measures: ~ Reorient or relocate the receiving antenna. ~ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ~ Consult the dealer or an experienced radio/ TV technician for help. To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures; and should transmit no more than 50% of the time, although the hardware support transmission up to 100% of the time in analog mode and up to 50% in digital mode. 1 Contents Items in the Package -------------------------------------------------------------------2 Product Overview -----------------------------------------------------------------------3 Radio Unit --------------------------------------------------------------------------3 Remote Speaker Microphone ------------------------------------------------3 Installation------------------------------------------------- --------------------------------3 Instructions ------------------------------------------------------------------------3 Installation Tools ------------…

Text truncated - open the document above for the full version.

Hytera Communications Co., Ltd 022311 – 6 Authority to Act as Agent Date: 2014-06- 24 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Shenzhen Huatongwei International Inspection Co., Ltd / Hans Hu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____2015-06-01_____ By: Xiong Lei (Signature 1 ) (Print name) Title: Director of management dept On behalf of: Hytera Communications Co., Ltd (Company Name) Telephone: 86-075 5 2697 2999 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Hytera Communications Co., Ltd 022311 – 6 Request for Confidentiality Date: 2014-06-24 Subject: Confidentiality Request for: FCC ID: YAMMD65XVHF Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Hytera Communications Co., Ltd has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, Xiong Lei By: (Signature4) (Print name) 2 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Differences Declaration To whom concern, We company Hytera Communications Co.,Ltd hereby declares: The product model(s) MD652 VHF,MD655 VHF, MD656 VHF, MD658 VHF is identical in the same PCB layout, interior structure and electrical circuits with the model MD650 VHFwhich tested in Shenzhen Huatongwei International Inspection Co., Ltd, the only differences are the model name for commercial purpose. Sincerely yours, Name:Xiong Lei Position: Director of management dept CompanyAdress: HYT Tower,Hi-Tech Industrial Park North, Nanshan District, Shenzhen China Tel/Fax: +86 755 2697 2999/+86 755 8613 7130 E-Mail: [email protected]

Report No : TRE1405009001 Page 69 of 75 6. External and Internal Photos of the EUT External photos of the EUT Report No : TRE1405009001 Page 70 of 75 Report No : TRE1405009001 Page 71 of 75 Report No : TRE1405009001 Page 72 of 75

Label location

6927404370536 *12912A3039* 0678 FCC ID: YAMMD65XVHF IC :8913A-MD652VHF 136-174MHz DC 13.6V---8A MD650-000G00P0-000000-V1-A-A A6.01.05.004 Digital Mobile Radio 6927404370536 *12912A3039* 0678 FCC ID: YAMMD65XVHF IC :8913A-MD652VHF MD650 VHF 136-174MHz DC 13.6V---8A MD650-000G00P0-000000-V1-A-A A6.01.05.004 Digital Mobile Radio 6927404370536 *12912A3039* 0678 FCC ID: YAMMD65XVHF IC :8913A-MD652VHF 136-174MHz DC 13.6V---8A MD650-000G00P0-000000-V1-A-A A6.01.05.004 Digital Mobile Radio 6927404370536 *12912A3039* 0678 FCC ID: YAMMD65XVHF IC :8913A-MD652VHF 136174MHz DC 13.6V---8A MD650-000G00P0-000000-V1-A-A A6.01.05.004 Digital Mobile Radio 6927404370536 *12912A3039* 0678 FCC ID: YAMMD65XVHF IC :8913A-MD652VHF 136-174MHz DC 13.6V---8A MD650-000G00P0-000000-V1-A-A A6.01.05.004 Digital Mobile Radio MD650 VHF MD652 VHF MD655 VHF MD656 VHF MD658 VHF MD652 VHF MD655 VHF MD656 VHF MD658 VHF

Report No : TRE1405009001 Page 73 of 75 Internal photos of the EUT Report No : TRE1405009001 Page 74 of 75 Report No : TRE1405009001 Page 75 of 75 .....................End of Report.........................

TEST REPORT Report Reference No. : TRE1405009002 R/C..........: 40766 Applicant’s name ........................... : Hytera Communications Co.,Ltd Address ............................................. : HYT Tower,Hi-Tech Industrial Park North, Nanshan District, Shenzhen China Manufacturer......................................: Hytera Communications Co.,Ltd Address...............................................: HYT Tower,Hi-Tech Industrial Park North, Nanshan District, Shenzhen China Test item description .................... : Digital Mobile Radio Trade Mark ....................................... : Hytera Model/Type reference ....................... : MD650 VHF Listed Model(S) ................................ : MD652 VHF,MD655 VHF, MD656 VHF, MD658 VHF Standard ......................................... : FCC Per 47 CFR 2.1091(b) KDB447498 v05r01 Date of receipt of test sample...........: May 10, 2014 Date of testing..............................: May 10, 2014- Jun 05, 2014 Date of issue.................................: Jun 05, 2014 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators Yuchao Wang Supervised by ( position+printed name+signature) .. : Project Engineer Jerome Luo Approved by ( position+printed name+signature) .. : RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Report No : TRE1405009002 Page 2 of 7 Contents 1. SUMMARY 3 1.1. Client Information 3 1.2. Product Description 3 1.3. EUT operation mode 3 1.4. Note 4 2. TEST ENVIRONMENT 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION 7 Report No : TRE1405009002 Page 3 of 7 1. SUMMARY 1.1. Client Information Applicant: Hytera Communications Co.,Ltd Address: HYT Tower,Hi-Tech Industrial Park North, Nanshan District, Shenzhen China Manufacturer: Hytera Communications Co.,Ltd Address: HYT Tower,Hi-Tech Industrial Park North, Nanshan District, Shenzhen China 1.2. Product Description The Hytera Communications Corporation Ltd.’s Model: MD650 VHF or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Digital Mobile Radio Model Number MD650 VHF FCC ID YAMMD65XVHF Support data rate 9.6kbps Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog 11K0F3E for 12.5KHz Channel Separation Digital 7K60FXD for Digital Data only 7K60FXW for Digital Data & Digital Voice Channel Separation Analog Voice 12.5KHz Digital Voice/Data 12.5KHz Digital Data 12.5KHz Antenna Type External Frequency Range From 136 MHz to 174 MHz Maximum Transmitter Power Analog 26.92W for 12.5 KHz Channel Separation Digital 28.97W for 12.5 KHz Channel Separation Note: The product has the same digital working characters when operating in both two digitized voice/data mode (7K60FXD and 7K60FXW). So only one set of test results for digital modulation modes are provided in this test report. Test frequency list Modulation Type Channel Separation Test Channel Test Frequency (MHz) Analog/FM 12.5KHz Ch1 136.5 Ch2 155.0 Ch3 173.5 Digital/4FSK 12.5KHz Ch1 136.5 Ch2 155.0 Ch3 173.5 Note: 1. Analog/FM was set at Area 1 and Digital/4FSK was set to Area 2 for test sample. 2. In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the highest frequency of channel were selected to perform the test, please see the above listed frequency for testing. 1.3. EUT operation mode The EUT has been tested under typical operating condition and The Transmitter was operated in the normal Report No : TRE1405009002 Page 4 of 7 operating mode. The TX frequency was fixed which was for the purpose of the measurements. EUT operation mode no. Description of operation mode Additional information Op 1 FM+BW12.5KHz+TX The equipment is set with FM modulation and 12.5KHz bandwidth at maximum rated power for transmitter,powered by DC 13.60V Op 2 FM+BW12.5KHz+TX The equipment is set with FM modulation and 12.5KHz bandwidth at minimum rated power for transmitter,powered by DC 13.60V Op 3 4FSK+BW12.5KHz+TX The equipment is set with 4FSK modulation and 12.5KHz bandwidth at maximum rated power for transmitter,powered by DC 13.60V Op 4 4FSK+BW12.5KHz+TX The equipment is set with 4FSK modulation and 12.5KHz bandwidth at minimum rated power for transmitter,powered by DC 13.60V Op 5 FM+BW12.5KHz+RX The equipment is set with FM modulation and 12.5KHz bandwidth at receiver or standby,powered by DC 13.60V Op 6 4FSK+BW12.5KHz+RX The equipment is set with 4FSK modulation and 12.5KHz bandwidth receiver or standby,powered by DC 13.60V 1.4. Note 1. The EUT is a V frequency band (136-174MHz) Digital Mobile Radio with GPS function,The functions of the EUT listed as below: Test Standards Reference Report Radio FCC Part 90 TRE1311014701 MPE FCC Part 2.1093 TRE1311014702 MPE FCC Part 2.1093 TRE1311014703 Report No : TRE1405009002 Page 5 of 7 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone:…
