YAMMD78XU1Digital Mobile Radio

Preface Thank you for purchasing Hytera MD780 DMR digital mobile radio. As a product built to the DMR standard, MD780 is endowed with ergonomic design and comprehensive digital functions to deliver an advanced communication solution. With MD780, you can make use of digital functions to top the competition! To derive optimum performance from your radio, please read this manual and the supplied Safety Information Booklet carefully before use. 1 Icon Information The following icons are available through this manual: Alert Icons Caution: indicates situations that could cause damage to your radio. Note: indicates tips that can help you make better use of your radio. Function Icons : indicates functions that are available on digital channel only. : indicates functions that are available on analog channel only. Functions marked with no function icons are available on both analog and digital channels. Term Explanation Key Operation Short press: to press a key and release it quickly; Long press: to press a key and remain holding it down for a predefined period (2 seconds by default); Hold down: to press a key and remain holding it down. Private Call Private call is initiated by a single user to another user, involving the calling party and the called party only. Group Call Group call is initiated by a single user to a group, involving the calling party and all the group members. All Call All call is a call initiated to all the users on a channel. It is used to deliver important notices. Squelch This technology can remove excessive background noises, improving your 2 communication quality. Copyright Information Hytera and CRS are registered trademarks of Hytera in the PRC and/or other countries or areas. Hytera retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The Hytera product described in this manual may include Hytera computer programs stored in memory or other media. Laws in the PRC and/or other countries or areas preserve for Hytera exclusive rights for Hytera computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser with respect to Hytera computer programs. Any Hytera computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of Hytera. Disclaimer Hytera endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of Hytera. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera.cn . Note: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment RF Energy Exposure Compliance Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. Your radio complies with the following of RF energy exposure standards and guidelines z United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J z American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 z Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition z International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures: Transmit and Receive To transmit (talk), push the Push-To-Talk (PTT) key; to receive, release the PTT key. FCC Licensing Information Part 15 Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. FCC Licensing Requirements A license from Federal Communications Commission is required prior to use. Your dealer will program each radio with your authorized frequencies, signaling codes, etc., and will be there…

Text truncated - open the document above for the full version.

Justification Letter DATE: May 5, 2010 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMMD78XU1 Model: MD780 Dear Sir/Madam, We, Hytera Communications Corporation Ltd., acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We, Hytera Communications Corporation Ltd., acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Hytera Communications Corporation Ltd. Suzi Lan /Certification Engineer Fax: +86 755 8613 7130 Tel: +86 755 2697 2999

Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: Digital Mobile Radio Product Model: MD780 FCC ID: YAMMD78XU1 The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Title: Certification Engineer Hytera Communications Corporation Ltd. Hytera Tower, Hi-Tech Industrial Park North, Nanshan District, Shenzhen city, GuangDong Province, P.R.China 518057 Tel: 086-755-26972999 Fax: 086-755-86137130

YAMMD78XU1 External Photo

YAMMD78XU1 Internal Photo

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) FCC ID . ............................................ : YAMMD78XU1 Compiled by ( position+printed name+signature) .. : File administrators Xiankun Ding Supervised by ( position+printed name+signature) .. : Test Engineer Wenliang Li Approved by ( position+printed name+signature) .. : Manager Jimmy Li Date of issue ..................................... : June 23, 2010 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Hytera Communications Corporation Ltd. Address ............................................. : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Digital Mobile Radio Trade Mark ....................................... : Manufacturer .................................... : Hytera Communications Corporation Ltd. Model/Type reference ....................... : MD780/MD782/MD785/MD786/MD788 Listed Models .................................. : / Ratings .............................................. : DC 13.60V Modulation ......................................... FM&4FSK Channel Separation ........................... 12.5KHz/25KHz Frequency Range 400 MHz -470 MHz Result ................................................ : Positive V1.0 Page 2 of 8 FCC ID: YAMMD78XU1 MPE T E S T R E P O R T FCC ID : YAMMD78XU1 June 23, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Mobile Radio Model /Type : MD780/MD782/MD785/MD786/MD788 Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 8 FCC ID: YAMMD78XU1 Contents 1. MEASUREMENT UNCERTAINTY ................................................. 4 2. METHOD OF MEASUREMENT .................................................... 4 2.1. EME measurements made on trunk mounted antennas 4 2.1.1. External vehicle EME measurement .............................................................................. 4 2.1.2. Internal vehicle EME measurement ............................................................................... 4 2.2. EME measurements made on center roof mounted antennas 4 2.2.1. External vehicle EME measurement .............................................................................. 4 2.2.2. Internal vehicle EME measurement ............................................................................... 4 3. TEST RESULT ........................................................................ 5 4. CONCLUSION ........................................................................ 7 5. ANTENNA LOCATION DRAWING ................................................ 8 V1.0 Page 4 of 8 FCC ID: YAMMD78XU1 1. Measurement Uncertainty The information below presents an estimate of the possible errors that are associated with the measurement system. Description Error NARDA Survey Meter ± 3% Repeatability Accuracy ± 7% 2. Method of measurement 2.1. EME measurements made on trunk mounted antennas 2.1.1. External vehicle EME measurement (Antenna mounted in trunk center) With the survey meter and probe, take ten (10) measurements, at the standard test distance of 60 cm to the antenna, from the back of the vehicle in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters. 2.1.2. Internal vehicle EME measurement (Antenna mounted in trunk center) While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each location. After the highest level is found, scan vertically making two (2) additional measurements within an area approximately 40 cm wide (representing the width of a person) so as to have a total of three (3) measured points as indicated below that will be averaged . a) Head area b) Chest area c) Lower Trunk area 2.2. EME measurements made on center roof mounted antennas 2.2.1. External vehicle EME measurement With the survey meter and probe, take ten (10) measurements, at the standard test distance of 110 cm from the vehicle-mounted antenna, in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters; this would be representative of a person standing next to a vehicle during a mobile radio transmission. 2.2.2. Internal vehicle EME m…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.910917 RF Exposure Evaluation Report No.: SRMC2010-H072-E0005 Product Name: Digital Mobile Radio Product Model: MD780 MD782 MD785 MD786 MD788 Applicant: Hytera Communications Corporation Ltd. Manufacture: Hytera Communications Corporation Ltd. Specification: FCC Part2.1091 OET Bulletin 65 Supplement C[June 2001] FCC ID: YAMMD78XU1 The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center No.: SRMC2010-H072-E0005 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 2 of 8 CONTENTS 1．General information ................................................................................ 3 1.1 Notes of the test report...................................................................................................3 1.2 Information about the testing laboratory.......................................................................3 1.3 Applicant’s details............................................................................................................3 1.4 Manufacturer’s details.....................................................................................................3 1.5 Application details............................................................................................................4 1.6 Reference specification...................................................................................................4 1.7 Information of EUT..........................................................................................................4 1.7.1 General information..............................................................................................4 1.7.2 EUT details............................................................................................................5 2. Test information ........................................................................................ 6 2.1 Summary of the calculation results...............................................................................6 2.2 Calculation result.............................................................................................................7 2.2.1 Maximum Permissible Exposure (MPE)...........................................................7 The State Radio Monitoring Center No.: SRMC2010-H072-E0005 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 3 of 8 1．General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio Monitoring Center. The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] 1.3 Applicant’s details Company: Hytera Communications Corporation Ltd. Address: Hytera Tower, Hi-Tech Industrial Park North, Nanshan District, 518057 City: Shenzhen Country or Region: P.R.China Grantee Code: YAM Contacted person: Suzi Lan Tel: +86-755-26972999 Fax: +86-755-86137130 Email: [email protected] 1.4 Manufacturer’s details Company: Hytera Communications Corporation Ltd. Address: Hytera Tower, Hi-Tech Industrial Park North, Nanshan District, 518057 City: Shenzhen Country or Region: P.R.China Grantee Code: YAM Contacted person: Suzi Lan Tel: +86-755-26972999 Fax: +86-755-86137130 Email: [email protected] The State Radio Monitoring Center No.: SRMC2010-H072-E0005 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 4 of 8 1.5 Application details Date of reception of test sample: 1 st Feb 2010 Date of test: 1 st Feb 2010 to 24 th June 2010 1.6 Reference specification FCC Part2.1091, OET Bulletin 65 Supplement C [June 2001] 1.7 Information of EUT 1.7.1 General information Name of EUT Digital Mobile Radio FCC ID YAMMD78XU1 Frequency range 400MHz ~ 470MHz Rated output power 46.5dBm Analog Voice: FM Modulation type Digitized Voice/Data: 4FSK Analog Voice: 16K0F3E 11K0F3E Emission Designator Digitized Voice/Data: 7K60FXD 7K60FXW Analog Voice: 25KHz 12.5kHz Channel Bandwidth Digitized Voice/Data: 12.5kHz Antenna type External Antenna gain 5dBi Power Supply External DC power supply Rated Power Supply Voltage 13.6Vd.c. Extreme Temperature Lowest: -30°C Highest: +50°C Extreme Voltage Minimum: 10.8Vd.c. Maximum: 15.6Vd.c. HW Version V1.00.00.432 SW Version MD780_P3A The State Radio Monitoring Center No.: SRMC2010-H072-E0005 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 5 of 8 1.7.2 EUT details Name Model Serial Number Digital Mobile Radio MD780 10421K0002 Note: The Digital Mobile Radio MD780, MD782, MD785, MD786 and MD788 are all the same on every functional aspect. They just named differently due to the marketing purposes. Therefore, this report is just to provide the test values of MD780. And the results could represent all the features which other product models have. The State Radio Monitoring Center No.: SRMC2010-H072-E0005 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 6 of 8 2. Test information 2.1 Summary of the calculation results No. Test case FCC reference Verdict 1 MPE Calculation FCC Part2.1091, OET Bulletin 65 Supplem…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRMC2010-H072-E0001 Product Name: Digital Mobile Radio Product Model: MD780 MD782 MD785 MD786 MD788 Applicant: Hytera Communications Corporation Ltd. Manufacture: Hytera Communications Corporation Ltd. Specification: FCC Part90, Part 2 (January 9, 2010 edition) TIA-603-C (December, 2004 edition) FCC ID: YAMMD78XU1 The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center No.: SRMC2010-H072-E0001 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 2 of 45 CONTENTS 1．General information ................................................................................ 3 1.1 Notes of the test report...................................................................................................3 1.2 Information about the testing laboratory.......................................................................3 1.3 Applicant’s details............................................................................................................3 1.4 Manufacturer’s details.....................................................................................................3 1.5 Application details............................................................................................................4 1.6 Reference specification...................................................................................................4 1.7 Information of EUT..........................................................................................................4 1.7.1 General information..............................................................................................4 1.7.2 EUT details............................................................................................................5 2. Test information ........................................................................................ 6 2.1 Summary of the test results............................................................................................6 2.2 Test result..........................................................................................................................7 2.2.1 Frequency Stability-FCC Part2.1055/Part90.213............................................7 2.2.2 RF Power Output-FCC Part2.1046/Part90.205(h)........................................10 2.2.3 Audio Frequency Response-FCC Part2.1047(a)/TIA-603-C....................... 11 2.2.4 Occupied Bandwidth-FCC Part2.1049/Part90.209(b)(5)/Part90.210(b)....14 2.2.5 Modulation Limiting-FCC Part2.1047(b)/Part90.210/TIA-603-C.................21 2.2.6 Conducted Spurious Emissions-FCC Part2.1051/90.210(b)(d)...................25 2.2.7 Radiated Spurious Emissions-FCC Part2.1053/Part90.210(b)...................35 2.2.8 Transient Frequency Behavior-FCC Part90.214...........................................40 2.3. List of test equipments.................................................................................................44 Appendix................................................................................................................................45 The State Radio Monitoring Center No.: SRMC2010-H072-E0001 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 3 of 45 1．General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio Monitoring Center. The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] 1.3 Applicant’s details Company: Hytera Communications Corporation Ltd. Address: Hytera Tower, Hi-Tech Industrial Park North, Nanshan District, 518057 City: Shenzhen Country or Region: P.R.China Grantee Code: YAM Contacted person: Suzi Lan Tel: +86-755-26972999 Fax: +86-755-86137130 Email: [email protected] 1.4 Manufacturer’s details Company: Hytera Communications Corporation Ltd. Address: Hytera Tower, Hi-Tech Industrial Park North, Nanshan District, 518057 City: Shenzhen Country or Region: P.R.China Grantee Code: YAM Contacted person: Suzi Lan Tel: +86-755-26972999 Fax: +86-755-86137130 Email: [email protected] The State Radio Monitoring Center No.: SRMC2010-H072-E0001 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 4 of 45 1.5 Application details Date of reception of test sample: 1 st Feb 2010 Date of test: 1 st Feb 2010 to 24 th Mar 2010 1.6 Reference specification FCC Part90, Part 2 (January 9, 2010 edition) TIA-603-C (December, 2004 edition) 1.7 Information of EUT 1.7.1 General information Name of EUT Digital Mobile Radio FCC ID YAMMD78XU1 Frequency range 400MHz ~ 470MHz Rated output power 46.5dBm Analog Voice: FM Modulation type Digitized Voice/Data: 4FSK Analog Voice: 16K0F3E 11K0F3E Emission Designator Digitized Voice/Data: 7K60FXD 7K60FXW Analog Voice: 25KHz 12.5kHz Channel Bandwidth Digitized Voice/Data: 12.5kHz Antenna type External Power Supply External DC power supply Rated Power Supply Voltage 13.6Vd.c. Extreme Temperature Lowest: -30°C Highest: +50°C Extreme Voltage Minimum: 10.8Vd.c. Maximum: 15.6Vd.c. HW Version V1.00.00.432 SW Version MD780_P3A Note: The product has the same digital working characte…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRMC2010-H072-E0001 Product Name: Digital Mobile Radio Product Model: MD780 MD782 MD785 MD786 MD788 Applicant: Hytera Communications Corporation Ltd. Manufacture: Hytera Communications Corporation Ltd. Specification: FCC Part90, Part 2 (January 9, 2010 edition) FCC ID: YAMMD78XU1 The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center No.: SRMC2010-H072-E0001 State Radio Spectrum Monitoring and Testing Center FCC ID: YAMMD78XU1 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Page 2 of 2 Appendix1 Test Setup Radiated Spurious Emissions Test setup
