YAMMT680F5TETRA Mobile Terminal

Preface Thank you for purchasing Hytera MT680 TETRA digital mobile terminal. MT680 is equipped with a large transflective TFT color display and a built-in GPS module, and can operate in both TMO and DMO modes. The benefits that this terminal can deliver will dramatically improve your working efficiency. To derive optimum performance from the terminal, please read the Safety Information Booklet and Owner’s Manual carefully before use. Telephone Call Telephone call is usually a full duplex call initiated between the terminal and a PSTN subscriber (such as telephone user or mobile phone user). To send or receive telephone calls, the mobile terminal must operate in TMO mode, and must be authorized to access public network through PSTN gateway. Telephone call is a network service. For more details and availability of the service, please contact your service provider. Emergency Call Emergency call has the highest priority, and is very helpful for the user to request help when emergency occurs. Generally, it is set to group call type. Emergency call can break off any non-emergency calls in progress. DMO (Direct Mode Operation) DMO mode allows the terminals to communicate directly w i t h e a c h o t h e r i n s i m p l e x m o d e , w i t h o u t n e t w o r k restriction. But functions that require network access, such as telephone call and short message, will be disallowed. TMO (Trunked Mode Operation) TMO mode allows the terminals to communicate with each other via the TETRA network, in half duplex or full duplex mode. Functions that require network access are supported. Icon Information The following icons are available through this manual: Caution: indicates situations that could cause damage to your terminal. Note: indicates tips that can help you make better use of your terminal. Term Explanation Key Operation Short press: to press a key and release it quickly. Long press: to press and hold down a key for above 2.5 seconds. Hold down: to press a key and remain holding it down. Individual Call Individual call is a simplex or duplex call initiated by a single user to another user, involving the calling party and the called party only. Group Call Group call is a simplex call initiated by a single user to a group of users, involving the calling party and all the group members. To operate in TMO mode, the terminal must be granted authorization by your service provider, and must be within the network coverage. Full Duplex Full duplex allows the ability to communicate in both directions simultaneously. Half Duplex Half duplex, also known as simplex, allows the ability to communicate in only one direction, at a time. Two-way communication is possible, but not simultaneously. Copyright Information Hytera and HYT are the trademark or registered trademark of Shenzhen Hytera Science & Technology Co.,Ltd. in PRC and other countries and/or areas. Hytera retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The Hytera product described in this manual may include Hytera computer programs stored in memory or other media. Laws in the PRC and/or other countries or areas preserve for Hytera exclusive rights for Hytera computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser with respect to Hytera computer programs. Any Hytera computer programs may not be copied, modified, distributed, decompiled, or reverse- engineered in any manner without the prior written consent of Hytera. Disclaimer H y t e r a e n d e a v o r s t o a c h i e v e t h e a c c u r a c y a n d completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of Hytera. If you have any suggestions or would like to learn more details, please visit us at http://www.hytera.cn. RF Energy Exposure Compliance ● Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. ● The device complies with SAR and/or RF field strength limits of RSS-102 requirement Your radio complies with the following of RF energy exposure standards and guidelines ● United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J ● American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 ● Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition ● International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998  Operational Instructions and Training Guidelines ● To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures: ● Gain of antenna must not exceed 7.0dBi. ● Antenna Installation: Install the mobile antenna at least 108 cm away from your body, in accordance with the requirements of the antenna manufacturer/supplier. Transmit and Receive To transmit (talk), push the Push-To-Talk (PTT) key; to receive, release the PTT key. EU Reg…

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAMMT680F5 to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Federal Communications CommissionFCC 11-63 Beforethe Federal Communications Commission Washington, D.C. 20554 In the Matter of Amendment of Part 90 of the Commission’s Rules to Permit Terrestrial Trunked Radio (TETRA) Technology Request by the TETRA Association for Waiver of Sections 90.209, 90.210 and 2.1043 of the Commission’s Rules ) ) ) ) ) ) ) ) ) ) WT Docket No. 11-69 ET Docket No. 09-234 NOTICE OF PROPOSED RULE MAKING AND ORDER Adopted: April 18, 2011Released: April 26, 2011 Comment Date:[45 days after publication in the Federal Register] Reply Comment Date:[60 days after publication in the Federal Register] By the Commission: I.INTRODUCTION 1.In this Notice of Proposed Rule Making and Order, we propose to modify our rules to permit the certification and use of Terrestrial Trunked Radio (TETRA) equipment under Part 90 of our Rules. 1 TETRA is a spectrally efficient digital technology with the potential to provide valuable benefits to land mobile radio users. It does not, however, conform to all of our Part 90 technical rules. The TETRA Association (the Association) 2 filed a request for waiver of the Part 90 occupied bandwidth limit and emission masks, in order to permit implementation of TETRA technology in the United States. For the reasons set forth below, we grant the waiver request in part, to permit certification and use of TETRA equipment, subject to certain conditions, pending the outcome of this rulemaking proceeding. II.BACKGROUND 2.Subpart I of Part 90 of our Rules sets forth the general technical requirementsfor use of frequencies and equipment in the private land mobile radio services. Such requirements include standards for acceptability of equipment, frequency tolerance, modulation, emissions, power, and bandwidths. 3 The purpose of these technical standards is to limit wireless systems’ interference potential. 4 The Association 1 47 C.F.R. Part 90. 2 See Request for Waiver of Sections 90.209, 90.210 and 2.1043 (filed November 20, 2009) (Request). The TETRA Association is composed of 150 organizations from 37 countries, and promotes the use of TETRA technology around the world. Id.at 2. 3 See 47 C.F.R § 90.201. 4 See Biennial Regulatory Review –Amendment of Parts 1, 22, 24, 27, and 90 to Streamline and Harmonize Various Rules Affecting Wireless Radio Services, Report and Order and Notice of Proposed Rulemaking, WT Docket No. 03-264, 20 FCC Rcd 13900, 13923 n.168 (2005). Federal Communications CommissionFCC 11-63 2 asserts that, because the Part 90 technical rules were originally developed for analog technology, they are not always appropriate for evaluating more spectrally efficient digital technologies that have been developed. 5 3.TETRA is a digital, trunked radio technology that operates with Time Division Multiple Access (TDMA) in four-slot channels within a twenty-five kilohertz bandwidth. In 2009, the Association filed a request for waiver of Parts 2 and 90 of the Commission’s rules on behalf of manufacturers to allow TETRA technology to be used in the United States. The Association states that the TETRA standard, which was developed by the European Technical Standards Institute (ETSI), is used around the world, and that manufacturers are ready to produce TETRA devices for use in the United States on several frequency bands. 6 Italso states that TETRA technology provides better efficiency and security than available alternatives, 7 and offers interoperability among equipment from different manufacturers. 8 4.In order to permit implementation of TETRA technology in the United States, the Association requests waivers of the Part 90 occupied bandwidth limit and emission masks. For devices operating with twenty-five kilohertz channel spacing, Section 90.209(b)(5) of our Rules limits the authorized bandwidth to twenty kilohertz, 9 and Section 90.210 of our Rules specifies particular emission masks. 10 TETRA equipment, however, exceeds these limits, because the ETSI standard does not set occupied bandwidth limits. Instead, it sets standards for adjacent channel power and for unwanted emissions at different frequency offsets. This results in operation with a bandwidth of up to twenty-two kilohertz, 11 and excursions of up to five decibels from the Part 90 emission masks. 12 5.The Association also requests a waiver of the permissive change rules regarding equipment certification. Itnotes that certain manufacturers, in order to meet immediate demand for TETRA equipment, have obtained Commission certification of TETRA radios that comply with the Part 90 rules by using reduced power. Certain changes to approved equipment, including changes to the maximum 5 See Request at 7. 6 See id.at 2-3, 10. 7 See id.at 2-3 (“TETRA utilizes a highly efficient data transport mechanism allowing Short Data messages to be sent on the control circuit. Circuit mode data and IP packet data can be transmitted at up to 36kbits/s (gross) and 28kbits/s (net) for multi-slot operation. . . . Additionally, TETRA-based products come with built-in air interface encryption and optional end-to-end encryption features to protect the integrity of the voice/data mobile communications. Finally, TETRA allows for fast call set-up times of typically less than 300 ms which are essential for mission critical mobile communications. In sum, TETRA combines the advantages of two-way radio, mobile telephony, messaging and data in a way that is clear, fast and less expensive than other technologies.”). 8 See id.at 3. 9 See47 C.F.R. § 90.209(b)(5). 10 See47 C.F.R. § 90.210(b), (c), (g). The emission mask is the technical specification that limits the distribution of power of a radio transmitter as a function of frequency. The Development of Operational, Technical and Spectrum Requirements for Meeting Federal, State and Local Public Safety Agency Communication Requirements Through the Year 2010, First Report and Order and Third Notice of Proposed Rulemaking, WT Docket No. 96-86, 14 FCC Rcd 152, 213 n.337 (1998). The em…

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. Frequency Attestation Letter DATE: July 12, 2012 FCC ID: YAMMT680F5 Model: MT680 F5 Dear Sir/Madam, We, Hytera Communications Corporation Ltd. acknowledge that this device can only use 817-824MHz/862-869MHz in USA and 806-824MHz/851-869MHz in Canada. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

External photos of the EUT

FCC RF Warning Label

Internal photos of the EUT

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No. ..................... : FCC ID . ............................................ : TRE1206003503 YAMMT680F5 Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : June 29, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Hytera Communications Corporation Ltd. Address............................................. : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: TETRA Mobile Terminal Trade Mark ....................................... : Manufacturer .................................... : Hytera Communications Corporation Ltd. Model/Type reference ....................... : MT680 F5 Listed Models .................................. : / Modulation ....................................... : π/4 DQPSK Channel Separation ........................... 25KHz Rated Power .................................... : 10.0 Watts(40.00dBm) Operation Frequency ......................... 817MHz-824MHz/862MHz-869MHz Ratings.............................................. : DC 13.20 V Result ................................................ : Positive Report No.: TRE1206003503 Page 2 of 11 Issued:2012-06-29 FCC ID: YAMMT680F5 MPE T E S T R E P O R T Test Report No. : TRE1206003503 June 29, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : TETRA Mobile Terminal Model /Type : MT680 F5 Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1206003503 Page 3 of 11 Issued:2012-06-29 FCC ID: YAMMT680F5 Contents 1. MEASUREMENT UNCERTAINTY ................................................. 4 2. METHOD OF MEASUREMENT .................................................... 4 2.1. EME measurements made on trunk mounted antennas 4 2.1.1. External vehicle EME measurement .............................................................................. 4 2.1.2. Internal vehicle EME measurement ............................................................................... 4 2.2. EME measurements made on center roof mounted antennas 4 2.2.1. External vehicle EME measurement .............................................................................. 4 2.2.2. Internal vehicle EME measurement ............................................................................... 4 3. TEST RESULT ........................................................................ 5 4. CONCLUSION ........................................................................ 8 5. ANTENNA LOCATION DRAWING ................................................ 8 Report No.: TRE1206003503 Page 4 of 11 Issued:2012-06-29 FCC ID: YAMMT680F5 1. Measurement Uncertainty The information below presents an estimate of the possible errors that are associated with the measurement system. Description Error NARDA Survey Meter ± 3% Repeatability Accuracy ± 7% 2. Method of measurement 2.1. EME measurements made on trunk mounted antennas 2.1.1. External vehicle EME measurement (Antenna mounted in trunk center) With the survey meter and probe, take ten (10) measurements, at the standard test distance of 60 cm to the antenna, from the back of the vehicle in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters. 2.1.2. Internal vehicle EME measurement (Antenna mounted in trunk center) While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each location. After the highest level is found, scan vertically making two (2) additional measurements within an area approximately 40 cm wide (representing the width of a person) so as to have a total of three (3) measured points as indicated below that will be averaged . a) Head area b) Chest area c) Lower Trunk area 2.2. EME measurements made on center roof mounted antennas 2.2.1. External vehicle EME measurement With the survey meter and probe, take ten (10) measurements, at the standard test distance of 110 cm from the vehicle-mounted antenna, in a vertical line and then average the results. These measurements are taken and recorded…

Text truncated - open the document above for the full version.

FCC PART 90 TEST REPORT FCC Part 90 Report Reference No. ..................... : FCC ID. ............................................. : TRE1206003501 R/C:79874 YAMMT680F5 Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : June 21, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Hytera Communications Corporation Ltd. Address............................................. : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ........................................... : FCC Part 90 / FCC Part 2 FCC Waiver for Tetra FCC 11-63 and FCC DA 11-1604 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: TETRA Mobile Terminal Trade Mark ....................................... : Manufacturer .................................... : Hytera Communications Corporation Ltd. Model/Type reference ....................... : MT680 F5 Listed Models .................................. : / Modulation ....................................... : π/4 DQPSK Channel Separation ........................... 25KHz Rated Power .................................... : 10.0 Watts(40.00dBm) Operation Frequency ......................... 817MHz-824MHz/862MHz-869MHz Ratings.............................................. : DC 13.20 V Result ................................................ : Positive Report No.: TRE1206003501 Page 2 of 69 Issued: 2012-06-21 FCC ID: YAMMT680F5 T E S T R E P O R T Test Report No. : TRE1206003501 June 21, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : TETRA Mobile Terminal Model /Type : MT680 F5 Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1206003501 Page 3 of 69 Issued: 2012-06-21 FCC ID: YAMMT680F5 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Discription of Tested Modes 8 3.6. Statement of the measurement uncertainty 8 3.7. Test Description 9 3.8. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS 11 4.1. Conducted Emissions Test 11 4.2. Occupied Bandwidth, Adjacent Channel Power Test 16 4.3. Transmitter Radiated Spurious Emssion 24 4.4. Spurious Emssion on Antenna Port 29 4.5. Modulation Charcateristics 35 4.6. Frequency Stability Test 36 4.7. Maximum Transmitter Power 38 4.8. Transmitter Frequency Behavior 41 4.9. Receiver Radiated Spurious Emssion 42 4.10. Receiver Conducted Spurious Emssion 52 5. TEST SETUP PHOTOS OF THE EUT 53 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 61 Report No.: TRE1206003501 Page 4 of 69 Issued: 2012-06-21 FCC ID: YAMMT680F5 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603 C: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. FCC Rules Part 15 Subpart B: RADIO FREQUENCY DEVICES-Unintertional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS FCC Waiver for Tetra FCC 11-63 and FCC DA 11-1604 Report No.: TRE1206003501 Page 5 of 69 Issued: 2012-06-21 FCC ID: YAMMT680F5 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : June 12, 2012 Testing commenced on : June 12, 2012 Testing concluded on : June 21, 2012 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: MT680 F5 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT TETRA Mobile Terminal Model Number MT680 F5 FCC ID YAMMT680F5 Rated Output Power 10Watt(40.00dBm) Modilation Type π/4 DQPSK Channel Separation 25KHz Emission Designation 20K0DXW/20K0GXW Antenna Type External Frequency Range 817MHz-824MHz/862MHz-869MHz Maximum Transmitter Power DMO 11.91 W for 25 KHz Channel Separation TMO 11.72 W for 25 KHz Channel Separation 2.3. Equipment under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ …

Text truncated - open the document above for the full version.

Test setup photos of the EUT
