YAMPD79XEXEx Digital Radio

Preface Thanks for your favor in our product. To derive optimum performance from the product, please read this manual and the supplied Safety Information Booklet carefully before use. This manual is applicable to the following model: PD79X Ex (X may indicate 2, 5, 6 or 8) 1 Instructional Icons The following icons are available through this manual: Alert Icons Caution: indicates situations that could cause damage to your product. Note: indicates tips that can help you make better use of your product. Function Icons : indicates functions that are available on digital channel only. : indicates functions that are available on analog channel only. Functions marked with no function icons are available on both analog and digital channels. Term Explanation Key Operation z Short press: to press a key and release it quickly. z Long press: to press a key and remain holding it down for a predefined period (2 seconds by default). z Hold down: to press a key and remain holding it down. Private Call Private Call is a call initiated by a single user to another user. Group Call Group Call is a call initiated by a single user to a group. All Call All Call is a call initiated by a single user to all the other users on a channel. Squelch This technology can remove excessive background noises, improving your communication quality. PTT ID PTT ID, namely radio identity, allows a radio with display or the control center to identify the calling party. 2 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The product described in this manual may include the Company’s computer programs stored in memory or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of the Company with respect to its computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser regarding the Company’s computer programs. Any of the Company’s computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of the Company. The AMBE+2 TM voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding technology is licensed solely for use within this product. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code or in any other way convert the Object Code into a human readable form. U.S. Patent Nos. #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. Disclaimer The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of us. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera.com . 3 RF Radiation Information RF Radiation Profile Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are transmitted. RF technology is widely used in communication, medicine, food processing and other fields. It may generate radiation during use. RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: ¾ United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; ¾ American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; ¾ Institute of Electrical and Electronic Engineers (IEEE) C95. 1 – 1999; ¾ International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998; FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures: (1) Your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. (2) Keep the radio at least 2.5 centimeters away from your body during transmission. 4 EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. Please note that the above information is applicable to EU countries only. Safety Instructions To protect you against any property loss, bodily injury or even death, be sure to observe the following safety instructions: z Use only the Ex-battery BL1807-Ex specified by the Company. The use of other batteries may result in Ex-protection failure. z Charge the battery in a non-hazardous area …

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAMPD79XEX to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Hytera Communications Corporation Ltd. Frequency Attestation Letter DATE: Jan 18, 2012 FCC ID: YAMPD79XEX Model: PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex, HD795 Ex Dear Sir/Madam, We, Hytera Communications Corporation Ltd. acknowledge that this device can only use the allowed frequency band from 400 MHz to 406 MHz and 406.1MHz to 470MHz for USA. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Justification Letter DATE: Jan 18, 2012 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMPD79XEX Model: PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex, HD795 Ex Dear Sir/Madam, We , Hytera Communications Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communications Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

External photos of the EUT

FCC Label FCC RF Warning Label

Internal photos of the EUT

TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1112-2095SAR01R1 Page 1 of 72 TESTING No. L2264 OET 65 TEST REPORT Product Name Ex Digital Radio Model PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex,HD795 Ex FCC ID YAMPD79XEX Client Hytera Communications Co.,Ltd. TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1112-2095SAR01R1 Page 2 of 72 GENERAL SUMMARY Product Name Ex Digital Radio Model PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex,HD795 Ex FCC ID YAMPD79XEX Report No. RZA1112-2095SAR01R1 Client Hytera Communications Co.,Ltd. Manufacturer Hytera Communications Co.,Ltd. Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438 June 19, 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emission 447498 D01 Mobile Portable RF Exposure v04 : Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies. KDB 643646 D01 SAR Test for PTT Radios v01r01: SAR Test Reduction Considerations for Occupational PTT Radios. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 6 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: January 9 th , 2012 Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1112-2095SAR01R1 Page 3 of 72 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT................................................................................................................ 7 1.6. The Maximum SAR 1g Values ................................................................................................ 8 1.7. Test Date .............................................................................................................................. 8 2. Operational Conditions during Test ..............................................................................................9 2.1. Test Positions........................................................................................................................ 9 2.1.1. Face-Held Configuration ................................................................................................ 9 2.1.2. Body-Worn Configuration .............................................................................................. 9 3. SAR Measurements System Configuration ................................................................................ 10 3.1. SAR Measurement Set-up .................................................................................................. 10 3.2. DASY5 E-field Probe System ............................................................................................. 11 3.2.1. EX3DV4 Probe Specification ....................................................................................... 11 3.2.2. E-field Probe Calibration .............................................................................................. 12 3.3. Other Test Equipment .........................................................................................................12 3.3.1. Device Holder for Transmitters .................................................................................... 12 3.3.2. Phantom...................................................................................................................... 13 3.4. Scanning Procedure........................................................................................................... 13 3.5. Data Storage and Evaluation .............................................................................................. 15 3.5.1. Data Storage................................................................................................................ 15 3.5.2. Data Evaluation by SEMCAD ...................................................................................... 15 3.6. System Check..................................................................................................................... 18 3.7. Equivalent Tissues ..............................................................................................................20 4. Laboratry Requirements............................................................................................................. 20 5. Conducted Output Power Measurement.................................................................................... 21 5.1. Conducted Power Results .................................................................................................. 21 6. Test Results ..................…

Text truncated - open the document above for the full version.

FCC PART 90 TEST REPORT FCC Part 90 Report Reference No......................: FCC ID..............................................: TRE11100038 YAMPD79XEX Compiled by ( position+printed name+signature)..: File administrators Tim Zhang Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Jan 05, 2012 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Hytera Communications Corporation Ltd. Address ............................................: HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ...........................................: FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Ex Digital Radio Trade Mark .......................................: Manufacturer ....................................: Hytera Communications Corporation Ltd. Model/Type reference.......................: PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex,HD795 Ex Listed Models ..................................: / Ratings .............................................: DC 7.40 V Modulation .......................................: FM&4FSK Channel Separation........................... 12.5KHz Rated Power ..................................... 1 Watts(30.00dBm)/0.5 Watts(26.99dBm) Operation Frequency Range ............. From 400 MHz to 470 MHz Result................................................: Positive V1.0 Page 2 of 116 Report No.: TRE11100038 FCC ID: YAMPD79XEX T E S T R E P O R T Test Report No. : TRE11100038 Jan 05, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Ex Digital Radio Model /Type : PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex,HD795 Ex Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 116 Report No.: TRE11100038 FCC ID: YAMPD79XEX Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 7 2.9. Modifications 7 2.10. Note 7 3. TEST ENVIRONMENT 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Configuration of Tested System 9 3.5. Discription of Tested Modes 9 3.6. Statement of the measurement uncertainty 9 3.7. Test Description 10 3.8. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test 12 4.2. Occupied Bandwidth and Emission Mask Test 17 4.3. Transmitter Radiated Spurious Emssion 35 4.4. Spurious Emssion on Antenna Port 42 4.5. Modulation Charcateristics 64 4.6. Frequency Stability Test 67 4.7. Maximum Transmitter Power 69 4.8. Transmitter Frequency Behavior 80 4.9. Receiver Radiated Spurious Emssion 83 4.10. Receiver Conducted Spurious Emssion 93 5. TEST SETUP PHOTOS OF THE EUT 104 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 108 V1.0 Page 4 of 116 Report No.: TRE11100038 FCC ID: YAMPD79XEX 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. ANSI C63.4-2009 : American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. FCC Rules Part 15 Subpart B: RADIO FREQUENCY DEVICES-Unintertional Radiators V1.0 Page 5 of 116 Report No.: TRE11100038 FCC ID: YAMPD79XEX 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Oct 19, 2011 Testing commenced on : Oct 19, 2011 Testing concluded on : Jan 05, 2012 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: PD792 Ex, PD795 Ex PD796 Ex, PD798 Ex, HD795 Ex or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Ex Digital Radio Model Number PD792 Ex, PD795 Ex, PD796 Ex, PD798 Ex,HD795 Ex FCC ID YAMPD79XEX Rated Output Power 1 Watts(30.00 dBm)/0.5 Watts(26.99dBm) Support data rate 9.6kbps FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog 11K0F3E for 12.5KHz Channel Separation 7K60FXD for Digital Data only Modilation Type Digital 7K60FXW for Digital Data & Digital Voice Analog Voice 12.5KHz Digital Voice/Data 12.5KHz Channel Separation Digita…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
