YAMPNC380B9PoC Radio

1. Product Overview H y tera Communications Corporation Limited Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China 2. Before Use 2.1 Installing the SIM Card and SD Card 1.Slide the battery latch to and remove the battery cover. 2. Remove the battery. 3. Open the card slot cover. 4. Put the card into corresponding slot. 2.2 Attaching the Battery Use the appr oved battery to avoid the risk of explosion. Dispose of the used battery according to “Precautions for Disposal” in the Safety Information Booklet. Attach the battery as sho wn below, then press the cover into place and slide the battery latch to the lock position. 2.3 Charging the Battery Use the approved cha rger to charge the battery. Read the Safety Information Booklet before charging. The remaining lithium-ion battery power is limited to 30% pursuant to the new lithium battery shipment regulation approved by International Air Transport Association (IATA). To charge the battery, connect the terminal to the powe r adapter, power bank, or computer with the USB cable. To determine the charging status, check the battery icon or percentage shown on the LCD display. To ensure optimum waterproof and dustproof performance, close the USB port cover after charging the terminal. 2.4 Attaching the Belt Clip Attach the belt clip a s shown below. 2.5 Attaching the Audio Accessory Open the cover of the audio accessor y connector and insert the audio accessory into the connector. To ensure optimum waterproof and dustproof performance, close the cover after removing the audio accessory. 3. Operation 3.1 Powering the Terminal On or Off To power on the terminal, press and hold the key. To power off the terminal, press and hold the key, and select Power Off . 3.2 Adjusting the Volume To increase the volume, pr ess + key. To decrease the volume, press – key. 3.3 Turning the Screen On or Off To turn off th e screen when it is on, press the SK key. To turn on the screen when it is off, press the SK key, Emergency Alarm key or any key on the keypad. 3.4 Using Flashlight To turn the flashlight on or off when the screen is o n , press and hold the key . 3.5 Setting the Shortcut Key SK key is th e prog rammable key of the terminal. For enhanced convenience, you can go to to select Programmable key to set the key as the shortcut of certain functions. 3.6 Connecting to the Internet You can connect to the Inter net by using the cellular network or WLAN network. To connect to the cellular network, install the SIM card and activate the cellular data service. To connect to the WLAN network, do as follows: 1. Go to to select WLAN to enable the WLAN network. 2. Choose one of the listed networks. If a password is required, enter the password and select Connect . 3.7 Checking the Device Information To check information such as device status, model and version, go to to select “About phone”. To avoid possible hearing damage, do not listen at high audio volume for long periods of time 4. PoC Service Push-to-talk over Cellular (PoC) provides direct one-to-one and one-to-many voice communica tion services over the cellular network. This service is available only whe n you have installed the PoC application on the terminal. You can access PoC menu to initiate a call. 1. Go to Home > PoC, and then press OK/Menu key. 2. Select the required contact. 3. Press and hold the PTT key and speak. You can listen to a call without any operation. AT BE CY CZ DK EE FI FR DE EL HU IE IT LV LT LU MT NL PL PT SK SI ES SE UK BG RO HR In all EU member states,operation of 5150-5250MHz is restricted to indoor use only FCCStatement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. SAR tests are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value, in general, the closer you are to a wireless base station antenna, the lower the power output. Before a new model device is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure limit established by the FCC, Tests for each device are performed in positions and locations (e.g. at the ear and worn on the body)as required by the FCC. For body worn operation, this model device has been tested and meets the FCC RF exposure guidelines when used wi…

Text truncated - open the document above for the full version.

QA-FR-170-B H ytera Communications Corporation Limited Add: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, 518057 China Tel: +86-755-26972999 Fax: +86-755-86139020 Email: [email protected] FCC Authorization Date: 2020-04-07 FEDERAL COMMUNICATIONS COMMISSION Authorization an d Evaluation Division 74 35 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Hytera Communications Corporation Limited, hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Tiantian Chen Certification Engineer

QA- FR-172-A Hytera Communications Corporation Limited Add: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, 518057 China Tel: +86-755-26972999 Fax: +86-755-86139020 Email: [email protected] FCC Confidential Authorization Date: 2020-04-07 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Sub ject: Confidentiality Request regarding application for certification of FCC ID: YAMPNC380B9 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Hytera Communications Corporation Limited, hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description Parts List/Tune-up Procedure (for licensed devices) The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Tiantian Chen Certification Engineer

Label and Location Model ：PNC3 8 0 I MEI : 8 6 5 0 6 8 0 3 0 0 0 0 0 0 5 *Z26CJD0901* PoC Radio FCC ID : YAMPNC380B9 IC : 8913A-PNC380B9

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS NFC Antenna Wifi/BT antenna GPRS/WCDMA/LTE Main Antenna Aux Antenna NFC Antenna

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. SAR EVALUATION REPORT For Hytera Communications Corporation Limited Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People’s Republic of China FCC ID: YAMPNC380B9 Report Type: Original Report Product Type: PoC Radio Report Number: RDG200109003-SAA Report Date: 2020-04-01 Reviewed By: Alvin Huang Lab Mana ger Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA SAR Evaluation Report 2 of 87 Attestation of Test Results EUT Information EUT Description PoC Radio Tested Model PNC380 FCC ID YAMPNC380B9 Serial Number RDG200109003-SA-S2 Test Date 2020/02/10 to 2020/02/13 MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) GSM 850 1g Face SAR 0.48 1. 6 1g Body SAR 0.50 PCS 1900 1g Face SAR 0.16 1g Body SAR 0.33 WCDMA Band 2 1g Face SAR 0.50 1g Body SAR 1.01 WCDMA Band 4 1g Face SAR 0.55 1g Body SAR 1.33 WCDMA Band 5 1g Face SAR 0.46 1g Body SAR 0.85 LTE Band 2 1g Face SAR 0.25 1g Body SAR 0.62 LTE Band 4 1g Face SAR 0.32 1g Body SAR 0.79 LTE Band 5 1g Face SAR 0.44 1g Body SAR 0.86 LTE Band 7 1g Face SAR 0.28 1g Body SAR 0.52 LTE Band 12&17 1g Face SAR 0.35 1g Body SAR 0.71 LTE Band 13 1g Face SAR 0.38 1g Body SAR 0.65 LTE Band 26 1g Face SAR 0.49 1g Body SAR 0.89 LTE Band 38 1g Face SAR 0.14 1g Body SAR 0.26 LTE Band 41 1g Face SAR 0.14 1g Body SAR 0.23 2.4G wifi 1g Face SAR 0.03 1g Body SAR 0.18 5.2G wifi 1g Face SAR 0.14 1g Body SAR 0.14 5.6G wifi 1g Face SAR 0.14 1g Body SAR 0.17 5.8G wifi 1g Face SAR 0.16 1g Body SAR 0.16 Simultaneous 1g Face SAR 0.71 1g Body SAR 1.51 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA SAR Evaluation Report 3 of 87 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEC 62209-2:2010 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices-Human models, instrumentation, and procedures-Part 2: Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body (frequency range of 30 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06 KDB 648474 D04 Handset SAR v01r03 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 KDB 941225 D01 3G SAR Procedures v03r01 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA SAR Evaluation Report 4 of 87 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 5 EUT DESCRIPTION ................................................................................................................................................... 6 TECHNICAL SPECIFICATION ......................................................................................................................................... 6 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 8 SAR LIMITS ................................................................................................................................................................ 9 FACILITIES ............................................................................................................................................................... 10 DESCRIPTION OF TEST SYSTEM ........................................................................................................................ 11 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 17 EQUIPMENTS LIST & CALIBRATION INFORMATION ................................................................................................... 17 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 18 LIQUID VERIFICATION ............................................................................................................................................... 18 SYSTEM ACCURACY VERIFICATION ...........................................…

Text truncated - open the document above for the full version.

APPENDIX C PROBE CALIBRATION CERTIFICATES APPENDIX C DIPOLE CALIBRATION CERTIFICATES

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 1 of 105 Test Plot 1#: GSM 850_Face Up_Low DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GSM (0); Frequency: 824.2 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.891 S/m; εr = 41.435; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN7520; ConvF(9.71, 9.71, 9.71) @ 824.2 MHz; • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1561; Calibrated: 2019/09/13 • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 • Measurement SW: DASY52, Version 52.10 (2); Face Up/GSM 850 Low/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.288 W/kg Face Up/GSM 850 Low/Zoom Scan (5x5x5)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=8mm Reference Value = 17.54 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 0.357 W/kg SAR(1 g) = 0.273 W/kg; SAR(10 g) = 0.201 W/kg Maximum value of SAR (measured) = 0.286 W/kg 0 dB = 0.286 W/kg = -5.44 dBW/kg Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 2 of 105 Test Plot 2#: GSM 850_Face Up_Mid DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GSM (0); Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.927 S/m; εr = 41.604; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN7520; ConvF(9.71, 9.71, 9.71) @ 836.6 MHz; • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1561; Calibrated: 2019/09/13 • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 • Measurement SW: DASY52, Version 52.10 (2); Face Up/GSM 850 Mid/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.321 W/kg Face Up/GSM 850 Mid/Zoom Scan (5x5x5)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=8mm Reference Value = 19.14 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 0.402 W/kg SAR(1 g) = 0.304 W/kg; SAR(10 g) = 0.219 W/kg Maximum value of SAR (measured) = 0.319 W/kg 0 dB = 0.319 W/kg = -4.96 dBW/kg Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 3 of 105 Test Plot 3#: GSM 850_Face Up_High DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GSM (0); Frequency: 848.8 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.948 S/m; εr = 41.527; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN7520; ConvF(9.71, 9.71, 9.71) @ 848.8 MHz; • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1561; Calibrated: 2019/09/13 • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 • Measurement SW: DASY52, Version 52.10 (2); Face Up/GSM 850 High/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.395 W/kg Face Up/GSM 850 High/Zoom Scan (5x5x5)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=8mm Reference Value = 19.59 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.490 W/kg SAR(1 g) = 0.376 W/kg; SAR(10 g) = 0.275 W/kg Maximum value of SAR (measured) = 0.395 W/kg 0 dB = 0.395 W/kg = -4.03 dBW/kg Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 4 of 105 Test Plot 4#: GSM 850_Body Worn Back_Mid DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GSM (0); Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.927 S/m; εr = 41.604; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN7520; ConvF(9.71, 9.71, 9.71) @ 836.6 MHz; • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1561; Calibrated: 2019/09/13 • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 • Measurement SW: DASY52, Version 52.10 (2); Body Worn Back/GSM 850 Mid 2/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.348 W/kg Body Worn Back/GSM 850 Mid 2/Zoom Scan (5x5x5)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=8mm Reference Value = 18.71 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.437 W/kg SAR(1 g) = 0.333 W/kg; SAR(10 g) = 0.241 W/kg Maximum value of SAR (measured) = 0.349 W/kg 0 dB = 0.349 W/kg = -4.57 dBW/kg Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 5 of 105 Test Plot 5#: GSM 850_Body Back_Low DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GPRS-2 slots (0); Frequency: 824.2 MHz;Duty Cycle: 1:4 Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.891 S/m; εr = 41.435; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN7520; ConvF(9.71, 9.71, 9.71) @ 824.2 MHz; • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1561; Calibrated: 2019/09/13 • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 • Measurement SW: DASY52, Version 52.10 (2); Body Back/GSM 850 Low/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.353 W/kg Body Back/GSM 850 Low/Zoom Scan (5x5x5)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=8mm Reference Value = 19.37 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.448 W/kg SAR(1 g) = 0.336 W/kg; SAR(10 g) = 0.240 W/kg Maximum value of SAR (measured) = 0.354 W/kg 0 dB = 0.354 W/kg = -4.51 dBW/kg Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RDG200109003-SAA Page 6 of 105 Test Plot 6#: GSM 850_Body Back_Mid DUT: PoC Radio; Type: PNC380; Serial: RDG200109003-SA-S2 Communication System: UID 0, Generic GPRS-2 slots (0); Frequency: 836.6 MHz;Duty Cycle: 1:4 Medium parameters used (inte…

Text truncated - open the document above for the full version.

Page 1 of 2 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm • Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 Face Up Setup Photo 25 mm Page 2 of 2 Body (Worn) Back Setup Photo (0mm) 10cm

FCC PART 22H, PART 24E,PART 27, PART 90 MEASUREMENT AND TEST REPORT For Hytera Communications Corporation Limited Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, 518057 China Report Type: Original Report Product Type: PoC Radio Report Number: RDG200109003-00E Report Date: 2020-03-30 Reviewed B y: Ivan Cao Assistant manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industry Area, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID:YAMPNC380B9 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 2 of 262 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 DECLARATIONS ............................................................................................................................................................ 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 JUSTIFICATION ............................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 7 CONFIGURATION OF TEST SETUP ................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................... 9 FCC §1.1310 & §2.1093- RF EXPOSURE .................................................................................................................. 10 APPLICABLE STANDARD ............................................................................................................................................ 10 TEST RESULT ............................................................................................................................................................. 10 FCC §2.1047 - MODULATION CHARACTERISTIC ............................................................................................ 11 FCC § 2.1046, § 22.913 (A) & § 24.232 (C) & § 27.50&§ 90.635 - RF OUTPUT POWER ................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 TEST PROCEDURE ...................................................................................................................................................... 13 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 19 TEST DATA ................................................................................................................................................................ 19 FCC §2.1049, §22.917, §22.905 & §24.238 & §27.53&§90.209- OCCUPIED BANDWIDTH ............................... 45 APPLICABLE STANDARD ............................................................................................................................................ 45 TEST PROCEDURE ...................................................................................................................................................... 45 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 45 TEST DATA ................................................................................................................................................................ 45 FCC §2.1051, §22.917(A) & §24.238(A) & §27.53, §90.691 - SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................................................................................................................................... 96 APPLICABLE STANDARD ............................................................................................................................................ 96 TEST PROCEDURE ...................................................................................................................................................... 96 TEST EQUIPMENT LIST AND DETAILS ....................................................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 91 of 262 16QAM_15 MHz 16QAM_20 MHz Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 92 of 262 LTE Band 41: QPSK_5 MHz QPSK_10 MHz Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 93 of 262 QPSK_15 MHz QPSK_20 MHz Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 94 of 262 16QAM_5 MHz 16QAM_10 MHz Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 95 of 262 16QAM_15 MHz 16QAM_20 MHz Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 96 of 262 FCC §2.1051, §22.917(a) & §24.238(a) & §27.53, §90.691 - SPURIOUS EMISSIONS AT ANTENNA TERMINALS Applicable Standard FCC §2.1051, §22.917(a) , §24.238(a) and §27.53, §90.691. The spectrum was to be investigated to the tenth harmonics of the highest fundamental frequency as specified in § 2.1051. Test Procedure The RF output of the transceiver was connected to a spectrum analyzer and simulator through appropriate attenuation. Sufficient scans were taken to show any out of band emissions up to 10 th harmonic. Test Equipment List and Details Manufacturer Description Model Serial Number Calibration Date Calibration Due Date R&S Spectrum Analyzer FSV40 101474 2020-01-09 2021-01-09 yzjingcheng Coaxial Cable KTRFBU- 141-50 41005011 Each Time / E-Microwave Two-way Spliter ODP-1-6-2SOE0120142 Each Time / E-Microwave Coaxial Attenuators EMCA10- 5RN-6 OE01203239Each Time / * Statement of Traceability: Bay Area Compliance Laboratories Corp. (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data Environmental Conditions Temperature: 19.1~22.9C Relative Humidity: 35~75 % ATM Pressure: 101.6~102.6 kPa Tester: Fay Hu Test Date: 2020-02-13~2020-02-20 EUT Spectrum Analyzer Splitter CMU200 /CMW500 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 97 of 262 Please refer to the following plots. GSM850_Middle Channel Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 98 of 262 PCS 1900_ Middle Channel Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 99 of 262 WCDMA Band II,Rel99 Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 100 of 262 WCDMA Band IV,Rel99 Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 101 of 262 WCDMA Band V,Rel99 Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 102 of 262 LTE Band 2 (Middle Channel) QPSK_1.4 MHz Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 103 of 262 QPSK_3 MHz Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 104 of 262 QPSK_5 MHz Fundamental Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200109003-00E Page 105 of 262 QPSK_10 MHz Fundamental…
