YAMRD96XVHFDigital Portable Repeater

Preface Thanks for your favor in our product. To derive optimum performance from the product, please read this manual and the supplied Safety Information Booklet carefully before use. This manual is applicable to the following model: RD96X（X may represent 2, 5, 6 or 8） Instructional Icons The following icons are available through this manual: The radio is not intended for use by general population in an uncontrolled environment. It is only for occupational use and only applied to work-related conditions.The radio must be only used by users, who are fully aware of the hazards of the exposure and who are able to exercise control over their RF exposure to qualify for the higher exposure limits. Alert Icons Caution: indicates situations that could cause damage to your product or bodily injury. Note: indicates tips that can help you make better use of your product. *: indicates functions available in later version. Term Explanation Key Operation z Short press: to press a key and release it quickly. z Long press: to press a key and remain holding it down for a predefined period (2 seconds by default). Hold down: to press a key and remain holding it down. Duplexer Duplexer is a device that allows bi-directional communication. Its role is to isolate the TX signal from the RX signal to ensure that the transmitter and receiver can work normally. It consists of two groups of band-stop filters with different frequencies, to prevent it from transmitting the signals to the receiver. Feed Line Feed Line is the cable or transmission line that connects the antenna with the radio transmitter or receiver. Voltage Standing Wave Ratio (VSWR) Voltage Standing Wave Ratio (VSWR) is a value that measures how well a load is impedance-matched to a source. Squelch Squelch is a circuit function that acts to suppress the audio output of a receiver in the absence of a sufficiently strong desired input signal. Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The product describes in this manual may include the Company’s computer programs stored in memory or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of the Company with respect to its computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser regarding the Company’s computer programs. Any of the Company’s computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of the Company. The AMBE+2 TM voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc.This voice coding technology is licensed solely for use within this product. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code or in any other way convert the Object Code into a human readable form. U.S. Patent No: #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. Disclaimer The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of us. We do not guarantee, for any particular purpose, the accuracy, validity, timeliness, legitimacy or completeness of the Third Party products and contents involved in this manual. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera.com. RF Radiation Information RF Radiation Profile Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are transmitted. RF technology is widely used in communication, medicine, food processing and other fields. It may generate radiation during use. RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: z United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; z American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; z Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999; z International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998. Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures when in PTT mode and transmit should no more than 100% of time when in repeater mode. FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. Operational Instructions and Training Guidelines To ensure the optimal performance and the compliance…

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. FCC ID: YAMRD96XVHF DATE: Nov 28, 2012 To whom it may concern: We the undersigned, hereby authorize Shenzhen Huatongwei International Inspection Co., Ltd to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Shenzhen Huatongwei International Inspection Co., Ltd on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Hytera Communications Corporation Ltd. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Hytera Communications Corporation Ltd. Frequency Attestation Letter DATE: Nov 28, 2012 FCC ID: YAMRD96XVHF Model: RD962 VHF,RD965 VHF,RD966 VHF,RD968 VHF Dear Sir/Madam, We, Hytera Communications Corporation Ltd. acknowledge that this device can only use the allowed frequency band from 136 MHz to 174 MHz for USA. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Justification Letter DATE: Nov 28, 2012 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMRD96XVHF Model: RD962 VHF,RD965 VHF,RD966 VHF,RD968 VHF Dear Sir/Madam, We , Hytera Communications Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communications Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Hytera Communications Corporation Ltd. FCC ID: YAMRD96XVHF DATE: Nov 28, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAMRD96XVHF to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Tune-Up Procedure 5． Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Product Similarity Declaration FCC ID: YAMRD96XVHF DATE: Nov 28, 2012 To Whom It May Concern, We, Hytera Communication Corporation Ltd., hereby declare that our (Digital Portable Repeater) Model Number: RD965 VHF, RD966 VHF and RD968 VHF are electrically identical with the Model RD962 VHF. RD965 VHF,RD966 VHF and RD968 VHF are named differently due to marketing purposes Please contact me if you have any question. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Link to Federal Communications Commission Home Page FCC Home | Search | RSS | Updates | E-Filing | Initiatives | Consumers | Find People Office of Engineering and Technology Office of Engineering and Technology Inquiry on 06/20/2013 : Inquiry: FYI this inquiry is inserted by FCC staff, for response tracking purposes. We will review this matter, maybe also will need to consult with FCC WTB staff, and will respond as soon as possible, but this consideration might take until early in week of June 24. Also some or all of this corresp. might also need to be inserted into the EA (or TC, TBD) record. From: wenliang lee [mailto:[email protected]] Sent: Thursday, June 20, 2013 5:20 AM To: Tim Harrington Cc: [email protected] ; [email protected]; [email protected]; [email protected] Subject: Re:FCC review for FCC ID:YAMRD96XVHF < GetApplicationAttachment[1].pdf > Dear Mr Tim: Good morning, I receive your comments of FCC ID:YAMRD96XVHF, but I find a question want to inquire for you that, I find the product (FCC ID:YAMRD96XVHF and FCC ID:YAMRD96XU1) was not belongs to fcc part 90 signal boosters; please see more information as follows: 1. The product in "repeater mode" as which accept a singal from others and transmit to others; but not meet signal boosters requirement; for example: if the product receive the receiver signal was -10dBm and maximum gain was 30dBm, so the repeater transmit maximum power should be -10+30=20dBm, which the product transmit the maximum power more than 20dBm, also the product transmit power was control by owner power amplifer and same as PTT mode; 2.The repeater mode was receive a signal to active the product to transmit, if without receiver signal, which can not transmit any signal in repeater mode, so I think this product should be belongs to "base station" instead of "repeater"; 3.I think signal boosters was a only amplifer and will not affect the amplifer signal, while the product accpet signal and transmit according its protocol and will change the signal character if orignal signal was not using protocol same as the product; This is my summary some technical of the product, so I think the product should not belong to part 90 signal boosters and should be as base stations, but I am not sure, please tell me the correct judge? Thank you very much and have a nice day! Thanks! Best Regards! Sincerely Page 1 of 4 2013-8-1file://C:\Documents and Settings\0111\Local Settings\Temporary Internet Files\unknow ... wenliang Li SHENZHEN HUATONGWEI INTERNATIONAL INSPECTIONAL CO.?LTD. Huatongwei Building, Kejinan 12 Road, High-tec Industrial Park , Nsnshan District , Shenzhen City, Guangdong Province, P.R.China E-mail: [email protected] Tel: +86-755-26715335 Mobil: 13530396306 Fax: +86-755-26748005 Web Site: http://www.szhtw.com.cn ——Integrated Lab of CCIC group ——EMC Lab of Shenzhen CIQ Industrial Product Testing Center EMC Full testing / Safety Testing /Medical Device Testing /Machinery Product Testing/ Environment Testing IT/AV/Appliance/Luminaire Global Certification /Toys Tesging / RF Product testing RoHS,REACH Testing One stop service, professional and high efficiency/Provide CCC CE FCC R&TTE ETL UL GS CB PSE VCCI ect global certification service ********* Internet E-mail Confidentiality Disclaimer ********** This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy or rely upon this message or attachment in any way. If you received this e-mail message in error, please return by forwarding the message and its attachments to the sender. ***************************************************************** FCC response on 06/27/2013 FYI we have been reviewing this matter, as well as the FCC-13-21 and other rules and FCC proceedings. Whereas this device MIGHT not be subject to 90.219 as established by FCC-13-21, we still need more info to make a determination. A) The 6/19/13 corresp. in EA 478338 included: “Please provide operational description / scenarios about "PTT mode" and "Repeat mode" operations; including is repeat mode for same frequency or if translated then what/how, etc.” Unless it is in exhibits already (where?) please explain/show how user switches between PTT and repeat modes. B) We might still need to confirm with our colleagues at FCC WTB, but it appears FCC-13-21 provisions are not intended to override 90.247. From 90.7: “Mobile repeater station. A mobile station authorized to retransmit automatically on a mobile service frequency, communications to or from hand-carried transmitters.” In FCC practice, mobile repeaters are intended for use under station class MO3 in Form-601; as we understand such repeater operation requires automatic retransmission by this device on a frequency different from that received the portable/handheld station or other mobile station. See e.g. (http://transition.fcc.gov/pshs/docs -best/imel-wireless03.pdf) “The repeater makes use of two frequencies. The repeater radio functions as an amplified relay station receiving high- or low-power base stations, low-level mobile, and handheld radio signals, changing their frequency, amplifying the signals, and re-transmitting them on the repeater output frequency.” Page 2 of 4 2013-8-1file://C:\Documents and Settings\0111\Local Settings\Temporary Internet Files\unknow ... Attachment Details: See also e.g. (http://wireless.fcc.gov/reports/documents/whtepapr.pdf ). Acceptable compliance supporting information for 90.247 provisions will need to be submitted and reviewed by FCC. C) Unless suitable supporting information can be established per the preceding items, otherwise the 90.219 definition as booster would apply and the items in the EA filing corresp. would need to be addressed for application processing to continue. “a part 90 signal booster is a device or system that automatically receives, amplifies, and retransmits signals from wireless stations into and out o…

Text truncated - open the document above for the full version.

Dear Sir: I am sorry for delay response as I am waiting for KDB inquire 486416,which tells me can deal with the case,could you please help me deal with the case,Thank you very much! Thanks! Best Regards! Wenliang Li

Dear Sir: We used network analysis test out of band rejection,and test Filter freq. response plots.we provided Filter freq. response plots.

FCC Label FCC RF Warning Label

Report No.: RXA1209-0859SAR01R3 Page 1 of 76 TESTING No. L2264 OET 65 TEST REPORT Product Name Digital Portable Repeater Model RD962 VHF/RD965 VHF/RD966 VHF/RD968 VHF FCC ID YAMRD96XVHF Client Hytera Communications Co.,Ltd. TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1209-0859SAR01R3 Page 2 of 76 GENERAL SUMMARY Product Name Digital Portable Repeater Model RD962 VHF/RD965 VHF/RD966 VHF/RD968 VHF FCC ID YAMRD96XVHF Report No. RXA1209-0859SAR01R3 Client Hytera Communications Co.,Ltd. Manufacturer Hytera Communications Co.,Ltd. Reference Standard(s) FCC 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438 June 19, 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01 SAR Measurement Requirements for 100 MHz to 6 GHz KDB 447498 D01 Mobile Portable RF Exposure v05: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 643646 D01 SAR Test for PTT Radios v01r01: SAR Test Reduction Considerations for Occupational PTT Radios Tracking Number 593788 Tracking Number 868998 Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards for the tested bands only. General Judgment: Pass (Stamp) Date of issue: March 15 th , 2013 Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1209-0859SAR01R3 Page 3 of 76 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT................................................................................................................ 7 1.6. The Maximum Reported SAR 1g ............................................................................................ 8 1.7. Test Date .............................................................................................................................. 8 2. SAR Measurements System Configuration .................................................................................. 9 2.1. SAR Measurement Set-up .................................................................................................... 9 2.2. DASY5 E-field Probe System ............................................................................................. 10 2.2.1. ES3DV3 Probe Specification ....................................................................................... 10 2.2.2. E-field Probe Calibration .............................................................................................. 11 2.3. Other Test Equipment ......................................................................................................... 11 2.3.1. Device Holder for Transmitters .................................................................................... 11 2.3.2. Phantom...................................................................................................................... 12 2.4. Scanning Procedure........................................................................................................... 12 2.5. Data Storage and Evaluation .............................................................................................. 14 2.5.1. Data Storage................................................................................................................ 14 2.5.2. Data Evaluation by SEMCAD ...................................................................................... 14 3. Laboratory Environment............................................................................................................. 16 4. Tissue-equivalent Liquid ............................................................................................................ 17 4.1. Tissue-equivalent Liquid Ingredients................................................................................... 17 4.2. Tissue-equivalent Liquid Properties .................................................................................... 18 5. System Check ............................................................................................................................ 19 5.1. Description of System Check .............................................................................................. 19 5.2. System Check Results ........................................................................................................ 20 6. Operational Conditions during Test ............................................................................................ 21 6.1. General Description of Test Procedures............................................................................. 21 6.2. Test Config…
