Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Preface Thank you for purchasing Hytera DMR Repeater. Combination of ergonomic design, versatile digital functions and remarkable quality would refresh your experience and enable you to be responsive to emergent situations. To derive optimum performancefrom your product, please read this manual and the supplied Safety Information Booklet carefully before use. The manual is applicable to the following model: RD98X 1 Instructional Icons The following icons are available through this manual: Caution:indicates situations that could cause damage to your product. Note:indicates tips that can help you make better use of your product. *: indicates functions available in later version. Copyright Information Hytera and HYT are trademarks or registered trademarks of Hytera Communications Co., Ltd. (“Hytera”) in PRC and/or other countries or areas. Hytera retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The Hytera product described in this manual may include Hytera computer programs stored in memory or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of Hytera with respect to its computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser regarding Hytera computer programs. Any Hytera computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of Hytera. The AMBE+2 TM voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding technology is licensed solely for use within this product. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code or in any other way convert the Object Code into a human 2 readable form. U.S.PatentNumbers:#6,912,495B2,#6,199,037B1,#5,870,405,#5,826,222,#5,754,974,#5,701,390, #5,715,365,#5,649,050,#5,630,011,#5,581,656,#5,517,511,#5,491,772,#5,247,579,#5,226,084and #5,195,166. Disclaimer Hytera endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of Hytera.If you have any suggestions or would like to learn mo redetails, please visit our website at: http://www.hytera.cn. RF Energy Exposure Compliance ● Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. ● The device complies with SAR and/or RF field strength limits of RSS-102 requirement and contact information where the user can obtain Canadian information on RF exposure and compliance. Your radio complies with the following of RF energy exposure standards and guidelines ● United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J ● American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 ● Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition ● International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 Operational Instructions and Training Guidelines ● To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no 3 more than 50% of the time and always adhere to the following procedures: ● Gain of antenna must not exceed 6.5dBi. ● Antenna Installation: Install the mobile antenna at least 350 cm away from your body, in accordance with the requirements of the antenna manufacturer/supplier. Transmit and Receive To transmit (talk), push the Push-To-Talk (PTT) key; to receive, release the PTT key. EU Regulatory Conformance The equipment is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. Note: The above information is applicable to EU countries only. FCC Licensing Information Part 15 Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced r…
Text truncated - open the document above for the full version.
Hytera Communications Corporation Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAMRD98XU2 to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. BOM The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]
Justification Letter DATE: March 29, 2011 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMRD98XU2 Model: RD982 U(2), RD985 U(2), RD986 U(2), RD988 U(2) Dear Sir/Madam, We , Hytera Communication Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communication Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]
Product Similarity Declaration To Whom It May Concern, We, Hytera Communication Corporation Ltd., hereby declare that our (Digital Base Station Repeater) Model Number: RD985 U(2), RD986 U(2), and RD988 U(2) are electrically identical with the Model RD982 U(2). RD985 U(2), RD986 U(2), RD988 U(2) are named differently due to marketing purposes Please contact me if you have any question. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected] .
External photos of the EUT
Label Label Location RF Warning Label RF Warning Label Location
Internal photos of the EUT
FCC PART 90 TEST REPORT FCC Part 90 Report Reference No......................: FCC ID..............................................: WE11030045 YAMRD98XU2 Compiled by ( position+printed name+signature)..: File administrators Eric Zhang Supervised by ( position+printed name+signature)..: Test Engineer Wenliang Li Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Apr 25, 2011 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Hytera Communications Corporation Ltd. Address ............................................: HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ...........................................: FCC Part 90: PRIVATE LAND TWO-WAY RADIO SERVICES TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Digital Base Station Repeater Trade Mark .......................................: Manufacturer ....................................: Hytera Communications Corporation Ltd. Model/Type reference.......................: RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) Listed Models ..................................: / Modulation ......................................... FM&4FSK Channel Separation........................... 12.5KHz Operation Frequency......................... From 450 MHz to 520 MHz Ratings .............................................: DC 13.60 V Rated Power ....................................: 5Watt(36.99dBm)-50Watt(46.99dBm) Continuous Result................................................: Positive V1.0 Page 2 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 T E S T R E P O R T Test Report No. : WE11030045 Apr 25, 2011 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Base Station Repeater Model /Type : RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 10: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 7 3. TEST ENVIRONMENT 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Configuration of Tested System 9 3.5. Discription of Tested Modes 9 3.6. Statement of the measurement uncertainty 9 3.7. Test Description 10 3.8. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test 12 4.2. Occupied Bandwidth and Emission Mask Test 18 4.3. Transmitter Radiated Spurious Emssion 38 4.4. Spurious Emssion on Antenna Port 43 4.5. Modulation Charcateristics 63 4.6. Frequency Stability Test 66 4.7. Maximum Transmitter Power 68 4.8. Transmitter Frequency Behavior 75 4.9. Receiver Radiated Spurious Emssion 78 4.10. Receiver Conducted Spurious Emssion 88 5. TEST SETUP PHOTOS OF THE EUT 95 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 99 V1.0 Page 4 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND TWO-WAY RADIO SERVICES. TIA/EIA 603: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. ANSI C63.4-2009 : American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. V1.0 Page 5 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Mar 28, 2011 Testing commenced on : Mar 28, 2011 Testing concluded on : Apr 25, 2011 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) or the “EUT” as referred to in this report;more general information as follows: Name of EUT Digital Base Station Repeater Model Number RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) FCC ID YAMRD98XU2 Rated Output Power 5Watt(36.99dBm)-50Watt(46.99dBm) Continuous Operation Type The repeater cannot operate on multi-channels Support data rate 9.6kbps FM for Analog Voice 4FSK for Digital Voice/Digital Data Analog 11K0F3E for 12.5KHz Channel Separation 7K60FXD for Digital Data only Modilation Type Digital 7K60FXW for Digital Data & Digital Voice Analog Voice 12.5KHz Channel Separation Digital Voice/Data 12.5KHz Antenna Type External Frequency Range From 450 MHz to 5…
Text truncated - open the document above for the full version.
V1.0 Page 78 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 4.9. Receiver Radiated Spurious Emssion TEST APPLICABLE The field strength is calculated by adding the Antenna Factor and Cable Factor and subtracting the Amplifier Gain and Duty Cycle Correction Factor(if any) from the measured reading. The basic equation with a sample calculation is as follows: FS = RA + AF + CL - AG Where FS = Field Strength CL = Cable Attenuation Factor (Cable Loss) RA = Reading Amplitude AG = Amplifier Gain AF = Antenna Factor TEST CONFIGURATION (A) Radiated Emission Test Set-Up, Frequency below 1000MHz (B) Radiated Emission Test Set-Up, Frequency above 1000MHz 1m to 4m Test Receiver EUT 3m 0.8m Turntable Coaxial Cable Ground Plane V1.0 Page 79 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 TEST PROCEDURE 1 The EUT was placed on a turn table which is 0.8m above ground plane. 2 Maximum procedure was performed by raising the receiving antenna from 1m to 4m and rotating the turn table from 0 to 360 to acquire the highest emissions from EUT°C°C 3 And also, each emission was to be maximized by changing the polarization of receiving antenna both horizontal and vertical. 4 Repeat above procedures until all frequency measurements have been completed. RECEIVER RADIATED SPOUIOUS LIMIT For unintentional device, according to § 15.109(a) and RSS-Gen, except for Class A digital devices, the field strength of radiated emissions from unintentional radiators at a distance of 3 meters shall not exceed the following values: Frequency (MHz) Distance (Meters) Radiated (dBμV/m) Radiated (μV/m) 30-88 3 40.0 100 88-216 3 43.5 150 216-960 3 46.0 200 Above 960 3 54.0 500 For intentional device, according to § 15.209(a), the general requirement of field strength of radiated emissions from intentional radiators at a distance of 3 meters shall not exceed the above table. TEST RESULTS The Radiated Measurement are performed to the three channels (the high channel, the middle channel and the low channel), the datum recorded below is the worst case for each channel separation;and the EUT shall be scanned from 30 MHz to the 5th harmonic of the highest oscillator frequency in the digital devices or 1 GHz whichever is higher. V1.0 Page 80 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 Maximum Radiated Emissions Modulation Type Channel Separation Test Frequency (MHz) Polar. Frequency (MHz) Datum (dBuV/m) FCC Limit (dBuV/m H 344.91 30.10 46.00 FM 12.5 KHz 450.5000 V 342.97 30.20 46.00 Test Results Compliance SWEEP TABLE: "test (30M-1G)" Short Description: Field Strength Start Stop Detector Meas. IF Transducer Frequency Frequency Time Bandw. 30.0 MHz 1.0 GHz MaxPeak Coupled 120 kHz HL562 2011 0 10 20 30 40 50 60 70 80 Level [dB 礦/m] 30M50M70M100M200M300M500M700M1G Frequency [Hz] x x x x x x x MES HTW04011421_red MES HTW04011421_pre LIM FCC ClassB F QP/AV FCC ClassB, field strength MEASUREMENT RESULT: "HTW04011421_red" 4/11/2011 9:53PM Frequency Level Transd Limit Margin Det. Height Azimuth Polarization MHz dBμV/m dB dBμV/m dB cm deg 30.000000 21.30 -10.2 40.0 18.7 Peak 300.0 254.00 HORIZONTAL 86.372745 11.20 -21.7 40.0 28.8 Peak 300.0 360.00 HORIZONTAL 123.306613 14.80 -18.4 43.5 28.7 Peak 300.0 23.00 HORIZONTAL 249.659319 26.90 -20.0 46.0 19.1 Peak 100.0 291.00 HORIZONTAL 344.909820 30.10 -16.9 46.0 15.9 Peak 100.0 278.00 HORIZONTAL 935.851703 29.70 -5.7 46.0 16.3 Peak 100.0 239.00 HORIZONTAL V1.0 Page 81 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 SWEEP TABLE: "test (30M-1G)" Short Description: Field Strength Start Stop Detector Meas. IF Transducer Frequency Frequency Time Bandw. 30.0 MHz 1.0 GHz MaxPeak Coupled 120 kHz HL562 2011 0 10 20 30 40 50 60 70 80 Level [dB 礦/m] 30M50M70M100M200M300M500M700M1G Frequency [Hz] x x x x x x x MES HTW04011422_red MES HTW04011422_pre LIM FCC ClassB F QP/AV FCC ClassB, field strength MEASUREMENT RESULT: "HTW04011422_red" 4/11/2011 9:57PM Frequency Level Transd Limit Margin Det. Height Azimuth Polarization MHz dBμV/m dB dBμV/m dB cm deg 30.000000 21.40 -10.2 40.0 18.6 Peak 300.0 45.00 HORIZONTAL 86.372745 11.80 -21.7 40.0 28.2 Peak 300.0 349.00 HORIZONTAL 117.474950 14.80 -18.5 43.5 28.7 Peak 100.0 46.00 HORIZONTAL 249.659319 27.20 -20.0 46.0 18.8 Peak 100.0 298.00 HORIZONTAL 342.965932 30.20 -17.0 46.0 15.8 Peak 100.0 275.00 HORIZONTAL 951.402806 29.70 -5.1 46.0 16.3 Peak 100.0 56.00 HORIZONTAL V1.0 Page 82 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 Maximum Radiated Emissions Modulation Type Channel Separation Test Frequency (MHz) Polar. Frequency (MHz) Datum (dBuV/m) FCC Limit (dBuV/m H 5829.66 45.90 54.00 FM 12.5 KHz 450.5000 V 5909.82 45.90 54.00 Test Results Compliance SWEEP TABLE: "test (1G-18G) P" Short Description: EN 55022 Field Strength Start Stop Detector Meas. IF Transducer Frequency Frequency Time Bandw. 1.0 GHz 18.0 GHz MaxPeak Coupled 1 MHz HF906 2011 Average 0 10 20 30 40 50 60 70 80 Level [dB 礦/m] 1G2G3G4G5G6G Frequency [Hz] x x x x x x x MES HTW04011430_red MES HTW04011430_pre LIM FCC ClassB F QP/AV FCC ClassB, field strength LIM FCC ClassB F QP-HF FCC ClassB, field strength MEASUREMENT RESULT: "HTW04011430_red" 4/12/2011 2:55PM Frequency Level Transd Limit Margin Det. Height Azimuth Polarization MHz dBμV/m dB dBμV/m dB cm deg 1260.521042 33.10 -7.6 54.0 20.9 Peak 100.0 65.00 HORIZONTAL 1791.583166 36.90 -3.1 54.0 17.1 Peak 100.0 84.00 HORIZONTAL 2432.865731 40.10 0.6 54.0 13.9 Peak 100.0 26.00 HORIZONTAL 3014.028056 44.30 2.1 54.0 9.7 Peak 100.0 148.00 HORIZONTAL 4096.192385 43.00 3.6 54.0 11.0 Peak 100.0 255.00 HORIZONTAL 5829.659319 45.90 7.1 54.0 8.1 Peak 100.0 302.00 HORIZONTAL V1.0 Page 83 of 118 Report No.: WE11030045 FCC ID: YAMRD98XU2 SWEEP TABLE: "test (1G-18G) P" Short Description: EN 55022 Field Strength Start Stop Detector Meas. IF Transducer Frequency Frequency Time Bandw. 1.0 GHz 18.0 GHz MaxPeak Coupled 1 MHz HF906 2011 Average 0 10 20 30 40 50 60 70 80 Level [dB 礦/m] 1G2G3G4G5G6G Frequency [Hz] + + + + + + x x x x x x x MES HTW04011431_red + MES HTW04011431_…
Text truncated - open the document above for the full version.
MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No....................... FCC ID .............................................: WE11030046 YAMRD98XU2 Compiled by ( position+printed name+signature)..: File administrators Eric Zhang Supervised by ( position+printed name+signature)..: Test Engineer Wenliang Li Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Apr 25, 2011 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Hytera Communications Corporation Ltd. Address.............................................: HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ...........................................: FCC Per 47 CFR 2.1091(b) OET Bulletin 65 Supplement C[June 2001] TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Digital Base Station Repeater Trade Mark .......................................: Manufacturer ....................................: Hytera Communications Corporation Ltd. Model/Type reference.......................: RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) Listed Models ..................................: / Channel Separation ........................... 12.5KHz Modulation ......................................... FM&4FSK Ratings..............................................: DC 13.60 V Frequency Range From 450 MHz to 520 MHz Rated Power ....................................: 5Watt(36.99dBm)-50Watt(46.99dBm) Continuous Result................................................: Positive V1.0 Page 2 of 8 Report No.: WE11030046 MPE T E S T R E P O R T FCC ID : YAMRD98XU2 Apr 25, 2011 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Base Station Repeater Model /Type : RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 8 Report No.: WE11030046 Contents 1. SUMMARY............................................................................. 4 1.1. EUT configuration 4 1.2. Product Description 4 1.3. Equipment under Test 4 1.4. Note 5 2. TEST ENVIRONMENT............................................................... 6 2.1. Address of the test laboratory 6 2.2. Environmental conditions 6 2.3. Statement of the measurement uncertainty 6 3. METHOD OF MEASUREMENT .................................................... 6 3.1. Applicable Standard 6 3.2. Limit 7 3.3. MPE Calculation Method 7 4. CONCLUSION ........................................................................ 8 V1.0 Page 4 of 8 Report No.: WE11030046 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ● Power Cable Length (m) : 3 Shield : Unshield Detachable : Detachable ○ Multimeter Manufacturer : / Model No. : / 1.2. Product Description The Hytera Communications Corporation Ltd.’s Model: RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) or the “EUT” as referred to in this report; more general information as follows: Name of EUT Digital Base Station Repeater Model Number RD982 U(2)/ RD985 U(2)/ RD986 U(2)/ RD988 U(2) FCC ID YAMRD98XU2 Rated Output Power 5Watt(36.99dBm)-50Watt(46.99dBm) Continuous Operation Type The repeater cannot operate on multi-channels Support data rate 9.6kbps FM for Analog Voice 4FSK for Digital Voice/Digital Data Analog 11K0F3E for 12.5KHz Channel Separation 7K60FXD for Digital Data only Modilation Type Digital 7K60FXW for Digital Data & Digital Voice Analog Voice 12.5KHz Channel Separation Digital Voice/Data 12.5KHz Antenna Type External Frequency Range From 450 MHz to 520 MHz Analog 50.00 W for 12.5 KHz Channel Separation Maximum Output Power Digital 50.35 W for 12.5 KHz Channel Separation Note: The product has the same digital working characters when operating in both two digitized voice/data mode (7K60FXD and 7K60FXW). So only one set of test results for digital modulation modes are provided in this test report. 1.3. Equipment under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 13.60 V V1.0 Page 5 of 8 Report No.: WE11030046 Test frequency list Modulation Type Test Channel Test Frequency Low Channel 450.5000 MHz Middle Channel 485.0000 MHz Analog/FM High Channel 519.5000 MHz Low Channel 450.5000 MHz Middle Channel 485.0000 MHz Digital/4FSK High Channel 519.5000 MHz 1.4. Note 1. The EUT is a U frequency band (450-520MHz) Digital Base Station Repeater, The functions of the EUT listed as below: Test Standards Reference Repo…
Text truncated - open the document above for the full version.
Test Setup Photos of the EUT
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 3 | 9 | 450 MHz - 520 MHz | 49.2 W | 7K60FXW | 1.2 ppm |
