YAMX1PU1Digital Portable Radio

Preface Thanks for your favor in our product. To derive optimum performance from the product, please read this manual and the supplied Safety Information Booklet carefully before use. This manual is applicable to the following model: X1p 1 Instructional Icons The following icons are available through this manual: Alert Icons Caution: indicates situations that could cause damage to your product. Note: indicates tips that can help you make better use of your product. Function Icons : indicates functions that are available on digital channel only. : indicates functions that are available on analog channel only. Functions marked with no function icons are available on both analog and digital channels. Term Explanation Key Operation Short press: to press a key and release it quickly. Long press: to press a key and remain holding it down for a predefined period (2 seconds by default). Hold down: to press a key and remain holding it down. Private Call Private Call is a call initiated by a single user to another user. Group Call Group Call is a call initiated by a single user to a group. All Call All Call is a call initiated by a single user to all the other users on a channel. Squelch This technology can remove excessive background noises, improving your communication quality. 2 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. The product described in this manual may include the Company’s computer programs stored in memory or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of the Company with respect to its computer programs. The purchase of this product shall not be deemed to grant, either directly or by implication, any rights to the purchaser regarding the Company’s computer programs. Any of the Company’s computer programs may not be copied, modified, distributed, decompiled, or reverse-engineered in any manner without the prior written consent of the Company. The AMBE+2 TM voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding technology is licensed solely for use within this product. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code or in any other way convert the Object Code into a human readable form. U.S. Patent Nos. #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. 3 Disclaimer The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of us. If you have any suggestions or would like to learn more details, please visit our website at: http://www.hytera.com . 4 RF Radiation Information The radio is not intended for use by general population in an uncontrolled environment. It is only for occupational use and only applied to work-related conditions. The radio must be only used by users, who are fully aware of the hazards of the exposure and who are able to exercise control over their RF exposure to qualify for the higher exposure limits. RF Radiation Profile Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are transmitted. RF technology is widely used in communication, medicine, food processing and other fields. It may generate radiation during use. RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: ¾ United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; ¾ American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; ¾ Institute of Electrical and Electronic Engineers (IEEE) C95. 1 – 1999; ¾ International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998; FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there 5 is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct. The interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. ● Connect the equi…

Text truncated - open the document above for the full version.

Hytera Communications Corporation Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Hytera Communications Corporation Ltd. would like the following documents regarding this submission for FCC ID: YAMX1PU1 to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Part List 5. Tune-Up Procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Hytera Communications Corporation Ltd. Frequency Attestation Letter DATE: Sep 29, 2012 FCC ID: YAMX1PU1 Model: X1p U(1) Dear Sir/Madam, We, Hytera Communications Corporation Ltd. acknowledge that this device can only use the allowed frequency band from 400 MHz to 406MHz and 406.1MHz to 470 MHz for USA. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

Justification Letter DATE: Sep 29, 2012 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: YAMX1PU1 Model: X1p U(1) Dear Sir/Madam, We , Hytera Communications Corporation Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Hytera Communications Corporation Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Hytera Communications Corporation Ltd. Xiong Lei/ Director of management dept Fax: +86 755 8613 7130 Tel: +86 755 2697 2999 E-mail:[email protected]

External photos of the EUT

FCC RF Warning Label

Internal photos of the EUT

Report No.: TRE12080112 Page 51 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 52 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 53 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 54 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 55 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 56 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 57 of 66 Issued:2012-09-27 6.3. DAE4 Calibration Ceriticate Report No.: TRE12080112 Page 58 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 59 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 60 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 61 of 66 Issued:2012-09-27 Report No.: TRE12080112 Page 62 of 66 Issued:2012-09-27 7. Test Setup Photos Report No.: TRE12080112 Page 63 of 66 Issued:2012-09-27 The EUT display towards phantom of battery 1# The EUT display towards Ground of battery 1# 2.5CM Report No.: TRE12080112 Page 64 of 66 Issued:2012-09-27 The EUT display towards Phantom of battery 1# The EUT display towards Ground of battery 2# Report No.: TRE12080112 Page 65 of 66 Issued:2012-09-27 8. EUT Photos Battery 1# Report No.: TRE12080112 Page 66 of 66 Issued:2012-09-27 Battery 2# Headset .....................End of Report.........................

TEST REPORT OET 65C Report Reference No. ..................... : TRE12080112 R/C:36566 Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Sep 27, 2012 Testing Laboratory Name .............. : CCIC Southern Electronic Product Testing(Shenzhen) Co.,Ltd. Address............................................. : Electronic Testing Building, Shahe Road, Xili Town, Shenzhen, P.R.China Representative Laboratory Name . : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Hytera Communications Corporation Ltd. Address............................................. : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ........................................... : OET 65C TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Digital Portable Radio Trade Mark ....................................... : Manufacturer .................................... : Hytera Communications Corporation Ltd. Model/Type reference ....................... : X1p U(1) Listed Models .................................. : / Ratings.............................................. : DC 7.4 V Modulation ....................................... : FM&4FSK Channel Separation ........................... 12.5KHz Operation Frequency Range ............. From 400 MHz to 470 MHz Result ................................................ : Positive Report No.: TRE12080112 Page 2 of 66 Issued:2012-09-27 T E S T R E P O R T Test Report No. : TRE12080112 Sep 27, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Portable Radio Model /Type : X1p U(1) Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE12080112 Page 3 of 66 Issued:2012-09-27 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. TEST Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. SAR Limits 7 3.5. Equipments Used during the Test 8 4. SAR MEASUREMENTS SYSTEM CONFIGURATION 9 4.1. SAR Measurement Set-up 9 4.2. DASY5 E-field Probe System 10 4.3. Phantoms 11 4.4. Device Holder 11 4.5. Scanning Procedure 12 4.6. Data Storage and Evaluation 13 4.7. Tissue Dielectric Parameters for Head and Body Phantoms 14 4.8. System Check 15 5. TEST CONDITIONS AND RESULTS 16 5.1. Conducted Power Results 16 5.2. Sar Measurement Results 17 5.3. Measurement Uncertainty 18 5.4. System Check Results 19 5.5. Sar Test Graph Results 20 6. CALIBRATION CERTIFICATE 37 6.1. Probe Calibration Ceriticate 37 6.2. D450V3 Dipole Calibration Ceriticate 48 6.3. DAE4 Calibration Ceriticate 57 7. TEST SETUP PHOTOS 62 8. EUT PHOTOS 65 Report No.: TRE12080112 Page 4 of 66 Issued:2012-09-27 1. TEST STANDARDS The tests were performed according to following standards: IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438 June 19, 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. KDB 447498 D01 Mobile Portable RF Exposure v04: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies Report No.: TRE12080112 Page 5 of 66 Issued:2012-09-27 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sep 10, 2012 Testing commenced on : Sep 10, 2012 Testing concluded on : Sep 27, 2012 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: X1p U(1) or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Digital Portable Radio Model Number X1p U(1) Rated Output Power 4 Watts(36.02dBm)/1 Watts(30.00dBm) Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digita…

Text truncated - open the document above for the full version.

FCC PART 90 TEST REPORT FCC Part 90 Report Reference No. ..................... : FCC ID. ............................................. : TRE1208011001 R/C: 88054 YAMX1PU1 Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Sep 17, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Hytera Communications Corporation Ltd. Address............................................. : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test specification: Standard ........................................... : FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Digital Portable Radio Trade Mark ....................................... : Manufacturer .................................... : Hytera Communications Corporation Ltd. Model/Type reference ....................... : X1p U(1) Listed Models .................................. : / Ratings.............................................. : DC 7.40 V Modulation ....................................... : FM&4FSK Channel Separation ........................... 12.5KHz Rated Power ..................................... 4 Watts(36.02dBm)/1 Watts(30.00dBm) Operation Frequency Range ............. From 400 MHz to 470 MHz Result ................................................ : Positive Report No.: TRE1208011001 Page 2 of 112 Issued:2012-09-17 FCC ID: YAMX1PU1 T E S T R E P O R T Test Report No. : TRE1208011001 Sep 17, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Portable Radio Model /Type : X1p U(1) Listed Models : / Applicant : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Manufacturer : Hytera Communications Corporation Ltd. Address : HYT Tower,Hi-Tech Industrial Park North,Nanshan District,Shenzhen China.518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1208011001 Page 3 of 112 Issued:2012-09-17 FCC ID: YAMX1PU1 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 7 2.10. Note 7 3. TEST ENVIRONMENT 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Configuration of Tested System 9 3.5. Discription of Tested Modes 9 3.6. Statement of the measurement uncertainty 9 3.7. Test Description 10 3.8. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test(Not applicable to this device) 12 4.2. Occupied Bandwidth and Emission Mask Test 14 4.3. Transmitter Radiated Spurious Emssion 32 4.4. Spurious Emssion on Antenna Port 39 4.5. Modulation Charcateristics 61 4.6. Frequency Stability Test 64 4.7. Maximum Transmitter Power 66 4.8. Transmitter Frequency Behavior 77 4.9. Receiver Radiated Spurious Emssion 80 4.10. Receiver Conducted Spurious Emssion 90 5. TEST SETUP PHOTOS OF THE EUT 101 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 105 Report No.: TRE1208011001 Page 4 of 112 Issued:2012-09-17 FCC ID: YAMX1PU1 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603 C: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS Report No.: TRE1208011001 Page 5 of 112 Issued:2012-09-17 FCC ID: YAMX1PU1 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Nov 10, 2011 Testing commenced on : Nov 10, 2011 Testing concluded on : Sep 17, 2012 2.2. Product Description The Hytera Communications Corporation Ltd.’s Model: X1p U(1) or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Digital Portable Radio Model Number X1p U(1) FCC ID YAMX1PU1 Rated Output Power 4 Watts(36.02dBm)/1 Watts(30.00dBm) Support data rate 9.6kbps Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog 11K0F3E for 12.5KHz Channel Separation Digital 7K60FXD for Digital Data only 7K60FXW for Digital Data & Digital Voice Channel Separation Analog Voice 12.5KHz Digital Voice/Data 12.5KHz Digital Data 12.5KHz Antenna Type External Frequency Range From 400 MHz to 470 MHz Maximum Transmitter Power Analog 4.38W for 12.5 K…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
